Kigumi

Kigumi is the 3D viewer and CAD environment for Kumiki, an open-source programmatic CAD library for designing timber-framed structures and woodworking joinery in Python.

• Website & Downloads: kumiki.build
• Try in your browser: kumiki.build/try
• Documentation & API Reference: kumiki.build/docs
• GitHub Repository: minimapletinytools/kumiki

Prerequisites

To use the Kigumi VS Code extension, you need:

• VS Code (or Cursor / VSCodium) with the Kigumi extension installed
• uv or Python so Kigumi has something to bootstrap the Python virtual environment.
  • Preferred: install uv ahead of time: https://docs.astral.sh/uv/getting-started/installation/
  • Auto-bootstrap fallback: Kigumi tries python3.13, then python3/python (or py -3.13/py -3 on Windows) and installs uv into a throwaway virtual environment at .kigumi/uv-bootstrap/

Kigumi does NOT require pre-installed packages. It handles dependency setup in a project-local virtual environment automatically.

Initialization

Kigumi is built around the VS Code workspace (i.e. a folder) where all your Kumiki project files live.

To initialize a project, open a folder in VS Code that will be your workspace. Then open the Kigumi sidebar and click Initialize Project. This generates an example frame (my_cute_frame.py), AI agent authoring instructions (.kigumi/docs/), and a project settings file.

The sidebar also checks for Kumiki updates so you can update to the latest version.

The sidebar contains a project file explorer. Click on a frame to open it in the Kigumi viewer.

You can also use the "Kigumi: Open Current File in Viewer" command from the command palette (Cmd/Ctrl + Shift + P) to quickly open the current file.

The sidebar also contains a pattern book explorer which provides built-in examples of joints and structures you can build with Kumiki. You can view the source or duplicate any pattern into your workspace.

Features

Once you open a frame, Kigumi renders an interactive 3D view alongside your Python code:

• Live 3D inspection: Select individual timbers, faces, edges, or joint features, and walk the CSG cut tree.
• X-ray and section views: Inspect internal mortises, tenons, pegs, wedges, and splines.
• Parametric controls (Kiwari): Adjust dimensions, angles, and counts live in the parameters panel.
• 2D shop drawings & measurements (beta): View generated or coded elevation and piece drawings, add manual point-to-point measurements (M), and export sheets as PNG.
• Assembly timeline (beta): Scrub through the computed assembly/disassembly sequence to verify how joints slide together.
• CAD export: Export frames and timbers to STEP, STL, OBJ, and 3MF.

Details

Runtime Contract for Kumiki files

When Kigumi imports a Python module, it discovers functions decorated with @frame (or @pattern for pattern books). For older files, it also falls back to resolving:

1. @frame-decorated functions returning a Frame
2. Module-level example
3. build_frame() function
4. Module-level patternbook

example may be either:

• A frame-like value
• A callable returning a frame-like value
• A patternbook

If no supported entry point exists, the viewer returns an error.

Project Discovery

Kigumi resolves project roots the same way for both "Render Kigumi" and "Initialize Current Project":

1. Start from the active Python file (when available) and walk upward.
2. If a folder contains kumiki/, treat it as local development mode (not relevant unless you are developingon kumiki)
3. If a folder contains .kigumi/kumiki.yaml, treat it as a normal Kigumi project.
4. If no marker is found, fall back to the workspace root (or file parent) and create .kigumi/kumiki.yaml.

This lets you open a single Python file and still bootstrap a runnable Kigumi project without manual setup first.

First Run: Automatic Python Environment Setup

On first render in a project, Kumiki bootstraps a project-local environment automatically:

1. Finds project root by walking upward from the target file
2. Ensures uv is available (uses installed uv when present -- including the usual install locations that a GUI-launched editor's PATH can miss -- otherwise bootstraps it into .kigumi/uv-bootstrap/)
3. Creates .venv with uv venv --python 3.13 .venv
4. Installs required dependencies via pip:
   • Local dev checkout: pip install -e <projectRoot> (editable kumiki)
   • Non-local project: pip install kumiki (from PyPI)

• Core packages: sympy, numpy, trimesh, manifold3d

5. Writes .kigumi/kigumi.yaml with Python path and setup metadata

On later runs, Kigumi reuses the configured interpreter from .kigumi/kigumi.yaml when available.

Note: If neither uv nor a working bootstrap Python launcher is available, initialization will fail with instructions to install uv manually.

Pattern Browsing

Kumiki scans three sources:

• local project patterns in <projectRoot>/patterns
• shipped patterns bundled with kumiki
• patterns bundled with any other python dependency in your project

License

Kigumi is under the Elastic License 2.0. You may use, modify and redistribute it freely, including commercially, but you may not offer it to others as a hosted or managed service. Versions up to and including 0.7.2 were released under MPL-2.0 and remain so.

kumiki, the Python library kigumi runs, stays under the Mozilla Public License 2.0. Third-party files bundled with kigumi, such as those in webview/vendor/, keep their own licenses.
