NaturalCC Code Agent

code_agent is a local code-editing agent that combines static project understanding with Aider-based edits.

It first parses a project to collect functions, variables, types, members, includes, and symbol relations. It then builds a semantic prompt for the requested task and hands that prompt to Aider, which edits the selected target files.

The project supports two user-facing paths:

Graphical UI: FastAPI backend + React/Vite frontend.
CLI: aider_runner.py.

The first selected target file is always the primary file used for NaturalCC prompt construction. Aider can still receive and edit multiple target files.

What It Is

This is not a general chat bot. It is a context-enhanced code agent for project-aware code completion and editing.

Typical tasks:

complete a function body
complete a function signature
complete a variable, member, or type
make small code changes that should follow existing project style
detect potential vulnerabilities and optionally auto-fix them
preview the exact semantic prompt before running Aider

Main files:

agent_web_api.py: FastAPI backend and bundled frontend server.
webui/: React + Vite graphical interface.
aider_runner.py: CLI entry and Aider command orchestration.
completion_prompt_agent.py: semantic prompt construction.
rag/c/: C/C++ parsing and context retrieval.
rag/java/: Java parsing and prompt path.
test_api.py: OpenRouter key/connectivity check.

Environment Setup

Prerequisites

uv (Python package manager)
Node.js & npm (for the frontend)

1. Install System Dependencies

C/C++ parsing requires the system libclang library. Install it via your OS package manager before running uv sync:

Ubuntu/Debian: sudo apt install libclang1
macOS: brew install libclang
Other: consult your distribution's package repository for libclang

2. Create the Python Environment

From code_agent/:

uv sync

This creates a .venv virtual environment and installs all locked Python dependencies. No manual conda or pip steps are needed.

The project expects these runtime capabilities (all handled by uv sync):

fastapi
uvicorn
clang Python bindings
aider on PATH

If you need GPU support (e.g. for vLLM-based offline evaluation), install it manually:

uv pip install vllm

For OpenRouter/OpenAI calls, either pass an API key in the UI/CLI or set environment variables:

export OPENROUTER_API_KEY=sk-or-v1-...
export OPENAI_API_KEY=sk-...

3. Install Frontend Dependencies

From code_agent/:

cd webui
npm install

Using The Graphical Interface

The UI has a FastAPI backend and a React frontend.

Quick Start (One-Click)

If you have a graphical terminal emulator installed (gnome-terminal, konsole, alacritty, etc.), or tmux as a fallback:

./start.sh

This script automatically uses the .venv Python and opens two terminal windows (or tmux panes):

One for the FastAPI backend
One for the Vite frontend dev server

When using tmux, the session is named ncc-agent. Press Ctrl+B then D to detach; re-attach with tmux attach -t ncc-agent.

Development Mode

Use this while editing frontend code. It gives Vite hot reload.

Terminal 1:

uv run python agent_web_api.py --host 127.0.0.1 --port 7860

Terminal 2:

cd webui
npm run dev

Open:

http://127.0.0.1:5173/

In development mode, Vite serves the frontend on 5173 and proxies /api/* requests to FastAPI on 7860.

Bundled Local Mode

Use this when you want one server to serve both the UI and API.

cd webui
npm run build
cd ..
uv run python agent_web_api.py --host 127.0.0.1 --port 7860

Open:

http://127.0.0.1:7860/

In bundled mode, FastAPI serves webui/dist and all backend APIs from the same port.

UI Workflow

Set the project root.
Select one or more target files.
Keep the first selected file as the primary parse file.
Choose or type a model.
Optionally enter API key, symbol, completion type, or prefix.
Enter the development instruction.
Click preview to inspect the final prompt, or execute to run Aider.

Using The CLI

Run commands from code_agent/.

