mdimgup: Markdown Image Upload for VS Code

mdimgup is a VS Code extension that uploads local images referenced in Markdown files to S3-compatible cloud storage (Cloudflare R2, AWS S3, MinIO, DigitalOcean Spaces, Backblaze B2, etc.), then updates the image links in-place.

Features

Scan Markdown files for local image links (![alt](https://github.com/leonwong282/mdimgup/raw/HEAD/path))
Resize images (except GIFs) to a configurable max width before upload
Upload images to any S3-compatible storage using AWS S3 API
Replace Markdown image links with CDN URLs after upload
Parallel uploads with configurable concurrency
In-memory cache to avoid duplicate uploads in a session
Support for multiple storage providers: Cloudflare R2, AWS S3, MinIO, DigitalOcean Spaces, and more

Requirements

An S3-compatible storage account and bucket (see Supported Providers)
Storage credentials and domain configured in VS Code settings
Only local image paths are uploaded; remote URLs are skipped

Supported Providers

✅ Cloudflare R2 - Object storage with zero egress fees
✅ AWS S3 - Amazon's industry-standard object storage
✅ MinIO - Self-hosted S3-compatible storage
✅ DigitalOcean Spaces - Simple object storage with CDN
✅ Backblaze B2 - Affordable cloud storage
✅ Any S3-compatible service - Use the s3-compatible provider mode

Extension Settings

Quick Start: Choose Your Provider

Cloudflare R2 (Recommended for blogs)

{
	"mdimgup.storageProvider": "cloudflare-r2",
	"mdimgup.accountId": "your_account_id",
	"mdimgup.bucket": "my-blog-images",
	"mdimgup.accessKey": "your_access_key",
	"mdimgup.secretKey": "your_secret_key",
	"mdimgup.cdnDomain": "https://cdn.example.com",
	"mdimgup.pathPrefix": "blog",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

How to get credentials:

Go to Cloudflare Dashboard → R2
Create a bucket
Create an API token with R2 read/write permissions
Set up a custom domain for your bucket

AWS S3

{
	"mdimgup.storageProvider": "aws-s3",
	"mdimgup.region": "us-east-1",
	"mdimgup.bucket": "my-blog-images",
	"mdimgup.accessKey": "AKIAIOSFODNN7EXAMPLE",
	"mdimgup.secretKey": "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY",
	"mdimgup.cdnDomain": "https://my-blog-images.s3.amazonaws.com",
	"mdimgup.pathPrefix": "images",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

How to get credentials:

Go to AWS IAM Console
Create an IAM user with S3 permissions
Create access keys for the user
Create an S3 bucket in your desired region
Configure bucket permissions (public read or CloudFront)

MinIO (Self-hosted)

{
	"mdimgup.storageProvider": "s3-compatible",
	"mdimgup.endpoint": "https://minio.example.com",
	"mdimgup.bucket": "blog",
	"mdimgup.accessKey": "minioadmin",
	"mdimgup.secretKey": "minioadmin",
	"mdimgup.cdnDomain": "https://minio.example.com/blog",
	"mdimgup.pathPrefix": "",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

How to set up:

Install MinIO: docker run -p 9000:9000 minio/minio server /data
Access MinIO Console (default: http://localhost:9000)
Create a bucket and access keys
Set bucket policy to public if needed

DigitalOcean Spaces

{
	"mdimgup.storageProvider": "s3-compatible",
	"mdimgup.endpoint": "https://nyc3.digitaloceanspaces.com",
	"mdimgup.region": "nyc3",
	"mdimgup.bucket": "my-space",
	"mdimgup.accessKey": "DO00EXAMPLE",
	"mdimgup.secretKey": "your_secret_key",
	"mdimgup.cdnDomain": "https://my-space.nyc3.cdn.digitaloceanspaces.com",
	"mdimgup.pathPrefix": "blog",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

How to get credentials:

Go to DigitalOcean Cloud
Create a Space in your preferred region
Generate API keys under API → Spaces Keys
Enable CDN for your Space (recommended)

Backblaze B2

{
	"mdimgup.storageProvider": "s3-compatible",
	"mdimgup.endpoint": "https://s3.us-west-001.backblazeb2.com",
	"mdimgup.bucket": "my-bucket",
	"mdimgup.accessKey": "your_key_id",
	"mdimgup.secretKey": "your_application_key",
	"mdimgup.cdnDomain": "https://f001.backblazeb2.com/file/my-bucket",
	"mdimgup.pathPrefix": "blog",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

How to get credentials:

Go to Backblaze B2 Console
Create a bucket
Create an application key with read/write access
Use the S3-compatible endpoint for your region

