QueryCanvas - AI-Powered Database Client

A Cursor-integrated database client extension for VS Code. Supports MySQL/PostgreSQL with AI-powered schema documentation and query management features designed for seamless integration with Cursor AI.

Features

🤖 Cursor AI Integration ⭐

• Edit SQL via AI: Cursor can modify .vscode/querycanvas-session.json to update SQL in real-time
• Automatic sync: File watcher detects changes and updates UI immediately
• AI-powered query generation: Ask Cursor to write SQL with display options
• Smart formatting: Cursor knows the display options syntax and can apply it
• One-click setup 🆕: "📝 Cursor AI設定" button adds QueryCanvas rules to .cursorrules

🗄️ Database Connection

• Multiple Connections: Manage connections for development, staging, production environments
• MySQL Support: Supports MySQL 5.7+, 8.0+
• PostgreSQL Support: Supports PostgreSQL 12+
• Secure Authentication: Passwords securely stored in VS Code Secret Storage

📊 SQL Query Execution

• Intuitive UI: SQL input area and result display table
• Performance Measurement: Monitor query performance
• Error Handling: Clear error messages
• 🔒 Read-Only Mode: Only SELECT, SHOW, DESC, EXPLAIN queries allowed (prevents accidental data modification)
• ✨ SQL Formatter: One-click SQL formatting for better readability
• 🎨 Display Options: Customize result display via SQL comments (alignment, number format, datetime format, colors)
• 🎯 Conditional Styling 🆕: Dynamic cell styling based on values (e.g., negative numbers in red, values over threshold in bold)
• 📈 Graph Visualization 🆕: Interactive charts (line, bar, pie, area, scatter) using Chart.js
• 📋 Clipboard Copy 🆕: Copy results as TSV or HTML (paste directly into PowerPoint/Excel/Word)

📋 Automated Schema Documentation ⭐

• Automatically extract table structures
• Generate documentation in Markdown format (querycanvas-schema/tables/)
• Add logical names and descriptions with Cursor AI
• Preserves your additions during re-extraction
• Auto-extracts foreign keys and indexes

💾 Query Result Saving ⭐

• Export in TSV/JSON format
• Manage with names and comments (querycanvas-results/)
• Automatically records metadata (SQL, timestamp, row count)
• Analyze saved data with Cursor AI

💾 Saved Query Library ⭐

• Save frequently-used queries with names
• Categorize and search with tags
• Cache query results
• Instant display next time (no database connection needed)

🔄 Session Persistence ⭐

• Auto-save SQL input
• Continue work even after closing panel
• Cursor can edit session file
• Real-time SQL sync (Cursor ↔ UI)

🌍 Multilingual Support

• English (Default)
• Japanese
• Automatically adapts to VS Code language settings

Screenshot

Database Client Panel

┌─────────────────────────────────────────┐
│ Connection: [Dev DB ▼] Status: ●Connected│
│ [⚙️ Manage] [📋 Schema] [💾 Saved]       │
├─────────────────────────────────────────┤
│ SQL Input Area                          │
│ SELECT * FROM users;                    │
│                                         │
│ [Execute ▶]  [Clear]  [💾 Save Result]  │
├─────────────────────────────────────────┤
│ Result Table                            │
│ ┌────┬────────┬─────────┐              │
│ │ id │ name   │ email   │              │
│ ├────┼────────┼─────────┤              │
│ │ 1  │ Alice  │ a@ex.com│              │
│ │ 2  │ Bob    │ b@ex.com│              │
│ └────┴────────┴─────────┘              │
│                                         │
│ Execution time: 0.123s | Rows: 2        │
└─────────────────────────────────────────┘

Usage

1. Open Database Client

1. Open Command Palette (Cmd+Shift+P / Ctrl+Shift+P)
2. Type "Database Client: Open" and execute
3. Database client panel will open

2. Connect to Database

1. Click "⚙️ Manage Connections" button
2. Click "+ Add New Connection"
3. Enter connection information and save
4. Select connection from dropdown
5. Click "Connect" button

3. Execute SQL Query

1. Enter query in SQL input area
2. Click "▶ Execute" button
3. Results will be displayed in the table

Tip: Use display options for better presentation:

