ModelScript — Modelica for VS Code

Modelica language support with interactive diagram editing, simulation, and scripting — powered by ModelScript.

Batteries Included

ModelScript is a complete Modelica development environment — no external compilers, tools, or configuration required. Everything runs directly in the browser or in VS Code, powered by the ModelScript framework:

• 🔋 Modelica Standard Library bundled and ready — full type resolution out of the box
• 🚀 Zero configuration — install the extension and start writing Modelica immediately
• 🌐 Works everywhere — desktop VS Code, vscode.dev, and the browser-based IDE

Features

Interactive Diagram Editing

Open a visual diagram view for any Modelica model with ModelScript: Open Diagram. Components are rendered as interactive SVG schematics with connection lines, icons, and labels.

• Drag to move — reposition components and the code updates automatically with Placement annotations
• Auto-layout — intelligent automatic placement of components via ModelScript: Auto Layout
• Add components — browse the Modelica library tree and add components directly to the diagram
• Edit connections — create and modify connect statements visually
• Bidirectional sync — changes in the diagram update the code, and vice versa

Simulation & Plotting

Run simulations directly from the editor with ModelScript: Run Simulation:

• ODE/DAE solver with Pantelides index reduction and BLT ordering
• Interactive plots — view simulation results as time-series charts
• Configurable — set start/stop time, solver, and output format
• No external tools — the solver runs entirely in the browser via WebAssembly

Modelica Scripting

Full support for Modelica Script (.mos) files with an integrated interpreter:

• Execute scripts — run simulate(), plot(), loadModel(), and other scripting commands
• REPL-style workflow — evaluate expressions and inspect results interactively
• Flatten models — introspect and debug class hierarchies with flatten()

Notebook Interface

Modelica Notebook support (.monb) for literate programming:

• Code cells — write and execute Modelica script blocks
• Rich output — see simulation results, plots, and diagnostic messages inline
• Documentation — mix Modelica code with markdown explanations

Intelligent Code Editing

Completions

• Dot-path completions — type Modelica. and get sub-packages, classes, and components from the entire standard library
• Keyword completions — all Modelica language keywords
• Contextual suggestions — parameters, modifications, and annotations

Hover Information

Hover over any Modelica identifier to see its type, description, and classification (model, connector, component, enumeration literal, etc.).

Go to Definition & References

• Go to Definition — jump to the declaration of any class, component, or type
• Go to Type Definition — navigate to the type of a component
• Find All References — locate every usage of a symbol across the workspace

Rename

Safely rename identifiers across files with F2 — the rename provider validates the new name before applying changes.

Signature Help

View function parameter signatures as you type, with documentation for each argument.

Document Symbols & Outline

Navigate complex Modelica files with the Outline view — classes, components, equations, and algorithms are organized hierarchically.

Workspace Symbol Search

Find any class or component across the entire workspace with Ctrl+T.

Error Diagnostics

Real-time error detection with 15+ lint rules:

• Parse errors — caught via tree-sitter incremental parsing
• Unresolved references — missing imports, typos, undefined names
• Type mismatches — incompatible types in assignments, equations, and function calls
• Array dimension errors — shape mismatches, index type errors, wrong subscript counts
• Structural errors — circular extends, duplicate modifications, unbalanced models
• Quick fixes — code actions to resolve common issues

Document Formatting

Format Modelica files with proper indentation for class definitions, equations, algorithms, and control structures.

Auto-Indentation

Smart indentation and dedentation rules for Modelica keywords like equation, algorithm, end, else, etc. — the editor adjusts indentation as you type.

Semantic Highlighting

Full semantic token support — variables, parameters, constants, types, and built-in identifiers are colored distinctly based on their semantic role, not just syntax.

Color Provider

Inline color swatches for Modelica annotation color fields (color, lineColor, fillColor, textColor). Click to use the VS Code color picker.

Code Folding

Fold class definitions, equation and algorithm sections, and control structures for easier navigation of large files.

Modelica Library Browser

A dedicated sidebar panel for browsing the Modelica Standard Library:

• Hierarchical tree — navigate packages, models, connectors, and functions
• Class icons — each class kind has a distinct icon (model, connector, block, function, etc.)
• Add to Diagram — insert components directly from the library browser into your model

AI Assistant

A browser-local AI chat powered by WebLLM (Qwen3-0.6B):

• Privacy-first — the model runs entirely in your browser, no data leaves your machine
• Modelica-aware — can flatten models, run simulations, and inspect classes via built-in tools
• LaTeX rendering — mathematical equations are rendered as Unicode for readability

Requirements

• VS Code 1.100.0 or later
• Works in both desktop VS Code and vscode.dev

Extension Settings
