ChordPro VSCode

Write, rehearse, and perform your songs — without leaving VSCode.

Available on both the VS Code Marketplace and OpenVSX (for VSCodium, Gitpod, and other open-source VSCode distributions).

ChordPro VSCode turns VSCode into a full-featured songwriting and performance environment. Write .cho files with rich auto-completion, visualise chord fingerings instantly, scroll through your setlist hands-free, and generate print-ready PDFs — all from the editor you already use.

Highlights

GIF Showcase

Performance View

Chord Diagram Hover — source file & HTML preview

Chord Builder

Chord Reference Panel

Tab Editor

Song Library & Setlist

Grid Editor

Quick Start

1. Install the extension and open (or create) a .cho file — syntax highlighting activates automatically
2. Press Ctrl+Alt+P to open the Performance View (no CLI needed), or Ctrl+Shift+V for the PDF preview
3. Press Space to start scrolling — use the control bar to adjust speed, transpose, or jump to a section

PDF rendering requires the ChordPro CLI installed and on your PATH. For the ChordPro format itself, see the official documentation.

Commands & Shortcuts

Performance & Preview

Auto-scroll controls (inside the preview)

Editing & Writing

Song Library & Setlist

Setlist navigation:

Templates & Configuration

Feature Details

Chord Diagram Hover

Hover over any [chord] token — in your .cho source file or in the Performance View — to see an SVG fretboard diagram popup.

• Built-in library of ~100 chords (all roots × major, minor, 7th, maj7, sus, dim, aug, 6, 9, 11, 13, m7b5, mmaj7, 69, and more)
• {define:} blocks in the file take priority over the built-in library
• Chords saved via the Chord Builder also override the built-in defaults
• The hover tooltip also shows how many times the chord appears in the song

Performance View

Press Ctrl+Alt+P to render the song as HTML and open it in a clean, distraction-free performance view. No ChordPro CLI needed.

• Tempo-based speed — add {tempo: 120} to your file; scroll speed is calculated automatically so the song passes at the right pace. A ♩ button snaps back to tempo speed at any time.
• Tap tempo — tap T repeatedly to set BPM from your rhythm; averaged over the last 8 taps.
• Metronome — M key or ♪ button; Web Audio click track locked to the current BPM (from {tempo:} or tap tempo); beat 1 accented.
• Live transpose — ♭ / ♯ buttons shift all chord names in the view without touching the source file.
• Section jump — § button opens a numbered list of all sections; click to scroll smoothly.
• Lyrics-only mode — L key hides chord symbols while preserving layout.
• Auto-reload on save — the preview refreshes automatically every time you save, restoring scroll position.
• Save as HTML — 💾 button saves a fully self-contained _preview.html to disk; all controls work in any browser.

Song Library & Setlist

Open the Song Library panel in the activity bar (music note icon).

1. Click 📂 to set your library folder — all .cho files in subfolders are found automatically
2. Songs are listed by title (from {title:}) with the artist as a subtitle
3. Ctrl+click or Shift+click to select specific songs
4. Click ▶ Play as Setlist to open the selected songs (or all songs if none are selected) in the Setlist Preview
5. In the Setlist Preview, use PageUp / PageDown or the ◀ ▶ buttons to navigate; enable Auto to advance automatically at the end of each song
6. The setlist can be saved as a standalone HTML file with the 💾 button

Chord Reference Panel

Open from the ChordPro Library activity bar icon — the Chord Reference view appears below the Song Library.

Three tabs:

Interacting with chord cards:

• Click a card to insert [CHORD] inline at the cursor; if the chord has no {define:} in the file yet, one is inserted automatically in the header
• Ctrl+click to insert {chord: CHORD} (diagram directive) instead
• Right-click for a context menu with both insert options
• ◀ ▶ arrows to cycle through multiple voicings of the same chord
• × button (hover over a card) to delete a voicing — choose to remove just that voicing or all voicings of the chord
• Search bar filters all tabs by chord name (fuzzy matching)
• A↕ / #↕ toggle (My Chords tab) to sort alphabetically or by frequency of use
• Hover tooltip shows which files the chord was found in

My Chords tracking — every {define:} you write or save is tracked automatically. Voicings from {define:} blocks, the Chord Builder, and the built-in library are merged and deduplicated per chord name. Saving a file updates My Chords immediately.

Chord Builder

Open with Ctrl+Alt+B or from the panel at the bottom.

• Click strings and frets to place fingers on the fretboard; drag across strings to place the same fret on multiple strings
• Auto-detect — the chord name fills in automatically as you place fingers; fret dots show the note name (e.g. C#) or the interval relative to the root (1, m3, 5, b7…) — toggle with the Notes / Intervals switch
• Smart voicing memory — every chord you insert is remembered as a shape. Next time you play the same fingering (or a barre-transposed version), your name appears as a ★ suggestion. Click × to forget a shape.
• Name validation — any insert button validates the chord name first:
  • Unknown name: suggests the closest recognized chord names; click one to re-validate instantly
  • Note mismatch: lists the notes the name requires but the voicing is missing
  • Wrong root: if the shape is a valid voicing of the same chord quality on a different root (e.g. you typed Cmaj6 but the fingering is Dmaj6), the correct root is suggested automatically
• Audio playback — click 🔊 (or press P) to hear the chord: strings are plucked one by one from low E to high e, then a quick full strum rings out (Karplus-Strong synthesis, no external library)
• Fingering mode — toggle to assign finger numbers (1–4) by clicking the fret dots
• Inline — inserts [CHORD] at the cursor; {chord:} inserts the directive and adds a {define:} block; {define:} adds the define block only
• ↺ Reset — clears the fretboard; −1 / +1 shift all frets down or up by one semitone; Ctrl+Z / Ctrl+Shift+Z undo/redo fret changes
• Open in Builder — hover over any [chord] or {define:} line and click the link to load that chord's fingering directly into the Builder
• Saved chords appear at the top of the [ auto-completion list and in chord hover diagrams

