Routiq

Test REST, GraphQL, WebSocket, SSE, gRPC and Kafka without leaving VS Code. Routiq is a lightweight Insomnia/Postman-style API client whose collections are plain JSON files you can commit to git.

Highlights

Install

Search for Routiq in the VS Code Extensions view, or run ext install israelsaraiva.routiq. Requires VS Code 1.85 or newer.

Quick start

HTTP

1. Open the Routiq view in the activity bar and click New Collection; add a request or import one (cURL, Postman, Insomnia, OpenAPI).
2. Enter a URL and press Send; the response appears below with status, time, size and a pretty-printed body.
3. Save or Ctrl/Cmd+S persists the request. Define {{variables}} under Environments to reuse them across requests.

Kafka

1. Open the Kafka view in the activity bar and click New Connection (or run Routiq: Open Kafka Listener).
2. Enter brokers and topics (or pick Use Test Kafka for a local broker), choose a start position and press Connect.
3. Watch messages arrive grouped by flow, then use the Send, Topics, Consumer groups and Cluster tabs.

Need more? Run Routiq: Help for a searchable guide and Routiq: About for versions and diagnostics (see Help and About).

Screenshots

Variables are highlighted as defined or unresolved, with autocomplete while you type.

GraphQL queries with variables, schema support and a pretty-printed response.

The Kafka listener groups messages into flows and filters by topic, text and headers.

Consumer groups	Send to Kafka

Topics	Cluster

gRPC	Scripts and tests

Environments	Collection runner

Settings

Security note on scripts

Pre-request and post-response scripts are JavaScript that runs on your machine. Only run scripts from collections you trust; Routiq asks for consent before running scripts of a collection and applies a time limit (see Script security).

Usage

1. Open the Routiq view in the activity bar.
2. New Collection, then right-click it (or use the inline buttons) → New Request or New Folder.
3. Click a request to open its editor: method, URL, Params / Headers / Body (none, JSON, XML, text, form-urlencoded, multipart form, binary file, GraphQL) / Auth (none, bearer, basic, API key in header/query, OAuth 2.0 client-credentials/password, Digest).
4. Send runs the request from the extension host (Node 18+ fetch, default 30 s timeout) and shows status, time, size, headers and a pretty-printed body.
5. Save or Ctrl/Cmd+S persists the request.

Layout and appearance

The request editor and response share a resizable split: drag the divider (or focus it and use the arrow keys, double-click to reset) and use the layout button next to Response to switch between stacked and side-by-side. The choice is remembered. The method selector is colour-coded, tabs show counts of active params/headers, the response shows a coloured status badge with time/size chips, and the collections tree shows a coloured dot per HTTP method with a markdown tooltip. Everything uses VS Code theme colours, so it follows light, dark and high-contrast themes.

Folders

A collection holds requests and nested folders (any depth). Right-click a collection or folder → New Folder / New Request; folders can be renamed, duplicated (with their contents) and deleted. Drag and drop in the tree moves requests and folders between folders and collections. Dropping on a collection or folder appends to it; dropping on a request places the dragged item before it when moving up and after it when moving down (VS Code does not expose the exact drop position). Dropping a folder on a sibling folder reorders them instead of nesting. A folder can't be moved into itself or its own subfolders. Order is stored in the collection file, so it is shared when the storage folder is committed.

Sorting and moving

• Sort (collection or folder context menu → Sort): A→Z, Z→A or by Method (GET, POST, PUT, PATCH, DELETE, others, then name), each also as a (Recursive) variant. Folders come first, comparison is natural and case-insensitive. Sorting is a one-time reorder that is saved; you can keep dragging afterwards.
• Sort Collections A→Z / Z→A are in the view title … menu. Collections have Move Collection Up/Down in their context menu; dropping a collection on the empty area of the tree moves it to the end.
• Subcollections: drag a collection onto another collection or folder (or use Move to…) to turn it into a folder there. Its requests and folders move along; its base variables and environments are merged into the target without overwriting existing values (environments match by name), secret values follow into the target, and anything that could not be merged is listed in a warning. The active environment selection and the old collection's cookies are not carried over. Promote Folder to Collection (context menu, Move to… → New top-level collection, or dragging a folder to the empty area) does the reverse.
• Move to… (collection, folder and request context menu) is the keyboard alternative to drag and drop.

