SimIDE (Simulation + IDE)

SimIDE — Real-time C++ debugging and interactive Data Structures & Algorithms (DSA) simulation directly in your Visual Studio Code sidebar.

SimIDE (Simulation + IDE) helps students, educators, and developers master C++ memory management and pointer-based data structures. As you step through your code, SimIDE dynamically watches the running program, extracts heap state, and renders an interactive, physics-driven canvas with plain English explanations for every pointer assignment, deletion, and traversal.

This is a real developer tool connected directly to native GDB/LLDB via VS Code's Debug Adapter Protocol (DAP)—not a pre-recorded animation, disconnected simulation, or static mockup.

Table of Contents

• Why SimIDE?
• Key Features
• Architecture Overview
• Quick Start
• Prerequisites
• Installation & Setup
• Usage Walkthrough
• Visual Design System & Physics Canvas
• 8 Distinct UI States
• Testing & Verification
• FAQ & Troubleshooting
• Roadmap
• Contributing
• License
• Contact

Why SimIDE?

Learning pointer-based data structures in C++ is notoriously challenging:

• Raw memory addresses like 0x74a3b0 and 0x74a3f0 in the debugger's variable pane are difficult to mentally map into a linked chain.
• Learners often confuse heap allocation (new Node{10, nullptr}) with linking (head = first; or first->next = second;).
• Disconnected browser simulators force students to copy and paste code away from their real IDE, losing access to language servers and compiler diagnostics.

SimIDE solves this right inside VS Code:

1. You write standard C++ code in the editor.
2. Click [ Visualize ] in the Debug Mentor sidebar.
3. The extension compiles your code with debug flags (-g -O0 -std=c++17), launches GDB/LLDB, captures state upon every step, and renders interactive diagrams with pedagogical teaching explanations.

Key Features

• Genuine Debugger Execution: Runs real native C++ binaries using VS Code's Debug Adapter Protocol (DAP). Stepping in Debug Mentor advances the actual C++ program and highlights the live source line in the VS Code editor.
• Dynamic Pointer Discovery: Discovers any pointer variables in the user's code dynamically via source regex and line thresholds—no hardcoded variable names!
• Pointer Aliasing Tracking: Visually flags when multiple pointers refer to the same heap node (e.g., head aliasing first at 0x74a3b0).
• Spring-Damper Physics Canvas: Powered by a hybrid physics engine (integrated with d3-force). Nodes behave as physical bodies connected by elastic springs with natural recoil and repulsion.
• Excalidraw-Style Infinite Pan & Zoom: Navigate large diagrams with Right-Click Pan, Mouse Wheel Zoom (0.35x to 2.5x), Spacebar drag, double-click reset, and a quick ↺ Reset layout button—with zero clunky scrollbars!
• Detached Allocation Tracking: Uniquely tracks local unlinked node allocations (first, second, newNode) before they are linked into head, helping students visualize the moment memory is allocated versus when it is connected.
• Pedagogical Step Explanations: Generates clear, plain English teaching explanations for every mutation (e.g., "The node containing 10 now points to the node containing 20.").
• C Runtime (CRT) Boundary Protection: Detects when execution reaches return 0; or C runtime exit routines, cleanly finishing execution and preserving the completed linked list diagram without flickering.
• Non-Destructive Time Travel: Review past states by clicking Previous without terminating or corrupting the running C++ process. Step forward again to seamlessly resume live debugging.

Architecture Overview

Debug Mentor coordinates four decoupled subsystems across process boundaries:

+-------------------------------------------------------------------------+
|                        VS CODE EXTENSION HOST                           |
|                                                                         |
|  [src/extension.ts] ──▶ [LinkedListViewProvider] (Sidebar Webview Hub)  |
|                                │                                        |
|         ┌──────────────────────┼──────────────────────┐                 |
|         ▼                      ▼                      ▼                 |
|  [src/debug/]           [src/visualization/]     [webview/app.ts]       |
|  • CppCompiler          • LinkedListModel        • Spring Physics Engine|
|  • DebugSessionManager  • ExplanationGenerator   • Pan & Zoom Camera    |
|  • DebugAdapterTracker  • SnapshotManager        • SVG Dynamic Arrows   |
|  • ExecutionController  • Pointer Models         • Dot-Grid Canvas      |
|  • StateExtractor                                                       |
+---------│─────────────────────────────────────────────▲-----------------+
          │ (DAP Protocol)                              │ (Typed IPC)
          ▼                                             │
+───────────────────────+                     +──────────────────+
| Native GDB / LLDB     |                     | Sidebar Webview  |
| (Real C++ Process)    |                     | (Chromium View)  |
+───────────────────────+                     +──────────────────+

