MuxDock

Persistent terminal sessions. One dock.

MuxDock brings tmux, zmx, screen, Zellij, shpool, abduco and a4 into a dedicated terminal panel in VS Code and Cursor. Work in the terminal on the left and browse managers, named sessions and tmux windows on the right.

Your sessions belong to the underlying manager. Close a tab, detach or reload the editor, then reconnect to continue working.

Features

• Seven managers in one place. Discover installed tools and browse their existing sessions without replacing their configuration.
• A real interactive terminal. Keep native keyboard shortcuts, pane layouts, status bars, shell prompts, ANSI colors and truecolor output.
• Session tabs. Switch between open terminals, close individual tabs, hide the tab bar or set a maximum tab count.
• tmux window navigation. Expand a session to select, create, rename or close its windows. Native shortcuts such as Ctrl+B keep working.
• A compact session tree. Open the filter with the magnifying glass, then collapse it when you are done. Choose which managers appear and in what order.
• More room for the terminal. Collapse the session panel with the button at the far right of the terminal toolbar. Expand it from the same button; its width and visibility are remembered.
• Local and remote hosts. Run the extension where your workspace lives, including Remote SSH, WSL and Dev Containers.

Requirements

• VS Code 1.95 or later, or a compatible Cursor version.
• A macOS or Linux extension host. On Windows, open a WSL or Linux Remote SSH workspace.
• At least one supported manager installed on that host. MuxDock discovers installed tools; it does not install them.
• Python 3 on Linux hosts and on any host where the native PTY cannot be loaded. The extension includes native macOS PTY binaries for Apple Silicon and Intel.

The managers must be installed on the workspace host: locally for a local workspace, on the SSH host for Remote SSH, inside WSL for a WSL workspace, or inside the container for Dev Containers.

Getting started

1. Install MuxDock from your editor's Extensions view, or run Extensions: Install from VSIX... and select muxdock-0.0.2.vsix.
2. Open the Command Palette, search for MuxDock, and open the dock (muxdock.open). You can also select the MuxDock panel tab.
3. Click a session in the right-hand tree to attach, or use the + beside a manager to create a named session.
4. Expand a tmux session to browse its windows. Click a window to select it, or use its context menu for window actions.
5. Use the tabs above the terminal to switch between open sessions. Each tab shows its session name and manager.

Only installed managers are shown by default. After installing a tool, refresh the tree. If a binary is not on the extension host's search path, set its absolute path with muxdock.executables.

For example, a session tree can look like this:

tmux
  backend
    0: api
    1: logs
zmx
  worker
screen
  training

Session lifecycle

The default limit is 8 tabs, including closed tabs. Selecting an existing tab does not change its position in the eviction order. The limit also applies when the tab bar is hidden.

Screen restoration and scrollback after reconnecting depend on the manager. In particular, abduco does not provide full screen restoration.

Supported operations

• tmux: multiple clients attached to the same session share its current window. Selecting a window in MuxDock can also change the window shown by other clients.
• shpool: a session accepts one attached client. MuxDock does not force another client's connection to detach.
• New session names must start with a Unicode letter, digit or underscore. The remaining characters may also include hyphens and dots. For new tmux session names, use underscores instead of dots.
• This is a dedicated terminal panel. Tasks, debugging sessions and other extensions' terminal commands continue to use the editor's built-in Terminal.

Settings

Search for MuxDock in Settings, or use @ext:muxdock.muxdock.

Tab and manager-visibility settings apply immediately. Changing a manager's executable or global arguments affects future connections; detach existing clients before switching backend configuration.

For example, show three managers, keep six tabs and connect to a named tmux server:

{
  "muxdock.visibleManagers": ["tmux", "zmx", "screen"],
  "muxdock.maxTabs": 6,
  "muxdock.arguments": {
    "tmux": ["-L", "work"]
  }
}

Manager IDs are tmux, zmx, screen, zellij, shpool, abduco and a4. Arguments are passed directly to the executable, without shell interpolation.

Navigation and terminal tools

• Click the magnifying glass beside the session heading to expand the filter. Click it again or press Esc to clear and collapse the filter.
• Use arrow keys to navigate the tree, Left/Right to collapse or expand nodes, and Enter to attach.
• Use Left/Right or Home/End to navigate focused terminal tabs. Press Enter to focus the terminal, or Delete to close the focused tab.
• Drag the divider between the terminal and session tree to resize it. The focused divider also accepts Left/Right keys.
• Use the rightmost terminal-toolbar button to hide or show the entire session panel. Existing terminal connections keep running, and tabs remain available while the panel is hidden.
• Use Cmd+C/V on macOS or Ctrl+Shift+C/V on Linux to copy and paste. Terminal context menus also provide clipboard actions.
• Use Cmd+F or Ctrl+F to search terminal output. HTTP and HTTPS links can be opened from the terminal.

Troubleshooting

A manager is missing from the tree

Check muxdock.visibleManagers, confirm the tool is installed on the workspace host, then refresh. If necessary, add its absolute executable path to muxdock.executables.

A Linux terminal cannot start

Confirm that python3 is available to the extension host. The fallback uses Python's standard library and does not require additional Python packages.

A shpool session is already attached

Detach it from its existing client before opening it in MuxDock.

More diagnostics are needed

Open the MuxDock output channel using muxdock.logs. Include the editor version, workspace host OS, manager version and relevant log output when reporting an issue.

Source

Source code and development documentation are available in the MuxDock repository.

License

MIT.