Variables and environments

Use {{name}} in URL, params, headers, body and auth; unknown placeholders are left untouched.

Every collection has base variables and any number of environments (dev, staging, prod, …), each with its own key/value variables (enable/disable per row). One environment per collection can be active; its variables override base variables of the same name. With no active environment only base variables apply.

• Manage: collection context menu → Manage Environments (or the gear next to the environment dropdown in a request panel) opens an editor to add, rename, delete environments, set the active one and edit variables; Save or Ctrl/Cmd+S.
• Switch: the Environment dropdown in the request panel, the status bar item ($(server-environment) <name>, showing the collection of the focused request panel or selected tree item; click to switch), or Routiq: Switch Environment.
• The active environment is stored in the collection file (so it is shared if you commit the file).
• Collections created before environments existed keep their old variables as base variables; nothing is lost.

Dynamic variables resolve on every send (your own variables of the same name win): {{$uuid}}, {{$timestamp}} (seconds), {{$timestampMs}}, {{$isoTimestamp}}, {{$randomInt}} (0–999), {{$randomString}}, {{$randomHex}}, {{$randomBoolean}}.

Secret variables

In the environment editor, click the lock next to a base or environment variable to mark it secret. Its value is shown masked and stored in VS Code SecretStorage (keyed by collection / environment / variable), never in the collection JSON file: the file keeps only the name and "secret": true with an empty value. Secrets are resolved at send time like any other variable, and are omitted from Routiq and Postman exports. Existing files are unaffected; a secret flag added by hand to a variable that still has a value in the file is migrated to SecretStorage on the next save in the editor. Secrets are per machine: they are not shared when you commit or copy the collection file, and duplicating a collection does not copy them.

Searching and filtering requests

• Search Requests ($(search) button in the view title, or the command palette) opens a quick pick over every request (name, method, URL, collection/folder path) and opens the selected one.
• Filter Requests in Tree ($(filter) button) asks for text and fuzzy-filters the tree by request name, method or URL, keeping matching requests, their folders, and folders whose name matches; matching branches are expanded. The active filter is shown in the view message; Clear Tree Filter removes it.

Variable highlighting and autocomplete

{{name}} placeholders are coloured wherever variables are substituted: the URL, params, header, form and multipart cells, body editors (JSON, XML, text, GraphQL query and variables, gRPC message), auth fields, WebSocket subprotocols and the environment editor values. Existing variables (environment, collection, dynamic and secret) are green; unresolved ones are orange with a wavy underline. Hover a variable to see its resolved value and scope (secrets show dots, never the value) or Unresolved variable.

Typing {{ (or moving the caret into an unfinished {{partial) opens a list at the caret with the active environment's variables, collection variables, dynamic $ variables and secret names, each with a value preview (masked for secrets) and its scope. Keep typing to filter; use ↑/↓ to move, Enter or Tab (or a click) to insert the variable with its closing }}, Esc to dismiss. The list follows the active environment. The headers table also suggests common header names. The WebSocket composer sends text as typed, so it is not highlighted.

Authentication

OAuth 2.0 tokens are fetched by the extension host (client secret sent via HTTP Basic), cached in memory and, for every grant, kept in VS Code secret storage until shortly before expiry, then refreshed with the refresh token when present or refetched on send; use Fetch token in the Auth tab to force a refresh. Digest auth (MD5/SHA-256, qop=auth) is applied by retrying once after a 401 challenge. Secrets are stored in the collection JSON file as plain text. The authorization code grant (optional PKCE) opens the browser and receives the redirect on a loopback server (free port, or a configured http://localhost:PORT/path); the token and refresh token are stored in VS Code secret storage and refreshed silently. AWS Signature v4 signs every request, including redirect hops, from the access key, secret, optional session token, region and service; copy-as-cURL omits the signed headers.

