ProtoGraph

ProtoGraph

Preview

Papaltine

|
4 installs
| (0) | Free
ProtoGraph Language Support
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

ProtoGraph

This extenstion provides basic support for programming in ProtoGraph within VSCode.

Features

  • Syntax highlighting
  • Auto-complete and on-hover tooltip for ProtoFlux nodes
  • Auto-indentation
  • Code folding

Requirements/Install

  • Download the protograph .vsix package from the releases page
  • In VSCode, go to the extensions page and in the options select the 'Install from VSIX...' option in the menu and select the downloaded vsix protograph package
  • Follow the general setup instructions in the primary README to get .NET 9 installed to be able to compile ProtoGraph into Resonite records using the command line

Build Task

A build task can be configured with the flux-sdk to enable compiler messages to show up in the problems pane and display squiggles/popups in the code viewer. Use the following task as a template that you can customize to your own needs:

{
    // See https://go.microsoft.com/fwlink/?LinkId=733558
    // for the documentation about the tasks.json format
    "version": "2.0.0",
    "tasks": [
        {
            "label": "Compile ProtoGraph - Watch",
            "type": "shell",
            "isBackground": true, // set to false if not using --watch
            "command": "flux-sdk",
            "args": [
                "build",
                "-L",
                "/path/to/your/steam/steamapps/common/Resonite/Resonite_Data/Managed/", // path to Resonite DLLs
                "-d",
                "${workspaceFolder}", // ProtoGraph project directory
                "--watch", // will recompile on file change. Remove to manually start task (maybe as a build task)
                "--stop-after-resolve", // stop after resolution. Do all the parsing and type checking, but don't format and create output. Remove to generate the .brson file
                "--compact-error-messages", // IMPORTANT: makes error messages readable by the problemMatcher below
                "${workspaceFolder}/CSV/ParseTable.pg" // The file to compile
            ],
            "presentation": {
                "echo": true,
                "reveal": "always",
                "focus": false,
                "panel": "dedicated",
                "showReuseMessage": true,
                "clear": true
            },
            "problemMatcher": {
                "owner": "protograph",
                "fileLocation": [
                    "relative",
                    "${workspaceFolder}"
                ],
                "pattern": {
                    "regexp": "^(error|warning|info) at (.*)\\((\\d+):(\\d+) to (\\d+):(\\d+)\\): (.*)$",
                    "severity": 1,
                    "file": 2,
                    "line": 3,
                    "column": 4,
                    "endLine": 5,
                    "endColumn": 6,
                    "message": 7
                },
                "background": { // remove if not using --watch
                    "activeOnStart": true,
                    "beginsPattern": "Change detected. Recompiling...",
                    "endsPattern": "Waiting for file change..."
                }
            }
        }
    ]
}

Known Issues

There is currently no pre-configured build/run tasks, so the compiler has to be installed and run separatly.
