Maa Support

针对 MaaFramework/MaaAssistantArknights 项目, 提供下列功能:

控制面板在左侧类似设置图标的面板中

功能均基于 interface.json 配置

插件根据打开文件夹的根目录是否有 src/MaaCore 文件夹来判定是否是 MaaAssistantArknights 项目

• 语义化资源分析
  • 查询任务定义
  • 查询任务引用
  • 补全任务
  • 补全图像路径
  • 校验任务
  • 校验图像路径
  • 多路径资源支持
• MaaPiCli功能 (仅MaaFramework项目)
  • 选择控制器
  • 选择资源
  • 添加并管理任务
  • 执行任务
• 截取图片 (依赖控制器提供截图能力)
• 裁剪图片

For MaaFramework/MaaAssistantArknights project, providing following features:

Control Panel stays at left, with an icon similar to settings.

All features are based on interface.json

Extension will check if src/MaaCore exists, to decide if it is MaaAssistantArknights project.

• Semantic resource analyze
  • Query task definition
  • Query task reference
  • Task autocompletion
  • Image path autocompletion
  • Task diagnostic
  • Image path diagnostic
  • Multiple paths of resource support
• Ability of MaaPiCli (MaaFramework project only)
  • Select controller
  • Select resource
  • Add and manipulate tasks
  • Run tasks
• Take screenshots (Relying on controllers for screenshot ability)
• Crop images

提供的vscode命令

使用 Ctrl Shift P (MacOS下 Command Shift P) 打开命令面板后搜索使用

• Maa: 打开Maa日志
  • 打开MaaFramework的日志.
• Maa: 打开插件日志
  • 打开插件的日志.
• Maa: 跳转到任务
  • 搜索并跳转到指定任务.
• Maa: 执行任务
  • 基于interface配置创建实例, 然后执行指定任务.
• Maa: 执行interface
  • 基于interface配置创建实例, 然后执行所有配置任务.
• Maa: 快捷键启动
  • 在控制面板激活的 VS Code 窗口中执行当前资源项目的配置任务.
• Maa: 暂停/继续全部运行实例
  • 存在未暂停实例时全部暂停, 否则全部继续.
• Maa: 停止全部运行实例
  • 停止快捷键目标窗口中的全部运行实例.
• Maa: 截图
  • 截取快捷键目标窗口中的当前控制器画面并保存到运行资源项目的 debug/screenshot.
• Maa: 打开截图工具
  • 打开 进行截图裁剪 的 Webview.
• Maa: 展示控制面板
  • 展示并聚焦 控制面板.
• Maa: 选择 MaaFramework 版本
  • 下载并切换插件自身使用的 MaaFramework.
• Maa: 选择下载源
  • 选择下载插件自身使用的 MaaFramework 的镜像源.

先在 Maa 控制面板点击“激活全局快捷键”，将当前窗口设为唯一执行目标。VS Code 1.128 及以上可在用户 keybindings.json 中将上述任一命令配置为系统级快捷键，例如：

[
  { "key": "ctrl+shift+f9", "command": "maa.start", "systemWide": true },
  { "key": "ctrl+shift+f10", "command": "maa.toggle-pause", "systemWide": true },
  { "key": "ctrl+shift+f8", "command": "maa.stop", "systemWide": true },
  { "key": "ctrl+shift+f12", "command": "maa.screencap", "systemWide": true }
]

Provided vscode commands

Use Ctrl Shift P (Command Shift P for MacOS) to open command panel and search

• Maa: open maa log
  • Open the log of MaaFramework.
• Maa: open extension log
  • Open the log of extension.
• Maa: goto task
  • Search and navigate to certain task.
• Maa: launch task
  • Create instance based on interface, and launch the specified task.
• Maa: launch interface
  • Create instance based on interface, and launch all configured tasks.
• Maa: shortcut start
  • Launch the configured tasks in the VS Code window activated from the Maa control panel.
• Maa: pause or continue all running instances
  • Pause all when any active instance is not paused, otherwise continue all paused instances.
• Maa: stop all running instances
  • Stop every running instance in the shortcut target window.
• Maa: take screenshot
  • Capture the current controller in the shortcut target window and save it under debug/screenshot in the runtime resource project.
• Maa: open crop tool
  • Open webview for taking screenshots and cropping images.
• Maa: reveal control panel
  • Reveal and focus control panel.
• Maa: select MaaFramework version
  • Download and change the version of MaaFramework used by extension.
• Maa: select fetch registry
  • Select the mirrors to download MaaFramework used by extension.

First click Activate Global Shortcuts in the Maa control panel to make that window the sole command target. With VS Code 1.128 or later, any command above can be configured as an OS-level shortcut in your user keybindings.json, for example:

[
  { "key": "ctrl+shift+f9", "command": "maa.start", "systemWide": true },
  { "key": "ctrl+shift+f10", "command": "maa.toggle-pause", "systemWide": true },
  { "key": "ctrl+shift+f8", "command": "maa.stop", "systemWide": true },
  { "key": "ctrl+shift+f12", "command": "maa.screencap", "systemWide": true }
]
