SQLFluff Formatter

VS Code extension for formatting SQL files using sqlfluff.

Features

• Format SQL on Selection: Select text and format only the selected SQL
• Format Entire File: Format the entire SQL file if no selection is made
• Configurable: Support for global and local sqlfluff configuration
• Multiple Dialects: Support for various SQL dialects (ANSI, T-SQL, MySQL, PostgreSQL, Snowflake, BigQuery, etc.)
• Custom Rules: Override sqlfluff rules via VS Code settings
• Rule Exclusion: Exclude specific rules from formatting

Installation

1. Install the extension from VS Code marketplace
2. Ensure you have sqlfluff 1.0.0 or higher installed locally:

   # Install latest sqlfluff
   pip install --upgrade sqlfluff

   # Or install specific version
   pip install sqlfluff>=1.0.0

   # Verify installation
   sqlfluff --version


3. Configure Python path in VS Code settings if using custom Python installation

Configuration

Basic Settings

Add these settings to your VS Code settings.json:

{
  "sqlfluff.pythonPath": "python",
  "sqlfluff.sqlfluffPath": "sqlfluff"
}

How the Extension Resolves Execution

The extension tries three execution methods in priority order:

1. sqlfluffPath configured AND exists → Execute sqlfluff binary directly

   • Most reliable and fastest
   • Requires sqlfluff installed as standalone executable

2. Falls back if above fails → Execute python -m sqlfluff format via pythonPath

   • Good compatibility with Python virtual environments
   • Uses Python's module system to load sqlfluff
   • Requires pip install sqlfluff

3. Final fallback if both fail → Use Python API directly

   • from sqlfluff.core import Linter method
   • Most reliable option (works as long as Python and sqlfluff are installed)
   • Guarantees formatting will work

Recommendation: Set only pythonPath to your Python interpreter. The extension will automatically try all three methods and use whatever works on your system.

Configuration Options

• pythonPath: Path to Python interpreter (default: "python")

  • Example: /usr/bin/python3 or C:\\Python39\\python.exe
  • Used as fallback when sqlfluffPath is not available

• sqlfluffPath: Path to sqlfluff executable (default: "sqlfluff")

  • Example: /usr/local/bin/sqlfluff

• rules: Override specific sqlfluff rules

  • Example:

    {
      "sqlfluff.rules": {
        "L001": { "capitalisation_policy": "upper" },
        "L003": { "indent_size": 2 }
      }
    }


• excludeRules: Rules to exclude from formatting

  • Example: ["L009", "L027"]

Usage

Keyboard Shortcut

• Alt+Shift+F (Windows/Linux) or Option+Shift+F (macOS): Format SQL

Command Palette

1. Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (macOS)
2. Type "SQLFluff: Format SQL"
3. Press Enter

Selection-based Formatting

1. Select the SQL code you want to format
2. Use the keyboard shortcut or command

File-wide Formatting

1. Open a SQL file with no selection
2. Use the keyboard shortcut or command to format the entire file

Selecting the Right SQL Dialect

SQLFluff supports many SQL dialects. Choose the one that matches your database system:

Supported Dialects

Troubleshooting Parsing Errors

If you see "[1 templating/parsing errors found" messages:

1. Check your templater setting: By default, the extension uses Jinja2 templating

   • If your SQL doesn't use templates (dbt, Jinja, etc.), set templater = raw in your .sqlfluff
   • Example: templater = raw in workspace .sqlfluff file

2. Check your dialect: Ensure the .sqlfluff configuration matches your SQL database

   • Example: If using Snowflake syntax like INSERT OVERWRITE, set dialect to snowflake in ~/.sqlfluff
   • If using DECLARE (T-SQL), set dialect to tsql in ~/.sqlfluff

3. Try a different dialect: Some SQL features are only supported in specific dialects

   • If ANSI dialect fails, try postgresql or your actual database system

4. Update your .sqlfluff file: Set the correct dialect in your configuration:

   [sqlfluff]
   dialect = snowflake
   templater = raw


5. Use proper configuration location:

   • Workspace root .sqlfluff takes priority over home directory config
   • Home directory ~/.sqlfluff provides global defaults

Jinja2 Template Support

The extension can support Jinja2 templating, which is useful if you:

• Use dbt for data transformations
• Have SQL files with Jinja template variables (e.g., {{ variable_name }})
• Use template inheritance or macros in your SQL

By default, the extension uses raw templating (no template processing) for maximum compatibility.

Enabling Jinja2

To enable Jinja2 templating, add this to your .sqlfluff (workspace or home directory):

[sqlfluff]
templater = jinja

[sqlfluff:templater:jinja]
apply_dbt_macros = False

Using dbt Macros

If you're using dbt and want the formatter to understand dbt-specific syntax:

[sqlfluff]
templater = jinja

[sqlfluff:templater:jinja]
apply_dbt_macros = True

Note: This requires dbt to be installed in your Python environment.

