One Key Vault UI

Azure Key Vault explorer extension for VS Code with inline secret editing capabilities.

Features

• 🔐 Connect to Azure Key Vaults - Add and manage multiple Key Vaults
• 📋 Browse and list secrets - View all secrets in a vault
• 🔍 Search and filter secrets - Find secrets quickly
• 📊 Pagination and sorting - Navigate through secrets with sorting options
• ✏️ Inline secret editing - Edit secret values directly
• 🗑️ Delete secrets - Remove secrets from the vault
• 👁️ Toggle secret visibility - Reveal/hide secret values for security
• 📤 Bulk import secrets - Upload a JSON file to create multiple secrets at once
• 📥 Bulk export secrets - Select multiple secrets and download them as a JSON file

Usage

Adding a Key Vault

1. Click the cloud icon in the Activity Bar (left sidebar) to open the Azure Key Vault explorer
2. Click the "+ Add Key Vault" button in the tree view
3. Enter your Key Vault URL in the format: https://<vault-name>.vault.azure.net/
4. Enter a friendly name for the vault
5. Click Enter to confirm

Example:

• URL: https://myvault.vault.azure.net/
• Name: Production Vault

Viewing Secrets

1. Click on a Key Vault in the tree view to open the secrets editor
2. The secrets will be displayed in a table with:
   • Name: Secret name
   • Value: Secret value (masked by default)
   • Status: Enabled/Disabled badge
   • Updated: Last update timestamp
   • Actions: Edit and Delete buttons

Searching Secrets

1. In the secrets view, type in the search box to filter secrets by name
2. Search is real-time and case-insensitive

Sorting Secrets

1. Click on column headers to sort:
   • Name: Alphabetical order
   • Created: By creation date
   • Updated: By modification date
2. Click again to reverse sort direction (ascending/descending)

Revealing Secret Values

1. Click the eye icon (👁️) next to a secret to reveal its value
2. Click again to hide the value
3. Values are masked by default for security

Editing Secrets

1. Click the Edit button next to a secret
2. Enter the new value in the prompt dialog
3. Click OK to confirm
4. The secret will be updated in the Key Vault

Deleting Secrets

1. Click the Delete button next to a secret
2. Confirm the deletion in the prompt
3. The secret will be permanently removed from the Key Vault

Pagination

• Secrets are displayed 10 per page by default
• Use the Previous and Next buttons to navigate
• The page indicator shows current page and total secret count

Downloading / Exporting Secrets

1. In the secrets view, check the checkbox next to each secret you want to export
2. Use the Select All checkbox in the table header to select all secrets on the current page
3. A selection bar appears showing how many secrets are selected
4. Click the "Download Selected" button in the toolbar
5. Choose a save location in the file dialog — the file is saved as a .json file
6. The exported file uses the same flat JSON format accepted by the Upload JSON feature

Example exported file:

{
  "db-connection-string": "Server=myserver.database.windows.net;...",
  "api-key-openai": "sk-proj-abc123...",
  "jwt-signing-secret": "my-super-secret-key"
}

Note: Only secrets whose values have been revealed (by clicking the eye icon 👁️) will have their actual value in the export. Secrets that are still masked will export an empty string for that entry — reveal values first if you need them included.

Bulk Importing Secrets

1. In the secrets view, click the "Upload JSON" button in the toolbar
2. Select a .json file from your local machine
3. The file must be a flat JSON object with string key:value pairs — each key becomes the secret name and each value becomes the secret value
4. After upload, a summary shows how many secrets were created/updated and how many were skipped
5. The secrets list refreshes automatically

Example JSON file format:

{
  "db-connection-string": "Server=myserver.database.windows.net;...",
  "api-key-openai": "sk-proj-abc123...",
  "jwt-signing-secret": "my-super-secret-key"
}

Note: If a secret with the same name already exists it will be updated with the new value.

Removing a Key Vault

1. Right-click on a Key Vault in the tree view
2. Click Remove Key Vault
3. Confirm the removal
4. The vault will be removed from the extension (not from Azure)

Authentication

The first time you open a Key Vault in a session, the extension prompts you to choose an authentication method. This prompt appears once per VS Code session — subsequent vault opens skip the prompt until VS Code is restarted or credentials are cleared.

Option 1: Sign in with VS Code

Uses the Azure Account extension's active sign-in. Select this option if you are already signed in to Azure in VS Code.

Requirements: Azure Account extension installed and signed in.

Option 2: Sign in with Azure CLI

Opens a terminal and runs az login for you. Complete the browser sign-in, then click Continue in the dialog to proceed.

Requirements: Azure CLI installed and available on your PATH.

