ManulMcpServer

Bridge between GitHub Copilot and deterministic browser automation. ManulMcpServer is a VS Code extension that exposes ManulEngine as a native MCP server — giving Copilot Chat (and any MCP-compatible agent) the ability to drive real browsers, run .hunt test scripts, and generate automation from natural language, all inside your existing development workflow.

Status: Alpha. Actively developed alongside ManulEngine. APIs and file formats may evolve.

Why ManulMcpServer

• Deterministic automation inside Copilot Chat. Copilot gains browser control backed by ManulEngine's heuristic element resolver — no LLM required for element targeting.
• Natural language to executable DSL. Say "log in to SauceDemo and verify the inventory page" — the server normalizes it into .hunt steps, runs them, and returns a replayable script.
• Editor-first authoring. Syntax highlighting, IntelliSense, hover docs, inline diagnostics, and one-click run for .hunt files.
• CI/CD ready. The same .hunt scripts that run in Copilot Chat can run headless in your pipeline with manul <path>.
• Explainable and auditable. Every action is a readable DSL line, every element resolution scores 0.0–1.0 with an explain mode — no black-box clicks.

Quick Demo

1. Write a .hunt file

@context: Login flow smoke test
@title: SauceDemo Login

STEP 1: Login
    NAVIGATE to 'https://www.saucedemo.com/'
    VERIFY that 'Username' is present
    Fill 'Username' field with 'standard_user'
    Fill 'Password' field with 'secret_sauce'
    Click the 'Login' button
    VERIFY that 'Sauce Labs Backpack' is present

DONE.

2. Run from the editor

Click the ▷ button in the editor title bar, or press Ctrl+Shift+R (Cmd+Shift+R on Mac).

3. Run from Copilot Chat

Open Copilot Chat and use the MCP tools directly:

# Run a single step
@manul Run step: NAVIGATE to 'https://www.saucedemo.com/'

# Run a full goal — Copilot calls manul_run_goal under the hood
@manul Log in to SauceDemo with standard_user / secret_sauce
       and verify the inventory page loads

# Scan the page after navigation
@manul Scan the current page for interactive elements

Copilot uses manul_run_step for individual actions, manul_run_goal for multi-step flows, and manul_scan_page to discover page elements. After a goal run, ask Copilot to save the generated .hunt file — it calls manul_save_hunt to write it to tests/.

Integration Patterns

Copilot Chat (primary workflow)

ManulMcpServer registers itself as an MCP server automatically. Copilot Chat discovers the Manul tools and can:

• Run individual DSL steps or natural-language actions (manul_run_step)
• Execute multi-step goals and produce replayable .hunt files (manul_run_goal)
• Read page content and discover interactive elements (manul_scan_page, manul_read_page_text)
• Validate and normalize DSL without execution (manul_validate_hunt, manul_normalize_step)

CI/CD pipelines

.hunt scripts generated via Copilot are plain text — commit them to your repo and run headless in CI:

pip install manul-engine==0.0.9.28
playwright install chromium
manul tests/ --headless --html-report

The CLI produces exit code 0 on pass, 1 on failure, and optionally generates a self-contained HTML report.

Other MCP clients

Any MCP-compatible agent or client can connect to ManulMcpServer's stdio bridge. The server advertises 11 tools with full JSON Schema input definitions, making integration straightforward for custom agent harnesses, product dashboards, or internal tooling.

Installation

1. Install the extension

code --install-extension manul-mcp-server-0.0.7.vsix

Or install from the VS Code Marketplace.

2. Install runtime dependencies

pip install manul-engine==0.0.9.28
playwright install

3. Reload VS Code

Ctrl+Shift+P → Developer: Reload Window

After reload, ManulMcpServer appears in the MCP Servers panel and Copilot Chat gains the Manul tools automatically.

Prerequisites

• VS Code 1.107+
• Node.js on PATH (the managed MCP entry launches the bridge with node -e)
• Python 3.10+ with manul-engine installed
• Playwright browsers (playwright install)

Workspace .venv detection: Open the target workspace folder first, or set manul.pythonPath to the exact interpreter path.

Configuration

Open Settings (Ctrl+,) and search for manul:

Example settings.json:

{
  "manul.pythonPath": "/home/user/project/.venv/bin/python",
  "manul.headless": true,
  "manul.executablePath": "/opt/my-electron-app/app"
}

Two execution paths: MCP tools (manul_run_step, manul_run_goal, etc.) use the bundled Python runner directly — no server needed. Editor title bar Run commands use the ManulEngine HTTP API at manul.apiBaseUrl (start it with manul serve).

