OpenWire

Expose VS Code language models as an OpenAI-compatible REST API on localhost.

One extension. Every model VS Code can see. Standard API. Built for agents.

Features

• OpenAI-compatible. /v1/chat/completions and /v1/models, with SSE streaming.
• Auto-discovery. Every language model registered in VS Code shows up. No configuration.
• Enforced JSON mode. response_format is honoured server-side: strict instruction, JSON recovery from prose, schema validation, and a bounded repair retry.
• Sampling controls. temperature, top_p, max_tokens, stop, seed and penalties are forwarded to the model.
• Image input. OpenAI image_url parts reach vision-capable models (VS Code 1.125+).
• No silent no-ops. Anything OpenWire cannot honour is rejected or reported back in the response. GET /v1/capabilities states what this build supports.
• Tool forwarding. Send OpenAI-format tools, get tool_calls back, with full tool_choice support.
• XML tool call fallback. Non-streaming responses containing a <function_calls> block are converted to tool_calls.
• Rate limiting. Configurable per-minute request cap.
• API key auth. Bearer token authentication enabled by default.
• Tight CORS defaults. Browser requests are limited to loopback origins.
• Zero dependencies. Node's built-in HTTP server, no Express.

Models

Any model registered with VS Code's Language Model API is exposed automatically. In practice that means:

• Claude. Whatever Anthropic model family/tier is currently registered by an installed extension (e.g. Opus, Sonnet, Haiku)
• GPT. Whatever OpenAI model family is currently registered by an installed extension (e.g. GPT and reasoning-tier variants)
• Gemini. Whatever Google model family is currently registered by an installed extension (e.g. Pro, Flash)
• Ollama. Only when a separate extension registers your local models with VS Code. OpenWire never talks to Ollama directly.
• Anything else registered with the VS Code Language Model API

Call GET /v1/models to see what your setup actually exposes.

Provider compatibility

OpenWire normalises differences between providers so callers get a consistent OpenAI-format response:

Image input additionally requires VS Code 1.125 or newer, whatever the provider.

Content normalisation. Message content can be a plain string or an array of parts; assistant content may also be null when valid tool_calls are present. Text parts flatten to a plain string. User image_url parts are carried through as binary image data rather than dropped. Malformed messages, unknown roles, role-incompatible images, and unsupported content parts are rejected with a 400 instead of being silently normalised or discarded.

Tool call fallback. A model can answer with a raw XML <function_calls> block instead of a native tool call. On non-streaming requests OpenWire parses that block into standard tool_calls and strips it from the message content. Streaming requests rely on native tool-call parts, so an XML block can still reach the client as ordinary text.

Request parameters

OpenWire never silently ignores a parameter. Every field lands in one of four buckets, and GET /v1/capabilities reports the split for the running build.

Set openWire.server.strictParams to true to turn the Reported bucket into 400s as well. That gives agents a hard guarantee that unsupported fields are rejected. It cannot guarantee that a model provider applies fields in the Forwarded bucket; check the provider's own capabilities when those controls are required.

Invalid values are rejected rather than clamped. temperature: 9 returns a 400; it does not quietly become 2.

prompt is honoured only by /v1/completions. Sending it to /v1/chat/completions has no effect, so it is reported there like any other unknown field.

Streaming requests carry the same report in a metadata-only frame (choices: []) emitted before the first content delta, so stream: true is not a way to lose it.

JSON mode

The VS Code Language Model API has no provider-level JSON mode, so OpenWire enforces response_format itself:

1. A strict instruction is appended to the conversation.
2. The reply is parsed. JSON is recovered even when wrapped in prose or ```json fences.
3. For json_schema, the value is validated against the schema.
4. On failure, OpenWire retries once with a harsher instruction that quotes the bad output.
5. If it still cannot produce valid JSON it returns 502. It never returns prose that claims to be JSON.

curl http://localhost:3030/v1/chat/completions \
  -H "Authorization: Bearer $OPENWIRE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "<model-id>",
    "messages": [{"role": "user", "content": "Rate this repo out of 10"}],
    "response_format": {
      "type": "json_schema",
      "json_schema": {
        "name": "rating",
        "schema": {
          "type": "object",
          "required": ["score"],
          "properties": {"score": {"type": "integer", "minimum": 0, "maximum": 10}}
        }
      }
    }
  }'

json_object guarantees a JSON object. A bare scalar or array is treated as a failure and sent back through the repair retry, so JSON.parse(content).field is always safe.

Supported schema keywords. type, enum, const, required, properties, additionalProperties (boolean or sub-schema), items (single schema), minimum, maximum, minLength, maxLength, minItems, maxItems. Annotations such as title and description are ignored.

Anything else returns a 400 rather than being accepted and left unenforced — including $ref, allOf, anyOf, oneOf, patternProperties, and the tuple form of items.

Streaming. Validity cannot be judged mid-stream, so a JSON-mode request with stream: true buffers the reply, enforces the contract, then emits it as a single content delta followed by [DONE]. The SSE contract is preserved; the token-by-token behaviour is not.

