Demo

The walkthrough's five chapters:

#	At	Chapter
01	0:00	Analyze workspace
02	0:06	Dependency graph
03	0:30	Data flow
04	0:40	Agent context file
05	0:51	Your own AI provider

---

Why RepoGraph AI

RepoGraph AI turns any repository into an AI coding agent graph — a machine-readable map with files as nodes and imports & calls as typed edges, so both you and your AI agent can navigate, summarize, and question the codebase with full structural context. Most code-graph tools ask you to run a CLI, index a database, or open a browser tab. RepoGraph AI takes a different path:

• Zero setup. Open any folder and the graph builds itself — no CLI, no config files, no per-project reruns, no terminal.
• Honest by design. Every edge carries a provenance label — EXTRACTED (read directly from source), INFERRED (derived by analysis), or AMBIGUOUS (uncertain, low confidence). The graph always tells you what it knows versus what it guessed.
• AI optional. The full graph, flow diagrams, guided tour, health report, and agent-context export all work with no API key at all. Add a key only when you want AI-written summaries and Q&A.
• Agent-ready. One click exports REPOGRAPH-CONTEXT.md — a compact, factual snapshot your coding agent reads instead of burning tokens re-scanning the whole repo. Fewer tokens, fewer hallucinated imports, fewer "fixes" that undo things you already fixed.
• Private. No telemetry, no backend, no account. Everything except the optional AI call runs on your machine.

Who it's for: indie hackers · freelancers · OSS maintainers · students · startup teams · agencies · enterprises · researchers — anyone who reads code, especially on day one of a new codebase.

---

The Panel — A Tour

RepoGraph AI lives in a sidebar panel with six tabs. Here is what each one does, top to bottom.

1 · Analyze

The command center. Shows the current workspace, provider status, and a single Analyze Workspace button that walks a visible 5-step pipeline — scan files → build graph → repo summary → file summaries → flow diagrams — with live progress and status after each step. After the run you get the agent-context export card here (one click to save REPOGRAPH-CONTEXT.md).

2 · Graph

An interactive, force-directed map of your workspace: every file is a node, every import an edge.

• Search any file by name; hover to highlight its connections; drag and zoom freely.
• Click a node to open a detail panel: what this file imports, what imports it, its language, size, and a one-click jump to the file in your editor.
• 2D ↔ 3D toggle — flip the same graph onto a 3D sphere with perspective depth. Same nodes, same edges, same sizes; drag rotates the globe, shift-drag pans, scroll zooms. Big repos stay readable because every node renders near-equal on the sphere.
• Friend-link detection: edges needing inference (aliases, path shims, call chains) are labeled and counted, so you always know how much of the picture is hard evidence.

3 · Insights (summaries + Q&A)

The reading tab — and the thinking one.

• Repo overview: plain-English overview, architecture description, tech stack, entry points, and key modules — with a heuristic version available even with no API key.
• File cards: the most important files, each with its purpose, exports, and key functions. No more opening random files to find where things live.
• Q&A chat: ask anything — "where is authentication handled?", "which files touch the database?", "how does routing work?". The agent expands your question against the codebase's actual vocabulary, walks the dependency graph up to 3 hops, keeps the answer within a token budget, and cites the files it used. Multi-turn, with history — paste any answer straight into your agent. When the graph can't support an answer, it says so instead of inventing one.
• Agent-context export button lives here too.

4 · Flow

Auto-generated flow diagrams of how the system actually behaves — rendered as tiles you click to open full-size.

• Preset questions (API request, Auth flow, Component data, DB writes…) plus a free-text box: "how does checkout work?" generates a custom diagram grounded in your code.
• Multiple dialects, picked automatically — flowcharts, sequence diagrams, class diagrams, and single-function control flow (see Flow Diagrams below).
• Guided tour — a recommended reading order across diagrams for newcomers.
• Click-to-line chips — related files carry exact file:line targets; clicking one opens the editor scrolled there.
• Exports — save any diagram as .mmd (git-diffable Mermaid), .svg, or .json.

5 · History

Every analysis is a named, timestamped snapshot stored locally. Reload any past analysis to compare how the codebase looked before and after a refactor, and delete records you no longer need.

6 · Settings

Pick one of five AI providers, paste a key (stored in VS Code's encrypted SecretStorage), choose/change model names, and toggle auto-indexing. Keys never leave your machine.

