Unreal Angelscript VS Code Extension

English | 中文

Table of Contents

English Overview Quick Start Core Features Offline Cache Language Model Tools LM Tool Templates Build Known Limits Fork Maintenance Upstream

目录

中文 概览 快速开始 核心功能 离线缓存 Language Model Tools LM Tool Templates 构建 已知限制 维护策略 上游

English

Overview

This extension provides language server and debugger support for UnrealEngine-Angelscript, with additional LM tools in this fork.

Quick Start

1. Use an Unreal Editor build with Angelscript enabled.
2. Open either your project's Script folder itself, or its parent folder that contains Script, in VS Code.
3. Start Unreal Editor. The extension connects automatically.

Notes:

• Core language features run across all resolved Script roots from the current workspace folders.
• LM tool filePath inputs and outputs use normalized absolute paths.
• Supported workspace layouts are strict: the root must be Script itself, or contain <workspace>/Script.
• Startup indexing scans only resolved Script roots (Script/**/*.as), not the entire workspace tree.
• Runtime file watching and incremental parse/update handling are also restricted to resolved Script roots only.
• Initial indexing honors UnrealAngelscript.scriptIgnorePatterns.
• If workspace folders change after activation, reload the window to refresh Script-root watchers and indexing.
• Unsupported workspace layouts fail fast with an error message and skip initial indexing.

Core Features

• Code completion, go to definition, rename, find references, semantic highlighting.
• Compile errors from Unreal Editor on save.
• Debugging support, breakpoints and exception pause.
• Context commands: Go to Symbol, Wrap with //#region.

Some features degrade when Unreal Editor is disconnected.

Offline Cache

The extension restores cache data at startup to provide baseline capabilities without an active engine connection.

• Cache path: Script/.vscode/angelscript/unreal-cache.json
• Refresh trigger: DebugDatabaseFinished or DebugDatabaseSettings
• Includes: DebugDatabase chunks, scriptSettings, engineSupportsCreateBlueprint
• Excludes: assets, script-index
• Corrupt or version-mismatched cache is ignored safely
• Write strategy: temp file + fsync + rename

Language Model Tools

Exposed tools:

• angelscript_searchApi
• angelscript_resolveSymbolAtPosition
• angelscript_getTypeMembers
• angelscript_getClassHierarchy
• angelscript_findReferences

Tool notes:

• angelscript_searchApi: Requires query. Default mode is smart; use regex only with /pattern/flags. kinds is a hard filter. symbolLevel=type still lets members or mixins match, but only returns owner class|struct|enum results. scope narrows a known namespace or type before ranking, includeInheritedFromScope only changes class scopes, and includeDocs=true adds docs without changing ranking.
• angelscript_resolveSymbolAtPosition: Requires absolute filePath plus 1-based position. includeDocumentation defaults to true.
• angelscript_getTypeMembers: Requires exact name; namespace only disambiguates collisions. type.description is always returned, while member docs need includeDocs=true.
• angelscript_getClassHierarchy: Requires exact class name. maxSuperDepth, maxSubDepth, and maxSubBreadth bound the returned tree and default to 3/2/10.
• angelscript_findReferences: Requires absolute filePath plus 1-based position. limit defaults to 30 and caps results at 200.

Output rules:

• This repository now implements VS Code Language Model Tool only.
• There is no built-in MCP server/runtime in this repository.
• LM tools always return human-readable text. Structured JSON is optional.
• UnrealAngelscript.languageModelTools.outputMode controls LM output mode:
  • text-only (default)
  • text+structured
• Human-readable success text now defaults to a code-first style:
  • stable title line
  • declarations/snippets as the primary body
  • /** ... */ for normalized docs
  • // ... comments for owner, origin, range, scope, and truncation metadata
  • source previews rendered as lineNumber + ':'/'-' + 4 spaces + source text
• Human-readable text is always returned.
• Structured JSON is returned only when UnrealAngelscript.languageModelTools.outputMode=text+structured.
• text+structured and text-only do not change the text style.
• Input and output filePath use normalized absolute paths.
• For line-based results, text output includes source previews (max 20 lines, truncated with ... (truncated), fallback <source unavailable>).

Build

• npm install installs the root dependencies and the nested extension and language-server packages via postinstall.
• npm run compile builds both the extension bundle and the language server bundle.
• npm run watch watches both bundles during development.
• npm test runs the full test suite.
• npm run test:fork-boundary runs the fork-boundary regression suite for LM tool contracts and workspace layout behavior.
• npm run sync:lm-tools refreshes generated LM tool documentation in README.md, package.json, and face-ai-report.md.

LM Tool Templates

Detailed per-tool input/output templates live in lm-tool-templates.md.

Use that document as the maintained reference for:

• sample inputs
• success text shape
• success json shape
• representative error outputs

Known Limits

• When engine is disconnected, details depend on cached DebugDatabase and available doc fields.
• Cache is not written before DebugDatabase processing completes.
• This extension is incompatible with Hazelight.unreal-angelscript. On each startup, if that extension is installed, this extension shows an error message with an Open Extensions action, then stops initialization.

Fork Maintenance

This fork uses a layered-compatibility maintenance strategy to keep future upstream merges manageable.

• This repository follows a layered-compatibility strategy for future upstream merges.
• Detailed maintenance rules live in MAINTAINING.md.
• Agent and automation execution rules live in AGENTS.md.

Upstream

Language Server and Debug Adapter for UnrealEngine-Angelscript: https://angelscript.hazelight.se

中文

概览

这是 UnrealEngine-Angelscript 的 VS Code 扩展分支版本,提供语言服务与调试能力,并新增 LM tools 支持.

