Git Lines

A read-only Git graph for VS Code. See the current DAG in stable lanes, with Operation Overlays only for operations that can be reliably reconstructed from standard Git data.

Git Lines: hero

Git Lines does not fill gaps with guesses. When evidence is insufficient, it leaves the current DAG without an inferred operation.

What is Git Lines?

Git Lines places commit parent relationships (the DAG) and the current Working Tree on one timeline. Lanes are a visual arrangement; parent edges are never reassigned.

Operations such as Amend, Cherry-pick, and Rebase appear in a separate overlay layer only when standard Git data still available, such as reflogs and commit bodies, proves them. Similar messages or trees are not used to guess a source.

Features

Git graph with stable branch lanes
Proven fast-forward merges preserve receiving-branch continuity and the source branch’s separate route
Working Tree and in-progress operations on one timeline
Operation Overlays backed by evidence
Reflog-based PREVIOUS commits and historical routes
Commit and Operation Detail panels
Detached HEAD and multiple worktree annotations
Read-only: does not execute checkout, merge, rebase, or other Git mutations

Display options

Choose the editor, bottom panel, or left sidebar from Git Lines in the status bar. The sidebar uses narrower lanes and single-line messages aligned with commit nodes. Click to open details, including change statistics, in a popover; click outside or press Esc to close it.

Editor and bottom-panel views default to Compact density. History loading and pagination use performance optimizations, with improved long-distance connections and column alignment.

Visual Overview

An overview of the graph. Expand the operation sections below for the meaning of each Git operation.

Current DAG

Display the DAG reachable from current refs alongside the Working Tree.

Git Lines: original

Historical context

With Reflog enabled, show additional context including PREVIOUS commits, historical routes, and reflog-only history.

Git Lines: previous

Grouped visualization

When related commits can be reliably identified, they may be grouped for readability. See each operation section for its specific semantics.

Git Lines: group

N → 1 rewrite

A dedicated overlay shows multiple commits collapsing into one when the rewrite can be reliably proven. Interactive Squash and Fixup are examples.

Git Lines: n to 1 rewrite

In-progress integration

In-progress Git operations are integrated into the Working Tree row, rather than represented as artificial commits.

Git Lines: in progress

Reflog OFF

Turning Reflog off hides operation marks, operation details, reflog-only past commits, and historical ref positions. Commits in the current history remain visible. Available history evidence still supports branch layout, continuation, and intake. Unproven relationships are never guessed. Proven FF intake remains as lines, without an event mark or annotation row.

Git Lines: reflog off

See the operation sections below for examples of ref movements such as Reset and Branch move.

Detail Panel

Inspect both commits and operations in Detail, including the evidence behind an operation.

Commit

Operation

Commit Detail shows additions, deletions, changed files, author, parents, and branch or route.

Operation Detail shows the operation type, Evidence, and only the information actually available for that relation: Mappings for Cherry-pick, independent Old order / New order for Rebase, or Old commits / New commit / Rewrite for Squash and Fixup.

Evidence-first Design

Reliable evidence     → Dedicated Operation Overlay
Partial / ambiguous   → Safe fallback (generic event or Current DAG)
No reliable evidence  → No inferred operation

Git Lines does not infer past operations solely from commit similarity or assumptions about what happened. It overlays only what can be proven and otherwise prioritizes the current DAG.

Intentionally not inferred

The following are intentionally not inferred, because standard Git data cannot establish them exactly:

Source or range of a completed Squash Merge (the result looks like a normal single-parent commit)
Noncontiguous member sets in Interactive Squash / Fixup
Cherry-pick without a reliable source indicator such as -x

See Graph architecture for detection conditions and research notes (Japanese).

Supported Operations

Only implemented and verified behavior is listed here.

✅ means that handling is implemented under the evidence-first policy, whether or not it produces a dedicated overlay.