Import / Export

• Export: toolbar (all collections) or collection context menu (one collection) → .json. Export as Postman v2.1… (collection context menu or command palette) writes a single collection as a Postman collection (formdata/urlencoded/graphql/binary bodies, bearer/basic/API key/digest/OAuth 2.0 auth, collection variables) and one <environment>.postman_environment.json file next to it per environment (secret values are blanked).
• Import (toolbar button, collection/folder context menu or Routiq: Import…) offers From file…, From clipboard and cURL command…. Routiq: Import from Clipboard (also a toolbar button) reads the clipboard and auto-detects the content:
  • a cURL command (starts with curl, optionally after $ ) → a request in a chosen collection/folder;
  • a Routiq export or a single collection file (JSON);
  • a Postman v2.1 collection (JSON; nested item[] folders become folders; name, method, URL, headers, raw (JSON/XML/text), urlencoded, formdata (text/file), GraphQL and binary-file bodies, bearer/basic/API key/digest/OAuth 2.0 (client-credentials, password) auth, with collection- and folder-level auth copied onto requests that inherit it; unsupported auth (OAuth 2.0 authorization code/implicit, AWS Signature v4, Hawk, NTLM, Akamai EdgeGrid, …) and ignored OAuth 2.0/Digest settings are reported as import warnings; collection variables; pre-request and test scripts are translated best-effort to the rq API — pm.environment/variables/collectionVariables/globals.set/get, pm.response.code/json()/text(), pm.test and the common pm.expect(...).to.equal/eql/include/above/below/… and pm.response.to.have.status forms; lines that cannot be translated are kept as // [not translated] comments and reported as warnings; collection- and folder-level scripts are prepended to every contained request's script — pre-request outermost first, test scripts innermost first).
  • a Postman environment (*.postman_environment.json) → added as an environment of a chosen collection (right-click the collection, or you are asked); secret variables are stored in the secret vault.
  • an OpenAPI 3.x / Swagger 2.0 document (JSON or YAML): one folder per (first) tag, URLs as {{baseUrl}}/path/{{param}} with baseUrl taken from servers[0] (or Swagger host/basePath), query/header parameters (optional ones disabled), example bodies generated from schemas, multipart/form-data bodies (binary properties become file fields), and securitySchemes mapped to request auth (http bearer/basic, apiKey in header/query/cookie (cookies become a Cookie header) and oauth2 clientCredentials/password/authorizationCode flows (PKCE enabled) with tokenUrl and scopes, using global and per-operation security — the first usable scheme among alternatives wins; openIdConnect is reported as a warning; secrets are never imported, placeholders such as {{bearerToken}}/{{apiKey}}/{{clientSecret}} are added as empty collection variables);
  • an Insomnia v4 export (JSON): workspaces → collections, request groups → folders, requests with method/URL/headers/parameters/body (JSON/XML/text, form, multipart, GraphQL, binary file)/auth (bearer, basic, digest, API key, AWS IAM, OAuth 2.0 client-credentials/password/authorization-code with PKCE; requests without their own auth inherit from the folder or workspace; Hawk, NTLM, ASAP, netrc, OAuth 1.0 and implicit/refresh-token grants are skipped with a warning); the base environment → collection variables, sub-environments → environments (private environments and secret pairs become secret variables; pre-request scripts are not applicable and skipped). After every import an information message shows the counts of collections/folders/requests and the number of warnings, with a Show details action that opens the Routiq Import output channel listing each warning. Anything else shows an error saying what was expected (empty text, invalid JSON, unknown JSON shape). Files chosen with From file go through the same detection. IDs are regenerated on import; imported environments keep their active selection.

Export format (version 2; version 1 exports with a flat requests list still import):