快速开始

1. 使用启用 Angelscript 的 Unreal Editor 版本.
2. 在 VS Code 中打开项目的 Script 文件夹本身,或打开其上一级且包含 Script 的目录.
3. 启动 Unreal Editor,扩展会自动连接.

说明:

• 核心语言功能会覆盖当前 workspace folders 中所有解析成功的 Script 根目录.
• LM tool 的 filePath 输入和输出统一使用标准化后的绝对路径.
• 工作区兼容策略为严格模式: 根目录必须是 Script 本身,或包含 <workspace>/Script.
• 启动索引只扫描解析后的 Script 根目录(Script/**/*.as),不会全盘递归扫描工作区.
• 运行期文件监听与增量解析/更新同样严格限制在解析后的 Script 根目录内.
• 初始索引会遵守 UnrealAngelscript.scriptIgnorePatterns.
• 如果激活后发生 workspace folders 变更,需要 reload window 才会刷新 Script watcher 和索引.
• 对不受支持的工作区形态会快速报错并跳过初始索引.

核心功能

• 代码补全、定义跳转、重命名、引用查找、语义高亮.
• 保存时展示 Unreal Editor 返回的编译错误.
• 调试支持,含断点与异常暂停.
• 右键命令: Go to Symbol、Wrap with //#region.

部分能力依赖 Unreal Editor 连接,断开时会降级.

离线缓存

扩展启动时会恢复缓存,在未连接引擎时提供基础能力.

• 缓存路径: Script/.vscode/angelscript/unreal-cache.json
• 刷新时机: DebugDatabaseFinished 或 DebugDatabaseSettings
• 包含: DebugDatabase chunks、scriptSettings、engineSupportsCreateBlueprint
• 不包含: assets、script-index
• 缓存损坏或版本不匹配会被安全忽略
• 写入策略: 临时文件 + fsync + rename

Language Model Tools

提供以下工具:

• angelscript_searchApi
• angelscript_resolveSymbolAtPosition
• angelscript_getTypeMembers
• angelscript_getClassHierarchy
• angelscript_findReferences

工具说明:

• angelscript_searchApi: 需要 query. mode 默认是 smart, 只有明确提供 /pattern/flags 时才使用 regex. kinds 是硬过滤. symbolLevel=type 允许成员或 mixin 参与命中, 但最终只返回 owner class|struct|enum. scope 会在排序前收窄已知 namespace 或 type, includeInheritedFromScope 只改变 class scope, includeDocs=true 只补全文档而不改变排序.
• angelscript_resolveSymbolAtPosition: 需要绝对路径 filePath 和 1-based 的 position. includeDocumentation 默认是 true.
• angelscript_getTypeMembers: 需要精确 name; namespace 只用于消除重名歧义. type.description 始终返回, 成员文档需要 includeDocs=true.
• angelscript_getClassHierarchy: 需要精确 class name. maxSuperDepth, maxSubDepth 和 maxSubBreadth 用来裁剪返回层级, 默认值是 3/2/10.
• angelscript_findReferences: 需要绝对路径 filePath 和 1-based 的 position. limit 默认 30, 最大 200.

输出规则:

• 当前仓库只实现 VS Code Language Model Tool.
• 仓库内不再提供内建 MCP server/runtime.
• LM tool 始终返回可读文本,结构化 JSON 为可选附加内容.
• UnrealAngelscript.languageModelTools.outputMode 用于控制 LM 输出模式:
  • text-only(默认)
  • text+structured
• 可读成功文本默认采用 code-first 风格:
  • 稳定标题行
  • 以声明式文本或源码片段作为主体
  • 文档统一归一化后渲染为 /** ... */
  • owner、来源、range、scope、truncation 等元信息统一使用 // ... 注释
  • 源码预览仍使用 行号 + ':'/'-' + 4 个空格 + 源码
• LM tool 始终返回可读文本.
• 只有在 UnrealAngelscript.languageModelTools.outputMode=text+structured 时才会附带结构化 JSON.
• text+structured 和 text-only 不会改变文本风格.
• 输入和输出 filePath 统一使用标准化后的绝对路径.
• 涉及行号/范围的结果会直接在文本中渲染源码片段(最多 20 行,超出追加 ... (truncated),不可读时为 <source unavailable>).

构建

• npm install 会安装根目录依赖,并通过 postinstall 安装嵌套的 extension 和 language-server 包依赖.
• npm run compile 会同时构建 extension bundle 和 language server bundle.
• npm run watch 会在开发时同时监听这两个 bundle.
• npm test 会运行完整测试集.
• npm run test:fork-boundary 会运行 fork boundary 回归测试,重点覆盖 LM tool contract 和 workspace layout 行为.
• npm run sync:lm-tools 会刷新 README.md、package.json 和 face-ai-report.md 中生成的 LM tool 文档.

LM Tool Templates

逐 tool 的输入/输出模板文档见 lm-tool-templates.md.

该文档用于持续维护:

• 输入示例
• 成功 text 形态
• 成功 json 形态
• 代表性错误输出

已知限制

• 引擎断开时,详情能力依赖缓存 DebugDatabase 与 doc 字段可用性.
• DebugDatabase 完整结束前不会写入缓存.
• 本扩展与 Hazelight.unreal-angelscript 不兼容. 每次启动如果检测到该扩展已安装,会弹出错误提示并提供 Open Extensions 入口,随后停止初始化.

维护策略

这个 fork 默认采用分层兼容维护策略,以便后续继续合并 upstream 时把冲突控制在可管理范围内.

• 本仓库采用 layered compatibility 策略来降低未来合并 upstream 的成本.
• 更完整的维护规则见 MAINTAINING.md.
• agent 和自动化执行约束见 AGENTS.md.

上游

Language Server and Debug Adapter for UnrealEngine-Angelscript: https://angelscript.hazelight.se