/**
 * @column amount type=int align=right format=number comma=true if<0:color=red if>1000:bold=true
 * @column created_at format=datetime pattern=yyyy/MM/dd_HH:mm
 */
SELECT amount, created_at FROM orders LIMIT 10;

3.5. Copy Results to PowerPoint/Excel 📋

After executing a query, you can copy the results to clipboard:

1. TSV Copy: Click "📋 TSVコピー" button

   • Simple tab-separated format
   • Works everywhere (PowerPoint, Excel, Word)
   • No styling preserved

2. HTML Copy: Click "📋 HTMLコピー" button

   • Rich HTML format with styles
   • Colors, bold, number formatting preserved
   • Conditional styling (red for negative, etc.) preserved
   • Paste directly into PowerPoint/Excel/Word

Example workflow:

/**
 * @column 売上 type=int align=right format=number comma=true if<0:color=red
 * @column 達成率 type=float if>=100:color=green,bold=true
 */
SELECT 店舗名, 売上, 達成率 FROM sales LIMIT 10;

→ Execute → HTMLコピー → Paste in PowerPoint → Beautiful table with colors!

See PowerPoint Copy Guide for details.

4. Save Query Results

1. After executing a query, click "💾 Save Result" button
2. Enter name, comment, and format (TSV/JSON)
3. Click "💾 Save" to save to querycanvas-results/
4. Manage past results via metadata file

5. Extract Schema

1. Connect to database
2. Click "📋 Extract Schema" button
3. All table definitions are saved to querycanvas-schema/tables/ in Markdown format
4. Add logical names and descriptions with Cursor AI
5. Your additions are preserved during re-extraction

6. Use with Cursor AI (Advanced) 🤖

You can use Cursor AI to edit SQL queries directly:

Quick Setup (Recommended)

1. Open Database Client
2. Click "📝 Cursor AI設定" button
3. Done! QueryCanvas rules are added to .cursorrules

Or use Command Palette:

Cmd+Shift+P → "QueryCanvas: Setup Cursor AI Rules"

Manual Usage

1. Open Database Client and connect to database
2. Session file is created at .vscode/querycanvas-session.json
3. In Cursor Chat, ask:

   @Codebase Edit the SQL in querycanvas-session.json to select top 10 orders with amount > 1000,
   and add display options to format the amount with commas


4. Cursor AI modifies the session file
5. Changes appear in Database Client UI immediately
6. Click Execute to run the query

Example prompts:

• "Add a WHERE clause to the current SQL query"
• "Format the price column with 2 decimal places"
• "Add datetime formatting to the created_at column"
• "Rewrite this query to join with users table"

Implementation Status

✅ Completed

• Basic Webview panel
• Database connection layer (MySQL/PostgreSQL)
• Interface-based design
• SSL connection support
• Connection profile management (add, edit, delete)
• Password management (Secret Storage)
• Actual query execution
• Schema extraction & Markdown documentation generation
• Query result saving (TSV/JSON + metadata)
• Session persistence (auto-save, file watching)
• Saved query library (with caching)
• Internationalization (English/Japanese)

📋 Future Plans

• Query history
• Auto-complete (table/column names)
• ER diagram generation
• Dataset diff view

Advanced Features

📈 Graph Visualization

Visualize query results with interactive charts. Use the @chart directive in SQL comments:

/**
 * @chart type=line x=日付 y=小村井店,京成小岩店 title="店舗別売上推移"
 * @row 曜日=="土":bg=#eeeeff
 * @row 曜日=="日":bg=#ffeeee
 * @column 小村井店 type=int align=right format=number comma=true color="#FF0000"
 * @column 京成小岩店 type=int align=right format=number comma=true color="#008800"
 */
SELECT
  DATE_FORMAT(YMD_CREATED, '%Y/%m/%d') AS '日付',
  CASE DAYOFWEEK(YMD_CREATED)
    WHEN 1 THEN '日' WHEN 2 THEN '月' WHEN 3 THEN '火'
    WHEN 4 THEN '水' WHEN 5 THEN '木' WHEN 6 THEN '金' WHEN 7 THEN '土'
  END AS '曜日',
  SUM(CASE WHEN SHOP_NAME = '小村井店' THEN 1 ELSE 0 END) AS '小村井店',
  SUM(CASE WHEN SHOP_NAME = '京成小岩店' THEN 1 ELSE 0 END) AS '京成小岩店'
FROM sales_data
WHERE YMD_CREATED LIKE '202508%'
GROUP BY YMD_CREATED
ORDER BY YMD_CREATED;

Supported chart types:

• line: Line chart (time-series, trends)
• bar: Bar chart (category comparison)
• pie: Pie chart (proportions)
• area: Area chart (cumulative data)
• scatter: Scatter plot (correlations)

View Toggle: When @chart is specified, 📊 テーブル and 📈 グラフ buttons appear, allowing you to switch between table and chart views.