{ "version": 2, "collections": [
  { "id": "…", "name": "…",
    "variables": [{ "key": "", "value": "", "enabled": true }],
    "environments": [{ "id": "…", "name": "dev", "variables": [{ "key": "", "value": "", "enabled": true }] }],
    "activeEnvironmentId": "…",
    "items": [
      { "id": "…", "name": "Folder", "items": [ /* requests and folders */ ] },
      { "id": "…", "name": "…", "method": "GET", "url": "", "params": [], "headers": [],
        "body": { "type": "none|json|text|form", "text": "", "form": [] },
        "auth": { "type": "none" } } ] } ] }

cURL

• Import cURL (Routiq: Import cURL, or from a collection/folder context menu) takes a command from the input box or the clipboard and creates a request in the chosen collection/folder. Supported: method (-X, -I/--head; implied POST with data), URL (also --url), -H, -d/--data/--data-raw/--data-binary/--data-ascii/--data-urlencode (repeated parts joined with &), --json, -G, -u (basic auth), --oauth2-bearer, Authorization: Bearer … headers (become bearer auth), -A, -e, -b, single/double/$'…' quoting, Windows commands (curl.exe, cmd ^ escapes and ^-newline continuations as in Chrome's Copy as cURL (cmd), PowerShell quoting with backtick escapes and continuations), backslash escapes, \-newline continuations and clustered short flags (-sSXPOST). The body type is inferred from Content-Type (JSON, form-urlencoded → form rows, otherwise text); JSON of the shape {query, variables} becomes a GraphQL body. -F/--form (text and @file) and --form-string become a multipart body, --data-binary @file a binary body. -d @file, -F name=<file and unsupported methods are ignored with a warning; irrelevant flags (-L, -k, --compressed, -o, …) are skipped.
• Paste cURL into the URL field (HTTP and GraphQL requests): pasting a command that starts with curl replaces the current request's method, URL, query params (moved into the Params table), headers, body and auth with the parsed command, keeping its name. A notice says Imported cURL, lists any warnings (ignored flags…) and offers Undo; it dismisses itself after a few seconds. Other pastes behave normally.
• Copy as cURL: button in the request panel and request context menu. Variables (active environment included) are substituted and auth is applied, so the command is ready to run. On Windows (or with routiq.curlShell) the command uses curl.exe, PowerShell quoting with backtick continuations, or cmd quoting with ^ continuations, so it runs in that shell. Digest auth is emitted as --digest -u user:password; OAuth 2.0 uses the cached token if one was fetched, otherwise the Authorization header is omitted and a warning says so.

Network

• Cookies: a per-collection cookie jar honours Set-Cookie (domain, path, expiry, Secure), is applied across redirects and persisted in the extension's global storage. Use Routiq: Manage Cookies to view/delete/clear.
• Redirects: routiq.followRedirects (default on) and routiq.maxRedirects (default 10). 301/302 on POST and 303 switch to GET without body; 307/308 keep method and body. Authorization/Cookie headers are dropped on cross-origin hops.
• Proxy / TLS: routiq.proxy (falls back to http.proxy, then HTTPS_PROXY/HTTP_PROXY, honouring NO_PROXY) and routiq.rejectUnauthorized (set to false for self-signed certificates).
• Timeout: routiq.timeoutMs default, overridable per request via the timeout field next to Send. Hover the response time for a wait/download breakdown.
• Connect timeout: routiq.connectTimeoutMs (default 10000). Unreachable IPv6 addresses fall back to IPv4 after 250 ms.
• Diagnose network: Routiq: Diagnose Network for this Request (also in the request's … menu and on timeout/connection errors) checks the resolved URL, DNS, proxy resolution, TCP, HTTP through each transport and TLS, then suggests settings. Credentials and tokens are stripped; Copy report to share it.

Requests time out but work in Postman

Run Diagnose network. Typical findings: direct fails but VS Code networking works → set routiq.useVsCodeNetworking to true (honours the Windows system proxy/PAC and OS certificates); only the proxy is reachable → set routiq.proxy; connect timeout → the host/port is unreachable from this network or needs a proxy; response timeout → a gateway or firewall accepts the connection but does not answer. Tick Use the real method and body to also re-send the actual request.

Request kinds: SSE and WebSocket

New Request first asks for the kind; the tree shows a kind icon and label (SSE, WS) instead of the HTTP method. Params, headers, auth, {{variables}}, environments and the timeout work for every kind. SSE, WebSocket and gRPC sessions are recorded in the request's History (see below).