---

Screenshots

Dependency Graph (3D)	Communities (2D)
The whole repo on a sphere — frontend (gold) and backend (blue) hemispheres, hover to trace imports	In 2D the same graph falls apart into natural clusters — backend and frontend separate on their own
Complete data-flow	Settings
Every route → middleware → handler → next hop, exported from the Flow tab — saved as .mmd/.svg/.json with one click	Five AI providers with recommended models, FREE/PAID badges — keys stay in VS Code encrypted SecretStorage

---

Features In Depth

One-Click Auto-Index

The defining feature: you never run anything.

• Open a folder → RepoGraph scans it and builds the graph within seconds. The status bar shows live index state.
• A FileSystemWatcher watches your code files; save a change and the graph updates after a short ~1.5 s debounce — always current, never in your way. No per-project config, no server to keep running: install once, open any folder, hit Analyze Workspace, and the graph is ready in seconds — switch projects and repeat, same flow every time.
• Results are cached to disk with a content-hashed manifest: on reopen, only files whose contents actually changed are reprocessed, so the same project loads near-instantly (cache lives in VS Code's storage dir; no artifacts polluting your repo).
• Manual control whenever you want it: RepoGraph AI: Reindex Workspace forces a full rebuild, and the repograph.autoIndex setting can turn the magic off.

Provenance Dependency Graph

Not just that things connect, but how we know:

Edge label	Meaning	Confidence
EXTRACTED	Parsed directly from a real import/require/use statement	1.0
INFERRED	Resolved through aliases, call chains, or heuristics	0.85
AMBIGUOUS	Multiple candidates or unresolved path	0.3

On top of that evidence model, the builder computes:

• God nodes — files whose change ripples widest, ranked by degree.
• Blast radius — pick any file and see everything reachable within 2 hops before you refactor it.
• Communities — the graph is clustered into natural modules, so large repos don't turn into hairballs.
• Health report — automatic diagnosis with warnings (hub overload, orphan clusters, high ambiguity rate) and a shareable graph report.

Flow Diagrams

One diagram type is never enough, so RepoGraph picks the right dialect per question:

Diagram	What it shows	Built from
Flowchart	End-to-end system flow, module hubs, component/data/auth flows	Routes, call chains, DB access, events
Sequence	Ordered request lifecycle: client → handler → middleware → service → DB → response	Real routes + middleware stacks + call chains
Class	Classes, interfaces, and uses relationships	File summaries + import edges
Function control flow	Branches, loops, try/catch, and DB/emit markers inside one function — every node tagged with file:line	On-demand extraction (enter file + function name)

The end-to-end flow and the sequence + class diagrams are deterministic — computed from static analysis, never from a language model — so they exist even with no API key and are always trustworthy. When AI generates additional diagrams, they pass through safeguards that generic diagram generators skip:

• Grounding validator — every node label must match a real route, symbol, file, or method from the static index. Invented labels are dropped; a diagram falling below a minimum edge count is rejected and replaced with the deterministic fallback. The AI can decorate, but it cannot invent.
• Cycle fixer — self-loops and malformed edges are repaired before rendering.
• Guided tour — diagrams are ordered into an onboarding path: end-to-end first, then request order, API surface, data layer, auth — up to six steps.
• Health badges — tiles touching god files get a visible risk badge.

Agent Context Export — the Token Saver

One click writes REPOGRAPH-CONTEXT.md to your workspace root, ready to paste into (or be read by) any coding agent — Copilot, Cursor, Claude Code, Codex, OpenCode, Windsurf, Cline — instead of letting it re-scan the repo. The export reports its approximate token count and estimated savings vs. raw source.

What's inside:

• Overview, architecture, tech stack, entry points, key modules
• Top 15 files with purpose + exports
• Key symbols with file:line locations, ranked by export status and hub centrality
• The 60 most central dependency edges (a hub neighbourhood, not a 250-line dump)
• Routes, call chains, data access, events, middleware
• Up to six flow diagrams embedded as Mermaid
• Compact, noise-filtered file tree

And one line agents need to hear:

Note for agents: imports above are a static-analysis snapshot, not verified ground truth. Cross-check by reading source files before refactoring.

That single line — plus grounded, file:line-referenced facts — is what stops agents from re-fixing things you already fixed and importing modules that don't exist.