Preview Prompt Only

uv run python aider_runner.py \
  -dir /path/to/project \
  -f src/foo.c include/foo.h \
  -i "补全 foo 函数实现" \
  --preview

Execute Aider

uv run python aider_runner.py \
  -dir /path/to/project \
  -f src/foo.c include/foo.h \
  -i "根据现有风格完善 foo 函数实现" \
  -m openrouter/deepseek/deepseek-chat

Useful CLI Options

-dir /path/to/project
-f src/foo.c include/foo.h
-i "你的修改或补全需求"
-m openrouter/deepseek/deepseek-chat
-key sk-...
-s parse_flags
-t function_body
--prefix parse_
--preview

-t accepts:

member
variable
function
function_body
type

API Endpoints

agent_web_api.py exposes:

GET /api/health
GET /api/bootstrap
GET /api/models
GET|POST /api/workspace/scan
GET /api/browse
POST /api/command-preview
POST /api/prompt/preview
POST /api/run

/api/run streams newline-delimited JSON events so the frontend can display live Aider logs.

Feature Plugin System

The Advanced panel is now powered by a plugin architecture. Each feature is a FeaturePlugin under plugins/. The frontend renders forms dynamically from each plugin's config_schema, so adding a new capability does not require any frontend code changes.

Architecture

plugins/base.py — FeaturePlugin abstract base class, ExecutionMode (aider/direct/hybrid), ConfigField schema definition, ExecutionContext.
plugins/registry.py — @register_plugin class decorator; plugins auto-register on import.
plugins/dispatcher.py — routes execution to AIDER, DIRECT, or HYBRID mode.
plugins/code_completion.py — the existing symbol/completion_type/prefix logic, migrated to a plugin.
plugins/code_summary.py — NaturalCC + Aider dry-run code summaries.
plugins/code_repair.py — AIDER-mode repair prompts for bug, compile, and test failures.
plugins/vulnerability_detection.py — vulnerability analysis with optional Aider remediation.

Execution Modes

Mode	Behavior	Example
`aider`	Generate prompt → call Aider → modify code files or dry-run reports	Code completion, code repair, code summarization
`direct`	Analyze directly → return report / write files	Static reports
`hybrid`	Analysis via API → generate fix prompt → Aider repair	Vulnerability detection

Built-in Code Summarization Feature

Feature name: code_summary (AIDER mode)

Behavior:

Builds the normal NaturalCC semantic prompt for selected target files, or source files under the whole project.
Runs Aider with --dry-run, so summary generation does not modify files.
Uses the selected model to produce a deeper code-aware summarization.

Main config fields:

summary_scope: targets or project
detail_level: brief / standard / detailed
include_symbols: ask Aider to include key symbols and data flow
max_files: cap files sent through NaturalCC and Aider

NaturalCC / libclang Version Alignment

NaturalCC requires the Python clang bindings to match the installed system libclang. This project pins clang==18.1.8, which matches the Ubuntu LLVM 18 / libclang1-18 family. If your system uses a different major LLVM version, update the clang dependency and lock file to the same major version as libclang.so.

Built-in Code Repair Feature

Feature name: code_repair (AIDER mode)

Behavior:

Builds a focused repair prompt from the user instruction, repair type, optional failure log, and optional extra context.
Uses the existing NaturalCC semantic prompt path, then delegates edits to Aider.
Biases toward minimal fixes and preserving existing interfaces.

Main config fields:

repair_type: bug_fix / compile_error / test_failure / safe_refactor
failure_log: compiler, test, stack trace, or runtime output
extra_context: constraints, expected behavior, or reproduction notes
allow_refactor: allow small supporting refactors when needed

Built-in Vulnerability Detection Feature

Feature name: vulnerability_detection (HYBRID mode)

Behavior:

Phase 1: run static pattern-based vulnerability scan and generate a report.
Phase 2 (optional): if auto_fix=true, generate remediation instruction and run Aider on selected target files.

Main config fields:

scan_scope: targets or project
severity_threshold: low / medium / high / critical
rule_profile: default / c_cpp / web
auto_fix: enable/disable repair stage
max_findings: cap report size
extra_instruction: extra remediation constraints

Usage tips:

Select target files first if you plan to enable auto_fix.
Start with auto_fix=false and review findings before enabling automatic remediation.

How to Add a New Feature Plugin

Create a new file under plugins/, e.g. plugins/my_feature.py.
Inherit FeaturePlugin, implement metadata, config_schema, and execute.
Decorate the class with @register_plugin.
Restart the backend. The frontend will automatically show the new feature and render its form.

