OpenCraw for VS Code

Starts the OpenCraw Studio server and opens it in your normal browser. From the editor you can send a folder, a recipe file or a document to Studio with Open on OpenCraw.

Issue #228. The server side it relies on is choose-folder (#234, the Browse button) and open-path (#235).

Use

• OpenCraw: Open Studio (command palette): Studio on the workspace folder.
• Open on OpenCraw (right-click a file or folder in the explorer, the editor, or an editor tab):
  • a folder opens as the workspace;
  • a recipe file (.json with kind input or output) opens through its folder with the recipe selected;
  • any other file the engine reads (PDF, spreadsheet, deck, Word, CSV, JSON, YAML, XML, Markdown) starts a recipe from it, the same as dropping the file on Studio. A file inside the workspace folder is read in place; one from outside is copied into the workspace folder.

The server starts on first use, in a process of its own, and stops with the window. In a remote window (SSH, WSL, Codespaces, dev containers) it runs where the workspace is and its port is forwarded to the browser on your machine.

How it fits together

editor (extension host)            Studio process                       browser
  open-on-opencraw  ── link? ──▶   studio-host.process.mjs
  (use case)        ◀─ url ─────   startStudioServer({initialFolder})
        │ openExternal(asExternalUri(url))                              Studio UI
        └──────────────────────────────────────────────────────────▶   /?token=…&folder=…&open=…

• src/open-target: which workspace folder holds the picked path (pure).
• src/studio-host: forks the Studio process and asks it for links over IPC. The process is the editor's own executable run as plain Node (ELECTRON_RUN_AS_NODE), so the extension ships no Node.
• src/open-on-opencraw: the command's outcome, the only place that touches the editor API.
• src/extension.ts: the entry point the editor requires.

The folder dialog is the server's own (choose-folder), so the Browse… button in the browser works the same as everywhere else; in a remote window the dialog opens on the remote machine, which has no display, and the message says to type the folder instead.

Develop

npm run vscode:build        # builds dist/extension.cjs and dist/studio-host.process.mjs
npm run vscode:qa           # lint + unit tests

npm run vscode:package builds apps/vscode-extension/opencraw-<version>-<platform>-<arch>.vsix, for the platform it runs on (the engine's PDF reader is a native module): it stages the extension with its production dependencies from tarballs of the workspace packages, starts the staged Studio process once to prove the dependencies are complete, then runs a pinned vsce. Install it with code --install-extension <the .vsix>.

Try it in an Extension Development Host, after npm run studio:build and npm run vscode:build so @opencraw/studio, the Studio UI and the extension exist:

code --extensionDevelopmentPath apps/vscode-extension <a folder of recipes>

Hooks

opencraw.hooksFile (user settings only) names an absolute path to a hooks or plugins module, the same file opencraw studio --hooks takes. Studio then runs recipes with those hooks, and the hooks bar names them. The module runs as your code.

The setting is machine-scoped on purpose: a workspace's .vscode/settings.json cannot set it, so opening a repository can never make Studio load code that repository chose. Changing the setting restarts the server on the next "Open on OpenCraw".

Publishing

The workflow vscode-publish (Actions > Run workflow) packages the extension on Linux, Windows and macOS and publishes the three .vsix files to the Visual Studio Marketplace and to Open VSX. It runs when a change to the extension, or to a package bundled in it, lands on main, and publishes only if version in this package.json is not on the Marketplace yet: raise it in the change that should reach users, and a merge with the same version does nothing. It can also be started by hand. The project has no release tag.

Before the first run:

1. Create the publisher on the Marketplace (https://marketplace.visualstudio.com/manage) and put its id in publisher in this package.json (it is opencraw as a placeholder).
2. Let the workflow sign in to the Marketplace with Microsoft Entra, not a token (Azure DevOps PATs are retired on 2026-12-01): register an application in Entra ID, add a GitHub Actions federated credential for this repository with entity type Branch and branch main, add the application as a member of the publisher on the Marketplace manage page, and set the repository secrets AZURE_CLIENT_ID and AZURE_TENANT_ID. The Marketplace job only runs from main.
3. For Open VSX: create the namespace with the same name (npx ovsx create-namespace <name> -p <token>) and add the token as the secret OVSX_PAT.
4. Raise version in this package.json: a registry refuses a version it already has.

Open VSX is skipped when OVSX_PAT is not set.

End-to-end test

npm run vscode:e2e stages the extension as the editor loads it, starts a real VS Code (1.90.0, the oldest the extension supports; downloaded into .vscode-test on the first run) and runs e2e/suite/index.cjs in its extension host: the commands exist, "Open on OpenCraw" resolves a link to a real Studio process, the page is served, open-path answers, and the opencraw.hooksFile setting reaches the server. The browser the link is handed to is not looked at. In CI it runs on a virtual display (vscode-e2e).

Not done yet

• Publishing has not been run: it needs the publisher, the Entra application and OVSX_PAT.
• Reusing an open Studio tab: a page cannot be raised from outside the browser, so each "Open on OpenCraw" opens a new tab, as other tools do.