# Verify Azure CLI is installed
az --version

# Manually sign in (the extension will do this for you)
az login

Option 3: Use a Service Principal

Prompts for Tenant ID, Client ID, and Client Secret. Suitable for automated or non-interactive environments.

• Tenant ID and Client ID are stored in VS Code secret storage between sessions
• Client Secret is held in memory only and never persisted — you will be prompted for it each time a new session starts

Create and grant a service principal with Azure CLI:

# 1) Create service principal (save appId, password, tenant from output)
az ad sp create-for-rbac --name "<your-keyvault-name>" --skip-assignment

# 2) Set variables from step 1 output + your vault name
APP_ID="<appId>"
TENANT_ID="<tenant>"
CLIENT_SECRET="<password>"
VAULT_NAME="<your-keyvault-name>"

# 3) Resolve SP object ID and Key Vault scope
SP_OBJECT_ID=$(az ad sp show --id "$APP_ID" --query id -o tsv)
SCOPE=$(az keyvault show --name "$VAULT_NAME" --query id -o tsv)

# 4) Assign least-privilege role for secrets operations
az role assignment create \
   --assignee-object-id "$SP_OBJECT_ID" \
   --assignee-principal-type ServicePrincipal \
   --role "Key Vault Secrets Officer" \
   --scope "$SCOPE"

Use these values in the extension prompts:

• Tenant ID: $TENANT_ID
• Client ID: $APP_ID
• Client Secret: $CLIENT_SECRET

Managing Stored Credentials

Each vault in the tree view has two credential management buttons:

Clearing or editing credentials also resets the session authentication, so the login prompt will appear on the next vault open.

Permissions Required

Your Azure account needs the following permissions on the Key Vault:

• Microsoft.KeyVault/vaults/read - List vaults
• Microsoft.KeyVault/vaults/secrets/read - View secrets
• Microsoft.KeyVault/vaults/secrets/write - Edit secrets
• Microsoft.KeyVault/vaults/secrets/delete - Delete secrets

These are typically available with the "Key Vault Administrator" or "Key Vault Secrets Officer" roles.

Security Notes

⚠️ Important Security Considerations:

• Secret values are masked by default and only shown when you explicitly click the eye icon
• Never share secret values via screenshots, logs, or messages
• Ensure proper RBAC permissions on your Key Vault
• The extension caches secrets in memory for the current session
• Clear browser data periodically to remove any cached values
• Use Strong authentication (MFA recommended)

Keyboard Shortcuts

• F5 (in development) - Reload extension
• Ctrl+Shift+P - Open Command Palette
  • Search for "Key Vault" to see all available commands
• Ctrl+K Ctrl+0 - Focus on Explorer
• Ctrl+Shift+X - Open Extensions

Troubleshooting

Extension doesn't appear in VS Code

• Make sure the .vsix file was properly installed
• Reload VS Code (Ctrl+R)
• Check Extensions panel to see if it's installed and enabled

Login prompt or "Authentication required" error

• The extension will show a login prompt — choose your preferred method (VS Code, Azure CLI, or Service Principal)
• For Azure CLI option: make sure az is installed and run az login manually to verify it works
• For VS Code option: install and sign in with the Azure Account extension
• If a session expires mid-use, the extension will re-prompt automatically

Can't access Key Vault

• Verify the vault URL format: https://<vault-name>.vault.azure.net/
• Check that your Azure account has access to the vault
• Verify firewall/network rules aren't blocking access

Secrets not loading

• Check the Output panel (View → Output) for error messages
• Select "Extension Host" from the dropdown
• Verify your Azure credentials are valid

Slow performance

• Check your internet connection
• The extension fetches all secrets when opening a vault
• Large vaults may take longer to load

Tips & Tricks

1. Add frequently used vaults to quickly switch between them
2. Use meaningful names for vaults to easily identify them
3. Sort by "Updated" to quickly find recently modified secrets
4. Use search to find secrets without scrolling through pagination
5. Refresh using the button in the title bar if you make changes outside the extension

Known Limitations

• Currently supports Azure Key Vault's Secrets only (not Keys or Certificates)
• Maximum 10 secrets per page (configurable in future versions)
• Real-time sync not yet implemented - refresh manually if changes are made outside the extension

Future Enhancements

Planned features for future versions:

• [ ] Support for Azure Key Vault Keys and Certificates
• [ ] Bulk delete / edit multiple secrets
• [ ] Real-time secret sync across sessions
• [ ] Secret versioning and history
• [ ] Custom field mapping and tagging
• [x] Export/Import functionality — select and download secrets as JSON
• [ ] Scheduled secret rotation alerts
• [ ] Integration with GitHub Secrets

License

MIT License - see LICENSE file for details

Support

For issues, bugs, or feature requests, please open an issue on GitHub.
