Obsidian VFS

Browse, search, and edit your Obsidian vault directly in VS Code via a virtual file system (obs://). Mount vault folders into the Explorer sidebar, navigate [[wikilinks]], and open notes in Obsidian — all without leaving your editor.

Features

• Mount vault folders or individual notes into the Explorer tree view
• Browse and read Markdown files through the obs:// virtual file system
• Edit existing files with writes going directly to the vault on disk
• Link navigation, click [[wikilinks]] or [text](obs://...) links in Markdown to jump between notes
• Search notes via Quick Pick across all vault Markdown files
• Open in Obsidian, jump to the current file in the Obsidian app
• Copy path as obs:// URI to the clipboard (Shift+Alt+Cmd+C on obs:// files)
• Move into Vault — move files from your project into mounted vault folders
• Duplicate into Vault — duplicate files from your project into mounted vault folders
• Auto-mount configured folders on startup
• Status bar showing vault name and connection mode (full / degraded)
• Workspace folder, vault browsable in Explorer with Quick Open (Cmd+P) and Search (Ctrl+Shift+F) support
• Workspace file, generate a named .code-workspace to avoid the "Untitled Workspace" label
• File watching, changes in the vault are reflected in real time

Commands

Available via the Command Palette (Cmd+Shift+P / Ctrl+Shift+P):

Settings

Configure via Settings UI or settings.json:

Global

Vault

Controls vault-side files.exclude policy written to <vault>/.vscode/settings.json.

Status Bar

Explorer

Workspace

All toggle settings take effect immediately — no reload required.

Workspace Folder

When obsidianVFS.workspace.enabled is true and at least one autoMount entry is configured, the extension adds a single file:// workspace folder at the vault root (named obs://<vault> in the sidebar). VS Code's Quick Open (Cmd+P) and Search (Ctrl+Shift+F) discover vault files through this folder.

The Explorer tree view (the obs:// custom sidebar panel) only shows entries in autoMount. The workspace folder shows everything unless hidden by files.exclude — the extension writes patterns to match the tree view's visibility.

Non-autoMount vault content (.obsidian/, .trash/, and any directories not in autoMount) is hidden from Explorer and Quick Open via files.exclude patterns managed by the extension. Your own files.exclude patterns are never modified or removed.

Requirements:

• At least one local folder must be open — the vault workspace folder is appended to the list to avoid triggering an extension host restart.
• At least one autoMount entry must be configured — the workspace folder is not added when autoMount is empty.

How it works:

• The extension scans the vault root and adds files.exclude patterns for entries not in autoMount. Patterns are split into two tiers: vault-global patterns (dotfiles and blocked paths) are written to <vault>/.vscode/settings.json — controlled by vault.excludeDotfiles, vault.excludeDotfilePattern, and vault.excludeBlocked; remaining non-autoMount directories and file extension globs are written to workspace settings — controlled by workspace.excludeUnmountedFolders, workspace.excludeUnmountedFiles, and workspace.excludeUnmountedFilePattern. All managed patterns are tracked internally for cleanup.
• When autoMount entries or any vault.*/workspace.* toggle changes, patterns are re-synced automatically — stale patterns are removed and new ones added.
• When new dotfiles or directories are added to the vault outside VS Code, run Obsidian VFS: Reload Vault to manually refresh patterns and the tree view.
• When obsidianVFS.workspace.enabled is disabled, all managed patterns are removed and the workspace folder is deleted.
• The vault's .git repository is automatically added to git.ignoredRepositories (user-level setting) when vault.gitIgnore is true and a workspace folder is active, preventing VS Code's Git extension from listing it in Source Control. The entry is removed when vault.gitIgnore is disabled or the workspace folder is removed.

Sub-path mounting: When autoMount contains nested paths (e.g., ["areas/projects"]), only the mounted sub-directory is visible. Sibling directories under the same parent are hidden:

autoMount: ["areas/projects"]

Vault structure:           File explorer visibility:
areas/                     areas/
  projects/                  projects/    ← visible (mounted)
  personal/                (personal/ hidden)
  work/                    (work/ hidden)

This matches the tree view — only mounted paths appear in both views.

