TOML Highlighting, Validation, Schema & Autocompletion for VS Code

Comprehensive syntax highlighting, TOML v1.0.0 syntax validation, JSON Schema based validation, and schema-aware autocompletion for TOML (Tom's Obvious, Minimal Language) files in Visual Studio Code.

TOML Highlighting TOML Validation Demo

This extension provides detailed syntax highlighting for all TOML v1.0.0 features, adds real-time TOML syntax validation, introduces JSON Schema based validation, and offers schema-driven autocompletion to make your configuration files easier to read, write, and debug.

Features

Full TOML v1.0.0 Syntax Highlighting: Covers all TOML data types and structures.
Real-time TOML Syntax Validation: Catches TOML syntax errors as you type, powered by @ltd/j-toml.
JSON Schema Validation:
- Validates TOML documents against specified JSON Schemas for structural and content correctness.
- Associate schemas via # $schema: comments or toml.schema.associations setting.
- Supports local and remote (HTTP/HTTPS) schemas.
- Includes schema caching and a "TOML Schemas" output channel for diagnostics.
JSON Schema-based Autocompletion (MVP):
- Suggests TOML keys based on properties in the associated schema.
- Provides autocompletion for enum values.
- Suggests true and false for boolean types.
- Displays schema description and type for completion items.
- Context-aware suggestions (initial implementation focuses on current table scope and key prefixes).
Comments, Operators, Structure: Clear highlighting and scoping.
Language Configuration: Bracket matching, auto-closing, commenting (#).
Customizable Colors: Via TextMate scopes in settings.json.

Installation

Open Visual Studio Code.
Go to the Extensions view (Ctrl+Shift+X or Cmd+Shift+X).
Search for TOML Highlighting ParisNeo.
Click Install.
Reload VS Code if prompted.

Alternatively, install via the command line:

code --install-extension ParisNeo.toml-hilighter

Usage

The extension automatically activates for .toml files.

Syntax Highlighting: Applied immediately.
Syntax Validation: Errors appear in the "Problems" panel.
Schema Validation: If a schema is associated (see below), violations are reported in "Problems".
Autocompletion: Triggered as you type or by pressing Ctrl+Space (or your configured keybinding). Suggestions for keys and values (enums, booleans) will appear if a schema is active and relevant.

Associating JSON Schemas

(This section remains the same as before, explaining $schema comment and toml.schema.associations)

You can associate a JSON schema with your TOML files in two ways:

In-file $schema comment (Recommended for project-specific schemas): Add a comment at the top of your TOML file:
```
# $schema: ./path/to/your/schema.json
# or
# $schema: https://example.com/remote/schema.json

title = "My TOML Configuration"
# ... rest of your TOML content
```
Relative paths are resolved against the location of the TOML file. This method takes precedence over settings-based associations.
VS Code Settings (toml.schema.associations): Configure associations in your settings.json (Ctrl+, or Cmd+,):
```
"toml.schema.associations": {
    "**/my-project-config.toml": "./schemas/project-specific.json",
    "**/another-pattern/*.toml": "https://json.schemastore.org/cargo",
    "/Users/me/global_configs/**/conf.toml": "/absolute/path/to/global_schema.json"
}
```
The key is a glob pattern that matches TOML file paths, and the value is the schema URI (local path relative to the workspace root, absolute path, or an HTTPS URL).

Schema Validation & Autocompletion Notes

Both schema validation and autocompletion require a successfully parsed TOML document (no syntax errors).
Validation Errors: For the initial implementation, schema validation errors are typically placed on the line of the # $schema comment or the first line of the document. The diagnostic message will contain the instancePath (TOML path) and the error message from ajv.
Autocompletion Context: The current autocompletion is an MVP. It primarily understands the current table context (e.g., keys within [table.name]) and simple key prefixes. More complex TOML structures for context detection (like inline tables or deeply nested keys defined non-sequentially) will be improved in future versions.
The "TOML Schemas" output channel (View > Output, then select "TOML Schemas" from the dropdown) provides logs related to schema loading, validation, and completion activity.

Configuration

This extension offers the following settings (accessible via settings.json):

toml.schema.enableValidation (boolean, default: true): Enable or disable JSON Schema validation for TOML files.
toml.schema.enableCompletions (boolean, default: true): Enable or disable JSON Schema-based autocompletion for TOML files.
toml.schema.associations (object, default: {}): Associate TOML files matching glob patterns with JSON Schemas. Example: { "**/mypackage.toml": "./schemas/mypackage.schema.json" }
toml.schema.cache.maxSize (integer, default: 20): Maximum number of compiled schemas to keep in the cache. Set to 0 to disable caching (not recommended for remote schemas).

Customization (Highlighting)

(This section remains the same as before)

You can customize the syntax highlighting colors by targeting the TextMate scopes used in this extension within your VS Code settings.json. The default customizations provide examples:

"editor.tokenColorCustomizations": {
    "[toml]": { // Apply only to TOML files
        "textMateRules": [
            {
                "name": "TOML Sections (User Override)",
                "scope": [
                    "entity.name.section.table.toml",
                    "entity.name.section.array.table.toml",
                    "punctuation.definition.table.begin.toml",
                    "punctuation.definition.table.end.toml",
                    "punctuation.definition.table.array.begin.toml",
                    "punctuation.definition.table.array.end.toml",
                    "entity.name.section.key.quoted.toml"
                 ],
                "settings": {
                    "foreground": "#C586C0"
                }
            },
            {
                "name": "TOML Keys (User Override)",
                "scope": [
                   "variable.other.key.toml"
                ],
                "settings": {
                   "foreground": "#9CDCFE"
                }
            }
        ]
    }
}

Refer to the syntaxes/toml.tmLanguage.json file for a full list of scopes.

Dependencies

@ltd/j-toml: For parsing and validating TOML syntax.
ajv: For JSON Schema validation.
ajv-formats: For additional format validation in Ajv.

These dependencies are bundled with the extension.

Contributing

Contributions, issues, and feature requests are welcome! Please check the repository issues page.

License

This extension is licensed under the MIT License.

Enjoy clearer, more correct, well-structured, and intelligently completed TOML files!

TOML Syntax Highlighting, Validation, Schema & Autocompletion

ParisNeo
