Obsidian Preview

Interactive preview for Obsidian vaults in VS Code. Runs DataviewJS, DQL, and Obsidian Bases, resolves wikilinks, and writes task toggles back to the source file.

_{Properties panel and an embedded Base. Left: raw markdown source. Right: Obsidian Preview.}

_{Editable task checkboxes and live DQL results. Left: raw markdown source. Right: Obsidian Preview.}

Why a custom editor

VS Code's built-in markdown preview cannot host DataviewJS, for two independent reasons:

1. CSP. Its webview has no unsafe-eval, so new AsyncFunction(...) is unavailable.
2. Sync rendering. extendMarkdownIt fence rules are synchronous, and DataviewJS blocks are async by nature (await dv.view(...)).

This extension registers a CustomTextEditorProvider instead. That gives it its own CSP, async rendering, a private RPC channel to the extension host — and, because it works off the TextDocument, undo/redo, dirty state, and saving all flow through VS Code's normal pipeline rather than being reimplemented.

Open any note with Obsidian Preview: Open Preview to the Side, or right-click → Reopen Editor With…. The plain text editor keeps working untouched.

What works

Rendering — wikilinks ([[Note]], [[Note|alias]], [[Note#Heading]]), embeds, tags, ==highlights==, and markdown inside table cells.

Frontmatter renders as a collapsible properties panel rather than as two horizontal rules around a paragraph of raw YAML. Values are typed: dates are formatted, booleans and numbers get their own treatment, lists become chips, tags become clickable tag chips, wikilinks and URLs become links, and malformed YAML surfaces an error panel with the raw block instead of silently vanishing. The frontmatter lines are blanked rather than removed, so body line numbers still match the source file — which is what keeps task toggling accurate.

Interaction — clicking a checkbox edits the source note through a WorkspaceEdit, so it is undoable and marks the buffer dirty exactly like typing. Clicking a wikilink opens the target (⌘/Ctrl-click for a new tab); an unresolved link offers to create the note.

DQL — TABLE / TABLE WITHOUT ID / LIST / TASK, FROM (folders, tags, links, outgoing(), with and / or / negation), WHERE, SORT, GROUP BY, FLATTEN, LIMIT, AS. Expressions are parsed by a real tokenizer and Pratt parser, so keywords inside string literals (WHERE title = "From Russia") and wikilinks are safe. ~55 functions including contains, length, list, date, dur, dateformat, choice, default, filter, map.

After GROUP BY, rows is bound and later clauses operate on the groups — so GROUP BY type SORT length(rows) DESC orders the groups by size, and a grouped TABLE collapses into one table whose first column is the group key. Task rows inherit their page's fields (file.link, frontmatter), with the task's own implicit fields taking precedence. Duration literals (dur(14 days)) and date keywords (date(today), sow, eom) work.

Obsidian Bases — ![[Something.base]] embeds and ```base blocks render as a tabbed view switcher with table, cards, and list views, matching Obsidian's layout. Supports base-level and per-view filters (and / or / not), formulas, properties displayName, groupBy, sort, and limit.

Bases has its own expression language, separate from DQL — == / && / ||, method chaining (list("done").contains(status), type.upper().startsWith("I")), and a file namespace with inFolder(), hasTag(), hasLink(), hasProperty(), asLink(). Globals include if(), date(), today(), now(), list(), link(), number(), min(), max(), round(), and duration arithmetic ((today() - date(created)).days). Editing a .base file re-renders any preview embedding it.

A filter that fails to parse surfaces an error and is skipped, rather than silently matching nothing and showing an empty view.

Inline queries — `= this.created` evaluates DQL against the current page; `$= dv.pages().length` runs inline JavaScript in the same sandbox as a dataviewjs block. No separate setting to enable, unlike Obsidian.

DataviewJS — dv.container, view, el, header, paragraph, span, table, list, taskList, pages, pagePaths, page, current, array, date, duration, query, evaluate, luxon, func. DataArray is Proxy-backed, so field auto-mapping (pages.file.name), numeric indexing, and spreading all behave as they do in Obsidian.

Obsidian compatibility — moment, DateTime and luxon globals; the HTMLElement.prototype helpers (createEl, createDiv, empty, setText, addClass, …); and an app shim covering vault.read/modify/create/delete/getAbstractFileByPath, workspace.openLinkText/getActiveFile/activeLeaf, metadataCache.getFirstLinkpathDest/ getFileCache/resolvedLinks, and commands.executeCommandById.

dv.view("name", input) loads name/view.js (or name.js) plus a sibling view.css from the vault and executes it, the way Obsidian does.

What does not work

• Other plugins. app.plugins.plugins["some-plugin"] returns undefined. Snippets that reach into Obsidian Charts, Full Calendar, Tasks, or Templater cannot work outside Obsidian.
• Tasks from other files. Checkboxes rendered by a query that pulls tasks from other notes are display-only; only tasks in the previewed note can be toggled.
• Note embeds render as a clickable placeholder rather than recursively inlining content.
• Obsidian command ids are mapped for a small set; the rest report as unsupported.

Configuration

Development

npm install
npm run dev          # esbuild watch
npm run typecheck
npm test             # 177 regression tests, no VS Code needed

Two harnesses run the engine headlessly against a real vault:

npm run test:vault -- /path/to/vault   # execute every dataview/dataviewjs block
npm run test:links -- /path/to/vault   # verify link resolution

test:links distinguishes genuinely dangling links from resolver bugs, so a high unresolved count does not hide a broken resolver.

Notes on correctness

A few behaviours are easy to get subtly wrong and are covered by tests:

• file.name excludes the extension (Obsidian's does).
• FROM "notes" matches on a path boundary — it must not match my-notes-archive/.
• Tags are not harvested from code fences, inline code, or URL fragments.
• [[Foo]] prefers a same-folder match before a vault-root one; ambiguous basenames fall back to shortest-path, then alphabetical.
• file.day is derived without round-tripping through new Date().toISOString(), which shifts date-only values across the UTC boundary.
• FROM #alpha also matches #alpha/beta; tag sources are hierarchical.
• await someDataArray resolves instead of hanging (the Proxy returns undefined for then).

License

MIT