Works With or Without an API Key

Capability	No key (static mode)	With AI
Dependency graph + provenance + god nodes	✅	✅
2D / 3D views	✅	✅
Flow diagrams (flowchart, sequence, class, function)	✅ deterministic	✅ + AI-generated extras, validated
Guided tour + health badges	✅	✅
REPOGRAPH-CONTEXT.md export	✅ (facts only)	✅ + AI prose sections
Repo & file summaries	Heuristic	AI-written
Q&A in Insights	—	✅

---

Installation

From the VS Code Marketplace:

Search RepoGraph AI in the Extensions panel (Ctrl+Shift+X) and click Install — or paste this into the Command Palette:

ext install kaushalendra.repograph-ai

From a .vsix file:

code --install-extension repograph-ai-1.0.0.vsix

---

Quick Start

Step 1 — Open a project. That's it. The graph builds itself within seconds of opening a folder — watch the status bar. No CLI, no setup, no per-project reruns.

Step 2 — Explore immediately (no key needed):

• Graph tab — dependency map with provenance, god nodes, and the 2D/3D toggle
• Flow tab — end-to-end, sequence, and class diagrams with a guided tour
• Export REPOGRAPH-CONTEXT.md for your coding agent from Analyze or Insights

Step 3 — (Optional) Add AI. Open the RepoGraph panel → Settings → pick a provider → paste your key. It's stored encrypted via your OS keychain and never leaves your machine. Start free with Groq: https://console.groq.com/keys

Step 4 — Analyze with AI. Click Analyze Workspace for AI summaries and full Q&A. Most repos of 50–500 files finish in under a minute.

Commands & settings:

Item	What it does
Ctrl+Shift+P → RepoGraph AI: Open Panel	Focus the RepoGraph sidebar
RepoGraph AI: Reindex Workspace	Force a full graph rebuild
repograph.autoIndex (setting, default true)	Auto-build/update the graph on folder open and file save

---

Supported AI Providers

Works with the provider you already pay for. All five support custom model names, keys stay in your keychain, and switching providers never requires re-analyzing your workspace.

Provider	Cost	Default model	Best for	Auth
Groq	Free tier	llama-3.3-70b-versatile	Instant answers. Fast LPU-backed cloud inference; generous free limits to start.	API key
Ollama	Completely free	qwen3 on http://localhost:11434	Offline privacy. Run open models on your own machine — no key, no cloud, no source code leaving the laptop.	None required
Google Gemini	Free quota	gemini-2.5-flash	Long context for whole-repo questions. The free quota is enough to get started.	API key
Anthropic Claude	Paid	claude-sonnet-4-5	Careful reasoning and precise file:line citations for complex refactors and deep codebases.	API key
OpenAI	Paid	gpt-4o-mini	Battle-tested consistency for summaries, Q&A and docs at scale.	API key

Model names are configurable per provider via repograph.<provider>.model (e.g. repograph.groq.model) and repograph.<provider>.baseUrl (e.g. for Ollama).

---

Supported Languages

20+: TypeScript · JavaScript · Python · Go · Rust · Java · Kotlin · C/C++ · C# · Ruby · PHP · Swift · Vue · Svelte · Astro · GraphQL · Prisma · SQL · Shell

---

Compare

Graphs, grep, or review bots? The usual shortlist for reading a repo — and what each tool actually does inside yours. (Also on the website.)

Compared on	RepoGraph AI	Sourcegraph	Greptile	CodeRabbit
Runs on your machine	✅ parsing stays in the editor	❌ cloud index	❌ cloud SaaS	❌ cloud SaaS
Every import, mapped	✅ interactive graph + god nodes	✳️ search-first code intel	❌ graph, but review-only	❌ diffs, not a graph
Works fully offline	✅ with Ollama, zero cloud	❌ needs the cloud	❌ needs the cloud	❌ needs the cloud
Any AI provider (BYO key)	✅ Groq · Ollama · Gemini · Claude · OpenAI	❌ built-in models only	❌ built-in only	❌ built-in only
Ready in one install	✅ open any repo → it analyzes	❌ index a repo first	❌ connect repo, wait on index	❌ install the GitHub app
Install once, use in any project	✅ no per-repo setup	❌ index each repo first	❌ connect repo by repo	❌ set up per repo
Open source (MIT)	✅ auditable, forkable	✳️ open clients, closed core	❌ proprietary	❌ proprietary
Free to start	✅ free — bring your key	✳️ free tier → paid teams	❌ paid per dev	✳️ free for OSS → paid