All Settings Reference

Setting	Type	Default	Description
`mdimgup.storageProvider`	`"cloudflare-r2"` \| `"aws-s3"` \| `"s3-compatible"`	`""` (auto-detect)	Storage provider type
`mdimgup.endpoint`	string	`""`	Custom S3 endpoint (required for s3-compatible)
`mdimgup.region`	string	`"auto"`	AWS region (e.g., `us-east-1`)
`mdimgup.bucket`	string	`""`	S3 bucket name
`mdimgup.accessKey`	string	`""`	S3 access key ID
`mdimgup.secretKey`	string	`""`	S3 secret access key
`mdimgup.accountId`	string	`""`	Cloudflare R2 account ID (R2 only)
`mdimgup.cdnDomain`	string	`""`	CDN domain for uploaded images
`mdimgup.pathPrefix`	string	`"blog"`	Path prefix for uploads (e.g., `images`, `uploads/2025`)
`mdimgup.maxWidth`	number	`1280`	Max image width (px) before resize
`mdimgup.parallelUploads`	number	`5`	Number of concurrent uploads
`mdimgup.useCache`	boolean	`true`	Cache uploaded images (session-only)

Legacy R2 Settings (Deprecated)

If you're using the old R2-specific settings, they will continue to work but are deprecated:

{
	"mdimgup.r2AccountId": "...",
	"mdimgup.r2Bucket": "...",
	"mdimgup.r2AccessKey": "...",
	"mdimgup.r2SecretKey": "...",
	"mdimgup.r2Domain": "..."
}

Migration: Replace r2* settings with the new generic settings above. Your existing configuration will work without changes.

Usage

Open a Markdown file in VS Code
Right-click and select Upload Markdown Images to Cloud Storage from the context menu
Wait for the progress notification; image links will be updated automatically

Extension Settings

Configure these in your VS Code settings:

{
	"mdimgup.r2AccountId": "...",
	"mdimgup.r2Bucket": "...",
	"mdimgup.r2AccessKey": "...",
	"mdimgup.r2SecretKey": "...",
	"mdimgup.r2Domain": "https://your.cdn.domain",
	"mdimgup.maxWidth": 1280,
	"mdimgup.parallelUploads": 5,
	"mdimgup.useCache": true
}

Usage

Open a Markdown file in VS Code
Right-click and select Upload Markdown Images to Cloud Storage from the context menu
Wait for the progress notification; image links will be updated automatically

Examples

Before Upload

![My Screenshot](https://github.com/leonwong282/mdimgup/raw/HEAD/images/screenshot.png)
![Diagram](https://github.com/leonwong282/mdimgup/raw/HEAD/../assets/diagram.jpg)

After Upload

![My Screenshot](https://cdn.example.com/blog/1700000000000-screenshot.png)
![Diagram](https://cdn.example.com/blog/1700000000001-diagram.jpg)

Developer Workflows

Build: npm run compile or npm run watch
Lint: npm run lint
Test: npm run test (see src/test/extension.test.ts)
Debug: Use VS Code extension development host (F5)

Key Files

Main logic: src/extension.ts
Tests: src/test/extension.test.ts
Settings & commands: package.json

Known Issues

Extension will error if storage provider settings are missing or incomplete
Only supports local image paths (remote URLs are skipped intentionally)
Session-only cache (clears when VS Code restarts)

Troubleshooting

"Storage configuration missing" error

Check that all required settings for your provider are configured
For Cloudflare R2: accountId, bucket, accessKey, secretKey, cdnDomain
For AWS S3: region, bucket, accessKey, secretKey, cdnDomain
For S3-compatible: endpoint, bucket, accessKey, secretKey, cdnDomain

Images not uploading

Verify your credentials have write permissions to the bucket
Check that the bucket exists and is accessible
Ensure the bucket allows public read access (or configure your CDN)

CDN URLs not working

Verify cdnDomain is correctly configured
Check bucket CORS settings if accessing from web
Ensure custom domain DNS is properly configured (for R2/Spaces)

Release Notes

0.1.0 (Latest)

🎉 Multi-provider support: Now supports AWS S3, MinIO, DigitalOcean Spaces, Backblaze B2, and any S3-compatible service
✨ New generic settings: storageProvider, endpoint, region, bucket, accessKey, secretKey, cdnDomain, pathPrefix
🔄 100% backward compatible with existing R2 configurations
📝 Deprecated legacy r2* settings (still supported)
🎨 Updated command title to "Upload Markdown Images to Cloud Storage"
🛠️ Customizable path prefix (no longer hardcoded to blog/)
📚 Comprehensive documentation with provider-specific setup guides

0.0.1

Initial release with Cloudflare R2 support

See CHANGELOG.md for details.
