Linggen

Linggen VS Code Extension

Overview

This VS Code extension integrates Linggen into your editor so you can:

• Visualize your codebase as a graph
• Jump from VS Code into Linggen for deeper architecture exploration
• Wire Linggen into Cursor via msp.json
• Start and control the local Linggen backend from inside VS Code

Current Features

• Open Graph View

  • Command palette action to open Linggen's dependency graph for the current workspace.
  • Lets you see how files and modules depend on each other before you edit code.

• "Open in Linggen" context menu

  • Right–click on a file or folder in the VS Code explorer and choose "Open in Linggen".
  • Focuses the Linggen graph and design workspace around that selection (file, module, or folder).

• Cursor msp.json wiring

  • Helpers to make it easy to add Linggen as an MCP / tool source in Cursor's msp.json.
  • Ensures Cursor (and other LLM tools) can call into Linggen to:
    • Look up dependency neighborhoods.
    • Fetch design notes / specs.
    • Generate implementation briefs for specific components.

• Start Linggen backend

  • Command palette action to start the Linggen server (if it's not already running).
  • Optionally shows basic status / error output if the server fails to start.

Commands

The extension exposes these core commands in the VS Code Command Palette:

• Linggen: Install Linggen

  • Install or update the local Linggen binary / backend needed by the extension.
  • Opens https://linggen.dev in your browser with installation instructions.

• Linggen: Start Linggen

  • Start the local Linggen server (or bring it to the foreground if already running).

• Linggen: Index Current Project

  • Ask Linggen to index the currently opened project / workspace folder so the graph and specs stay in sync with your code.

• Linggen: Open in Linggen

  • Opens the selected file or folder in Linggen's UI (also available via right-click context menu).

• Linggen: Configure Cursor msp.json

  • Generates a configuration snippet for integrating Linggen with Cursor's MCP system.

Additional Ideas for This Extension

These are potential / planned capabilities that fit naturally into this extension:

• Per-file "Architecture Lens"

  • Side panel showing, for the active file:
    • Incoming and outgoing dependencies.
    • Linked design notes and specs from Linggen.
    • Known "owners" or responsible components.

• Neighborhood navigation

  • Commands to:
    • "Show dependency neighborhood in Linggen" for the current file.
    • "Show what might break if I edit this file" based on the graph.

• Design doc integration

  • Quick links to:
    • Open the design note / spec for the current file or component in Linggen.
    • Create a new design note that is auto-linked to the active file.

• Indexing and health controls

  • Commands to:
    • Trigger a re-index of the current workspace in Linggen.
    • Show indexing status (in progress, complete, last updated).

• LLM workflow helpers

  • From VS Code, generate an LLM-ready brief for the current task:
    • "Generate implementation brief in Linggen for this file/folder."
    • "Open spec + graph context in Linggen, then copy a ready-to-use prompt into the clipboard."

• LSP-enhanced graph updates

  • When you right–click "Open in Linggen" on a file or symbol, the extension can:
    • Query the language server (LSP) for definitions, references, symbols, etc.
    • Send these dynamic edges to Linggen to augment the static Tree-sitter graph for that view.
  • The Linggen graph can then show both:
    • Static edges (from static analysis / indexing).
    • Dynamic LSP edges (session-specific overlays), visually distinguished in the UI.

• Multi-root workspace support

  • Map each folder in a VS Code multi-root workspace to the appropriate Linggen source.
  • Quickly switch which source / subproject Linggen is showing.

Getting Started

Installation

1. Install the extension in VS Code (from VSIX or marketplace when published)
2. Install Linggen by running the command Linggen: Install Linggen from the Command Palette (Cmd/Ctrl+Shift+P)
   • This will open https://linggen.dev in your browser with installation instructions
3. Start Linggen using Linggen: Start Linggen command
4. Index your project with Linggen: Index Current Project

Configuration

The extension can be configured via VS Code settings (Preferences: Open Settings (JSON)):

{
  "linggen.backend.mode": "http", // "cli" or "http"
  "linggen.backend.cliPath": "linggen", // Path to Linggen binary
  "linggen.backend.httpUrl": "http://localhost:8787", // Linggen server URL
  "linggen.backend.mcpUrl": "http://localhost:8787/mcp/sse", // Linggen MCP SSE endpoint
  "linggen.installUrl": "https://linggen.dev" // Installation page URL
}

Note: Both the main API and MCP endpoints run on port 8787.

Usage

1. Start Linggen: The extension will automatically start Linggen when needed, or you can run Linggen: Start Linggen from the Command Palette
2. Index your project: Run Linggen: Index Current Project to build the dependency graph (auto-starts Linggen if not running)
3. Open files in Linggen: Right-click any file or folder in the Explorer and select Linggen: Open in Linggen (auto-starts Linggen if not running)
4. Configure Cursor integration: Run Linggen: Configure Cursor msp.json to automatically create the configuration file

Cursor Integration

To integrate Linggen with Cursor:

1. Run Linggen: Configure Cursor mcp.json command
2. The extension will automatically create or update .cursor/mcp.json in your workspace
3. Restart Cursor to apply the changes

The command will:

• Create .cursor/mcp.json if it doesn't exist
• Update the existing file if it already exists (preserving other MCP servers)
• Add the Linggen MCP server configuration

Example mcp.json configuration that will be created:

{
  "mcpServers": {
    "linggen": {
      "url": "http://localhost:8787/mcp/sse"
    }
  }
}

Note: The MCP endpoint uses Server-Sent Events (SSE) and runs on port 8787 by default. If your Linggen MCP server runs on a different port, update the linggen.backend.mcpUrl setting before running the configure command.

Development

Building from source

npm install
npm run compile

Running the extension

1. Open this folder in VS Code
2. Press F5 to open a new window with the extension loaded
3. Run commands from the Command Palette

Testing

npm test

Architecture

• Extension layer: TypeScript VS Code extension using the vscode API
• Backend communication: Communicates with Linggen via CLI commands or HTTP API (configurable)
• Commands: All commands are registered in package.json and implemented in src/extension.ts
• Logging: Dedicated "Linggen" output channel for debugging and status messages

License

MIT