Images

Vision requests use the standard OpenAI content-part shape:

{
  "model": "<model-id>",
  "messages": [{
    "role": "user",
    "content": [
      {"type": "text", "text": "What is in this screenshot?"},
    ]
  }]
}

• Base64 data: URIs only. Remote http(s) image URLs return a 400. OpenWire will not fetch a URL on your behalf, because that would let any caller drive requests from your machine into your own network.
• Supported types. image/png, image/jpeg, image/gif, image/webp.
• Validated bytes. Base64 must be canonical and non-empty, the file signature must match the declared MIME type, and each decoded image is limited to 8 MiB.
• Requires VS Code 1.125 or newer, where LanguageModelDataPart reached the stable API. On older builds an image request returns 501 rather than silently dropping the image. Check image_input.supported in GET /v1/capabilities.
• Image payloads are large, so the request body limit defaults to 10 MB (openWire.server.maxRequestBodyMb).

Quick start

Install from the VS Code Marketplace, or load the .vsix yourself. The server starts on http://127.0.0.1:3030 as soon as VS Code loads the extension.

If you haven't set openWire.server.apiKey, OpenWire generates a random key each session — check the "OpenWire" output channel after the server starts to find it, or set your own fixed key in settings.

export OPENWIRE_API_KEY="<key from the OpenWire output channel, or your own configured value>"

# List available models
curl http://localhost:3030/v1/models \
  -H "Authorization: Bearer $OPENWIRE_API_KEY"

# Chat completion
curl http://localhost:3030/v1/chat/completions \
  -H "Authorization: Bearer $OPENWIRE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "<model-id>",
    "messages": [{"role": "user", "content": "Hello"}]
  }'

# Streaming
curl http://localhost:3030/v1/chat/completions \
  -H "Authorization: Bearer $OPENWIRE_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "<model-id>",
    "messages": [{"role": "user", "content": "Explain zero-knowledge proofs"}],
    "stream": true
  }'

Replace <model-id> with any id from GET /v1/models. OpenWire matches on model id or family and has no built-in aliases, so an unrecognised name returns a 404 listing what is available.

Endpoints

Configuration

All settings live under openWire.server.* in VS Code:

Commands

• OpenWire: Start Server
• OpenWire: Stop Server
• OpenWire: Restart Server
• OpenWire: Toggle Server

Using with OpenClaw

OpenWire works as a model provider for OpenClaw agents. Register OpenWire as a custom provider called copilot-proxy in your ~/.openclaw/openclaw.json:

{
  "models": {
    "providers": {
      "copilot-proxy": {
        "baseUrl": "http://localhost:3030/v1",
        "apiKey": "<key from the OpenWire output channel, or your own configured value>",
        "api": "openai-completions",
        "models": [
          {
            "id": "<model-id>",
            "name": "<Display Name>",
            "contextWindow": 128000,
            "maxTokens": 8192
          }
          // add any other models from /v1/models
        ]
      }
    }
  },
  "agents": {
    "defaults": {
      "model": {
        "primary": "copilot-proxy/<model-id>"
      }
    }
  },
  "plugins": {
    "entries": {
      "copilot-proxy": { "enabled": true }
    }
  }
}

OpenWire requires a Bearer token by default. Set a custom openWire.server.apiKey in VS Code and use the same value in OpenClaw.

Architecture

src/
  extension.ts          activation, commands, status bar
  models/
    discovery.ts        model discovery, caching, dedup
  routes/
    chat.ts             vscode binding + orchestration
    content.ts          message/content normalisation, image parts
    params.ts           sampling params, capability classification
    json-mode.ts        response_format enforcement
    schema.ts           JSON Schema subset validator
    tool-calls.ts       tool mapping, tool_choice, XML fallback
    legacy.ts           text_completion shape for /v1/completions
    errors.ts           RequestError with an HTTP status
  server/
    config.ts           settings loader
    gateway.ts          HTTP server, routing, middleware
  ui/
    sidebar.ts          webview sidebar panel
  test/
    vscode-mock.ts      in-memory vscode stand-in for tests
    gateway.test.ts     end-to-end HTTP tests
  types/
    vscode-lm.d.ts      type augmentations

Everything under `routes/` except `chat.ts` is free of `vscode` imports, so it is unit
tested directly. `gateway.test.ts` runs the real server over HTTP against a mocked
`vscode` module, aliased in `vitest.config.ts`.

Development

Clone the repo and install dependencies:

npm install

Start esbuild in watch mode, then press F5 in VS Code to launch the Extension Development Host with OpenWire loaded:

npm run watch

.vscode/launch.json has two configurations. "Run Extension" builds once and launches. "Run Extension (Watch)" starts the watcher for you. Reload the Development Host window to pick up a rebuild.

npm run package fails when @types/vscode is newer than engines.vscode, so raising the types version means raising the engine floor too. The reverse is not checked. Raising engines.vscode on its own packages and publishes without complaint, which leaves the types older than the VS Code version the extension now claims to support, so bump @types/vscode to match by hand.

Releasing

CI runs lint, build and test on Node 20 and 22, and packages the extension once on Node 20. The .vsix from that run is uploaded as a build artifact, so you can install a branch build before it ships. It runs on every pull request whatever base branch it targets, so stacked branches are covered too.

To cut a release:

1. Bump version in package.json and merge that to main.
2. Tag the merge commit as vX.Y.Z, matching the version you just set.
3. Push the tag.

The Release workflow checks the tag against the version in package.json and stops if they disagree. It then runs lint, build and test, packages a single .vsix, publishes that exact file to the VS Code Marketplace, and attaches it to a GitHub release. Publishing needs a VSCE_PAT repository secret.

License

MIT
