Code Cartographer

Code Cartographer

pi22by7

|
23 installs
| (1) | Free
Automatically generate comprehensive documentation of your codebase optimized for LLM context windows
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

Code Cartographer

Code Cartographer is a powerful VS Code extension that automatically generates comprehensive documentation of your codebase, optimized for providing context to Large Language Models (LLMs).

Features

  • Project Documentation: Generate detailed file structure and content documentation
  • Flexible Configuration: Use a dedicated configuration file to control what gets documented
  • Intelligent Filtering: Skip binary files, generated code, and large files automatically
  • Multiple Output Formats: Choose between JSON, TXT, and CSV outputs
  • Interactive Views: Preview generated documentation in a rich interactive view
  • Quick Project Analysis: Get a quick overview of your project's structure and file distribution
  • Enhanced Debugging: Comprehensive logging to help diagnose issues
  • Manual Selection Mode: Selectively choose files and directories to document with a hierarchical UI
  • Token Counting: Calculate and display token usage for LLM context windows
  • Format & Type Selection: Choose output format and documentation type directly in the UI

Why Use Code Cartographer with LLMs

Code Cartographer was designed with LLM workflows in mind:

  • Optimized Context: Generate documentation that fits within LLM context windows
  • Better Comprehension: Help LLMs understand your codebase structure and relationships
  • Efficient Interaction: Get more accurate code suggestions by providing complete project context
  • Focused Documentation: Include only the files and code that matter using flexible configuration
  • Token Awareness: Know exactly how many tokens your documentation will consume in an LLM

Getting Started

Installation

Install from the VS Code Marketplace or:

  1. Press Ctrl+P (or Cmd+P on Mac)
  2. Type ext install pi22by7.code-cartographer

Quick Start

  1. Right-click on a project folder in the explorer
  2. Select "Generate Documentation"
  3. Choose your output location
  4. View the generated documentation

Using Manual Selection Mode

For precise control over what gets documented:

  1. Press Ctrl+Shift+Alt+G (or Cmd+Shift+Alt+G on Mac)
  2. Use the hierarchical tree view to select specific files and folders
  3. Choose your preferred documentation type (Both, Structure Only, Content Only)
  4. Select your desired output format (JSON, TXT, CSV)
  5. Toggle whether to honor .gitignore and cartographer.config.json settings
  6. Click "Generate Documentation"

Using a Configuration File

For more control over what gets documented, create a configuration file:

  1. Right-click on a project folder in the explorer
  2. Select "Create Config File" to generate a cartographer.config.json file
  3. Customize the patterns for included and excluded files
  4. Run "Generate Documentation" to use your custom configuration

Configuration

Configuration File

The recommended way to configure Code Cartographer is with a cartographer.config.json file in your project root. This gives you precise control over what gets documented:

{
  "version": "1.0",
  "include": [
    "src/**/*",
    "*.json",
    "*.md"
  ],
  "exclude": [
    "**/*.min.js",
    "**/*.test.ts",
    "node_modules/**",
    ".git/**",
    "dist/**"
  ],
  "maxFileSize": 500000,
  "skipBinaryFiles": true,
  "skipGeneratedFiles": true,
  "customFiles": {
    "large-important-files": {
      "include": ["src/some-important-file.ts"],
      "maxSize": 2000000
    }
  },
  "documentation": {
    "type": "both",
    "format": "json",
    "outputPath": "./documentation.json"
  }
}

You can also configure the extension through the VS Code settings UI:

  1. Go to the Command Palette (Ctrl+Shift+P or Cmd+Shift+P on Mac)
  2. Type "Code Cartographer: Configure Settings"
  3. Use the form interface to adjust your configuration

Configuration Options

Option Description
include Glob patterns for files to include
exclude Glob patterns for files to exclude
maxFileSize Maximum file size in bytes to include
skipBinaryFiles Automatically skip binary files
skipGeneratedFiles Skip files that appear to be machine-generated
customFiles Special rules for specific files (overrides default settings)
documentation.type Type of documentation to generate (structure, documentation, or both)
documentation.format Output format (json, txt, or csv)
documentation.outputPath Path where to save documentation

Keyboard Shortcuts

  • Ctrl+Alt+G (or Cmd+Alt+G on Mac): Generate documentation using configuration files
  • Ctrl+Shift+Alt+G (or Cmd+Shift+Alt+G on Mac): Open manual file selection interface

Commands

Code Cartographer provides several commands available from the Command Palette (Ctrl+Shift+P or Cmd+Shift+P on Mac):

  • Generate Documentation: Creates comprehensive documentation for your project
  • Manual File Selection: Opens a hierarchical UI for selecting specific files to document
  • View Documentation: Opens an existing documentation file in the viewer
  • Configure Settings: Opens the configuration UI
  • Create Config File: Generates a default configuration file in your project root
  • Quick Analyze Project: Provides a fast overview of your project structure
  • Show Logs: Opens the extension logs for troubleshooting

Troubleshooting

If you encounter issues with Code Cartographer, here are some steps to try:

  1. Enable Debug Mode: Set codeCartographer.debugMode to true in your VS Code settings
  2. Check the Logs: Run the "Show Logs" command to view detailed diagnostic information
  3. Verify Configuration: Make sure your cartographer.config.json file or VS Code settings have the correct format and values
  4. Review Exclusions: If files are missing, check that they aren't being excluded by your configuration

Common problems and solutions:

  • No files documented: Check your include/exclude patterns and make sure they match your project structure
  • Large files skipped: Increase the maxFileSize value or use customFiles to allow specific large files
  • Crashes on large projects: Try documenting smaller parts of your project first, then increase scope
  • Output file not found: If using relative paths, make sure they're relative to your project root

Release Notes

See the CHANGELOG.md file for detailed release notes.