---

How It Works

Open Workspace
      |
Auto-Index (extension.ts + RepoGraphPanel)
  - Immediate scan on folder open (debounced ~1.5 s)
  - FileSystemWatcher keeps the graph live on save
  - Disk cache (GraphCache): content-hashed manifest,
    incremental diff → instant reopen, rebuild only what changed
      |
WorkspaceScanner
  - Reads all source files, skips generated/build outputs
      |
GraphBuilder (provenance graph)
  - extractSymbols() → exported functions/classes with file:line
  - resolveImportWithProvenance() → EXTRACTED / INFERRED / AMBIGUOUS edges
  - Call-chain edges, community detection, god nodes,
    blast radius (2-hop), health diagnosis
      |
FlowAnalyzer
  - Extracts routes, middleware, DB access, events, call chains
      |
FlowDiagramAgent
  - Deterministic builders: end-to-end flowchart, sequence, class, function CFG
  - Optional AI diagrams → grounding validator + cycle fixer
  - Guided tour ordering + health badges
      |
AI Agents (your API key — optional)
  - RepoSummaryAgent → overview, architecture, tech stack
  - FileSummaryAgent → per-file purpose and exports (batched)
  - QAAgent          → vocab-constrained graph traversal Q&A with citations
      |
Webview Panel (6 tabs)
  Analyze · Graph · Insights · Flow · History · Settings

The entire pipeline runs locally. The only external call is to the AI provider you choose.

---

Project Structure

repograph-ai/
├── src/
│   ├── extension.ts                # Entry point: auto-index, watcher, status bar, commands
│   ├── providers/
│   │   ├── types.ts                # AIProvider interface
│   │   ├── GroqProvider.ts         # + Ollama, Gemini, Anthropic, OpenAI providers
│   │   └── index.ts                # Provider registry
│   ├── analyzer/
│   │   ├── WorkspaceScanner.ts     # File discovery and content reading
│   │   ├── GraphBuilder.ts         # Provenance graph: symbols, typed edges, communities,
│   │   │                           #   god nodes, blast radius, health, report
│   │   ├── GraphCache.ts           # Disk cache: content hash, manifest diff, load/save
│   │   ├── FlowAnalyzer.ts         # Route/middleware/DB/event/call-chain extraction
│   │   └── RepoFetcher.ts          # Remote-repo helpers
│   ├── agents/
│   │   ├── RepoSummaryAgent.ts     # Repo-level overview (+ heuristic fallback)
│   │   ├── FileSummaryAgent.ts     # Per-file summaries (+ heuristic fallback)
│   │   ├── FlowDiagramAgent.ts     # Diagram builders, grounding validator, guided tour
│   │   └── QAAgent.ts              # Traversal Q&A with citations
│   └── panel/
│       ├── RepoGraphPanel.ts       # WebviewViewProvider + auto-index orchestration
│       ├── handlers/               # Analysis, Flow, File, Export, History, Settings
│       └── webview/                # Tab HTML, scripts (graph/flow/messaging/ui), styles
├── docs/                           # Architecture deep-dives (see docs/README.md)
├── scripts/build-webview.js        # Assembles the webview bundle
├── public/                         # Icon, demo poster, logos, screenshots
├── package.json                    # Extension manifest
└── tsconfig.json

---

Development

Prerequisites: Node.js 18+, VS Code 1.85+

git clone https://github.com/Kaushalendra-Marcus/RepoGraph-AI
cd repograph-ai
npm install
npm run compile

Press F5 in VS Code to open the Extension Development Host with the extension loaded.

npm run compile runs two steps: TypeScript compilation (tsc -p ./) and the webview bundle build (node scripts/build-webview.js → out/webview-bundle.html). The webview is assembled from separate source files under src/panel/webview/ — edit those, not the bundle.

Watch mode (recompiles on save):

npm run watch

Package for distribution:

npm install -g @vscode/vsce
npm run compile
vsce package

This produces a .vsix file you can share or install locally.

