OGS Inspect

Language support, navigation, completion, and diagnostics for OpenGeoSys project files, powered by Rust-based ogs-inspect.

OGS Inspect is under active development. APIs, diagnostics, and behavior may change between releases.

Highlights

Context-aware completions and diagnostics

OGS Inspect completion

OGS documentation on hover

Hover documentation

Navigate to definitions

Go to definition

Rename across declared includes

Getting Started

Install the extension.
Open an OpenGeoSys .prj file.
Select the target OGS version with OGS Inspect: Select OGS Version, if needed.
Diagnostics, navigation, hover, references, and completion are provided automatically.

If OGS Inspect does not activate, make sure the file is opened in VS Code's XML language mode.

Features

Diagnostics for OpenGeoSys project files
Go to definition
Find references
Rename symbols
Schema and symbol information on hover
Support for OpenGeoSys includes
Document symbols / Outline view
Context-aware completion for project structure, configuration values, and references
Searchable, version-specific OpenGeoSys documentation

Diagnostics

OGS Inspect performs static analysis without running OpenGeoSys. The bundled language server uses ogs-inspect to parse project files, validate their structure against metadata for the selected OGS version, resolve references across includes, and provide editor diagnostics and navigation.

Where schema metadata is available, structural diagnostics identify unexpected, missing, or duplicate elements and attributes, as well as invalid cardinality and dependency constraints.

Suppressing diagnostics

A lint rule can be suppressed using an XML comment:

To suppress a rule for the following XML element:
```

```

To suppress a rule for the entire file:

<!-- ogs-inspect-disable-file OGS001 -->

To disable ogs-inspect entirely for a file:
```

```

Symbol-aware navigation is available for supported OGS elements:

Go to definition
Find references
Rename symbols
Hover information

Navigation works across supported OpenGeoSys include files.

Completion

OGS Inspect provides context-aware completion for OpenGeoSys elements, supported configuration values, and symbol references. Structural suggestions follow the schema for the selected OGS version and include snippets for required attributes and child elements, along with valid values for configuration selector elements, where available.

Completion support is still expanding and does not yet cover every configuration context.

Documentation

Hovering over a recognized element or attribute shows available schema details such as its type, whether it is required or repeatable, its default value, and a link to the corresponding OpenGeoSys documentation.

Use OGS Inspect: Open OGS Documentation to search the documentation available for the selected OGS version and open a page in your browser.

Document symbols

The Outline view exposes selected elements of the project structure.

Document-symbol support is currently incomplete.

OGS Version

OGS Inspect can analyze projects using metadata for different OpenGeoSys versions:

master - latest development metadata
stable - latest supported stable release
6.5.9 - OpenGeoSys 6.5.9
6.5.8 - OpenGeoSys 6.5.8

The active version can be changed using OGS Inspect: Select OGS Version or the OGSInspect.OGSVersion setting.

Diagnostics, completion, and structural information use metadata for the selected version.

For development against the latest OpenGeoSys sources, use master. For projects targeting a released OGS version, select the matching version, such as 6.5.9.

Project Files and Includes

OGS Inspect treats a .prj file and its referenced .include files as a single project.

Definitions and references can therefore be resolved across file boundaries. Changes to included files automatically trigger re-analysis of dependent project files. An include reused in multiple locations is analyzed in each of its structural contexts.

Supported files

OGS project files must be opened in VS Code's XML language mode.

.prj - OpenGeoSys project files
.include - included project fragments

Requirements

The language server is bundled with the extension.

Separate installation for ogs-inspect or OGS is not required.

Known Limitations

Not all OGS configuration elements are understood yet.
Completion does not yet cover every OGS configuration context.
Document symbols cover only part of the project structure.
Schema metadata and structural validation remain incomplete for some processes.
Support may differ between OGS versions.

Issues

Report issues on GitLab.
