Move Trace Debugging

Provides the ability to visualize Move trace files, which can be generated for a given package when running Move tests. These trace files contain information about which Move instructions are executed during a given test run. This extension leverages an implementation of the Debug Adapter Protocol (DAP) that analyzes Move execution traces and presents them to the IDE client (in this case a VSCode extension) in a format that the client understands and can visualize using a familiar debugging interface.

Supported features

Currently we support trace-debugging of Move unit tests only. and the following trace-debugging features are supported:

• stepping forward through the trace (step, next, step out, and continue commands)
• tracking local variable values (including enums/structs and references)
• line breakpoints
• disassembly view (disassembled bytecode view) with support for stepping and setting breakpoints in disassembled bytecode files

Note that support for trace-debugging macros and enums is limited at this point - stepping through macros or code related to enums may result in somewhat unexpected results due to how these constructs are handled internally by the Move execution framework. In particular, variable value tracking may be affected when trace-debugging these constructs. Work is ongoing to improve state-of-the-art - improvement suggestions and bug reports files as issues agains Sui's GitHub repository are greatly appreciated.

How to Install

1. Open a new window in any Visual Studio Code application version 1.61.0 or greater.
2. Open the command palette (⇧ + ⌘ + P on macOS, ^ + ⇧ + P on Windows and GNU/Linux, or use the menu item View > Command Palette...) and type Extensions: Install Extensions. This will open a panel named Extensions in the sidebar of your Visual Studio Code window.
3. In the search bar labeled Search Extensions in Marketplace, type Move Trace Debugger. The Move Trace debugger extension should appear as one of the option in the list below the search bar. Click Install.

How to trace-debug a Move unit test

Debugging a Move unit tests consists of two steps: generating a Move trace and actually trace-debugging it.

Generating a Move trace

If you have Mysten's Move extension installed you can generate a Move trace for tests defined in a given file by navigating to this file in VSCode and running Move: Trace Move test execution from the command palette. See the description of Mysten's Move extension for pre-requisites needed to run this command.

If you plan to use the Trace Debugging Extension by itself, you need to generate the traces using command-line interface of sui binary. See here for instructions on how to install sui binary. Note that the sui binary must be built with the tracing feature flag. If your version of the sui binary was not built with this feature flag, an attempt to trace test execution will fail. In this case you may have to build the sui binary from source following these instructions.

Once the sui binary is installed, you generate traces for all test files in a given package, as well as disassembled bytecode for all the modules (to support disassembly view) by running the following command in the package's root directory:

sui move test --trace-execution

You can limit trace generation to the tests whose name contains a filter string by passing this string as an additional argument to the trace generation command:

sui move test FILTER_STRING --trace-execution

Trace-debugging a test

Once traces are generated, open a Move file containing the test you want to trace-debug and execute Run->Start Debug command. The first time you execute this command, you will have to choose the debugging configuration for Move files, of which there should be only one available. Then you will have to choose a test to trace-debug if there is more than one test in a file (otherwise a trace-debugging session for a single test will start automatically). You can switch between source (regular) view and the disassembly view (where you can inspect and step through disassembled bytecode for lower-level view for Move code execution) by using Move: Toggle disassembly view and Move: Toggle source view commands from VSCode's command palette.