Configuration Files

Global Configuration (~/.sqlfluff)

You can customize the formatter globally by creating a .sqlfluff file in your home directory. Example:

[sqlfluff]
dialect = postgresql      # Change to your default SQL dialect
indent_unit = space
indent_size = 2
max_line_length = 88

[sqlfluff:rules]
L001 = { "capitalisation_policy" : "upper" }  # UPPERCASE keywords
L002 = { "capitalisation_policy" : "upper" }  # UPPERCASE functions
L003 = { "indent_size" : 2 }                   # 2-space indentation

# Enable Jinja2 if you use dbt or template engines
# [sqlfluff]
# templater = jinja

This global configuration applies to all your SQL projects unless overridden by a workspace-specific .sqlfluff file.

Local Configuration (.sqlfluff in workspace)

Override the global settings for specific projects by creating a .sqlfluff in your workspace root:

[sqlfluff]
dialect = snowflake      # Change dialect for this project
templater = raw          # Or keep jinja if needed
indent_size = 4

[sqlfluff:rules]
L001 = { "capitalisation_policy" : "upper" }
L009 = { "select_clause_trailing_comma" : "forbid" }

VS Code Workspace Settings

Override rules for specific projects in .vscode/settings.json:

{
  "sqlfluff.pythonPath": "/usr/bin/python3",
  "sqlfluff.excludeRules": ["L009", "L027"],
  "sqlfluff.rules": {
    "L001": { "capitalisation_policy": "lower" }
  }
}

Configuration Priority

The extension resolves .sqlfluff configuration files in this order (highest to lowest priority):

1. Workspace config (.sqlfluff in workspace root)

   • Project-specific formatting rules
   • Use this to override settings for a specific project

2. Home directory config (~/.sqlfluff)

   • Your personal formatting preferences
   • Applies to all projects where workspace config doesn't exist

3. Extension default config (.sqlfluff.default bundled with extension)

   • Built-in fallback configuration
   • Ensures consistent formatting even without any custom config files
   • Uses ANSI SQL and raw templating (no templates) by default for maximum compatibility

4. sqlfluff internal defaults

   • Used only if all above configurations are missing

Quick Setup

Zero-config option: Just install the extension!

• The extension's built-in configuration provides sensible defaults for most SQL projects
• No Jinja2 templates by default - safe and compatible with any SQL

Customize for your environment: Create ~/.sqlfluff in your home directory

• Overrides the extension's defaults globally
• Applies to all your SQL projects

Project-specific rules: Create .sqlfluff in your workspace root

• Overrides both home directory and extension defaults
• Useful for team standards or specific project requirements
• Example: Enable Jinja2 for dbt projects

Example Workflows

Setup for PostgreSQL Project

1. Create .sqlfluff in your project root:

   [sqlfluff]
   dialect = postgresql
   indent_unit = space
   indent_size = 2


2. In .vscode/settings.json:

   {
     "sqlfluff.pythonPath": "/usr/bin/python3",
     "sqlfluff.excludeRules": ["L027"]
   }


3. Format your SQL with Alt+Shift+F

Setup for Multiple Dialects

Create separate .sqlfluff files in different workspace directories:

• Create .sqlfluff in your Snowflake project with dialect = snowflake
• Create .sqlfluff in your SQL Server project with dialect = tsql

Each project's .sqlfluff file will be used based on the workspace root.

Troubleshooting

"sqlfluff not found" Error

1. Ensure sqlfluff is installed:

   pip install sqlfluff


2. Set the correct pythonPath or sqlfluffPath in settings:

   • Windows: C:\\Python39\\python.exe
   • macOS/Linux: /usr/bin/python3

"Format error: Permission denied"

Make sure you have execute permissions:

chmod +x /path/to/sqlfluff

Configuration Not Applied

1. Check that .sqlfluff exists in workspace root or home directory
2. Verify the configuration file format (INI format, not JSON)
3. Check file permissions to ensure it's readable

Common Sqlfluff Rules

• L001: Inconsistent capitalisation of keywords
• L002: Inconsistent capitalisation of function names
• L003: Indentation not in multiples of indent_size
• L004: Indentation size is not a multiple of indent_unit
• L005: Indentation is in tabs rather than spaces
• L009: Files must end with a newline
• L010: Comments should start with space after hash
• L011: Unused alias (select statement)
• L012: Aliases in join conditions should be qualified

See sqlfluff documentation for complete rule reference.

Requirements

• VS Code 1.60.0 or higher
• Python 3.7 or higher
• sqlfluff 1.0.0 or higher (for full compatibility with this extension)

License

MIT

Contributing

Contributions are welcome! Please feel free to submit pull requests or open issues on the repository.

Support

For issues, feature requests, or questions:

• Check the troubleshooting section
• Review sqlfluff documentation
• Open an issue on the GitHub repository