Operation / State	Support	Visualization
Fast-forward merge	✅	Proven branch continuation and intake; ◇ FF with Reflog ON
Amend	✅	Commit rewrite
Cherry-pick	✅	Exact relation / visual group for consecutive relations
Revert	✅	Cancellation relation
Reset	✅	Ref movement
Branch move	✅	Ref movement
Branch rename	✅	Rename event (no position change)
Rebase	✅	Single / group rewrite
Reorder	✅	Handled as Group Rebase; reorder itself is not inferred
Drop	✅	Generic Rebase fallback
Reword	✅	Generic Rebase + Exact local Reword
Edit	✅	Generic Rebase + the operation actually observed
Interactive Squash / Fixup	✅	Reliably proven contiguous N → 1 only
Detached HEAD	✅	Explicit HEAD state
Multiple worktrees	✅	Worktree annotations on commits
In-progress operations	✅	Integrated into the Working Tree row
Branch delete / reflog-only	✅	Historical / UNREFERENCED
ORIG_HEAD	✅	Normal commit / special ref
Reflog OFF	✅	Hide operations and reflog-only history; retain proven branch flow

Supported DAG Topologies

Independently of Operation Overlays, Git Lines draws the actual parent relationships stored in Git objects. Complex topologies do not introduce invented edges or operations.

Topology	Support	Visualization
Normal branch / merge	✅	Standard DAG
Octopus merge	✅	Three or more parent edges
Criss-cross merge	✅	Crossing merge DAG
Multiple roots	✅	Independent roots displayed separately
Unrelated histories merge	✅	Histories connect at the actual merge commit
Orphan branch	✅	Normal branch with an independent root

These topologies use actual parent relationships, without dedicated Operation Overlays.

Git Operations

Fast-forward (FF): When the merge and source branch’s origin are established, source commits remain in a separate column connected to the receiving branch’s continuation line. No merge commit is created, and actual parents and current ref positions stay unchanged. After the source branch is deleted, its route remains while the evidence and required commits are available; deleted ref labels are not restored.

Cherry-pick

A source → created commit relation appears only when standard Git data reliably identifies the source. Consecutive exact relations may be grouped for readability.

Git Lines: cherry pick

In progress

An in-progress Cherry-pick is integrated into the Working Tree row.

Git Lines: cherry pick in progress

Rebase

A completed session appears as a single or group rewrite when its linear old and new ranges can be reliably reconstructed.

Completed evidence generally cannot distinguish Reorder from an ordinary Rebase, so it is shown as Group Rebase. This does not claim individual commit mappings or preserved order. Drop falls back to Generic Rebase when the dropped members cannot be identified exactly.

Reword shows only a local rewrite directly proven by the reflog within a completed session, alongside Generic Rebase. Edit has no dedicated relation; an actually observed operation such as Amend appears alongside Generic Rebase.

Completed

Git Lines: rebase

Reword

The image shows an exact local Reword relation directly proven by the reflog: an UNREFERENCED temporary commit T → B reworded (B′) within a rebase session. It does not infer an individual mapping from the original pre-rebase commit B.

Git Lines: reword

In progress

An in-progress Rebase is integrated into the Working Tree row.

Git Lines: rebase in progress

Squash / Fixup

A dedicated visualization appears only when evidence reliably proves that a contiguous old range collapsed into one commit during Interactive Rebase, with rebase (squash) or rebase (fixup) evidence. Squash uses the N → 1 rewrite visualization shown above.

Git Lines: fixup

Reset

Reset is shown as a ref changing position, rather than a commit rewrite. It uses current refs and historical ghost refs where needed.

Git Lines: reset

Branch move

A branch tip movement uses the same Ref Movement visualization as Reset. The image shows consecutive Reset and Branch move operations.

Git Lines: branch move reset

Branch rename

Branch rename appears as an event that changes the ref name without moving its tip.

Git Lines: branch rename

Revert

A completed Revert may connect the created revert commit to its target with a cancellation relation and a dedicated target marker. This README does not currently include a screenshot of a completed Revert.

In progress

An in-progress Revert is integrated into the Working Tree row.

Git Lines: revert in progress

Merge in progress

Completed normal merges, Octopus merges, and unrelated-history merges appear as actual parent relationships in the Current DAG, without dedicated Operation Overlays. An in-progress Merge is integrated into the Working Tree row.

Git Lines: merge in progress

Special Git States

Detached HEAD

The commit currently pointed to by HEAD remains part of the live state even without a branch ref.

Git Lines: detached head

Multiple Worktrees

Linked worktrees appear as annotations on their commits, without creating additional graph lanes.