MCP Tools Reference

All tools use synchronous request/response. The browser session is persistent — it opens on first use and stays alive across tool calls for inspect/retry.

Troubleshooting

Ecosystem

ManulMcpServer is one layer of the Manul automation stack:

Keyboard Shortcuts

Active when a .hunt file is focused in the editor.

What's New

0.0.8

• Compatibility: Synced embedded DSL contract metadata to ManulEngine 0.0.9.29.
• DSL: Added REPEAT N TIMES:, FOR EACH {var} IN {collection}:, and WHILE condition: loop commands — validation, syntax highlighting, completion, snippets, and agent contract.
• Docs: Updated contracts/MANUL_MCP_AGENT_CONTRACT.md and .github/copilot-instructions.md with loops reference.
• Release: Updated extension/package versioning to 0.0.8.

0.0.7

• Compatibility: Synced embedded DSL contract metadata to ManulEngine 0.0.9.28.
• DSL: Added IF / ELIF / ELSE conditional branching — validation, syntax highlighting, completion, snippets, and agent contract.
• DSL: Updated canonical command labels to ALL UPPERCASE per engine casePolicy (CLICK, FILL, TYPE, SELECT, CHECK, UNCHECK, DRAG).
• Docs: Updated contracts/MANUL_MCP_AGENT_CONTRACT.md and .github/copilot-instructions.md with conditional branching reference.
• Release: Updated extension/package versioning to 0.0.7.

0.0.6

• Compatibility: Synced embedded DSL contract metadata to ManulEngine 0.0.9.27.
• Docs: Added contracts/MANUL_MCP_AGENT_CONTRACT.md — machine-readable contract for AI agents consuming ManulEngine via MCP (tool schemas, DSL reference, workflow guidelines, response shapes, security constraints).
• Docs: Updated .github/copilot-instructions.md with complete v0.0.9.27 DSL reference including OPEN APP, UPLOAD, MOCK, VERIFY VISUAL, strict placeholder/value assertions, CALL PYTHON, SCAN PAGE, DEBUG VARS, metadata headers (@import:, @export:, @data:, @schedule:), and hook blocks ([SETUP]/[TEARDOWN]).
• Release: Updated extension/package versioning to 0.0.6.

0.0.5

• Compatibility: Synced embedded DSL contract metadata to ManulEngine 0.0.9.26.
• DSL: Added support for @import:, @export:, and USE in validation, completion, hover docs, snippets, and syntax highlighting.
• Desktop automation: Added manul.executablePath and propagated MANUL_EXECUTABLE_PATH through the MCP bridge into the bundled Python runner for OPEN APP flows.
• Release: Updated extension/package versioning to 0.0.5.

0.0.4

• Stability: Fixed PythonRunner ensureProcess() race condition — concurrent callers no longer spawn duplicate processes.
• Stability: Browser now stays alive on step failure for inspect/retry instead of closing the session.
• Security: Workspace-jail path validation added to Python save_hunt handler and extracted into shared pathValidator.ts.
• Performance: Page scan now runs only on the last step or on failure, not after every step.
• Performance: Shadow-root traversal uses targeted selector instead of querySelectorAll('*').
• Maintainability: Centralized config defaults into src/config/defaults.ts — no more duplicated normalizers.
• Maintainability: Shared DSL line iterator (src/dsl/parser.ts) eliminates duplicated hook-block state machines.
• DX: Hover provider rewritten as data-driven loop from contract — no more hardcoded if-branches.
• DX: Qualifier suggestion regex derived from contract interactionMode instead of hardcoded list.
• DX: Keyboard shortcuts for Run Hunt File (Ctrl+Shift+R) and Run Step (Ctrl+Shift+Enter).
• DX: Added manul_read_page_text MCP tool for reading visible page text.
• Testing: Added vitest with 67 unit tests covering validator, builder, parser, and config defaults.
• Updated DSL contract to v0.0.9.21.

0.0.3

• Managed user-scope mcp.json sync on install, activation, settings change, and uninstall.
• User-scope MCP bootstrap now resolves the latest installed extension directory via node -e instead of a stale versioned script path.
• Documentation updated to reflect external runtime requirements and workspace .venv behavior.

License

Apache-2.0
