Azure Load Testing for Visual Studio Code

Use the Azure Load Testing extension to easily create Locust load tests using Copilot, iterate locally, and scale effortlessly in Azure. Whether you're new to Locust or a performance testing expert, the Azure Load Testing extension streamlines test creation, iteration, and scaling—right from your VS Code environment.

Get Started

This quickstart guides you through generating, refining, and executing realistic load tests.

By the end, you'll have a fully functional load test script generated from a Postman collection, Insomnia collection, or .http file, enhanced with Copilot-powered improvements, and ready to scale in Azure Load Testing.

Prerequisites

Before you begin, make sure you have the following:

1. Azure Load Testing extension for VS Code – Download and install it here.
2. GitHub Copilot – Set up Copilot in VS Code to generate and refine test scripts. Tip: If you don’t have a subscription, you can activate a free trial.
3. Python & Locust – Required to run and validate your Locust test scripts locally from VS Code. Install Locust here.
4. An Azure account – Needed to run load tests at scale in Azure Load Testing. If you don’t have an account, sign up for free.

Tip: VS Code's GitHub Copilot Chat offers multiple AI models. You can switch models using the model picker in the chat input field. If you're unsure which one to use, we recommend GPT-4o.

Open the Walkthrough

To get started, open the command palette in VS Code and run: Load Testing: Open Walkthrough. This walkthrough provides the key entry points of the extension.

You can also access the features directly from the command palette by using the Load Testing prefix. Some commonly used commands include:

• Load Testing: Create Locust test
• Load Testing: Run load test (local)
• Load Testing: Run load test (Azure Load Testing)

Generate a Locust Script with Copilot

You can generate a Locust script from any existing Postman collection, Insomnia collection, or .http file. If the file contains multiple requests, Copilot will attempt to sequence them into a cohesive scenario.

1. Click the Create a Load Test button in the walkthrough, or run Load Testing: Create Locust test from the command palette.

2. You can choose the source to auto-generate a Locust test script:

   • Selecting a Postman collection, Insomnia collection, or .http file lets Copilot extract multiple API operations, request data, and authentication details—creating a more complete and realistic load test.
   • Choosing Single URL allows you to enter a single endpoint URL, generating a simple script you can customize or expand.

3. For this walkthrough, you can select Try Sample: Pet Shop API, which uses the petstore-sample.http file to generate a sample Locust test script.

4. Copilot will analyze the selected file and generate a Locust-based load test script, automatically:

   • Sequencing API requests to simulate real-world usage.
   • Handling authentication securely.

5. Once the script is generated, the Copilot Chat window will suggest additional setup steps, such as defining environment variables.

   • If Copilot suggests environment variables, create a .env file in your project and add the recommended values.

Customize the Load Test Script

Before running the test, you can refine it with Copilot. For example, by examining the script, you might notice that the same request payload is sent with every request:

payload = {
    "id": self.pet_id,
    "name": "Fluffy",
    "category": {"id": 1, "name": "Dogs"},
    "photoUrls": ["https://example.com/photo.jpg"],
    "tags": [{"id": 1, "name": "cute"}],
    "status": "available"
}

To make the test more dynamic by randomizing the request payload:

1. Open the Copilot Chat panel.
2. Type: Randomize request payloads and press Enter.
3. Copilot will generate a suggested modification to introduce randomization.
4. Click Apply in Editor that appears above the generated code snippet in Copilot Chat window.
5. After reviewing the changes, click Keep to accept and update your script.
6. Save the file

Now, each request simulates a more realistic user interaction. The code will look something like the following:

payload = {
    "id": self.pet_id,
    "name": f"Pet{random.randint(1, 1000)}",
    "category": {"id": random.randint(1, 10), "name": random.choice(["Dogs", "Cats", "Birds"])},
    "photoUrls": [f"https://example.com/photo{random.randint(1, 100)}.jpg"],
    "tags": [{"id": random.randint(1, 10), "name": random.choice(["cute", "friendly", "playful"])}],
    "status": random.choice(["available", "pending", "sold"])
}

Run the Load Test

You can execute your load test in two ways:

• Run locally for quick validation
• Run in Azure Load Testing for high-scale, multi-region load

Run Locally for Quick Validation

To quickly validate your test, run it locally using Locust from Visual Studio Code:

1. Open the command palette and run: Load Testing: Run load test (local).

2. This will automatically launch the Locust web UI in a browser. It can take a few seconds for the Locust server to be ready and for the browser to open.

3. In the Start new load test page, review the input fields and click Start. Locust will begin sending requests, logging any failures, and tracking performance statistics.

4. Explore the Locust UI to analyze response times, error rates, and request throughput.

Tip: If Locust reports failures for the Retrieve Pet and Update Pet requests, it may be due to how the Pet Store API processes requests. Try asking Copilot to "Add random delays between requests in run_scenario". If you suspect an issue with the script itself, set DEBUG_MODE=True as an environment variable and rerun the test to get more detailed debug information.

If you prefer running the test from a VS Code Terminal:

1. Open a terminal in VS Code.
2. Run the following command:

   locust -f path/to/locustfile.py -u 10 -r 2 --run-time 1m


   • -f path/to/locustfile.py → Specifies the Locust test script.
   • -u 10 → Simulates up to 10 virtual users.
   • -r 2 → Ramps up 2 virtual users per second.
   • --run-time 1m → Runs the test for 1 minute.
3. Open a browser to http://0.0.0.0:8089 to view the Locust web UI.

Scale Up in Azure Load Testing

For high-load scenarios where you need to simulate many thousands of concurrent virtual users across multiple regions, you can run your test in Azure Load Testing.

To execute a large-scale test:

1. Open the command palette and run: Load Testing: Run load test (Azure Load Testing).
2. Select Create a configuration file....
3. Follow the guided setup, which includes:
   • Signing into Azure and selecting your subscription.
   • Creating a new Azure Load Testing resource or selecting an existing one.
   • Choosing load test regions to distribute traffic globally.
4. Once the setup is complete, a YAML configuration file (e.g., loadtest.config.yaml) is generated and added to your workspace root folder.
   • This file defines the Locust script, load parameters, environment variables, regions, and any additional files (e.g., CSV datasets).
   • Defaults are 200 virtual users running for 120 seconds in each selected region.
   • Commit this file in your repository to reuse and automate future load test executions.
5. Copilot validates the configuration before execution. Follow any instructions provided in the chat window. Otherwise, if everything checks out, the test script and its related artifacts are uploaded to Azure Load Testing and prepared for execution. (This process may take up to a minute—progress is shown in the Output panel.)

6. When the test starts, a notification (toast message) appears in the bottom-right corner. Click the Open in Azure Portal button to monitor test execution in real time.

Tip: To quickly access test results from previous runs, use the command: Load Testing: View load test runs.

Next Steps

So far in this quickstart, sensitive variables like API_KEY were stored in a .env file and uploaded to the cloud service. However, as a best practice, secrets should be securely managed in Azure Key Vault. The extension provides guidance on setting this up.

Secure Secrets with Azure Key Vault

1. Open the Copilot Chat window, type @testing /setupLoadTestSecretsInAzure and hit Enter.
2. Copilot will guide you through:
   • Creating an Azure Key Vault.
   • Assigning a managed identity to your Azure Load Testing resource.
   • Adding secrets to Azure Key Vault.
   • Configuring your YAML file to reference Key Vault secrets instead of .env.

Whenever you modify your Locust script or YAML configuration, you can re-run the test by executing Run load test (Azure Load Testing).

For more information, visit the Azure Load Testing documentation.
