ChurnLens

ChurnLens helps you identify "hotspots" in your codebase by visualizing Code Churn directly in the IDE. Files that change frequently are highlighted with different colors in a custom "Churn Explorer" sidebar, allowing you to spot potential areas of instability, high churn or high maintenance at a glance. A companion Trend panel charts that churn over time.

Churn and Delta

ChurnLens uses two different measures of change. They answer different questions.

Delta is the net change. It is the lines added minus the lines deleted.

• +40 means the file grew by 40 lines.
• -40 means the file shrank by 40 lines.
• 0 means the file changed size by nothing at all.

Delta tells you the direction and the net size of the change.

Churn is the total movement. It is the lines added plus the lines deleted, always positive.

• 100 means 100 lines changed, in either direction.

Churn tells you how much change happened.

Why both? A file can lose 200 lines and gain 200 different lines. Its delta is 0, but it was almost completely rewritten. Delta says "no change". Churn says "400 lines of movement". Only churn warns you.

This is the core idea of the research behind ChurnLens: removing a lot of code is about as dangerous as adding a lot. A file that is rewritten is risky even when it does not grow, and delta cannot see that. Churn can.

That is why ChurnLens ranks risk by churn, not by delta. In the original study, churn predicted defects better than the number of change requests, the net delta, and the number of people involved. Read the full explanation in docs/churn-and-delta.md.

This extension is inspired by the research on Code Churn as a predictor of defects:

Code Churn: A Measure for Estimating the Impact of Code Change > J.C. Munson; S.G. Elbaum IEEE International Conference on Software Maintenance, 1998.

Features

• Churn Explorer: A dedicated sidebar exploring the churn of your project with a tree view.
• Trend view: A dedicated panel with charts — churn over time, added vs removed, cumulative churn, deletion ratio, and churn grouped by commit type.
• Churn and Delta: Switch the metric you are looking at. Churn measures total movement, delta measures net change.
• Gitignore-aware: Files matched by .gitignore are left out of the calculations, the tree, and the charts.
• Date range: Presets for the last 2, 3, 7 or 30 days, plus a custom start and end date.
• Baseline grouping: Group the trend by semver tags, merge commits or time buckets.
• Risk panel: The top files by churn, as proportional bars. Click one to open the file.
• Context Menu Integration: Right-click on any file in the Churn Explorer to view its Git history in GitHub.
• Light on resources: Git is read only while a ChurnLens view is open. The extension does not start at editor startup.

Trend View

Run the command ChurnLens: Open Trend (or the chart button in the Churn Explorer toolbar) to open the trend panel. It shares its state with the sidebar: selecting a file or folder in the tree filters the trend, and clearing the selection (or clicking the workspace root row) restores the whole range.

The panel shows:

• Delta vs Churn — grouped bars per period.
• Composition — added and removed lines, stacked.
• Cumulative churn — the running total across the range.
• Deletion ratio — removed divided by added, the rework signal.
• Churn by commit type — grouped by Conventional Commit type.
• Highest churn — the top paths by churn. Click a bar to open the file, or hover a row and click the x to ignore that path (see churnlens.ignoredPaths).

Charts use hand-rolled SVG. Both views follow the VS Code theme by default; the Theme picker in the trend header restyles the whole extension (tree and charts) with any bundled daisyUI theme. Data colours (added, removed, churn, delta) stay fixed so the charts read the same in every theme. Periods are grouped by the configured baseline: semver tags when present, otherwise merge commits, otherwise day/week/month buckets.

Configuration

You can configure ChurnLens via the built-in configuration page or standard VS Code settings.

Configuration Page

Run the command ChurnLens: Open Configuration to open the visual configuration editor. Here you can:

• Set the range preset or a custom start and end date.
• Edit the commit labels used for grouping.

Extension Settings

• churnlens.rangePreset: 2d, 3d, 7d, 30d or custom (default: 30d).
• churnlens.rangeStart: Custom range start date, YYYY-MM-DD.
• churnlens.rangeEnd: Custom range end date, YYYY-MM-DD.
• churnlens.commitLabels: Comma separated Conventional Commit labels (default: the Angular convention).
• churnlens.baseline: How the trend groups churn into periods. auto uses semver tags, then merge commits, then time buckets (default: auto).
• churnlens.ignoredPaths: Workspace-relative paths excluded from every churn calculation and the Churn Explorer tree (default: []). Add entries by hovering a row in the Trend panel's Highest churn card and clicking the x, or edit the array directly. A directory entry ignores everything under it. Discarding generated or vendored outliers this way keeps them from skewing the charts.
• churnlens.theme: daisyUI theme for the tree and trend views (default: vscode). vscode follows the editor theme; any bundled daisyUI theme (dark, dracula, nord, synthwave, …) restyles the panels and their corner radius. Data colours (added, removed, churn, delta) stay fixed so the charts read the same in every theme. The Theme picker in the trend header sets this too.

Color Customization

While the UI customization has been streamlined, you can still customize the 6 churn levels in your settings.json using workbench.colorCustomizations:

"workbench.colorCustomizations": {
    "churnlens.level1": "#90EE90", // Low Churn
    "churnlens.level2": "#ADFF2F",
    "churnlens.level3": "#FFD700",
    "churnlens.level4": "#FFA500",
    "churnlens.level5": "#FF4500",
    "churnlens.level6": "#FF0000"  // High Churn
}

Commands

• ChurnLens: Open Configuration: Opens the configuration webview.
• ChurnLens: Open Trend: Opens the trend panel with the churn charts.
• ChurnLens: Refresh Stats: Manually recalculates churn statistics and updates the Churn Explorer.
• See git history in github: (Context menu) Opens the file's history on GitHub.

Requirements

• The opened folder must be a Git repository.
• Git must be installed and available in your system PATH.

Development

Launch debugger in an extension dev host

• Install dependencies with pnpm
• Run launch task Run Extension. A new window will open. The terminal will keep a watch task running the code compilation on every change.
• Select a repository and open the extension in the sidebar.

Quick test without debugger

Run in the Terminal:

pnpm build && code --extensionDevelopmentPath="$PWD"

(You need to have code command in th $PATH.)

Publishing

Create a PAT in https://dev.azure.com/paulmelero/_usersSettings/tokens, then:

pnpm exec vsce verify-pat paulmelero --pat '<PAT>'
pnpm exec vsce publish --no-dependencies --pat '<PAT>'