Example:

# plugins/my_feature.py
from typing import Any, Dict, Generator, List, Optional
from code_agent.plugins.base import (
    FeaturePlugin, FeatureMetadata, ExecutionMode,
    ConfigField, ConfigFieldType, ExecutionContext, PluginResult,
)
from code_agent.plugins.registry import register_plugin


@register_plugin
class MyFeaturePlugin(FeaturePlugin):

    @property
    def metadata(self) -> FeatureMetadata:
        return FeatureMetadata(
            name="my_feature",           # unique ID
            label="My Feature",          # display name
            description="What it does",
            execution_mode=ExecutionMode.DIRECT,  # or AIDER / HYBRID
        )

    @property
    def config_schema(self) -> List[ConfigField]:
        return [
            ConfigField(
                name="my_param",
                label="My Parameter",
                type=ConfigFieldType.TEXT,   # text / textarea / select / switch / file
                required=True,
                default="",
                placeholder="Enter value",
                help_text="This is shown under the field",
            ),
        ]

    def execute(self, context: ExecutionContext) -> Generator[str, None, None]:
        # yield strings for log output
        yield "Starting...\n"
        # ... your logic ...
        # yield PluginResult when done (for DIRECT / HYBRID)
        yield PluginResult(success=True, message="Done!")

Config Field Types

Type	Renders as	Extra properties
`text`	`<input type="text">`	`placeholder`, `default`
`textarea`	`<textarea>`	`placeholder`, `default`
`select`	`<select>`	`options: [{value, label}]`, `default`
`switch`	`<input type="checkbox">`	`default` (bool)
`file`	`<input type="file">`	`accept`, `multiple`

File Upload

If your plugin config contains a file type field, the frontend will automatically send the request as multipart/form-data. Uploaded files are available in context.uploaded_files as {field_name: UploadFile}.

API Changes for Plugins

/api/bootstrap now returns:

{
  "features": [{"name": "...", "label": "...", "execution_mode": "..."}],
  "schemas": {"feature_name": [{"name": "...", "type": "...", ...}]},
  "default_feature": "code_completion"
}

/api/run accepts both JSON (backward compatible) and multipart/form-data (for file uploads). The payload should include:

{
  "feature": "my_feature",
  "feature_config": {"my_param": "value"}
}

Notes And Limitations

C/C++ parsing depends on libclang.
Some C++ syntax may not parse reliably because parts of the parser still use C-oriented libclang settings.
rag/ includes offline research/evaluation scripts with local-path assumptions.
The project currently has smoke checks rather than a formal automated test suite.
test_api.py checks API connectivity; it is not a parser or UI test.

VS Code Extension

The local VS Code extension runs the same FastAPI service and opens its bundled web interface in an editor tab. It includes application source and the built frontend, but deliberately does not include Python packages, Aider, libclang, or local models.

Build a local installable package from code_agent/:

cd webui && npm run build
cd ..
npm run package

Install the resulting naturalcc-code-agent-0.1.0.vsix from VS Code's Extensions: Install from VSIX... command, then run NaturalCC: Open Code Agent. Configure naturalccCodeAgent.pythonPath to the Python interpreter created by uv sync (for example, /path/to/code_agent/.venv/bin/python) if the extension cannot find it automatically. The service binds only to 127.0.0.1 and stops when the extension deactivates.

User Environment And API Key

The extension bundles the application source but not its Python dependencies. Users should clone this repository and prepare the runtime once:

git clone --branch ncc3 --single-branch https://github.com/CGCL-codes/naturalcc.git
cd naturalcc/code_agent
uv sync

Then set the VS Code setting naturalccCodeAgent.pythonPath to the absolute path of that environment's Python executable, for example:

"naturalccCodeAgent.pythonPath": "/absolute/path/naturalcc/code_agent/.venv/bin/python"

Open NaturalCC: Open Code Agent, choose a model, and enter your own OpenRouter or OpenAI API key in the UI's API Key field. The key is sent only to the local agent process for that request and is not saved in VS Code settings. Alternatively, launch VS Code with OPENROUTER_API_KEY or OPENAI_API_KEY set in its environment, then restart the extension host.
