PerfChecker for VS Code

PerfChecker 1.0 brings a full Studio, interactive plots, Julia tools, MCP conversation, and reviewed agent implementation with Git recovery into VS Code. Use a controller environment containing PerfChecker.jl 1.0.0 or later.

The user guides are maintained with PerfChecker.jl on its existing documentation host:

• VS Code guide
• Complete extension configuration
• Plots, notebooks and Julia tools
• MCP advice, implementation and recovery

Measure existing Julia test items

Set perfchecker.runnerProject to a Julia environment containing PerfChecker and TestItemRunner 1.3.2 or later in 1.x. Run PerfChecker: Discover existing test items, then select individual items in the PerfChecker — mesures Test Explorer controller. The measurement controller is created only for the chosen folder when discovery is requested. In a multi-root workspace, the command prompts for a folder; companion extensions may pass an open folder URI directly to perfchecker.discoverTestItems. Its PerfChecker — mesures run profile measures items independently of the Julia extension's functional test controller; it does not intercept Julia test runs. Untagged items are shared, :check_only is measurement-only, :perf_only is its supported alias, and :test_only is functional-only. Shared items may appear in both controllers as two distinct actions. Set perfchecker.testItemTags to ["perf_only"] to show only measurement-only items in the PerfChecker controller. testItemExcludeTags further narrows selection. Each item runs once by default, in an isolated process; testItemSamples explicitly changes repetition. Save workspace changes before measuring. Cancellation asks the Julia controller to stop and waits for worker cleanup. A cleanup failure remains an error. After one minute without exit, a visible forced-stop warning explains that traces, private inventories or detached workers may remain.

The item timer includes setup, imports, assertions and cleanup. Green means correctness passed, with measurements retained; no regression budget has been compared. Ordinary Julia/TestItemRunner execution is unchanged: automatic exclusion of :check_only/:perf_only in Julia's Test Explorer needs upstream support. For a measurement-only item that must be safe under Julia's Run All, use:

@testitem "Measured case" tags=[:check_only] skip=(get(ENV, "PERFCHECKER_TESTITEM_MODE", "") != "performance") begin
    @test sum(1:1000) == 500500
end

PerfChecker sets this marker only in measured item workers; Julia's ordinary runner then skips the item. This guard is opt-in per declaration.

The investigation panel connects shared tests, declared performance scenarios, optional analyzers and saved evidence. It also provides a searchable tool catalogue, proposed CI coverage, bounded investigations and optional explanations from a configured model.

Use PerfChecker: Open investigations. Discover and select scenarios before measuring or investigating. Model settings selects the endpoint, model and Chat Completions/Ollama protocol; advanced Julia providers use an advisor JSON file. Local inference is the default and no model is downloaded or launched automatically. Remote transmission requires explicit opt-in. Generated explanations remain separate from deterministic findings and never alter correctness or performance verdicts.

perfchecker.investigationMaxExperiments and investigationBudgetSeconds bound work. advisorInvestigates optionally lets the configured model choose declared experiments; it is disabled by default. History shows completed and unexecuted experiments. CPU/allocation profiles provide filterable stack evidence. Changing the target implementation still requires an explicit before/after comparison with a stable oracle and measurement contract.

PerfChecker.jl turns performance checks into reproducible package, suite and version comparisons. This repository contains its independent VS Code client.

The extension is the central graphical workspace for package developers. It consumes PerfChecker's versioned plans and result bundles; it does not bundle the Julia package or enter measured workers.

Features

• Open PerfChecker: Open Studio for a full editor workspace with investigations, plots, Julia tools and advisor conversation. The sidebar remains a launcher.
• Ask an explicitly configured MCP advice tool, review its answer, then optionally ask an implementation tool to prepare changes in an isolated Git checkout. Review the diff before applying; restore the checkpoint if the repository has not changed. Conversation is kept in memory; Git recovery survives editor restarts. Starting a new conversation preserves the current proposal and its restore action.
• Connect an already authenticated Codex CLI from Chat for the same advice and reviewed implementation workflow. The temporary local connection preserves your saved provider configuration and ends when disconnected or the editor closes.
• Open a folder-scoped Julia terminal, create an unsaved Julia investigation notebook, open native notebooks, and debug saved Julia source using the Julia extension. Select an installed notebook kernel explicitly.
• Browse package → business feature → check type → target in the activity bar and native Test Explorer.
• Select BenchmarkTools, Chairmarks, allocations, CPU/wall-time profiles and network checks per business feature.
• Filter version ranges, sort and colour-label checks, and drag execution order.
• Add releases, branches, tags, commits and grouped comparison targets.
• Launch a whole suite or any selection with live progress and worker output.
• Open the exact Julia workload behind a check.
• Inspect interactive distributions, version curves, allocation pies and flame graphs with hover details for narrow points and frames.
• Save selections, comparison policies and documentation blocks in the shared perfchecker-ui-config/1 format.