Git Lines: multiple worktree

DAG Topologies

Octopus merge

For a merge commit with three or more parents, every parent edge follows the actual Git parent relationship.

Git Lines: octopus merge

Criss-cross merge

Crossing DAGs produced by mutual merges retain their parent relationships and branch lanes.

Git Lines: criss cross merge

Multiple roots

Roots without a common ancestor are displayed independently, without invented connecting edges.

Git Lines: multiple roots

Unrelated histories merge

Two independent histories first connect at the actual merge commit. No dedicated Unrelated operation overlay is created.

Git Lines: unrelated histories merge

Orphan branch

An orphan branch appears as a normal branch with a root independent of existing history.

Git Lines: orphan branch

Usage

Requires VS Code 1.90 or later and Git available on PATH. Open a Git repository folder and enable Workspace Trust. Remote workspaces require Git on the remote host. Virtual workspaces without files accessible to the Git CLI are not supported.

Select Git Lines in the status bar or Git Lines: Open in the Command Palette, then choose Open in Editor, Open in Panel, or Open in Sidebar. With multiple folders open, select a repository next.
Use the gear button to the left of ? in the graph to choose lane placement, Reflog, and Density. Refresh remains available in the graph header.
Select a commit or operation to open its details (a popover in the sidebar).
The initial view contains 30 commits. Scrolling near the bottom loads more history; Load more is also available.

To install a VSIX, run Extensions: Install from VSIX... from the Command Palette and select the desired releases/git-lines-<version>.vsix file.

The bottom panel has a Git Lines tab alongside Terminal and Output; the sidebar has a dedicated Activity Bar icon. All locations provide the same graph, Reflog, and detail information. You can also choose a location directly using Git Lines: Open in Editor, Git Lines: Open in Panel, or Git Lines: Open in Sidebar.

The graph is read-only. It does not provide Git mutations such as checkout, branch creation, merge, rebase, or push.

Display settings

Use the gear button to the left of ? in the graph, or run Git Lines: Settings. Changes are saved, restored on the next launch, and applied to open views. Settings normally use user scope; existing workspace overrides are respected and the save scope is shown. Density applies to the editor and bottom panel; the sidebar retains its dedicated spacing.

Choose Standard (the default) or Default Fixed. Both modes keep evidence-backed source and child branch histories in separate columns. Standard keeps the source to the left before a merge and when it receives the child. If the source is merged into the child, that placement is not guaranteed. Default Fixed places the default column leftmost while preserving route identities. Reflog records are used internally even when their display is off. Ambiguous branch origins are not guessed.

The target is resolved from locally stored remote HEAD metadata. If unresolved, choose a Fixed target in Settings. This override is stored per repository inside VS Code and does not modify Git configuration.

Development

GitHub defaults to the Japanese README.md; README.en.md is the English version. Packaging selects README.marketplace.md for Marketplace. Review all three files when updating documentation.

pnpm install
pnpm lint
pnpm test
pnpm build

Run pnpm check for lint, tests, and builds together. The Extension Host bundle is dist/extension.js, and the Webview is built to dist/webview. Use pnpm test:watch for test watching and pnpm dev:webview for Webview development.

After building, launch a development VS Code window:

code --extensionDevelopmentPath="<path-to-git-lines>" "<path-to-repository>"

pnpm package builds the extension and creates releases/git-lines-<version>.vsix. Different versions are retained; regenerating the same version overwrites that file. This command does not publish.

Settings

Setting	Default	Description
`branchGraph.layoutMode`	`legacy`	Legacy placement or fixed default column (`default-fixed`)
`branchGraph.showReflog`	`true`	Operation marks and reflog-only history; evidence still supports branch flow
`branchGraph.density`	`compact`	Row density (`comfortable` / `compact`)
`branchGraph.initialCommitCount`	`30`	Initial number of commits to load
`branchGraph.loadMoreCount`	`10`	Number of commits to load per page
`branchGraph.primaryBranch`	`null`	Primary visual branch (automatic when unset)

Roadmap

Support for the planned major local Git operations and special DAG topologies is complete.

Possible next areas:

Remote and ref edge cases
shallow clone
Expired or missing reflogs
Additional repository and history boundary verification

Technical Documentation

Graph architecture and invariants (Japanese)
