LDOC - Living Documents

Write plain text. Get an animated, hand-drawn explainer document.

LDOC reads a .ldoc file and renders it live in VS Code — styled prose, plus diagrams that draw themselves. You never pick a chart type or tag a style: the shape of what you wrote decides the picture.

Quick start

1. Install LDOC in VS Code.
2. Create a file ending in .ldoc.
3. Paste the example below. The preview opens automatically beside your .ldoc file.

# Java basics

@animate
# Java basics
- Integer division
  - 7 / 2 gives 3
- Type promotion
  - 7 / 2.0 gives 3.5
- Casting
  - Cast before division
@end

To disable automatic opening, turn off LDOC: Auto Preview in Settings. You can still run LDOC: Open Preview manually.

No API key is needed. Edit the bullets to update the preview. Use LDOC: Export to HTML for an offline, shareable animation.

Writing a document

Ordinary Markdown works, with a few conventions given richer meaning:

Animations

Wrap a description in @animate … @end. The diagram is chosen from the structure of what you wrote:

Name actors that talk to each other → a sequence diagram

@animate
browser: Browser
api: API Server

browser sends GET /users to api
api replies 200 JSON to browser
connection established
@end

Name things where flow only runs one way → a scene

@animate
sun: Sunlight
tree: Oak Tree

sun sends ENERGY to tree
@end

Name two things that don't interact → a comparison

@animate
Before: slow, manual, error-prone
After: fast, automated, repeatable
@end

Write plain statements → a process flow

@animate
Water travels up from the roots
CO2 enters through the stomata
Glucose is built and stored
@end

End with "and it repeats" → a cycle

@animate
Water evaporates from the ocean
Clouds release rain over land
Rivers carry it back to the sea
and the cycle repeats
@end

Things are drawn as what they are

An actor named user becomes a figure; database becomes a cylinder; tree, sun, cloud, water, server, screen and others become themselves. Anything unrecognised falls back to a labelled box — a less specific picture, never an error.

Usage

Open a .ldoc file and click Open Preview in the editor title bar, or run LDOC: Open Preview from the Command Palette. The preview updates as you type.

Animations start when you scroll to them, so a long document doesn't play everything at once.

Optional: write plain English instead

LDOC works completely without AI. If you'd rather not learn the syntax, you can bring your own API key and have a model write it for you.

1. Run LDOC: Set Up AI from the Command Palette. Choose a provider, enter a model ID and paste your API key. For a compatible service, also enter its base URL; local models can use an empty key.
2. Select a paragraph (or place the cursor in it) and run LDOC: Generate Animation from Text (AI).
3. LDOC inserts the block, shows a success message and opens the preview at that animation. It uses the same renderer as handwritten LDOC.

If the cursor is on a heading or blank line, the command asks what you want explained. Open Preview only renders existing blocks; it does not call an AI provider. Simple technical chains use numbered cards and animated handoffs; natural scenes keep their spatial layout, and conversations use sequence diagrams.

When a user logs in, the web app checks their credentials against the auth service, which looks them up in the database and returns a token.

…becomes a valid @animate block, inserted below your text.

The output is checked for missing participants and unsupported structures. LDOC asks for one correction if needed, and leaves your document unchanged if that also fails. If you edit the source while generation runs, the result opens in a new unsaved document instead of being inserted at an outdated location. Each provider request has a 60-second timeout; transient failures can be retried.

Only the selected paragraph (or current paragraph), the grammar instructions, and any correction request are sent to your chosen provider. Generation uses your provider account and may incur its normal API charges. Rendering and export stay offline.

Drawing objects that aren't in the library

Thirteen objects ship built in, including cache, queue, router and book. Redis draws a cache, Kafka a queue, gateway a router, and textbook a book. Run LDOC: Draw an Object (AI), type a noun, and it becomes drawable in every diagram from then on:

@animate
bird: Sparrow
tree: Oak Tree
bird sends SEEDS to tree
@end

The drawing is generated once and cached forever — after that it renders offline like any built-in shape, costs nothing, and is baked into exported HTML. Remove any of them with LDOC: Forget Generated Shapes.

Generated shapes are drawn with lighter roughness than the hand-drawn library. They carry finer detail, and the library's usual jitter would close the gaps between nearby lines into a scribble.

What the AI does and doesn't do. The model only writes LDOC syntax and shape outlines — it never touches rendering. It cannot choose colours, positions, timings or diagram types, because those are decided by the renderer from the structure of what was written. So AI removes the need to learn the syntax; it does not unlock different visuals. The same diagrams are available either way.

Supported providers: Anthropic, OpenAI, Gemini, or any OpenAI-compatible endpoint — including a local model through Ollama or LM Studio, which costs nothing and keeps your documents off third-party servers.

Your key is stored in VS Code's SecretStorage, never in settings.json. Keys are separate for each provider and each compatible endpoint. LDOC: Set API Key replaces the current provider's key; LDOC: Clear Stored API Key removes it.

Try this build

The simple Java mind map (examples/mindmap/README.md) uses a heading and nested bullets inside @animate. RoughJS draws the branches and short explanations, with no rich-card fields, toolbar or internal scrolling. Open its .ldoc source in LDOC Preview; an offline HTML export is included.

For documentation examples, open the showcase (examples/github-showcase/README.md): a learning mind map, a PR explanation, an LMS system example and a map of LDOC's actual codebase. Each has editable LDOC, a standalone animation and a PNG for GitHub.

Mind maps use parent includes child between defined topics. Use one root and one parent per child; cycles and disconnected topics are rejected. The AI grammar also supports this relationship.

Start with examples/mindmap/java-basics.ldoc, then try examples/mindmap/java-surrounding.ldoc and examples/github-showcase/pr-workflow.ldoc. Sequence diagrams keep participants visible and moving reply labels upright.

For development, run npm test to compile and run the regression suite. The optional node tests/browser-check.cjs checks the standalone export in headless Chrome and writes screenshots to a temporary directory. Set CHROME_PATH if Chrome is not installed at the default Windows location. Live provider access requires your key; the automated provider tests use mocked responses.

Notes

• Rendering is deterministic — the same document always produces the same animation. Nothing is generated by a model at render time, with or without a key.
• The extension needs no network connection. Both the preview and exported HTML run fully offline; the handwritten font is embedded, not fetched.
• Diagrams are drawn in a hand-sketched style using Rough.js, bundled with the extension.

Current limitations

This is the first public version. LDOC supports structured explanations, not arbitrary cinematic animation. Large maps get smaller when fitted into a narrow preview; split long lessons into concise diagrams. moves and appears are not supported actions. Architecture boundaries and arbitrary system graphs are not yet dedicated templates. GitHub Markdown does not play LDOC exports directly: use an image, or host the exported HTML. AI generation depends on the chosen provider and may need a model ID available to your account.

Feedback

Try explaining one concept or change with LDOC. Share what you wrote, what you expected, and where you got stuck. When reporting an AI problem, include the provider/model and error message, but never your API key. Issue templates are included for the public repository.

License

MIT
