You started a Claude Code session and walked away. The agent is reading files, running commands, making edits. Five minutes later you come back — and you have no idea what it did.

TraceBack fixes that. It hooks directly into Claude Code's hook system and streams every tool call into a live, scrolling action timeline in your VS Code sidebar — with anomaly detection that catches loops, error storms, and silent stalls while the agent is still running.

"What did my agent just do? Why is it stuck? Did it loop? What file did it touch?" — answered in real time, without leaving your editor.

Demo

Why TraceBack?

Most "agent observability" tools (Langfuse, Arize, LangSmith) ship cloud dashboards meant for production traffic. TraceBack is the opposite: local-first, in-editor, zero-setup, real-time, focused on the dev loop.

Quickstart

# 1. Clone & install
git clone https://github.com/madiyarzm/TraceBack
cd TraceBack
npm install
cd webview && npm install && cd ..

# 2. Build
npm run compile && npm run build:webview

# 3. Open in VS Code and press F5
#    (launches the Extension Development Host with TraceBack loaded)

Click the TraceBack icon ($(pulse)) in the activity bar, then run any Claude Code session in your terminal. Tool calls will start appearing in the sidebar as they happen.

How it works

TraceBack injects lightweight curl hooks into ~/.claude/settings.json on activation. Every time Claude Code fires PreToolUse, PostToolUse, PostToolUseFailure, or Stop, the hook payload is POSTed to a local HTTP server on localhost:7777. The extension parses those events, builds a session timeline, and streams updates into a React webview rendered in the VS Code sidebar.

Claude Code CLI
    │  PreToolUse / PostToolUse / PostToolUseFailure / Stop hook fires
    │  curl → POST localhost:7777/event
    ▼
TraceBack server  (Node.js, in-process)
    │  parses payload → TraceEvent
    ▼
TraceStore  (in-memory session state) ──► AnomalyDetector  (pure, tail-only, O(1))
    │  onDidUpdate event
    ▼
Webview  (React + Vite)
    └─ live timeline + metrics odometer, rendered in the sidebar

No sockets between extension and webview — just VS Code's postMessage. No polling. Zero latency between a tool call firing and the card appearing in the timeline.

Features

Live action timeline

Every tool call renders as a card — pending → success / error — in real time. Click any card to inspect the full tool input and output inline. File edits (Edit, Write, MultiEdit) render as a Git-style line diff.

Anomaly engine

A pure, tail-only detector that re-evaluates on every event in O(1). Catches three failure modes automatically:

• Repeater — 4 identical tool calls in a row (the agent is stuck in a loop).
• Error thrash — 3 consecutive failed tool calls (the agent is making things worse).
• Silent stall — a tool call pending for more than 60 seconds with no response.

Anomalies fire a native VS Code notification (even with the sidebar hidden), permanently tag the implicated cards, and count on the odometer. Live alerts self-clear the moment the condition stops holding — the evidence trail doesn't.

Breakpoints for running agents

Hit ⏸ pause and the agent freezes at its next tool call — TraceBack holds the hook's HTTP response open, exactly like a breakpoint in a debugger. Inspect the timeline, then ▶ resume… or type into the redirect box:

"Stop trying to install that package — use the native library instead."

Your message is delivered into the agent's context as the reason its call was denied. The agent reads it and changes course, mid-run. Human-in-the-loop steering for black-box agents.

Tripwires

Policy rules that protect every session at once, no human watching:

"traceback.tripwires": [
  { "tool": "Bash",       "pattern": "rm -rf|sudo ", "reason": "Destructive commands are blocked." },
  { "tool": "Edit|Write", "pattern": "\\.env|prod/", "reason": "Don't touch secrets or prod config." }
]

A matching call is denied before it executes via Claude Code's hook decision protocol, the agent is told why, and you get a notification. The CLI asks per session, interactively; tripwires are fleet-wide policy.

Multi-agent fleet view

Run multiple Claude Code sessions in parallel? TraceBack lists all of them in a dropdown with live status badges (🟢 running, ⚪ done, 🔴 anomalous). Background anomalies surface as a pulsing pill next to the dropdown — you see a failure in agent #3 even while watching agent #1.

Real token & cost metrics

Pulls actual token usage from the Claude Code transcript (input + cache_read + cache_creation + output) instead of estimating. Falls back to a character-based heuristic when the transcript isn't reachable.

Narrative Engine (optional)

Connect a Groq or local Ollama instance and TraceBack generates a 1–2 sentence plain-English summary of the session after each tool call. "It's been reading config files and is about to make its first edit."

Chat assistant (optional)

Ask questions about the current session directly in the webview. "Why did the agent fail?", "What files were touched?", "Is this loop intentional?" — answered with the timeline already loaded as context.

