Markdown Preview Markmap Support

Visualize Markdown as Mindmap (A.K.A Markmap) to VS Code's built-in markdown preview.

Demo 1

Features

Preview support to built-in markdown preview
Syntax highlighting support to markmap fenced code block
- See below a demo
Attributes support to markmap fenced code block
- See below details

Installation

To install this extension go to View->Extensions and search for markdown-markmap. Next click Install.

Usage

Create mindmap in markdown using markmap (or mdmm or mmmd) fenced code blocks:

```markmap
# Mindmap

## Extension

- [markdown-markmap](https://github.com/phoihos/vscode-markdown-markmap)

## Powered by

- <https://markmap.js.org/>
- [markmap-lib](https://github.com/gera2ld/markmap-lib)

## Highlighting

- links
- **inline** ~~text~~ *styles*
- multiline
  text
- `inline code`
-   ```js
    console.log('code block');
    ```
- Katex
  - $\pm\sqrt{a^2 + b^2}$
  - $x = {-b \pm \sqrt{b^2-4ac} \over 2a}$
  - $$\int_{0}^{\infty} f(x) dx$$
```

Syntax Highlighting

Syntax highlighting support exactly the same as VS Code's markdown.

Demo 2

Attributes

Add attributes to markmap fenced code block with {key1=value1 key2=value2} curly brackets:

Multiple attributes are separated by space.
Use single or double quotation marks when specifying value with spaces.

```markmap {scale=1.1 color=#888}
···
```

Available attributes:

Key	Default Value	Description
scale	`1.1`	Scale the preview render size
color	Empty (for Colorful)	Change the line color using predefined color name, or with RGB, HEX, HSL value

Available formats to attribute:

Format	Description
`{key1=value1 key2=value2}`	Wrap with curly brackets
`:key1=value1 key2=value2`	Start with colon mark
`?key1=value1 key2=value2`	Start with question mark

Markmap Visualizing

Settings

Currently, there is no settings.

Issues

If you find any problems using this extension or you want to propose new features to it, feel free to open an issue on Github.

Release Notes

Detailed Release Notes are available here or above Changelog tab.

Attributions

Icon made by Freepik from www.flaticon.com