Complete Documentation

For comprehensive technical deep-dives, please explore the docs/ directory:

• System Architecture: Process boundaries, DAP wire protocol, dynamic pointer discovery, and CRT protection.
• Component Deep-Dive: Module-by-module breakdown of all source files.
• Data Flow & Lifecycles: Sequence diagrams for launch, stepping, physics loop, and time-travel.
• AI Agent Guide: Developer guide for automated agents and contributors adding new data structures.

Quick Start

# 1. Clone the repository
git clone https://github.com/debug-mentor/vscode-debug-mentor.git
cd vscode-debug-mentor

# 2. Install dependencies
npm install

# 3. Build the extension and webview bundles
npm run compile

# 4. Run the automated test suite (verifies GCC, physics models & real GDB stepping)
npm test

To launch and test the extension interactively in VS Code:

1. Open the project folder in VS Code (code .).
2. Press F5 to open the Extension Development Host.
3. Open examples/linked-list.cpp.
4. Click the Debug Mentor icon in the Activity Bar.
5. Click [ Visualize ] and step through your code!

Prerequisites

Before running the extension, verify your system has the following tools installed:

1. Visual Studio Code: v1.85.0 or higher.
2. C++ Compiler: g++ (MinGW-w64 on Windows, GCC on Linux) or clang++ accessible in system PATH.
3. Debugger: gdb or lldb accessible in system PATH.
4. C/C++ Extension: ms-vscode.cpptools installed in VS Code.
5. Node.js: v18+ (tested on Node v20 and v26).

Installation & Setup

Building from Source

# Install Node dependencies (includes d3-force physics)
npm install

# Build bundles via esbuild
npm run compile

Packaging into a VSIX Extension (Optional)

npx @vscode/vsce package

This generates a .vsix file that can be installed into any Visual Studio Code instance using:

code --install-extension simide-0.1.0.vsix

Usage Walkthrough

Debug Mentor includes a complete singly linked list sample in examples/linked-list.cpp:

#include <iostream>
using namespace std;

struct Node {
    int data;
    Node* next;
};

int main() {
    Node* head = nullptr;
    Node* first = new Node{10, nullptr};
    head = first;
    Node* second = new Node{20, nullptr};
    first->next = second;
    Node* third = new Node{30, nullptr};
    second->next = third;
    return 0;
}

Step-by-Step Experience

1. Open File: Open examples/linked-list.cpp in the editor.
2. Open Sidebar: Click the Debug Mentor icon in the VS Code Activity Bar.
3. Click Visualize: Click the large blue [ Visualize ] button.
   • The status spinner updates: "Compiling source..." → "Starting debugger...".
4. Paused at Entry (Step 1):
   • GDB pauses at main().
   • Sidebar displays prompt: "Program paused at start of main(). Click Next to execute: Node head = nullptr;"*
5. Step 2 (Detached Allocation): Click [ Next ].
   • first = new Node{10, nullptr}; executes.
   • The detached card first (10) appears in the physics canvas with a spring connection to nullptr.
6. Step 3 (Head Connected & Aliasing): Click [ Next ].
   • head = first; executes.
   • head points to node 10, aliasing first: "head points to the node containing 10 (aliasing pointer 'first' at address 0x74a3b0)."
7. Steps 4–6 (Building the Chain): Click [ Next ] repeatedly.
   • Watch nodes 20 and 30 allocate and link one by one until the full chain is formed: head ──▶ [ 10 | • ] ──▶ [ 20 | • ] ──▶ [ 30 | • ] ──▶ nullptr.
8. Interacting with Canvas:
   • Click and drag any node card to test the spring elasticity.
   • Right-click drag to pan across the canvas.
   • Scroll mouse wheel to zoom in or out.
   • Click ↺ Reset to return to default layout.
9. Time Travel: Click [ Previous ] to rewind back through past states and inspect earlier pointer assignments.

