LLDB DAP

Procuring the `lldb-dap` binary

The extension requires the lldb-dap (formerly lldb-vscode) binary. This binary is not packaged with the VS Code extension.

There are multiple ways to obtain this binary:

Use the binary provided by your toolchain (for example xcrun -f lldb-dap on macOS) or contact your toolchain vendor to include it.
Download one of the relase packages from the LLVM release page. The LLVM-19.1.0-{operating_system}.tar.xz packages contain a prebuilt lldb-dap binary.
Build it from source (see LLDB's build instructions).

By default, the VS Code extension will expect to find lldb-dap in your PATH. Alternatively, you can explictly specify the location of the lldb-dap binary using the lldb-dap.executable-path setting.

Usage with other IDEs

The lldb-dap binary is a command line tool that implements the Debug Adapter Protocol. It is used to power the VS Code extension but can also be used with other IDEs and editors that support DAP. The protocol is easy to run remotely and also can allow other tools and IDEs to get a full featured debugger with a well defined protocol.

Launching & Attaching to a debugee

Launching or attaching a debugee require you to create a launch configuration. This file defines arguments that get passed to lldb-dap and the configuration settings control how the launch or attach happens.

Launching a debugee

This will launch /tmp/a.out with arguments one, two, and three and adds FOO=1 and bar to the environment:

{
  "type": "lldb-dap",
  "request": "launch",
  "name": "Debug",
  "program": "/tmp/a.out",
  "args": [ "one", "two", "three" ],
  "env": {
    "FOO": "1"
    "BAR": ""
  }
}

Attaching to a process

When attaching to a process using LLDB, you can attach in multiple ways:

Attach to an existing process using the process ID
Attach to an existing process by name
Attach by name by waiting for the next instance of a process to launch

Attach using PID

This will attach to a process a.out whose process ID is 123:

{
  "type": "lldb-dap",
  "request": "attach",
  "name": "Attach to PID",
  "program": "/tmp/a.out",
  "pid": 123
}

Attach by Name

This will attach to an existing process whose base name matches a.out. All we have to do is leave the pid value out of the above configuration:

{
  "name": "Attach to Name",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
}

If you want to ignore any existing a.out processes and wait for the next instance to be launched you can add the "waitFor" key value pair:

{
  "name": "Attach to Name (wait)",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
  "waitFor": true
}

This will work as long as the architecture, vendor and OS supports waiting for processes. Currently MacOS is the only platform that supports this.

Loading a Core File

This loads the coredump file /cores/123.core associated with the program /tmp/a.out:

{
  "name": "Load coredump",
  "type": "lldb-dap",
  "request": "attach",
  "coreFile": "/cores/123.core",
  "program": "/tmp/a.out"
}

Connect to a Debug Server on the Current Machine

This connects to a debug server (e.g. lldb-server, gdbserver) on the current machine, that is debugging the program /tmp/a.out and listening locally on port 2345.

{
  "name": "Local Debug Server",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
  "attachCommands": ["gdb-remote 2345"],
}

You can also use the gdb-remote-port parameter to send an attach request to a debug server running on the current machine, instead of using the custom command attachCommands.

{
  "name": "Local Debug Server",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
  "gdb-remote-port": 2345,
}

Connect to a Debug Server on Another Machine

This connects to a debug server running on another machine with hostname hostnmame. Which is debugging the program /tmp/a.out and listening on port 5678 of that other machine.

{
  "name": "Remote Debug Server",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
  "attachCommands": ["gdb-remote hostname:5678"],
}

You can also use the gdb-remote-hostname and gdb-remote-port parameters to send an attach request to a debug server running on a different machine, instead of custom command attachCommands. The default hostname being used localhost.

{
  "name": "Local Debug Server",
  "type": "lldb-dap",
  "request": "attach",
  "program": "/tmp/a.out",
  "gdb-remote-port": 5678,
  "gdb-remote-hostname": "hostname",
}

Configuration Settings Reference

For both launch and attach configurations, lldb-dap accepts the following lldb-dap specific key/value pairs:

Parameter	Type	Req
name	string	Y	A configuration name that will be displayed in the IDE.
type	string	Y	Must be "lldb-dap".
request	string	Y	Must be "launch" or "attach".
program	string	Y	Path to the executable to launch.
sourcePath	string		Specify a source path to remap "./" to allow full paths to be used when setting breakpoints in binaries that have relative source paths.
sourceMap	[string[2]]		Specify an array of path re-mappings. Each element in the array must be a two element array containing a source and destination pathname. Overrides sourcePath.
debuggerRoot	string		Specify a working directory to use when launching lldb-dap. If the debug information in your executable contains relative paths, this option can be used so that `lldb-dap` can find source files and object files that have relative paths.
commandEscapePrefix	string		The escape prefix to use for executing regular LLDB commands in the Debug Console, instead of printing variables. Defaults to a backtick. If it's an empty string, then all expression in the Debug Console are treated as regular LLDB commands.
customFrameFormat	string		If non-empty, stack frames will have descriptions generated based on the provided format. See https://lldb.llvm.org/use/formatting.html for an explanation on format strings for frames. If the format string contains errors, an error message will be displayed on the Debug Console and the default frame names will be used. This might come with a performance cost because debug information might need to be processed to generate the description.
customThreadFormat	string		Same as `customFrameFormat`, but for threads instead of stack frames.
displayExtendedBacktrace	bool		Enable language specific extended backtraces.
enableAutoVariableSummaries	bool		Enable auto generated summaries for variables when no summaries exist for a given type. This feature can cause performance delays in large projects when viewing variables.
enableSyntheticChildDebugging	bool		If a variable is displayed using a synthetic children, also display the actual contents of the variable at the end under a [raw] entry. This is useful when creating sythetic child plug-ins as it lets you see the actual contents of the variable.
initCommands	[string]		LLDB commands executed upon debugger startup prior to creating the LLDB target.
preRunCommands	[string]		LLDB commands executed just before launching/attaching, after the LLDB target has been created.
stopCommands	[string]		LLDB commands executed just after each stop.
exitCommands	[string]		LLDB commands executed when the program exits.
terminateCommands	[string]		LLDB commands executed when the debugging session ends.