Tab Editor

Open with Ctrl+Alt+T.

• Click any cell to select it, then type the fret number (0–24)
• Backspace clears a cell; Enter / → advances to the next column; ↑ / ↓ moves between strings
• + Column inserts a new column after the selected position
• | Bar inserts a bar line; Delete last removes the rightmost column; Clear empties all values
• A live tab preview is shown below the grid
• Insert tab wraps the result in {start_of_tab} / {end_of_tab} and inserts it at the cursor position in the source file

Grid Editor

Open with Ctrl+Alt+G.

Build {start_of_grid} chord progression grids visually:

• Each row is a line of the grid; each bar has one input per beat
• Beat 1 (primary chord) is larger; beats 2–4 are smaller — visually distinct
• Click a cell (or use Tab / Shift+Tab / arrow keys) to select it, then type the chord name
• Song chords palette — all [chord] tokens found in the open song are shown as buttons at the bottom; click any to fill the selected cell and auto-advance to the next beat
• + Line / − Last line add or remove rows; + Bar / − Last bar add or remove columns across all rows
• Time selector sets the time signature (4/4, 3/4, 2/4)
• First row starts with ||, last row ends with ||; all others use single |; empty beats render as .
• Live preview updates as you type
• Insert grid wraps the result in {start_of_grid} / {end_of_grid} and inserts it at the cursor

Chord hover in grids

Chord names inside {start_of_grid} blocks are fully interactive — both in the source file and in the HTML preview:

• Source file — chord names are syntax-highlighted in green (same as [chord] tokens); hover for the SVG diagram popup
• HTML preview — chord names are bold and colored; hover for the diagram tooltip
• Custom chords defined via {define:} in the file are recognized with their fingering diagram

Transposing

Live transpose (preview only): use the ♭ / ♯ buttons in the Performance View or Setlist preview to shift chord display without modifying the source.

Permanent transpose (source file): command palette → Transpose Chords — pick a musical interval or enter a custom number of semitones. Updates all [chord] tokens and {key:} directives. Undoable with Ctrl+Z.

For PDF only: add {transpose: 2} in the file; the CLI applies it at render time without changing the source (note: the HTML preview ignores this directive).

Syntax Highlighting

.cho, .chordpro, and .chopro files get full syntax highlighting automatically: chord tokens [Am], directives {title:}, section markers, comments, and rendering parameters are all coloured distinctly.

Auto-completion

• Type { → suggestions for all ChordPro directives; section pairs ({start_of_chorus} etc.) insert the closing tag automatically with the cursor placed between them
• Type [ → chord suggestions; your saved and defined chords appear first
• Rendering parameters (# {config = ...}, etc.) have their own completions in the first 25 lines

Rendering Parameters (PDF config)

Add these in the first 25 lines of your .cho file to control how the PDF is generated:

# {config = "modern1"}
# {options = --no-chord-grids}
# {suffix = "chords_only"}
# {output = mysong_out.pdf}

Three ways to configure:

• Auto-completion — type # { in the first 25 lines for a dropdown of parameters; config offers a preset picker
• Hover tooltip — hover over a # {key = ...} line to see a description, valid values, and common CLI flags
• ⚙ CodeLens — click the ⚙ Configure rendering button above line 1 for a guided step-by-step UI

User Config Library

The config picker in ⚙ Configure rendering shows three tiers:

• My configs — your personal .json files, stored in a folder of your choice
• Extension presets — configs bundled with the extension (e.g. two columns)
• ChordPro built-in presets — modern1, dark, nashville, etc.

Manage your personal configs via the ChordPro: … commands in the palette:

The folder defaults to VS Code's global storage and is created automatically on first use.

Chord Analyzer (Oolimo)

Press Ctrl+Alt+A to open Oolimo in a VSCode side panel — look up any chord, explore voicings, and analyse progressions without leaving the editor.

Requirements

PDF rendering requires the ChordPro CLI installed and on your system PATH.

The Performance View, Song Library, Setlist, Chord Builder, Chord Reference, Tab Editor, and Chord Analyzer all work without the CLI.

Useful Links

• VS Code Marketplace listing
• OpenVSX listing
• ChordPro official site & documentation
• ChordPro directive reference
• Oolimo chord analyzer
• Songcraft.io — BPM, autoscrolling, visual editor, chord progressions
• Full Changelog

Suggestions & Feedback

Have an idea, found a bug, or want to request a feature? Open an issue on GitHub — all suggestions are welcome!

Enjoy your playing!