• Server-Sent Events (kind Server-Sent Events, or an HTTP request with Stream ticked): Connect / Disconnect opens a streaming GET (Accept: text/event-stream added unless set) and lists events live (name, id, retry, multi-line data) with timestamps, filter, auto-scroll and clear.
• WebSocket: http(s):// URLs are mapped to ws(s)://. Set request headers and comma-separated subprotocols, then Connect. The composer sends text or JSON (with Format and validation); the log shows direction (↑ sent, ↓ received), timestamp and size, with filter, auto-scroll and clear.
• Auto-reconnect (optional) retries after an unexpected close, honouring the SSE retry: value (default 3 s).
• WebSocket and SSE connections honour the proxy settings (routiq.proxy / http.proxy / env, via https-proxy-agent for WebSocket), send the collection's cookie jar and store Set-Cookie from the upgrade/stream response. Binary WebSocket frames are flagged and can be shown as Hex or Base64 with the Binary frames selector.

gRPC

Choose gRPC in New Request (tree label gRPC). @grpc/grpc-js and @grpc/proto-loader are bundled into the extension.

• Target: host:port in the URL field (a grpc:// prefix is stripped), plus a TLS toggle (certificate checks follow routiq.rejectUnauthorized).
• Server reflection: the Use server reflection switch (on by default while no .proto file is set) lists the services and methods exposed by the server (reflection v1 and v1alpha, TLS or plaintext, request metadata sent along) and builds the example message from the reflected descriptors; Refresh services re-queries the server. Servers without reflection produce a friendly error.
• Schema: turn reflection off to add one or more .proto files and optional import paths with the file dialog. The methods are listed in the method dropdown with their call type (unary, server/client/bidirectional streaming). Selecting a method fills the Message tab with an example JSON body built from the request message fields (replaced only while the message is empty or still the previous example). Field names use the .proto spelling; int64 values and enums are exchanged as strings.
• Metadata: the Metadata tab (key/values, -bin keys take base64). The timeout field is the call deadline (empty means none).
• Calls: Invoke sends the Message for unary and server-streaming calls. For client-streaming and bidirectional calls the composer sends each message and End stream half-closes; Cancel aborts. The log shows sent/received messages, and the final status code, details and trailers appear above it.
• {{variables}} work in the target, proto paths, metadata and message.

Limitations: metadata and trailers are shown as text; calls are recorded in history as capped transcripts and run by the collection runner (unary calls, or the first 20 messages of a stream).

Body formatting

JSON, XML and text bodies have a Prettify button (or Shift+Alt+F in the editor) and JSON bodies also a Minify button. JSON is indented with two spaces, key order and number precision are kept, and {{variable}} placeholders stay intact, even unquoted ({"id": {{userId}}}). Invalid JSON is left unchanged and the error is shown with its line and column; a live Valid/Invalid indicator sits under the JSON editor. The same Prettify/Minify buttons, Shift+Alt+F shortcut, error positions and live indicator are available in the GraphQL Variables editor, the gRPC message editor and the WebSocket composer's JSON mode. XML is re-indented while keeping text, CDATA, comments and declarations; text bodies containing JSON or XML are formatted accordingly and otherwise trimmed.

GraphQL

Choose GraphQL in the New Request picker (tree label GQL). The method is fixed to POST and the request is sent as a { query, variables, operationName } JSON body. Right-click a request in the tree and choose Convert to GraphQL / Convert to HTTP (or use the request toolbar menu); a notice offers Undo and lists anything that could not be carried over. Existing POST requests with a GraphQL body type open in the same editor, and GraphQL bodies from cURL, Postman and Insomnia imports become GraphQL requests.

• Query tab: syntax-highlighted query editor, a Variables JSON editor with validation, and an operation selector that appears when the document contains several named operations. Prettify formats the query and variables.
• Schema explorer: Fetch schema runs the standard introspection query through the normal send pipeline (variables, environments, auth, cookies, proxy; scripts are skipped). The schema is cached in the extension's global storage per resolved URL and reloaded when the request opens. Search types, fields and arguments, and click a field to insert it into the query.
• Autocomplete: with a schema loaded, field and type suggestions appear while typing (Ctrl+Space to force them).
• Errors: entries in the response errors[] are listed above the response with their path, location and code. The full response stays in the response viewer, and Copy as cURL works as for any request.