Requirements

• VS Code 1.96 or newer.
• Julia available as julia, or configured through perfchecker.juliaExecutable.
• A controller environment in the opened package workspace, normally perf, containing PerfChecker.jl 1.0.0 or later and a suite.jl with build_suite().

The extension invokes the public PerfChecker CLI and reads only versioned JSON, JSONL and Markdown outputs. See CONTRACT.md for the exact boundary.

Install a local build

Set-Location C:\path\to\PerfCheckerVSCode
npm ci
npm test
npm run package -- --out perfchecker-vscode-1.0.0.vsix
code --install-extension .\perfchecker-vscode-1.0.0.vsix --force

Reload VS Code, open a Julia package workspace, then select the PerfChecker icon or run PerfChecker: Open Studio from the command palette. Studio also opens the suite editor and existing report viewers.

Workspace defaults

perf/Project.toml
perf/suite.jl
perf/perfchecker-ui.json
perf/results/vscode/

Every path is configurable in VS Code settings. The controller environment owns the PerfChecker.jl version, so upgrading the extension does not silently change the benchmark engine used by a project. When the default perfchecker.runnerProject is perf but perf/Project.toml is absent, PerfChecker selects perf/controller/Project.toml if it exists. The selection is reported in the PerfChecker output channel. An explicitly configured project always wins, even when its Project.toml is missing; that case shows a path-specific error. perf/runner is never selected automatically. The same rule applies to the default perfchecker.scenarioProject for investigations.

Opening from another VS Code extension

Companion extensions should detect the contributed command perfchecker.openDesignerForWorkspace in the installed extension's packageJSON before activation, then pass an open folder's vscode.Uri or vscode.WorkspaceFolder. This command requires the argument. The older perfchecker.openDesigner accepts one optional argument: a vscode.Uri or vscode.WorkspaceFolder identifying an open local workspace folder. For example, vscode.commands.executeCommand('perfchecker.openDesignerForWorkspace', folder.uri) opens that folder's suite with its folder-scoped PerfChecker settings. In a single-folder window, the command palette and existing no-argument calls keep working. In a multi-root window, callers must provide the folder explicitly; a missing or foreign folder is rejected before the suite factory runs. Activation in a multi-root window does not plan a suite automatically. Opening the designer does plan the selected suite, so callers should invoke it only after an explicit user action. Investigation and advisor commands use the same selected folder. Until one is selected, those commands reject a multi-root window instead of choosing its first folder. Native test item controllers already belong to individual folders.

Explicit live graphics measurement

A companion may call perfchecker.runLandscapeLiveForWorkspace(folder.uri, qualitySlug) after the user chooses a Beautiful Landscape quality profile and requests a live measurement. Both arguments are required. The command checks the open local folder, the quality contract and perf/live_provider.jl before launch. The provider must write perfchecker-provider-result/1 JSON to PERFCHECKER_OUTPUT, using the explicit --quality=<slug> argument. It runs in the game project; PerfChecker runs in the folder's configured controller project. The controller must already contain PerfChecker.jl 1.0.0 or later. No package installation or suite factory runs automatically.

The provider's suite is etendu-beautiful-landscape-live. Its environment contains quality_profile, effective width and height, resolution_source, hardware.cpu_name and hardware.gpu_name (use unavailable if unknown), gpu_timing="unavailable", physical_presentation="unavailable", scene_sha256, scene_file_changed_during_run=false, and a timing_boundary naming SDL_SubmitGPUCommandBuffer. It supplies UTC started_at and finished_at ending in Z, and numeric millisecond observations in both landscape.cpu.* and landscape.submit_interval.* families. GPU duration and physical display FPS are not observations without corresponding instruments.

PerfChecker archives a verified perfchecker-run-bundle/1 at perf/results/live/run-<uuid>/ and opens its manifest. This evidence is separate from the CPU suite's suite-result.json and VS Code's Testing results. A failed, cancelled, stale, or incomplete provider does not produce a completed live bundle.

Development

Shared scenarios and investigations

PerfChecker: Open investigations opens the investigation workspace. Use Discover scenarios from tests first: discovery parses source files without running the project. Declared scenarios are executable; inferred test cases remain proposals. Prepare a proposal as an unsaved Julia draft, implement its ordinary factory and oracle, then adopt its declaration with parameters, fixtures and collectors. Adoption preserves existing catalog text and rejects stale discovery.

The sidebar, Julia CodeLens and Testing view expose the same declared cases. Select implementations independently, then measure or diagnose. The workspace shows timing samples, allocation summaries, separate qualifications and saved advice. JET/AllocCheck findings appear in Problems with source navigation and an action to open their evidence. These actions offer experiments; they do not apply speculative edits or performance budgets. Save Julia edits before running checks.

