Next.js Component Boundary Visualizer

Visualizes server, client, and universal components with explorer badges, status bar indicators, editor decorations, JSX client boundary markers, and server component composition markers in Next.js App Router projects.

Screenshots

Explorer Badges and Status Bar

JSX Client Boundary Markers

Server Component Composition Markers

Extension ID: vscode-nextjs-component-boundary-visualizer

You can install this extension by searching for "Next.js Component Boundary Visualizer" or using the extension ID above in the VS Code Extensions view.

Features

• High‑precision static analysis: Infers server, client, and universal(shared) components using the TypeScript type checker and a dependency graph.
• Explorer Badges: Shows icons for client(⚡️) and universal(♾️) components in the file explorer.
• Status Bar: Displays the type of the currently open component (client, server, universal).
• JSX Client Boundary Markers: shows a subdued end‑of‑line indicator (⚡️ Client Boundary) on lines that render Client Components across a server-to-client boundary.
• Server Component Composition Markers: shows an end‑of‑line indicator (🌐 Server in Client) on lines where a Server or Universal Component is passed as props or children to a Client Component. This clarifies that the component executes on the server despite being visually nested inside a Client Component in JSX.
• Line Decorations: Adds a colored line and icon to the editor for client and universal components.
• Automatic Updates: Watches for file changes and updates the visualization in real time.

Requirements

• VS Code 1.100.0 or later
• A Next.js project using the App Router (TypeScript projects are supported; all .ts and .tsx files are analyzed for component boundaries, except for config, d.ts, test, spec, stories, and __mocks__ files)
• A tsconfig.json file must exist at the project root (or specify its path via extension settings)

Usage

Open a Next.js App Router project in VS Code. The extension will automatically analyze your files and display component type information in the explorer, status bar, and editor.

If your tsconfig.json is not at the project root, set the path in your VS Code settings:

"nextjsComponentBoundaryVisualizer.tsconfigPath": "path/to/your/tsconfig.json"

Extension Settings

• nextjsComponentBoundaryVisualizer.tsconfigPath: Path to tsconfig.json (absolute or workspace-relative). If empty, <project root>/tsconfig.json is used.
• nextjsComponentBoundaryVisualizer.enableLineIcon: Enable/disable the icon at the beginning of the line. Defaults to false.
  • Note: The JSX Client Boundary end‑of‑line indicator is always shown when applicable.
• nextjsComponentBoundaryVisualizer.exclude: List of glob patterns to exclude files or directories from analysis and decorations. Patterns are workspace‑relative.
  • Examples:

    {
      "nextjsComponentBoundaryVisualizer.exclude": [
        "**/*.want-to-exclude.tsx",
        "packages/ui/src/want-to-exclude/**"
      ]
    }


  • Note: Some files are excluded by default (e.g., config files, *.d.ts, tests, specs, stories, and __mocks__). Use this setting to add additional project‑specific exclusions.

Icons

Component Environment Icons

These icons represent the execution environment of a component file, appearing in the file explorer, status bar, and as line decorations:

• Client Component: ⚡️
• Universal Component: ♾️
• Server Component: No icon (server components are the default in Next.js App Router and do not display a badge)

JSX Render Tree Markers

These end‑of‑line markers appear on JSX lines to clarify execution environment relationships:

• Client Boundary (⚡️ Client Boundary): A Client Component rendered from a Server Component context.
• Server in Client (🌐 Server in Client): A Server or Universal Component passed as props or children to a Client Component — renders on the server despite appearing nested in JSX.

Note: visual decorations are applied only to .tsx files (component files). Plain .ts files are analyzed for dependency/type classification but are not decorated.

Known Issues

• Only supports projects using the App Router structure.
• Does not support legacy Next.js pages directory.
• Only .ts and .tsx files are analyzed for component boundaries (excluding config, d.ts, test, spec, stories, and __mocks__ files; .js/.jsx are not supported).
• Visual decorations (explorer badges, status bar, line icons, and JSX Client Boundary markers) are shown only for .tsx files. .ts files are excluded from icon display because they are not React component files.
• The extension will not work if tsconfig.json is missing or misconfigured.
• Does not analyze dynamic imports; only static imports and re-exports are considered for dependency graph and component type classification.