All commands and command outputs will be sent to the debugger console when they are executed. Commands can be prefixed with ? or ! to modify their behavior:

Commands prefixed with ? are quiet on success, i.e. nothing is written to stdout if the command succeeds.
Prefixing a command with ! enables error checking: If a command prefixed with ! fails, subsequent commands will not be run. This is usefule if one of the commands depends on another, as it will stop the chain of commands.

For JSON configurations of "type": "launch", the JSON configuration can additionally contain the following key/value pairs:

Parameter	Type	Req
program	string	Y	Path to the executable to launch.
args	[string]		An array of command line argument strings to be passed to the program being launched.
cwd	string		The program working directory.
env	dictionary		Environment variables to set when launching the program. The format of each environment variable string is "VAR=VALUE" for environment variables with values or just "VAR" for environment variables with no values.
stopOnEntry	boolean		Whether to stop program immediately after launching.
runInTerminal	boolean		Launch the program inside an integrated terminal in the IDE. Useful for debugging interactive command line programs.
launchCommands	[string]		LLDB commands executed to launch the program.

For JSON configurations of "type": "attach", the JSON configuration can contain the following lldb-dap specific key/value pairs:

Parameter	Type
program	string	Path to the executable to attach to. This value is optional but can help to resolve breakpoints prior the attaching to the program.
pid	number	The process id of the process you wish to attach to. If pid is omitted, the debugger will attempt to attach to the program by finding a process whose file name matches the file name from porgram. Setting this value to `${command:pickMyProcess}` will allow interactive process selection in the IDE.
waitFor	boolean	Wait for the process to launch.
attachCommands	[string]	LLDB commands that will be executed after preRunCommands which take place of the code that normally does the attach. The commands can create a new target and attach or launch it however desired. This allows custom launch and attach configurations. Core files can use `target create --core /path/to/core` to attach to core files.

Debug Console

The Debug Console allows printing variables / expressions and executing lldb commands. By default, lldb-dap tries to auto-detect whether a provided command is a variable name / expression whose values will be printed to the Debug Console or a LLDB command. To side-step this auto-detection and execute a LLDB command, prefix it with the commandEscapePrefix.

The auto-detection can be disabled using the lldb-dap repl-mode command. The escape character can be adjusted via the commandEscapePrefix configuration option.

lldb-dap specific commands

The lldb-dap tool includes additional custom commands to support the Debug Adapter Protocol features.

`lldb-dap start-debugging`

Using the command lldb-dap start-debugging it is possible to trigger a reverse request to the client requesting a child debug session with the specified configuration. For example, this can be used to attached to forked or spawned processes. For more information see Reverse Requests StartDebugging.

The custom command has the following format:

lldb-dap start-debugging <launch|attach> <configuration>

This will launch a server and then request a child debug session for a client.

{
  "program": "server",
  "postRunCommand": [
    "lldb-dap start-debugging launch '{\"program\":\"client\"}'"
  ]
}

`lldb-dap repl-mode`

Inspect or adjust the behavior of lldb-dap repl evaluation requests. The supported modes are variable, command and auto.

variable - Variable mode expressions are evaluated in the context of the current frame.
command - Command mode expressions are evaluated as lldb commands, as a result, values printed by lldb are always stringified representations of the expression output.
auto - Auto mode will attempt to infer if the expression represents an lldb command or a variable expression. A heuristic is used to infer if the input represents a variable or a command.

In all three modes, you can use the commandEscapePrefix to ensure an expression is evaluated as a command.

The initial repl-mode can be configured with the cli flag --repl-mode=<mode> and may also be adjusted at runtime using the lldb command lldb-dap repl-mode <mode>.

`lldb-dap send-event`

lldb-dap includes a command to trigger a Debug Adapter Protocol event from a script.

The event maybe a custom DAP event or a standard event, if the event is not handled internally by lldb-dap.

This command has the format:

lldb-dap send-event <name> <body>?

For example you can use a launch configuration hook to trigger custom events like:

{
  "program": "exe",
  "stopCommands": [
    "lldb-dap send-event MyStopEvent",
    "lldb-dap send-event MyStopEvent '{\"key\": 321}",
  ]
}

See the specification for more details on Debug Adapter Protocol events and the VS Code debug.onDidReceiveDebugSessionCustomEvent API for handling a custom event from an extension.

Contributing

lldb-dap and lldb are developed under the umbrella of the LLVM project. The source code is part of the LLVM repository on Github. We use Github's issue tracker and patches can be submitted via pull requests. Furthermore, there is a LLDB category on the LLVM discourse forum.

For instructions on how to get started with development on lldb-dap, see the "Contributing to lldb-dap"