Settings for this workflow:

History is stored inside the workspace. Read JSON/Markdown, regenerate advice without running the target, or compare two saved measurements. Unmeasured configurations remain visible. Cancel waits for the investigation controller to exit after cleanup, with the same one-minute forced-stop fallback. Closing its panel requests cancellation too. Cancelling a local MCP request does not guarantee that a remote agent stops.

The existing suite editor, result viewer and bundle commands remain available. Projects such as Étendu3D keep their own pinned controller and workspace settings; this extension does not migrate or replace their environments. Test it with a separate extension development profile before choosing a deployment.

Extension host integration test (opt-in)

Prepare a controller containing PerfChecker.jl 1.0.0 or later, SharedScenarioDemo, BenchmarkTools, Chairmarks and JET. Then create a new scratch workspace:

node test/prepare-host.mjs /path/to/PerfChecker/examples/shared-scenarios /path/to/controller /path/to/new-workspace

After npm test, launch your official VS Code executable with --extensionDevelopmentPath=/path/to/this/repo, --extensionTestsPath=/path/to/this/repo/test/extension-host.cjs, --user-data-dir=/path/to/scratch-profile, --extensions-dir=/path/to/scratch-extensions, --disable-extensions, and the new workspace path. Set PERFCHECKER_HOST_RESULT to an output JSON path. The test exercises real Julia discovery, measurement, JET findings, CodeLens, Problems, evidence actions and cancellation. Do not use your normal editor profile.

Chat, implementation and recovery qualification

npm test includes the chat model and Git checkpoint tests, including dirty/staged state, ignored-but-staged files, binary/non-UTF8 byte preservation, drift, nested folder boundaries, split indexes, linked worktrees and diff limits. Browser tests are opt-in and use an existing Playwright/Chromium installation:

PERFCHECKER_PLAYWRIGHT_MODULE=/existing/playwright \
PERFCHECKER_BROWSER=/existing/chromium node test/advisor-chat.browser.cjs

The Linux native-host fixtures deliberately require a new sacrificial Git workspace named /tmp/perfchecker-chat-host-*, with an initial HEAD, .perfchecker-test-fixture containing sacrificial and a final newline, source.jl containing saved text, and untracked.txt containing original untracked and a final newline. Add an ignored file containing PRIVATE_NOT_ATTACHED and stage a version of source.jl before changing its on-disk content. In .vscode/settings.json, set absolute juliaExecutable, runnerProject and scenarioProject paths. The prepared controller must contain PerfChecker.jl 1.0.0 or later and HTTP; no package installation occurs in these tests. Use new profile/extensions directories and keep their paths for the second process. Workspace-trust disabling below belongs only to these fixtures.

PERFCHECKER_HOST_RESULT=/tmp/chat-host-result.json code \
  --extensionDevelopmentPath="$PWD" \
  --extensionTestsPath="$PWD/test/advisor-chat-host.cjs" \
  --user-data-dir=/tmp/chat-test-profile --extensions-dir=/tmp/chat-test-extensions \
  --disable-extensions --disable-workspace-trust /tmp/perfchecker-chat-host-FIXTURE

# After the first test succeeds, reuse that exact profile, extensions and workspace.
PERFCHECKER_HOST_RESULT=/tmp/chat-recovery-result.json code \
  --extensionDevelopmentPath="$PWD" \
  --extensionTestsPath="$PWD/test/advisor-chat-recovery-host.cjs" \
  --user-data-dir=/tmp/chat-test-profile --extensions-dir=/tmp/chat-test-extensions \
  --disable-extensions --disable-workspace-trust /tmp/perfchecker-chat-host-FIXTURE

The first test starts a local MCP mock and exercises actual VS Code/Julia conversation, privacy, tool errors, cancellation, isolated edits, reviewed apply and restore. The second reconstructs the proposal in a fresh extension host and applies/restores it without the MCP server or stored conversation.

test/agent-mcp-host.cjs instead requires a real responding agent. Create a fresh /tmp/perfchecker-agent-host-* Git fixture with the same marker/settings, and source.jl defining score(xs) = sum([x * x for x in xs]). Supply a new private PERFCHECKER_AGENT_BRIDGE_DIR=/tmp/perfchecker-agent-bridge-*, the output variable PERFCHECKER_HOST_RESULT, and launch it with --extensionTestsPath as above using its own profile. The bridge writes ready.json and then request-N.json; a separately operated agent reads each request and writes response-N.json containing {"text":"its actual reply"}. For the implementation request, that agent edits only the supplied checkout and runs its chosen validation. The host waits up to 600 seconds, then verifies unchanged advice-mode source, reviewed application, the Julia result, warm allocation reduction and restoration. The extension does not automatically connect an agent. The optional local Codex connector below offers an explicitly selected alternative to that manual bridge.

