kymostudio — Diagram Preview (VS Code)

Live SVG preview for kymostudio diagrams, right inside VS Code. Both formats render natively, in-process, by the bundled, dependency-free kymostudio JS engine.

.diagram (the DSL) — parsed and positioned (grid / auto-layout, parent/child alignment, auto-bounded regions, auto-canvas) via parseDiagram, then rendered with renderSVG.
BPMN 2.0 (.bpmn) — imported via the file's Diagram-Interchange geometry (parseBpmn) and rendered with renderSVG.

Features

Open Preview to the Side button in the editor title bar for .bpmn / .diagram files (also in the Command Palette and the Explorer context menu).
Live re-render as you type (debounced) — toggle with kymostudio.preview.autoRefresh (off = refresh on save only).
Zoom & pan: scroll to zoom toward the cursor, drag to pan, plus toolbar buttons (− / + / Fit / reset).
Export SVG from the preview toolbar, or via kymostudio: Export Diagram as SVG….
Background: light · dark · transparent (kymostudio.preview.background).

Usage

Open a .diagram or .bpmn file.
Click the Open Preview to the Side icon (top-right of the editor), or run kymostudio: Open Preview from the Command Palette.
The diagram renders beside the source and updates as you edit.

Settings

Setting	Default	Description
`kymostudio.preview.background`	`light`	Canvas fill: `light`, `dark`, or `transparent`.
`kymostudio.preview.autoRefresh`	`true`	Re-render on every edit (debounced). When `false`, refresh on save only.

Build from source

The extension bundles the kymostudio JS engine, so build that package first:

# 1. build the JS engine (produces packages/js/dist)
cd packages/js && npm install && npm run build

# 2. build the extension bundle (dist/extension.js)
cd ../vscode-extension && npm install && npm run build

Then press F5 in VS Code (with this folder open) to launch an Extension Development Host, or package a VSIX:

npm run package   # → kymostudio-vscode-<version>.vsix  (npx @vscode/vsce)

npm run watch rebuilds on change; npm run typecheck runs tsc --noEmit.

How it works

src/render.ts dispatches by file extension — .diagram through parseDiagram(text), .bpmn through parseBpmn(text) — then renderSVG(diagram) from the kymostudio package, handing the SVG string to a webview that does nothing but display, zoom, and pan it. Rendering runs entirely in the extension host — the webview never parses diagrams — and esbuild inlines the engine into a single CommonJS file, so the shipped extension carries no runtime dependencies.

License

Apache-2.0 — see LICENSE.