Known limitations:

• Vault .vscode/ directory: The extension creates .vscode/settings.json inside the vault for vault-global files.exclude patterns (dotfiles and blocked paths). These patterns are independent of autoMount and apply to any workspace that includes the vault. The .vscode/ directory itself is never managed by the extension — if you want to hide it, add .vscode to your own files.exclude. When obsidianVFS.workspace.enabled is disabled, all managed patterns are removed from both folder and workspace settings. If your vault is git-tracked, consider adding .vscode/ to the vault's .gitignore.
• Not a security boundary: files.exclude hides content from Explorer and Quick Open but does not enforce access restrictions. The obs:// FileSystemProvider's path security (allowed/blocked lists in .obsidian-vfs.json) applies to tree view, wikilink, and drag-and-drop operations.
• Write protection covers obs:// only: vault.mode ("ro" / "partial") guards write operations through the obs:// FileSystemProvider — tree view sidebar, drag-and-drop into the tree, and obs:// editor saves. The file:// workspace folder (Explorer panel, Quick Open, Search) bypasses the provider and remains writable regardless of vault mode. This gap closes when VS Code stabilizes FileSearchProvider/TextSearchProvider, allowing a single obs:// workspace folder.
• Temporary workaround: files.exclude is used because VS Code's FileSearchProvider/TextSearchProvider APIs are still proposed (unstable). When stabilized, the extension can switch to a single obs:// workspace folder with native search, eliminating the files.exclude patterns entirely.
• Title bar: Adding the vault as a workspace folder creates a multi-root workspace. VS Code may show "UNTITLED (WORKSPACE)" in the title bar.

Notes:

• The Explorer tree view and the workspace folder both appear in the sidebar. The tree view provides custom UI (welcome view, context menus, drag-and-drop), while the workspace folder enables Quick Open and full-text search.
• The obs:// FileSystemProvider remains registered for the tree view sidebar, link navigation, and drag-and-drop — it does not back a workspace folder.

Workspace File (avoiding "Untitled Workspace")

When obsidianVFS.workspace.enabled adds the vault folder dynamically, VS Code transitions to a multi-root workspace. Because no .code-workspace file is involved, the title bar shows "UNTITLED (WORKSPACE)" — this is standard VS Code behavior for unsaved multi-root workspaces.

Enable obsidianVFS.workspace.codeWorkspaceFile to fix this. The extension generates a <project-name>.code-workspace file in your project root (e.g., my-app.code-workspace) and prompts you to open it.

What happens when you enable it:

1. The extension creates <project-name>.code-workspace in your project root containing the local folder(s) and the file:// vault folder entry (named obs://<VaultName>).
2. A notification asks: "Open workspace file? This will reload the window."
3. If you click Open, the window reloads once. After that, the title bar shows the project name and the vault is part of the saved workspace.
4. On subsequent activations, the extension detects you're already in a saved workspace and skips the prompt. Vault-global files.exclude patterns (dotfiles and blocked paths) are written to <vault>/.vscode/settings.json; workspace-specific patterns (non-autoMount directories) are written to workspace settings (routed to the .code-workspace file when one is active, or to the project's .vscode/settings.json otherwise).
5. If you click Not Now, the extension falls back to adding the vault dynamically via updateWorkspaceFolders (with files.exclude patterns in the vault's .vscode/settings.json). You can open the generated workspace file later.

UX trade-offs:

• One-time window reload — opening the workspace file causes VS Code to reload the window. This only happens once; after that the workspace file is saved and reloads are not needed.
• File on disk — a .code-workspace file is created in your project root. You can commit it to version control (so teammates get the same workspace layout) or add it to .gitignore.
• No overwrite — if a .code-workspace file already exists (e.g., from a previous run or your own), the extension will not overwrite it. It offers to open the existing file instead.
• files.exclude containment — vault-global patterns (dotfiles and blocked paths) are scoped to the vault workspace folder, preventing vault dotfiles (.git, .obsidian) from hiding same-named entries in your project. Workspace-specific patterns (non-autoMount directories like 00-inbox, 40-log) use workspace settings and are unlikely to collide with project entries.

When to use each setting:

Related Tools

This VSCode extension provides file-system access and UI integration for Obsidian vaults. If you use Claude Code, the companion @obsidian-vfs/claude-plugin enables Claude to read and search your vault via @obs: mentions and automatically resolves wikilinks in agent definitions and skills.

Prerequisites

• Obsidian installed with a vault open
• The obsidian CLI on your PATH (or set obsidianVFS.cliPath)

Installation

From VSIX

code --install-extension obsidian-vfs.vsix

Or via the Extensions sidebar: ··· menu > Install from VSIX...

From Source

git clone https://github.com/otaviof/obsidian-vfs.git

cd obsidian-vfs
pnpm install
pnpm package:vscode

code --install-extension packages/vscode/obsidian-vfs.vsix

Reload the window after installing (Developer: Reload Window).