Documentation: See docs/CHART-VISUALIZATION-GUIDE.md for complete guide.

Development

Setup

1. Install dependencies:

npm install

2. Compile TypeScript:

npm run compile

Or use watch mode for automatic compilation:

npm run watch

Debug and Run

1. Open this project in VS Code/Cursor
2. Press F5 (or "Run" → "Start Debugging")
3. A new window (Extension Development Host) will open
4. Open Command Palette (Cmd+Shift+P / Ctrl+Shift+P)
5. Type "Database Client: Open" and execute

Project Structure

querycanvas/
├── src/
│   ├── extension.ts                    # Extension entry point
│   ├── databaseClientPanel.ts          # Webview UI management
│   ├── schemaDocumentGenerator.ts      # Schema document generation
│   ├── queryResultSaver.ts             # Query result saving
│   ├── sessionStateManager.ts          # Session persistence
│   ├── savedQueryManager.ts            # Saved query library
│   ├── i18nManager.ts                  # Internationalization
│   ├── i18n/                           # Translation files
│   │   ├── en.json                     # English
│   │   └── ja.json                     # Japanese
│   └── database/                       # Database connection layer
│       ├── types.ts                    # Type definitions
│       ├── mysqlConnection.ts          # MySQL implementation
│       ├── postgresqlConnection.ts     # PostgreSQL implementation
│       ├── connectionFactory.ts        # Connection factory
│       ├── connectionProfileManager.ts # Profile management
│       └── index.ts
├── docs/                               # Documentation
│   ├── conversations/                  # Development history
│   └── specifications/                 # Specifications
├── querycanvas-schema/                 # Table definitions (auto-generated)
│   └── tables/                         # Markdown per table
├── querycanvas-results/                # Saved query results
│   └── metadata.json                   # Query result metadata
├── out/                                # Compiled JavaScript
├── .vscode/
│   ├── launch.json                     # Debug configuration
│   ├── tasks.json                      # Build task configuration
│   ├── querycanvas-connections.json    # Connection profiles (gitignored)
│   ├── querycanvas-session.json        # Session state (gitignored)
│   └── querycanvas-queries.json        # Saved queries (gitignored)
├── package.json                        # Extension manifest
├── tsconfig.json                       # TypeScript configuration
├── TESTING.md                          # Testing instructions
└── README.md                           # This file

Technology Stack

• TypeScript 5.3+: Type-safe development
• VS Code Extension API: Extension foundation
• mysql2: MySQL Node.js client (Promise-based)
• pg: PostgreSQL Node.js client
• Webview: Custom UI implementation
• Chart.js 4.4.1: Interactive chart visualization 🆕

Architecture

Design Patterns

• Strategy Pattern: Switch implementations based on database type
• Factory Pattern: Generate connection instances
• Interface Segregation: Unified common interface

Security

• Passwords stored in VS Code Secret Storage
• Parameterized queries to prevent SQL injection
• SSL connection support
• Read-Only Mode: Prevents accidental data modification (INSERT, UPDATE, DELETE, ALTER, TRUNCATE are blocked)

Documentation

• TESTING.md - Testing and debugging procedures
• Specifications - Feature specifications and architecture
• Conversation History - Development process

Customization

Adding a New Database Type

1. Add new type to src/database/types.ts
2. Create a new class implementing the IDBConnection interface
3. Add new case to ConnectionFactory

See Database Connection Layer Specification for details.

References

• VS Code Extension API
• Extension Guides
• mysql2 Documentation
• node-postgres Documentation

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

License

MIT License - see the LICENSE file for details.

Author

okuyamashin

• GitHub: @okuyamashin
• Repository: querycanvas

Repository

https://github.com/okuyamashin/querycanvas
