Rhai Language Support for VS Code

VS Code extension dedicated to the Rhai scripting language, providing comprehensive syntax highlighting, file outline/structure, code formatting and snippets for optimal productivity.

🐛 Known Limitations

Syntax highlighting is basic and could be improved
Autocompletion is limited to snippets
Code formatter is rudimentary
Some third-party extensions may cause hover documentation to display twice — disable conflicting extensions to resolve the issue

⚙️ Recommended Configuration (VS Code native)

For Ctrl+Click to work as navigation (Go to Definition) instead of multi-cursor:

"editor.multiCursorModifier": "alt"

This allows:

Ctrl+Click = Go to Definition
Alt+Click = Multi-cursor

Author

jhenriot alias lemeran81

Features

🎨 Syntax Highlighting

Full Rhai syntax support:

Keywords: fn, const, let, if, else, for, in, while, switch, import, as, export, private, break, continue, return, throw, try, catch
Types: integers, floats, hexadecimal, binary, octal numbers
Operators: and, or, not, is, is_empty, is_undefined
Functions: definitions fn name() and calls name()
Objects: maps #{}, closures |...| {}
Strings: interpolation ${...} in double-quoted "" and template literals `...`
Comments: //, /* */, documentation /// and //!
Constants: true, false, ()

📋 Structure / Outline

The outline displays in the sidebar:

Functions (fn) — with name and parameters (e.g. create_weapon(name, description))
Constants (const) — in uppercase
Imports (import "module" as alias) — with alias and source module
Regions (// region: Name) — collapsible, with hierarchy

🔗 Go to Definition (Ctrl+Click)

Navigate quickly through your Rhai code, even across files:

Ctrl+Click (or F12) on a function name → jumps to its definition fn name()
Ctrl+Click on a constant → jumps to its definition const NAME
Ctrl+Click on module::function (e.g. p::get_equipment) → opens the imported file and jumps to the definition
Ctrl+Click on an import alias (e.g. p in import "character" as p;) → opens the module file
Ctrl+Click on a used alias (e.g. p:: in code) → opens the module file
Supports imports via import "file" as alias

Example:

import "character" as p;

// Ctrl+Click on p → opens character.rhai
// Ctrl+Click on get_equipment → opens character.rhai at the definition
let equipment = p::get_equipment(character);

📖 Hover Documentation

Hover over a function to see its documentation instantly with rich display:

Native Rhai functions: 🔷

Hover on type_of(), print(), debug(), len(), etc.
Colorful display with emoji and link to official documentation

User-defined functions (local and imported): 🟢

Hover on a function displays its formatted /// documentation
Local functions: documentation extracted from the current file
Imported functions: module::function() opens the imported file and displays its doc

Imported modules: 📦

Hover on an import alias (e.g. p) displays the module's //! documentation
Module documentation extracted from //! comments at the top of the file

Smart formatting:

📌 Headers (# Arguments, # Returns) in bold — 📌 skipped if header already contains an emoji
• Bullets for parameter lists (* and -)
`Inline code` preserved
Code blocks (\```) preserved as-is (no formatting inside)
Bold (**text**) preserved in documentation
Original file structure preserved (blank lines, line breaks)

Example:

// In character.rhai:
/// Calculates character hit points
///
/// # Arguments
/// * `constitution` - Constitution value (8-18)
/// * `level` - Character level (1-20)
///
/// # Returns
/// Calculated hit points
fn calculate_hp(constitution, level) {
    return constitution * 2 + level * 5
}

// In another file:
import "character" as p;

// Hovering p::calculate_hp() shows:
// 🟢 calculate_hp()
// Calculates character hit points
// ...
// 🔗 Imported from character
let hp = p::calculate_hp(12, 3);

🧩 Snippets

Snippet	Description
`fn`	Function with full RhaiDoc documentation
`const`	Constant declaration
`region`	Region markers with name
`import`	Module import with alias
`map`	Object map `#{}`
`closure`	Closure `\\|...\\| {}`
`for`	For loop
`if`	If/else condition

🔧 Code Formatter

Formats function signatures with one parameter per line:

Before:

fn create_weapon(name, description, impact_points) {

After (Shift+Alt+F):

fn create_weapon(
	name,
	description,
	impact_points,
) {

Formatter rules:

Each parameter on its own line with trailing comma
Indentation respected (tabs or spaces per VS Code settings)
Already well-formatted functions are not modified
Functions without parameters remain fn name() {
Supports existing multi-line signatures

Configuration:

rhai.format.enable: Enable/disable the formatter (enabled by default)

🗂️ Language Configuration

Comments: // line, /* */ block
Brackets: {}, [], (), #{}
Auto-closing: automatic character pairs
Folding: regions // region: / // endregion:
Indentation: automatic on { and }

Installation

Method 1: VSIX File

code --install-extension vscode-rhai-support-2026.1.2.vsix

Or via the UI:

Open Extensions (Ctrl+Shift+X)
Click ... (more actions)
Install from VSIX...
Select vscode-rhai-support-2026.1.2.vsix

Method 2: Local Development

cd vscode-rhai
npm install
npm run compile
# Press F5 to launch in VS Code

Usage

Automatic Highlighting

.rhai files are automatically recognized with dedicated syntax highlighting.

Outline

Open a .rhai file
The structure appears in the Explorer sidebar → Outline section
Click an element to navigate

Snippets

Start typing the snippet name, then Tab to insert:

fn [Tab]  → Generates a function with documentation

Colored Code Example

//! Character management module

// region: Types

const WARRIOR_CLASS = #{
    "name": "Warrior",
    "base_hp": 10
};

// endregion: Types

/// Creates a new character
///
/// # Arguments
///
/// * `name` - Character name
/// * `class` - Class key
fn create_character(
	name,
	class,
) {
    let char = #{
        "name": name,
        "class": WARRIOR_CLASS,
        "inventory": []
    };

    for item in char.inventory {
        if item.key == "sword" {
            print("Sword found!");
        }
    }

    char
}

import "utilities" as u;

License

MIT — jhenriot alias lemeran81
