VS Code extension for ioBroker javascript adapter

ioBroker is a mighty IoT platform and enables you to write custom scripts with its JavaScript adapter.

This extension for Visual Studio Code enables you to develop the scripts completely in Visual Studio Code, without the need of the web interface.

Features

Open the command pallet (Strg + Shift + P OR F1) and type iobroker: to see all available commands.

Connect to your ioBroker instance by invoking the command iobroker: Connect to ioBroker. You can see the process in the gif above. If your connection fails, check the created file .iobroker-config.json and re-run the command iobroker: Connect to ioBroker for another connection attempt.

If .iobroker-config.json is found in the root of your workspace, the extension automatically starts a connection attempt.

Password protected ioBroker installations

If your ioBroker installation is protected via password, the extension will ask for it during the connection attempt. The username is stored in the config file .iobroker-config.jon and the password is stored in the VS Code internal secret storage. If the password was changed, the extions will automtically ask for the new one. It might be necessary to restart VS Code in the case supplying the new password fails.

Type definitions

If you choose to configure ioBroker type definitions, the current defintions are downloaded from GitHub. Additionaly a tsconfig.json is created (if it does not exist yet) with the necessary settings. This enables Visual Studio Code to know the ioBroker specific javascript functions.

View: Script explorer

The script explorer can be found in the activity bar behind the ioBroker logo. It shows all scripts, which are on the configured iobroker server. If the script content differs on the local disk from the remote version on the ioBroker server, a star (*) is shown next to the script name.

Click on script to show its contents. If the script is not downloaded yet, only a preview is openend.

Every time a script object is changed, the script explorer refreshes its view.

View: Changed scripts

The Changed scripts view can be found in the activity bar behind the ioBroker logo. It shows all scripts, where the local version differs from the server version. Only scripts which are on local disk and already uploaded to the server are shown (This might change in the future).

The same scripts are also shown in the script explorer marked with a star.

Download scripts

Either download only one script (iobroker: Download script) or all scripts at once (iobroker: Download all scripts). To download a single script you have to following options:

• Go to the script explorer and press the download button next to the script you want to download
• Use the command iobroker: Download script. This command is only for updating an existing script as it downloads the script in the active text editor.

Upload scripts

To upload a single script you have the following options:

• Go to the script explorer and press the upload button. This will only work, if the script resides on your disk.
• Use the command iobroker: Upload script. This command uploads the script in the active text editor.

Only scripts residing on local disk can be uploaded. Scripts which are marked as remote only in script explorer can be viewed by clicking on it, but changes cannot be uploaded.

Start/Stop scripts

To start/stop a single script you have the following options:

• Go to the script explorer and press the start or stop button.
• Use the command iobroker: Start script, respectively iobroker: Stop script. This command starts/stops the script in the active text editor.

Show diff between local and server version of a script

Use the diff button in either the script explorer or the changed scripts view to show a diff of all the changes made locally.

Move scripts

Scripts can be moved from one directory to another on your ioBroker server. Moving a script over the VS Code file browser is not supported yet.

Scripts can only be moved over the script explorer. Right click on the script you want to move, select Move and choose the directory you want the script to move to. If the script is synced to your local disk, it will also be moved there.

Create scripts and subdirectories

Right click on an existing directory to create a new file in this directory or in the root directory. It is possible to create subdirectories, TypeScript files and JavaScript files. Newly created scripts are immediatly uploaded to the server as stoped scripts.

Delete scripts

Scripts can be deleted on your ioBroker server via the script explorer. Right click on a script, select Delete and confirm that the script shall be really be deleted. If the script is synced to your local disk, it will also be deleted there.

Delete directories recursively

Directories can be deleted on your ioBroker server via the script explorer. Right click on a directory and select Delete and confirm that the directory and ALL of its content shall be deleted. If the directory is synced to your disk it will be deleted with all of its content.

Change JS Instance

The JS Instance for a script can be changed over the script explorer. Right click on a script and select Change instance via a quick pick.

Show script logging

Press Strg + Shift + U to open the "Output" view. Open the drop down and select ioBroker (all) or ioBroker (current script).

• ioBroker (all): As long as a connection to ioBroker exists, this will show the output of all scripts.
• ioBroker (current script): As long as a connection to ioBroker exists, this will show only the outputs of the script in the currently active tab. This output gets not cleared, if the tab is changed. If you need to clear the output use Visual Studios feature Clear Output.

Hover over state id string to show value

Hover over any string with a full state id to show current data of the state:

This only works for states and not for channels.

Auto completion (IntelliSense) of iobroker state ids

Press Strg + . in any string to show the IntelliSense menu. If the string contains parts of an ioBroker state id (for example admin.0.), IntelliSense will show all states/channels/devices/... under the given partial state id. In case of admin.0. it will look like this:

If you press . instead of enter to select an item the next item will appear automatically.

The whole auto completion process in action:

Add name of ioBroker object/state id as comment

Sometimes it is hard to remember the meaning of a generic ioBroker object/state id. To make this easier the name of an id can be added as comment via code action.

Put your cursor within a valid id and open the code actions menu (click on the light bulb or press Strg+.) and select Add iobroker state name as comment. The entry will only appear if the state id is valid.

Extension Settings

After the first activation a .iobroker-config.json file is created in the root directory of your workspace. It contains all settings.

Current limitation: Hot reloading the settings is currently not supported. After changing a setting, restart VS Code.

Available settings

An example with all available settings can be found here.

Admin versions

The extension currently supports the following Admin versions:

• Admin4 (Deprecated Some features like password protected installations are not supported)
• Admin5
• Admin6
• Admin7

Known Issues

If you got any problems, please open a GitHub issue.

Release Notes

See the section Releases on Github for release notes.
