Ink

AI orchestration visibility for VS Code workspaces.

Ink is a VS Code extension frontend for orchestration-oriented development workflows. Every operation is backed by the live ink_mcp server over the Model Context Protocol (stdio): the server performs repository analysis, dependency graph building, context optimization, agent scheduling, cache tracking, and report generation — no mock data.

Features

• Dedicated Ink Activity Bar container with Dashboard, Analytics, Agents, and Cache views.
• Dashboard webview with workspace-aware orchestration metrics, including tokens saved, cache hit rate, parallel tasks, execution time, and context reduction.
• Analytics webview with execution timeline, cache statistics, and runtime statistics.
• Context Optimization panel: token-before/after, reduction percentage, selected files with relevance reasons, and dropped files.
• Interactive dependency graph panel: a force-directed SVG visualization with draggable nodes, pan, zoom, and hover highlighting of each file's connections. Entry points render in the accent color.
• Agents tree view grouped by active, completed, and pending agent status.
• Cache tree view with cache entry count, total cache size, hit rate, and individual cache entries.
• Workspace-aware behavior that prompts users to open a project before running workspace-dependent commands.
• Command palette entries for opening the dashboard, optimizing context, building a dependency graph, scheduling agents, generating a report, and clearing cache.
• Settings for cache, analytics, parallelism, maximum scheduled agents, and the MCP server command.
• Output channel logging through the INK channel.
• Live MCP integration: the extension spawns the ink_mcp binary via the official @modelcontextprotocol/sdk over stdio and maps its analyze_repository, build_dependency_graph, and optimize_context tools onto the runtime interface.
• Runtime, MCP, settings, state, health, workspace, and event abstractions prepared for future runtime integration.

MCP Server Integration

The extension connects to the Rust ink_mcp server (see the sibling mcp directory) over stdio using the official @modelcontextprotocol/sdk:

• analyze_repository drives the Dashboard metrics.
• build_dependency_graph drives the dependency graph boundary.
• optimize_context drives context optimization.
• schedule_agents / list_agents drive agent scheduling and the Agents view.
• get_cache_stats / clear_cache drive cache visibility.
• generate_report drives the Analytics timeline and report.

All orchestration tools share process-local state on the server (agents, cache, run history), so the extension reflects live server activity rather than mock data.

The server command resolves in this order:

1. The ink.mcpServer.command setting if set.
2. An auto-detected sibling build at ../mcp/target/{debug,release}/ink_mcp relative to the extension.
3. ink_mcp on PATH.

If the server cannot be launched, the extension continues to run and logs the failure to the INK output channel.

Commands

Installation

Install from the VS Code Marketplace or Open VSX once the extension is published.

For local development:

npm install
npm run compile

Then open this repository in VS Code and press F5 to launch an Extension Development Host.

Quick Start

1. Open a workspace folder in VS Code.
2. Open the Ink Activity Bar container.
3. Review Dashboard metrics, Analytics timeline, Agents status, and Cache entries.
4. Run Ink: Open Dashboard from the Command Palette to return to the main Ink view.

Usage

Ink is designed around workspace visibility. When no folder is open, views show a project prompt and workspace-dependent commands are hidden from the Command Palette.

When a folder is open, Ink shows runtime preview data across four views:

• Dashboard summarizes orchestration metrics.

• Analytics shows execution timeline and runtime statistics.

• Agents groups scheduled work by state.

• Cache summarizes cached entries and cache health.

• Runtime operation commands exercise typed runtime boundaries backed by the live MCP server.

Architecture Overview

Ink uses a layered TypeScript architecture:

• src/extension.ts is the composition root for services, providers, commands, and VS Code context keys.
• src/commands/ registers command handlers with logging, workspace checks, and error handling.
• src/providers/ adapts VS Code webview and tree view APIs to runtime data.
• src/webviews/ renders dashboard and analytics HTML with VS Code theme variables.
• src/services/ contains runtime, settings, workspace, logging, health, state, and MCP abstractions.
• src/services/McpClient.ts is the SDK-backed MCP client that spawns ink_mcp over stdio.
• src/services/McpRuntime.ts maps every server tool onto the runtime interface.
• src/mcp/mcpMapping.ts converts engine JSON documents into extension data models.
• src/models/ defines typed data contracts shared by the runtime and UI.
• src/mocks/ provides the mock runtime and sample data used by tests and offline development.

Providers and commands depend on runtime interfaces rather than directly coupling to mock data, so a future runtime can be introduced behind the same contracts.

Configuration

Ink contributes these settings:

Development with the MCP server

Build the Rust server first so the extension can auto-detect it:

cd ../mcp
cargo build

Then launch the extension from this folder with F5. The INK output channel logs MCP connection details (tools discovered) and any server failures.

Troubleshooting

If Ink views ask you to open a project, open a folder or workspace before using workspace-dependent commands.

If a command fails, open the INK output channel from View: Toggle Output and inspect the logged error. Check for a "Failed to connect to the Ink MCP server" message; if present, run cargo build in the sibling mcp directory (or set ink.mcpServer.command to a valid server binary).

If views do not update after changing workspaces or settings, reload the Extension Development Host and reopen the Ink Activity Bar container.

Development

Install dependencies:

npm install

Start a TypeScript watch build:

npm run watch

Launch locally from VS Code with F5.

Build

Compile the extension:

npm run compile

The compiled JavaScript is emitted to out/.

Test

Run the extension test command:

npm test

The test script compiles the extension before launching the VS Code extension test runner.

Packaging

Before packaging, confirm package.json metadata, marketplace icon, README, changelog, and repository links.

Package with vsce after installing it:

npm install -g @vscode/vsce
vsce package

For Open VSX, use ovsx after installing it:

npm install -g ovsx
ovsx package

Release Process

1. Run npm run compile.
2. Run npm test.
3. Confirm assets/icon.png is referenced by package.json.
4. Review CHANGELOG.md and docs/marketplace/release-description.md.
5. Replace placeholder repository, bugs, and homepage metadata before publishing.
6. Package a .vsix and install it locally for smoke testing.
7. Publish to the VS Code Marketplace and Open VSX.

License

No license file is included yet. Add a license before public distribution.
