Ifc for VS Code
VS Code extension for editing IFC physical files (.ifc) — the text-based exchange format defined by ISO 10303-21, commonly used in building information modeling (BIM) and other STEP-based workflows.
Core capability: full EXPRESS WHERE validation. Most .ifc editors stop at syntax or attribute typing. This extension evaluates the IFC4X3 EXPRESS schema in depth — 752 entity WHERE rules, type WHERE, Global RULE, UNIQUE constraints, and DERIVE expressions — so constraint violations surface inline in the Problems panel as you edit.
Open any .ifc file and the extension activates automatically. No extra configuration is required.
Repository: github.com/JIM-GLITCH/ifc · Issues: github.com/JIM-GLITCH/ifc/issues · Licensed under MIT.
Features
Language recognition
- Registers the Ifc language for files with the
.ifc extension
- Applies the correct language mode, grammar, and editor behavior as soon as you open a file
Syntax highlighting
Colorizes the structure of ISO 10303-21 exchange files so you can scan large models more easily, including:
- File header and data section markers (
ISO-10303-21;, HEADER;, DATA;, ENDSEC;, etc.)
- Entity instance references (
#123)
- Keywords, strings, numbers, enumerations, and binary values
- Line (
//) and block (/* */) comments
Smart editing
- Bracket and quote matching for
( ), [ ], { }, ', and "
- Auto-closing pairs when you type opening brackets or quotes
- Familiar comment toggling via
Ctrl+/ / Cmd+/ (line comments) and block comment support
Language Server (LSP)
A built-in language server analyzes your file as you edit and integrates with standard VS Code features:
| Feature |
What it does |
| Diagnostics |
Syntax errors plus EXPRESS WHERE validation — entity/type WHERE, Global RULE, UNIQUE, and DERIVE — inline and in the Problems panel |
| Go to Definition |
Jump to the entity instance referenced by a # id |
| Find All References |
See every place an entity instance is used in the file |
| Completion |
Context-aware suggestions based on the ISO 10303-21 grammar |
| Document sync |
Keeps analysis up to date while you type |
Server activity is logged in the Output panel under Ifc Language Server.
Validation layer status bar
When an .ifc file is the active editor, the status bar shows IFC n/3 — how many of the three validation tiers are enabled. Click it (or run IFC: Toggle Validation Layers) to open a quick pick:
| Tier |
Setting |
What it controls |
| Structure |
ifc.validation.structure |
STEP encoding (ifc-param-*), attribute types (ifc-param-type, ifc-entity-type, ifc-enum-*), aggregate bounds, unknown/abstract entity |
| Types |
ifc.validation.types |
Type WHERE (ifc-type-where), DERIVE * evaluation (ifc-eval-unknown on derived attributes) |
| Rules |
ifc.validation.rules |
Entity WHERE (ifc-entity-where), Global RULE (ifc-global-rule), UNIQUE (ifc-unique, ifc-unique-aggregate) |
Lexer/parser errors and unresolved # linker diagnostics are always reported regardless of these toggles. Changing a setting re-validates open .ifc files automatically.
You can also edit the same keys under Settings → Ifc.
During each validation pass the language server:
- Indexes inverse relations once when building the entity population (forward
# references → inverse lists such as IsTypedBy). Entity WHERE rules query this index; they do not rescan the file.
- Caches attribute values (
eval_cache) keyed by entity #id and attribute name so Types-layer DERIVE checks and Rules-layer Entity WHERE do not repeat the same DERIVE or parameter conversion work.
- Memoizes schema-derived lookups — supertype closures, EXPRESS↔STEP name resolution,
TYPEOF qualified names, attribute index maps, forward-inverse merges, and SELECT type resolution are computed once per schema entry instead of per entity instance. On a 150-story reference model this makes full validation (all tiers) ~7x faster.
- Indexes entity references by name —
#N references resolve through a per-document name index (built once per build) instead of scanning every symbol per reference, making the linking phase ~9x faster on large files.
Turn off Types or Rules in the status bar if you want faster feedback while editing and only need structural checks.
EXPRESS schema validation (IFC4 / IFC4X3)
This extension validates .ifc files against the IFC4X3 EXPRESS schema (compiled from the official schema; files declaring IFC4, IFC4X3, or IFC4X3_DEV_* in FILE_SCHEMA are accepted).