Inspect the result JSON, then remove the sacrificial workspace, profile, extensions, bridge and result files. Do not run these destructive fixture checks against an existing project or your normal editor profile.

Build locally

npm ci
npm test
npm run package -- --out perfchecker-vscode.vsix

npm test compiles TypeScript and runs the model/contract tests. The generated dist directory and VSIX archives are intentionally not committed.

Marketplace publication

Publish the stable extension only after PerfChecker.jl 1.0.0 is available in Julia's General registry. Build and test the exact VSIX before publishing it.

The immutable Marketplace identity is mirage-interactive-fr.perfchecker-vscode. Repository extraction therefore does not change extension settings, commands, or installations.

For a manual stable release:

npx vsce login mirage-interactive-fr
npx vsce publish --packagePath .\perfchecker-vscode-1.0.0.vsix

Publishing requires a free Microsoft identity and Marketplace publisher, not a paid Azure subscription. Never commit a publication token. The future release workflow can use Marketplace identity-based publishing after its identity and publisher permissions have been configured.

License

MIT. See LICENSE.

Optional MCP advice

Open PerfChecker: Configure advisor and manage models for the guided panel. Discover and configure an MCP HTTP advice tool in text mode, then open PerfChecker: Chat with performance advisor. Nothing is generated on opening. Source files are not attached automatically; typed messages and explicitly selected bounded evidence are sent when requested. Replies remain unverified advice.

Implementation requires a separate explicit tool configuration in the chat's Implementation tab. The supplied checkout is not an operating-system sandbox: use a trusted agent that respects the path and can access the local filesystem. Preparation creates a checkpoint; application requires a separate reviewed action. The extension uses the controller's public chat and implement commands, which are supplied by PerfChecker.jl 1.0.0 or later; an older controller fails visibly instead of providing an implementation fallback. The extension does not install an agent backend. Its explicit Connect Codex CLI action starts an authenticated installed CLI on demand through a temporary local MCP endpoint; generic external MCP agents remain supported.

See the canonical MCP guide for provider configuration, credentials, supported revisions, transmission, cancellation and recovery. Stdio and OAuth login are not supported by this adapter.

Connect an installed Codex CLI

Authenticate your CLI using codex login in your own terminal. Set perfchecker.codexExecutable if codex is not on VS Code's PATH, open Chat, then choose Connect Codex CLI. Version, supported flags and login status are checked without starting a model turn. This requires --no-daemon, --ignore-user-config and --ignore-rules, in addition to the standard exec sandbox/ephemeral/output flags; Codex CLI 0.159.2 was qualified. Unsupported executables fail explicitly. Windows requires the native .exe; npm .cmd/.bat launchers are unsupported.

The connector uses the existing account and default CLI model. Custom user profiles, model/provider configuration, MCP servers, hooks and rules are not inherited. Workspaces or implementation copies containing project .codex configuration are refused. CLI sandbox support depends on the installation and platform; a copied checkout does not itself provide an operating-system sandbox. The agent can inspect files under its working directory; your configured model provider processes the requested context and ordinary CLI usage charges apply.

Advice uses read-only; implementation uses workspace-write only in a canonical temporary PerfChecker checkout. Both run without the shared Codex daemon. The loopback endpoint and its automatic authentication token live only for this editor session. Disconnect Codex restores your previous provider settings; reconnect after reloading the editor. Git proposals and checkpoints remain recoverable without the agent connection. Never save the temporary endpoint.

After compiling, reproduce the opt-in named-agent qualification in a sacrificial Node/Git workspace with your already authenticated CLI:

PERFCHECKER_TEST_CODEX=/path/to/codex node --test test/codex-real.test.mjs

This sends real model requests and verifies advice, isolated editing, Node semantics, diff, apply, byte-identical restoration and cancellation after a turn starts. It removes its temporary files. The default tests use a sacrificial CLI to verify errors, limits, process-tree termination and authentication separately.

The complete opt-in editor/controller qualification uses a prepared controller:

PERFCHECKER_TEST_CODEX=/path/to/codex \
PERFCHECKER_TEST_CONTROLLER=/path/to/prepared/controller \
PERFCHECKER_TEST_JULIA=/path/to/julia \
PERFCHECKER_VSCODE_EXECUTABLE=/path/to/code node test/run-codex-host.mjs

It opens an isolated editor profile and sacrificial Git workspace, checks the real Julia MCP conversation and reviewed changes, then confirms that disconnect restores an existing saved provider. It uses the account's model quota and removes its fixtures.
