BMP Debug

A VS Code extension for debugging ARM microcontrollers using the Black Magic Probe with Zephyr RTOS thread awareness support.

This extension is a fork of Cortex-Debug by Marus (marus25), stripped down and focused specifically on Black Magic Probe (BMP) workflows. Full credit and attribution to the original Cortex-Debug project and its contributors.

Features

Black Magic Probe GDB server integration
USB auto-detection — automatically finds the BMP by VID/PID (1d50:6018), no manual port configuration needed
RTT over BMP serial — opens the BMP's second serial port (UART/RTT) in a dedicated terminal panel when rttEnabled is set
Zephyr RTOS thread awareness in the Call Stack view
SWO decoding (console, binary, graphing)
SEGGER RTT support
Memory viewing via mcu-debug extensions
Disassembly debugging (provided by VS Code)

Currently only Black Magic Probe and Zephyr RTOS thread awareness are supported. QEMU and external GDB server types are available but without thread awareness. If you would like to add support for another GDB server without thread awareness, please open a PR. If you would like to support another RTOS besides Zephyr, please open an issue or PR.

Requirements

arm-none-eabi-gdb 12.1 or greater with Python support — the version of Python that arm-none-eabi-gdb was compiled against must also be installed on your system (the Zephyr SDK includes a compatible toolchain by default)
A Black Magic Probe (or compatible device)

Quick Start

Add the following to your .vscode/launch.json:

{
    "version": "0.2.0",
    "configurations": [
        {
            "name": "Debug with BMP",
            "cwd": "${workspaceFolder}",
            "executable": "./build/zephyr/zephyr.elf",
            "request": "launch",
            "type": "bmp-debug",
            "interface": "swd",
            "runToEntryPoint": "main",
            "rtos": "zephyr"
        }
    ]
}

USB Auto-Detection

The extension automatically detects a connected Black Magic Probe by scanning USB devices for VID 1d50 and PID 6018. The BMP exposes two serial ports:

Interface	Purpose
Interface 0 (`MI_00`)	GDB Server
Interface 1 (`MI_01`)	UART Console / RTT

The GDB port (Interface 0) is identified by its USB interface descriptor (MI_00). If the descriptor is unavailable, the extension falls back to choosing the lower-numbered port path (e.g. COM3 before COM4, or /dev/ttyACM0 before /dev/ttyACM1).

If multiple probes are connected you will be prompted to choose one. You can still override the port manually by adding "port": "/dev/ttyACM0" (Linux/macOS) or "port": "COM3" (Windows) to your configuration.

RTT over BMP Serial

When "rttEnabled": true is set in your launch configuration, the extension automatically:

Sends monitor rtt enable to the BMP before launch/attach
Detects the BMP's second serial port (UART/RTT interface, MI_01)
Opens that port at 115200 baud in a new VS Code terminal panel titled "BMP RTT: <port>"

The UART port is detected using these strategies (in order):

USB interface descriptor — looks for MI_01 with the same serial number as the GDB port
Single UART port — if only one BMP UART port is found, uses it directly
Path increment — increments the numeric suffix of the GDB port (e.g. COM3 → COM4, /dev/ttyACM0 → /dev/ttyACM1) and verifies it exists

The RTT terminal is bidirectional — you can both view output and send input. It is automatically closed when the debug session ends.

Example configuration with RTT

{
    "name": "Debug with RTT",
    "cwd": "${workspaceFolder}",
    "executable": "./build/zephyr/zephyr.elf",
    "request": "launch",
    "type": "bmp-debug",
    "interface": "swd",
    "runToEntryPoint": "main",
    "rtos": "zephyr",
    "rttEnabled": true
}

Specifying the GDB Executable and Python Runtime

The extension needs a GDB binary with Python support to communicate with the Black Magic Probe and enable RTOS thread awareness. You typically need to configure both the GDB path and the Python runtime together.

Selecting the GDB binary

The GDB binary is resolved in this order of precedence:

gdbPath in launch.json — overrides everything for that launch configuration. Can be a full path or just the executable name if it is on your PATH.
armToolchainPath in launch.json — sets the directory containing the toolchain binaries. The extension appends arm-none-eabi-gdb (or the configured prefix) automatically.
VS Code settings — the bmp-debug.gdbPath or bmp-debug.armToolchainPath settings apply globally (with per-platform variants .linux, .osx, .windows).
System PATH — if none of the above are set, the extension looks for arm-none-eabi-gdb on your system PATH.

Configuring the Python runtime

GDB builds with Python support (gdb-py) need to locate the correct Python runtime at startup. On Windows in particular, pythonXX.dll must be on PATH or the GDB process will fail immediately with exit code 0xC0000135 (DLL not found).

Set pythonPath to the Python interpreter GDB should use (e.g. one from a virtual environment). The extension automatically:

Sets PYTHONEXECUTABLE to the given interpreter.
Prepends the interpreter's directory to PATH so the runtime is findable.
If the interpreter is inside a venv, reads pyvenv.cfg to locate the base Python installation and prepends that too — this is where pythonXX.dll actually lives on Windows.
Sets PYTHONHOME to the venv root so site-packages resolves from the venv.

Set pythonHome explicitly only if you need to override the automatic PYTHONHOME detection.