Curated payloads & copy-everything

Expanded cards show purpose-built views instead of raw dumps: Bash commands with exit pills, file ops with line/byte metrics, web calls as chips, plus a deterministic one-line outcome (→ Error: Exit code 1 · npm error Missing script). Raw input/output stays one click away — and everything is copyable: single outputs, single commands, or the entire session as a markdown report (MD button) ready to paste into a GitHub issue or hand to a fresh agent session as context.

Export

Snapshot the current timeline as a PNG or dump the raw session JSON — useful for bug reports, post-mortems, and sharing with teammates.

Auto hook management

TraceBack surgically adds and removes only its own entries in ~/.claude/settings.json — never touches unrelated config.

Requirements

Installation

From source (recommended while pre-release)

git clone https://github.com/madiyarzm/TraceBack
cd TraceBack
npm install && cd webview && npm install && cd ..
npm run compile && npm run build:webview

Open the repo in VS Code and press F5 to launch the Extension Development Host. To install it permanently:

npm run package                           # produces traceback-0.1.0.vsix
code --install-extension traceback-0.1.0.vsix

Commands

Configuration

All settings live under traceback.* in VS Code settings.

Enabling the Narrative Engine

The AI helper (plain-English summary + sidebar chat) is opt-in and supports two backends. You can configure it via VS Code settings or a local .env file at the repo root — whichever is easier.

Option A — Groq (cloud, free tier, recommended)

1. Sign up at console.groq.com — it's free, no credit card required.

2. Open the menu in the top-right corner → API Keys → Create API Key.

3. Copy the generated key (starts with gsk_…).

4. Drop it into a .env file at the repo root:

   cp .env.example .env
   # then edit .env and paste your key


   # .env
   GROQ_API_KEY=gsk_your_key_here
   # GROQ_MODEL=llama-3.1-8b-instant   # optional override


5. Reload the VS Code window (Cmd+R in the Extension Development Host). TraceBack will auto-detect the key, log Loaded .env keys: GROQ_API_KEY to its output channel, and start producing live narrative summaries.

.env is git-ignored. The only env file ever committed is .env.example.

If you'd rather use VS Code settings (e.g. for a team-shared workspace), the equivalent is:

{
  "traceback.llmProvider": "groq",
  "traceback.groqApiKey":  "gsk_..."
}

VS Code settings always override .env when both are set.

Option B — Ollama (fully local, no API key)

Install Ollama from ollama.com, pull a model, then:

{
  "traceback.llmProvider": "ollama",
  "traceback.ollamaModel": "llama3.2"
}

or in .env:

OLLAMA_MODEL=llama3.2
# OLLAMA_PORT=11434

Architecture

src/
├── extension.ts        # activation, command registration, LLM wiring
├── server.ts           # HTTP server that receives Claude Code hook payloads
├── traceStore.ts       # session state, node building, batch grouping
├── anomalyDetector.ts  # pure tail-only detector: repeater / error_thrash / stall
├── tokenReader.ts      # tails the Claude transcript for real token usage
├── hookManager.ts      # reads/writes ~/.claude/settings.json
├── llmClient.ts        # Groq + Ollama abstraction
├── envLoader.ts        # tiny zero-dep .env loader (workspace + extension root)
└── webviewProvider.ts  # bridges the extension ↔ React webview

webview/src/
├── App.tsx                       # fleet state machine, scroll/follow logic
├── metrics.ts                    # session metrics (duration, tokens, cost)
└── components/
    ├── TimelineCard.tsx          # one tool call → one card
    ├── SessionOdometer.tsx       # sticky metrics bar (time / actions / errors / tokens)
    ├── SessionPicker.tsx         # multi-session dropdown with status badges
    ├── DiffViewer.tsx            # LCS line diff for Edit/Write
    ├── Toolbar.tsx               # LIVE/DONE pill + export/clear buttons
    └── EmptyState.tsx

Extension ↔ webview communicate exclusively over postMessage / onDidReceiveMessage. No sockets, no shared memory — just clean VS Code API primitives.

Development

npm run watch          # tsc -w  (extension host, incremental)
npm run dev:webview    # vite dev server (webview HMR)

npm run compile        # full extension build
npm run build:webview  # full webview build
npm test               # vitest unit tests
npm run lint           # eslint

Press F5 in VS Code to launch the Extension Development Host with the extension loaded.

Testing

Unit tests cover the pure modules — the anomaly detector and the trace store — and run on every push via GitHub Actions on Node 20 and 22.

npm test           # one-shot
npm run test:watch # watch mode

Roadmap

• OpenTelemetry GenAI spans. Emit gen_ai.*-tagged spans per session/tool call so TraceBack can forward to Langfuse / Phoenix / Honeycomb while staying the live local viewer.
• Beyond Claude Code. Generic OTLP-shaped adapter so any agent (LangGraph, OpenAI Agents SDK, MCP servers) can stream into TraceBack.
• Persistent session history. Save sessions to disk for post-hoc audit and replay.
• Smarter stumbles. Near-duplicate edits, thrashing on the same file, runaway cost detection.

License

MIT — built by Madiyar Zhunussov.