---

Documentation

Deeper dives live in docs/ and on the website:

Doc	Topic
01-architecture	Extension structure and message flow
02-graph	Provenance graph, god nodes, blast radius
03-flow-diagrams	Flow tab, diagram kinds, grounding validator
04-summary	Repo & file summary agents
05-qa	Traversal Q&A design
06-ai-tools	AI tool integrations
07-settings-providers	Provider configuration
08-history	Analysis snapshots
09-analysis-pipeline	The 5-step pipeline end to end
10-design-ui	Webview design system

---

FAQ

Is RepoGraph AI really free? Yes — 100% free and MIT-licensed. Bring your own key from Groq (free tier) or Ollama (fully local). No subscription, no account, no paywall.

Does my code get sent to a server? No. There is no backend. The only external call is to the AI provider you configure. Everything else stays on your machine.

Which AI providers are supported? Groq, Ollama, Gemini, Claude and OpenAI — with custom model names. Switch providers anytime without re-analyzing.

What is an AI coding agent graph? A machine-readable map of a repository: files as nodes, imports and calls as typed edges. RepoGraph AI builds exactly this graph for any repo, so both you and an AI coding agent can navigate, summarize, and question the codebase with full structural context.

Can coding agents use the RepoGraph agent graph? Yes. Export REPOGRAPH-CONTEXT.md and point your agent at it (Cursor, Copilot, Claude Code, Codex, OpenCode, Windsurf, Cline) — cited structure in, no wasted tokens re-reading files. v2.0 goes further: the flow tracer will export the repo graph as typed trace records agents can consume directly.

How large a codebase can it handle? Files are processed in batches with generated code skipped. Most repos of 50–500 files finish in under a minute.

I'm new to a project. Where do I start? Analyze the workspace once: the dependency graph shows you what connects to what, the repo overview explains the architecture, and Q&A answers "where is X handled?" with file references. Most developers go from zero to productive in a single sitting.

How is it different from other repo graph tools? Most repo graph tools only draw static pictures. RepoGraph AI combines a live dependency graph, per-file AI summaries, multi-turn codebase Q&A, five AI providers, and zero telemetry — free and open source, entirely inside VS Code.

Which languages are supported? 20+: TypeScript, JavaScript, Python, Go, Rust, Java, Kotlin, C/C++, C#, Ruby, PHP, Swift, Vue, Svelte, Astro, GraphQL, Prisma, SQL, Shell.

Why did my AI diagram disappear after analysis? The grounding validator rejected it — its labels didn't match real routes, symbols, files, or methods in your repo. The deterministic fallback you see instead is the honest version.

---

Roadmap · v2.0

Flow tracing is coming — not just what a file imports, but where each value travels:

• Hop-by-hop tracer — walks call edges across files, every hop declaring its input and output, so the whole path is auditable.
• trace.json artifact — the full path saved per workspace; diff it across refactors, and let coding agents consume the typed trace records directly.
• Flow view in-panel — click any hop to jump straight to the line.

Follow the GitHub repo to catch the release.

---

Privacy

Your code never leaves your machine. No backend. No account. No tracking. The only network request is to the AI provider you configure.

Data	Where it goes
Your workspace	Analyzed locally, in VS Code only
Graph + summaries	Local storage
File snippets	AI provider only (the one you configure)
Our servers	✕ do not exist
Analytics	✕ none
Account required	✕ never

Key guarantees:

• Encrypted key storage — keys live in VS Code SecretStorage via the OS keychain; never plaintext on disk
• Zero telemetry — no analytics, no crash reports; fully offline except AI calls
• Open source & auditable — every line public on GitHub; read it, verify it, fork it
• Everything except the optional AI call runs entirely on your machine — scanning, graph building, flow extraction, caching, and exports are all local

---

Creator

Built by a dev, for devs. No team, no roadmap committee: RepoGraph AI is designed, built, and maintained in the open by Kaushalendra Yadav — AI engineer building tools that make codebases legible, and the person behind every release.

GitHub · Marketplace · Website

---

Contributing

Contributions are welcome. This project is MIT licensed and open to everyone.

Read CONTRIBUTING.md to get started. For significant changes, please open an issue first to discuss what you'd like to change.

Good first issues:

• Adding support for a new programming language in GraphBuilder.ts
• Improving import resolution accuracy
• Deepening the function control-flow extraction (e.g. structured CFG instead of regex)
• Adding new suggested questions in the Q&A tab

---

Changelog

See CHANGELOG.md for the full history.

---

License

MIT — free to use, modify, and distribute. See LICENSE for details.

---