Validation goes beyond STEP syntax and attribute typing — it evaluates EXPRESS constraints from the schema. The status-bar tiers map to these checks:
| Tier (status bar) |
What is checked |
| Structure |
Parameter count; $ / * encoding; attribute types; enums; # entity types; aggregate bounds; unknown/abstract entity |
| Types |
Type WHERE on defined types; DERIVE evaluation for omitted * attributes |
| Rules |
Entity WHERE (752 rules for IFC4X3); Global RULE; UNIQUE and OF UNIQUE aggregates |
Always reported (not toggled): STEP parse errors and unresolved # linker diagnostics.
Optional $ values are treated as absent (no type-level WHERE on missing data). Derived * values are checked using computed DERIVE results where evaluators are available.
WHERE and RULE evaluation uses lazy short-circuiting: once a branch cannot be evaluated, later OR/AND branches in the same rule are skipped, and further WHERE rules on the same entity may be skipped when an eval-unknown is already recorded.
Diagnostics are anchored to the most specific location available: derived * tokens, other parameter tokens, or the declaring entity #id. Related entities in a reference chain (e.g. a parent IFCGEOMETRICREPRESENTATIONCONTEXT and its IFCGEOMETRICREPRESENTATIONSUBCONTEXT children) may each report issues so you can see the full impact radius.
Diagnostic codes (shown in the Problems panel):
| Code |
Meaning |
ifc-unknown-entity |
Entity keyword is not in the schema |
ifc-abstract-entity |
Abstract entity cannot be instantiated |
ifc-param-count |
Too many parameters, or a required parameter is missing |
ifc-param-required |
Required attribute is $ (unset) |
ifc-param-derived |
* used on a non-derived attribute |
ifc-param-type |
Value shape or type does not match the attribute |
ifc-entity-type |
# reference points to the wrong entity type |
ifc-enum-value |
Invalid enumeration literal |
ifc-typed-keyword |
Typed parameter keyword does not match the attribute type |
ifc-type-where |
Violates a WHERE rule on a defined type |
ifc-entity-where |
Violates an entity WHERE rule |
ifc-global-rule |
Violates a global RULE |
ifc-unique |
Violates an entity UNIQUE constraint |
ifc-unique-aggregate |
Duplicate element in a UNIQUE aggregate |
ifc-aggregate-bounds |
Aggregate element count outside declared [low:high] bounds |
ifc-eval-unknown |
Expression or constraint check could not be evaluated (e.g. DERIVE failure, parameter conversion failure). Entity WHERE / Global RULE messages include the rule label when applicable. |
Requirements
Installation
- Download or obtain the extension package (
ifc-vscode.vsix).
- In VS Code, open the Extensions view (
Ctrl+Shift+X on Windows/Linux, Cmd+Shift+X on macOS).
- Click the
... menu at the top of the Extensions sidebar.
- Choose Install from VSIX... and select the
.vsix file.
- Reload VS Code if prompted.
After installation, open any .ifc file to start using syntax highlighting and language-server features.
Usage tips
- Use Go to Definition (
F12) on a # entity reference to navigate to its declaration.
- Use Find All References (
Shift+F12) to trace how an entity is referenced elsewhere in the file.
- Check the Problems panel (
Ctrl+Shift+M / Cmd+Shift+M) for parse and EXPRESS validation issues.
- Click
IFC n/3 in the status bar (when an .ifc file is active) to enable or disable Structure / Types / Rules validation tiers.
- Filter Problems by diagnostic code (e.g.
ifc-entity-where, ifc-type-where) to focus on a class of errors.
- For troubleshooting, open View → Output and select Ifc Language Server from the dropdown.
Known limitations
- Support targets the ISO 10303-21 physical file format (
.ifc text files). Other IFC representations (e.g. IFC-XML, IFC-ZIP) are not covered.
- Validation uses a compiled IFC4X3 schema; entities or types from other schema releases may not be recognized.
- DERIVE codegen covers all schema DERIVE slots; failed DERIVE/type-WHERE evaluation reports
ifc-eval-unknown instead of silently skipping. Unresolved # references are reported by the linker only (not duplicated as eval-unknown). Optional $ / EXPRESS absent values still skip checks. Disable the Types tier to skip DERIVE and Type WHERE when validation feels slow on large files.
- Files with parse errors skip Global RULE and UNIQUE validation; remaining EXPRESS checks may still report eval-unknown on affected entities and parameters.
- This is an EXPRESS / schema validator, not a full BIM certification tool: no geometry kernel, IDS/MVD filtering, or clash detection.
- The extension focuses on single-file editing; cross-file workspace analysis depends on how your files are organized.
