Candela for Visual Studio Code

Editor support for the Candela language (.cdl files): TextMate syntax highlighting, language configuration (comments, brackets, auto-closing, indentation), snippets, and a language server client (live diagnostics, hover, completion, signature help, outline, go-to-definition) backed by candela-lsp.

Candela is the scripting language of the Lumen UI framework. It is a fork of keel by Horace Hoff, renamed and extended for Lumen (source file extension .cdl). See the repository NOTICE for attribution details.

Features

• Syntax highlighting for:
  • Keywords: if, else, match, while, for, in, loop, return, break, continue, try, catch, throw, let, fn, struct, enum, impl, import, as, is, host, dylib.
  • Built-in types: int, float, bool, string, plus user-defined structs and enums.
  • Function types, fn(int, int) -> int, wherever a type goes.
  • Constants: true, false, null.
  • Strings with escape sequences (\n, \t, \r, \\, \", \0).
  • Integer and float literals.
  • Operators, including the ... variadic marker in host blocks and the .. range operator.
  • import, host, and dylib constructs, struct declarations and literals, enum and impl declarations, function definitions and calls, method calls, and namespace:: access.
  • Generics: a declaration's type parameters (struct Cell<T>, fn first<T>, impl Signal<int>) and the type arguments a use names (Cell<int> in a type, first<int>(xs), Cell<int>{ .. }, Slot<int>::Filled(9)) color as types inside angle brackets. a < b and a < b > c stay comparisons: a list is read only where the closing > is followed by something no operand can start with. A list written across two lines is not recognized.
  • Macro invocations, name!( ... ): the name colors as a macro rather than a function, and the region between the parentheses stays raw, so markup written inside one is not read as candela strings and operators.
• Language configuration: line comments (//), bracket matching, auto-closing and surrounding pairs, and {} indentation rules.
• Snippets, by prefix: main, fn, struct, let, if, ifelse, ifis, for, forin, while, loop, match, host, dylib, import, importlib, and print.
• A language server client that launches candela-lsp over stdio for live diagnostics, hover, completion, signature help, document symbols (outline), and go-to-definition. See ../../lsp/README.md for the exact scope of each.

Language facts

• Comments: line comments only (// ...). There is no block comment syntax. /// documents the item below it and //! the file it is in; both color as documentation.
• Strings: double-quoted, with the escapes listed above. No string interpolation.
• Numbers: integers are i64 ([0-9]+); floats are f64 and must be written with a decimal point ([0-9]*.[0-9]+).
• Structs: struct Name { field: type, ... }; instantiated with Name { field: value }; fields accessed with x.field.
• Foreign functions: dylib "path" { rettype name(argtypes); ... } for dynamic libraries and host "namespace" { rettype name(argtypes); ... } for host-registered closures. A trailing ... argument marks a variadic host function.
• Modules: import "file.cdl"; for a file, import "std/json"; for a shipped library. An import binds the module under its name (json::parse); import "..." as alias; picks the name, and import "..." { a, b }; brings the named items into the file's scope.
• Macros: name!( ... ) hands the raw region between the parentheses to the program embedding candela, which returns candela source to parse in its place. The region ends at the parenthesis that balances the one that opened it, skipping parentheses inside a string or after //. candela defines no macros of its own and never reads a region.

Language server

This extension launches candela-lsp (a separate crate at ../../lsp/ in this repo) as a subprocess over stdio, the same transport every LSP client uses. It looks for a candela-lsp (or candela-lsp.exe on Windows) binary on PATH by default; set candela.languageServerPath in your settings to point at a specific binary instead (for example, one built locally with cargo build -p candela-lsp from the repo root; see that crate's README for why to avoid --release).

A script that imports a package no manifest lists, such as the module a host program ships (import "engine" { * };), needs the server to know where it is. Name it in candela.importRoots, a map from the name the script imports to the package's directory or its .cdl file:

"candela.importRoots": { "engine": "~/engine/module" }

~ and ${workspaceFolder} expand, and a relative path is read from the first workspace folder. candela.libPath points the server at a standard library other than the one installed beside it, the directory CANDELA_LIB_PATH would name. Changing either re-checks the open files.

If candela-lsp cannot be started, the extension shows an error message instead of failing silently; the syntax highlighting/snippets/language configuration above keep working either way, since those do not depend on the server.

Install / development

This extension has one runtime dependency (vscode-languageclient) that must be present in node_modules when packaged, so run npm install before packaging. There is no compile step; src/extension.js is plain CommonJS, not TypeScript.

• Install dependencies: npm install (from this directory).

• Run from source: open this folder (editors/vscode) in VS Code and press F5 to launch an Extension Development Host, then open any .cdl file.

• Package a .vsix:

  npm install
  npx --yes @vscode/vsce package


  Install the produced .vsix with code --install-extension candela-<version>.vsix.

The extension carries its own version, independent of the candela toolchain release it ships alongside. A change here bumps version in package.json and adds a CHANGELOG.md entry; without that the next release publishes nothing new, because the registries already hold the version in the manifest.

License

Apache-2.0. See the repository LICENSE and NOTICE.