Visual Design System & Physics Canvas

The user interface uses a curated, high-contrast dark theme designed to blend seamlessly with VS Code:

8 Distinct UI States

The sidebar is built as an explicit state machine transitioning through 8 visual states:

1. Screen 1 — Initial IDE State: Minimalist welcome view with brand icon, subtitle, and primary [ Visualize ] button.
2. Screen 2 — Loading / Launching: Animated spinner with live status updates ("Preparing C++ program", "Compiling source", "Starting debugger").
3. Screen 3 — Debugger Paused, Initial State: Paused at main(), step 1 chip, empty canvas message, execution controls enabled.
4. Screen 4 — First Node Allocated: Detached allocation first (data: 10) visible in the canvas with spring link to nullptr.
5. Screen 5 — First Node Connected: head connects to node 10, indicating pointer aliasing.
6. Screen 6 — Second Node Added: Node 20 connected: head ──▶ 10 ──▶ 20 ──▶ nullptr.
7. Screen 7 — Final Linked List: Complete 3-node chain: head ──▶ 10 ──▶ 20 ──▶ 30 ──▶ nullptr. Program execution finished.
8. Screen 8 — Error State: Informative diagnostic card with error title, scrollable compiler/debugger logs, and a [ Retry ] button.

Testing & Verification

Debug Mentor includes a dual-layer automated test suite:

• Unit & Mock Tests (test/runTests.ts): Verifies compiler path resolution, C++ compilation flags, snapshot history, and explanation generation across all states.
• Headless GDB Integration Test (test/gdbExecution.test.ts): Spawns real GDB as a child process against compiled C++ binaries, stepping line-by-line and verifying runtime memory values (10, 20, 30).

Running Tests

npm test

Verified Test Matrix

FAQ & Troubleshooting

Why does the compiler need the -O0 flag?

Compiler optimization levels (-O1, -O2, -O3) optimize away temporary pointer variables (like Node* first) into registers or inline them entirely. Compiling with -O0 ensures every variable exists in stack memory so the debugger can inspect it.

Can I pan and zoom the diagram?

Yes! Use Right-Click Drag, Middle-Click Drag, or Space + Left-Click Drag to pan. Use the Mouse Wheel to zoom in or out. Double-click the background or click ↺ Reset to re-center.

Can I step backwards in the real C++ execution?

Debug Mentor's Previous button navigates historical snapshots stored during execution. It does not send reverse-step commands to GDB, because GDB reverse debugging requires hardware record/replay targets that are not universally supported across Windows, Linux, and macOS.

What should I do if compilation fails with EBUSY on Windows?

On Windows, a running debugger locks the output .exe. Debug Mentor automatically detects locked files and compiles to an alternate timestamped executable (e.g. linked-list_1792051440937.exe). If an issue persists, click Restart or close hanging GDB processes.

Roadmap

• [x] Milestone 1: Singly Linked List visualization with GDB integration, spring-damper physics canvas, pan/zoom camera, dynamic pointer discovery, and time-travel history.
• [ ] Milestone 2: Doubly Linked Lists with bidirectional SVG arrows (prev and next).
• [ ] Milestone 3: Binary Search Trees (BST) with tree layout algorithm and branch visualization.
• [ ] Milestone 4: Stacks and Queues with push/pop animations.
• [ ] Milestone 5: Memory leak detection highlighting unreferenced heap allocations that fall out of scope without delete.

Contributing

Contributions from students, educators, and developers are warmly welcomed!

1. Fork the repository.
2. Create a feature branch: git checkout -b feature/doubly-linked-list.
3. Check the AI Agent & Developer Guide for architecture guidelines and conventions.
4. Make changes and verify that npm run compile and npm test pass cleanly.
5. Commit your changes: git commit -m 'feat: Add doubly linked list support'.
6. Push to your branch and open a Pull Request.

License

This project is licensed under the MIT License. See the LICENSE file for details.

Contact

• Issues & Bug Reports: GitHub Issues
• Discussion & Feature Requests: GitHub Discussions
• Maintainer: VS Code Debug Mentor Team