Example: GDB-py with a venv Python (Windows)

{
    "name": "Debug with BMP",
    "cwd": "${workspaceFolder}",
    "executable": "./build/zephyr/zephyr.elf",
    "request": "launch",
    "type": "bmp-debug",
    "interface": "swd",
    "runToEntryPoint": "main",
    "rtos": "zephyr",
    "gdbPath": "C:/zephyr-sdk/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb-py.exe",
    "pythonPath": "C:/myproject/.venv/Scripts/python.exe"
}

Example: Using `armToolchainPath` in launch.json

{
    "name": "Debug with BMP",
    "cwd": "${workspaceFolder}",
    "executable": "./build/zephyr/zephyr.elf",
    "request": "launch",
    "type": "bmp-debug",
    "interface": "swd",
    "runToEntryPoint": "main",
    "rtos": "zephyr",
    "armToolchainPath": "C:/zephyr-sdk-0.17.0/arm-zephyr-eabi/bin"
    //"gdbPath": "C:/zephyr-sdk-0.17.0/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb.exe"
}

Example: Using VS Code settings

In your .vscode/settings.json or user settings:

{
    "bmp-debug.gdbPath": "/opt/zephyr-sdk-0.17.0/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb",
    "bmp-debug.pythonPath.linux": "/opt/myproject/.venv/bin/python"
}

GDB and Python properties

Property	Description
`gdbPath`	Full path or name of the GDB executable. Overrides `armToolchainPath`.
`armToolchainPath`	Directory containing the ARM toolchain binaries.
`pythonPath`	Path to the Python interpreter GDB should use. Accepts a venv interpreter; the base install is found automatically via `pyvenv.cfg` (important on Windows).
`pythonHome`	Explicitly sets `PYTHONHOME` for GDB. Rarely needed — omit unless `pythonPath` alone does not work.

All properties support per-platform VS Code setting variants: .linux, .osx, .windows.

Getting a Compatible GDB for python based RTOS thread awareness

The Zephyr SDK ships a build of arm-zephyr-eabi-gdb that includes Python support and is the easiest way to get a compatible GDB.

Download the Zephyr SDK from the releases page. You can install the full SDK or just the ARM toolchain:

# Full SDK (includes all toolchains)
wget https://github.com/zephyrproject-rtos/sdk-ng/releases/download/v0.17.0/zephyr-sdk-0.17.0_linux-x86_64.tar.xz
tar xf zephyr-sdk-0.17.0_linux-x86_64.tar.xz

# Or minimal — ARM toolchain only
wget https://github.com/zephyrproject-rtos/sdk-ng/releases/download/v0.17.0/toolchain_linux-x86_64_arm-zephyr-eabi.tar.xz
tar xf toolchain_linux-x86_64_arm-zephyr-eabi.tar.xz

On Windows, download the .7z or installer variant and extract/install to a directory such as C:\zephyr-sdk-0.17.0.

Locate the GDB binary inside the extracted SDK:

OS Path

Linux <sdk>/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb

macOS <sdk>/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb

Windows <sdk>\arm-zephyr-eabi\bin\arm-zephyr-eabi-gdb.exe
Configure the extension using one of the methods above. Since the Zephyr SDK uses the prefix arm-zephyr-eabi instead of the default arm-none-eabi, the simplest approach is to set gdbPath directly:
```
{
    "bmp-debug.gdbPath": "<sdk>/arm-zephyr-eabi/bin/arm-zephyr-eabi-gdb"
}
```
Alternatively, set both armToolchainPath and armToolchainPrefix:
```
{
    "bmp-debug.armToolchainPath": "<sdk>/arm-zephyr-eabi/bin",
    "bmp-debug.armToolchainPrefix": "arm-zephyr-eabi"
}
```

Note: The Zephyr SDK GDB requires the Python version it was compiled against to be installed on your system. If you get errors about missing Python libraries, install the matching Python version (check with arm-zephyr-eabi-gdb --configuration and look for the Python path).

Key launch.json Properties

Property	Description
`servertype`	GDB server type: `"bmp"` (default), `"qemu"`, or `"external"`
`port`	Serial port for BMP GDB server. Auto-detected if omitted
`interface`	Debug interface: `"swd"` (default) or `"jtag"`
`targetId`	Target ID for BMP scan (default: `1`)
`powerOverBMP`	Power target via BMP: `"enable"`, `"disable"`, or `"lastState"` (default)
`rtos`	RTOS type for thread awareness. Currently only `"zephyr"` is supported
`rttEnabled`	Enable RTT over BMP serial. Opens the UART port in a terminal panel and sends `monitor rtt enable`
`runToEntryPoint`	Function name to run to on launch (e.g., `"main"`)
`gdbPath`	Full path or name of the GDB executable to use (overrides `armToolchainPath`)
`armToolchainPath`	Path to the directory containing the ARM toolchain binaries

For a full list of properties, see debug_attributes.md.

Acknowledgments

This extension is based on Cortex-Debug by Marus (marus25). The original project is licensed under the MIT License.

Parts of the original Cortex-Debug extension are based upon Jan Jurzitza's (WebFreak) code-debug extension, which provided an excellent base for GDB MI parsing and interaction.

The mcu-debug extensions (Memory Viewer, RTOS Views, Peripheral Viewer) are used for frontend debug views.
