Haskell Inspector — VS Code extension

Inspect heaps of running Haskell programs from VS Code. The extension discovers live debuggees (and saved snapshots / eventlogs), then opens the haskell-inspector web UI inline in a webview. It also contributes a haskell-inspector debug type, so the inspector can run as a debug session with VS Code's Call Stack panel cross-linked to the web view.

Requirements

The haskell-inspector binary on PATH, or pointed at via the haskellInspector.executable / haskellInspector.executables settings.
A debuggee instrumented with the haskell-inspector-connector library. The connector announces the process by writing a <pid>-<prog>.desc descriptor file (JSON: connection address, PID, cwd, executable path) to a conventional directory; the extension discovers targets by scanning that directory.

Using it

Activity bar (shown by default): a Haskell Inspector container with a Targets pane (live processes and snapshots, split into Project / System) and an Eventlogs pane (workspace *.eventlog files plus recently opened files). Click a row to open it. A badge counts live programs available to inspect.
Command palette: all commands live under the Haskell Inspector: category — Show… opens the target picker, Open Eventlog File… inspects an eventlog post-mortem, Open Current Inspector in Browser moves the focused inspector tab into your browser (works over Remote-SSH via VS Code's port forwarding).
Editor title button / status bar entry: optional extra entry points, hidden by default (haskellInspector.editorTitleButton, haskellInspector.statusBar).

Debug sessions (DAP)

Add a launch configuration of type haskell-inspector:

{
  "type": "haskell-inspector",
  "request": "attach",
  "name": "Haskell Inspector: attach (auto-discover)",
  "descriptor": "auto"
}

With "descriptor": "auto" (or omitted) each F5 attaches to the freshest live debuggee. A specific target can be pinned by pointing descriptor at its .desc descriptor file, or snapshot at a ghc-debug snapshot. While a session runs, the debug toolbar offers Open Web View for Debug Session and Start/Stop Sampling buttons; selecting a thread in the Call Stack panel focuses the same thread in the web view.

Settings

Setting	Default	Description
`haskellInspector.activityBar`	`shown`	Show the activity-bar view container.
`haskellInspector.editorTitleButton`	`hidden`	Editor-title button behaviour: `smart`, `submenu`, `picker`, or `hidden`.
`haskellInspector.statusBar`	`hidden`	Show a status-bar entry that opens the menu.
`haskellInspector.showAll`	`false`	Picker lists every discovered target, not just this workspace's.
`haskellInspector.executable`	`haskell-inspector`	Path or PATH-resolved name of the inspector binary.
`haskellInspector.executables`	`[]`	List of `{name, path, default}` binaries; the `default: true` entry wins.
`haskellInspector.customCss`	(empty)	CSS file appended after the web UI's stylesheet, passed as `--custom-css`.
`haskellInspector.descriptorDirectory`	(empty)	Override the descriptor discovery directory. Empty = standard XDG location.
`haskellInspector.snapshotDirectory`	(empty)	Override the snapshot discovery directory.
`haskellInspector.socketDirectory`	(empty)	Override the unix-socket directory swept for orphaned sockets.
`haskellInspector.environment`	`{}`	Extra environment variables for the spawned inspector process.

Path-valued settings support ~, ${HOME}, and ${workspaceFolder} (first folder; use ${workspaceFolder:name} to address a specific folder of a multi-root workspace).

Building

npm install
npm run compile

Then press F5 in this folder to launch an Extension Development Host, or package with vsce package for a .vsix you can code --install-extension.

Implementation notes

The extension never talks to the debuggee directly. It scans the conventional discovery directories ($XDG_DATA_HOME/haskell-inspector/{descriptors,snapshots,s}; %APPDATA% on Windows), filters by workspace, then spawns haskell-inspector --web --port 0 with --descriptor <file> (--snapshot / --eventlog for files) and reads the OS-assigned port back from the binary's stdout announcement. The web UI is hosted in a WebviewPanel whose portMapping lets the inner iframe reach the spawned server's loopback port. Debug sessions use the same binary with --with-dap; DAP runs over stdio, so there the web port is read from a --web-port-file instead of stdout.

On activation the extension also runs a one-shot sweep that removes stale descriptors, orphaned sockets, and stranded lockfiles left behind by debuggees that exited uncleanly (mirroring the inspector's own cleanup policy, for the case where no inspector process is running).

Remote development (SSH / WSL / Dev Containers)

The extension host runs on the remote machine, so target discovery, spawning, and the descriptor sweep all happen on the remote filesystem, and directory-override settings must name remote paths. The webview reaches the remote server through vscode.env.asExternalUri, which sets up VS Code's port forwarding automatically — no manual configuration needed, for the inline view and for Open Current Inspector in Browser alike.

Multi-root workspaces

All folders of a multi-root workspace participate: a target counts as "Project" when its working directory or executable is inside any open folder, eventlog discovery spans every folder, and eventlog rows are prefixed with their folder name when more than one is open. A bare ${workspaceFolder} in settings means the first folder; ${workspaceFolder:name} addresses a specific one.

Untrusted workspaces

The extension stays fully functional in VS Code's Restricted Mode, but the settings that choose the executed binary, its environment, and swept directories are then only honoured from user-level settings — a workspace-committed .vscode/settings.json cannot make the extension execute an arbitrary binary or delete files. See capabilities.untrustedWorkspaces in package.json for the exact list.