Scripts and tests

Each request has a Scripts tab with a pre-request and a post-response script (JavaScript). Scripts run in an isolated node:worker_threads worker (one per script run) with capped memory (64 MB old generation, 16 MB young generation, 2 MB stack), a hard wall-clock timeout of routiq.scripts.timeoutMs (default 5000 ms) after which the worker is terminated, and no access to host objects. Inside the worker the code runs in a frozen node:vm context with no require, process, fs, timers, fetch, dynamic import() or string evaluation (eval/new Function); the rq API is a snapshot of variables, request and response, and results are passed back by message. Stopping a collection run aborts the in-flight request and any running script. They are saved with the request.

// pre-request
rq.variables.set('nonce', String(Date.now()));
rq.request.headers['X-Nonce'] = rq.variables.get('nonce');

// post-response
rq.variables.set('token', rq.response.json().token);
rq.test('created', () => rq.expect(rq.response.status).toBe(201));
console.log('took', rq.response.timeMs, 'ms');

• rq.variables.get(name) / rq.variables.set(name, value) — values are strings. Writes are saved into the active environment (or the collection variables when none is active), so later requests can use {{name}}. Secret variables are never overwritten by scripts.
• rq.request — url, method, headers (object), body (text). Edits in the pre-request script apply to that send only and are not saved; {{variables}} are substituted after the script runs.
• rq.response (post-response only) — status, statusText, timeMs, headers (lower-case names), body, text(), json(), header(name).
• rq.test(name, fn) and rq.expect(value) with toBe, toEqual, toContain, toMatch, toHaveLength, toHaveProperty, toBeGreaterThan(OrEqual), toBeLessThan(OrEqual), toBeTruthy, toBeFalsy, toBeNull, toBeUndefined, toBeDefined, plus .not.
• console.log/info/warn/error output is captured.

The response viewer shows a Tests tab (pass/fail, errors, console) when a script produced output. The post-response script is skipped when the request itself failed.

Script security

• Consent: the first time a script would run in a collection (including every imported Postman collection), Routiq shows a modal warning; scripts stay disabled until you choose Allow Scripts. The decision is remembered per collection in the extension's global state. Declining skips the scripts, shows a "Scripts are disabled" error in the Tests tab and still sends the request.
• Workspace Trust: scripts never run while the workspace is untrusted (vscode.workspace.isTrusted), regardless of earlier consent.
• Limits: this is defence in depth, not a guarantee. The worker shares the extension host's process and OS user, so a V8 or Node vulnerability could in theory break out; only allow scripts from sources you trust. Scripts can still read the variables, request and response they are given, and rq.variables.set can change non-secret variables.

Collection runner

Right-click a collection or folder and choose Run Collection/Folder (also in the command palette). Requests (HTTP only; SSE/WebSocket are skipped) run sequentially in tree order, with their scripts, so variables set by one request are available to the next. A results tab shows status, time and pass/fail per request and per test. Stop aborts the in-flight request and any running script and ends the run. Set routiq.runner.delayMs to wait between requests. The runner sends the saved version of each request (unsaved edits in open tabs are not used). A request fails when it errors, a test fails, or a script throws.

Response viewer

Syntax-highlighted JSON/XML/HTML bodies (themed with VS Code colors), Pretty/Raw and line-wrap toggles, find-in-response (Enter / Shift+Enter for next/previous, match count), a JSON path filter ($.data[0].name, data[*].id, ['key'], negative indexes), copy, and Save body to file (default extension from Content-Type). Status, time and size are shown above the body.

Kafka listener

The Kafka view in the Routiq activity bar lists saved connections. Click New Connection (or run Routiq: Open Kafka Listener) to open a panel; each connection runs its own consumer inside the extension host (kafkajs) and is disconnected when the panel closes or the extension deactivates.

• Connection: broker list and comma-separated topics, optional consumer group (default: a fresh routiq-<id> group), consume from beginning, SSL/TLS, SASL PLAIN / SCRAM-SHA-256 / SCRAM-SHA-512, Use Test Kafka preset (localhost:9092 with sample topics). Brokers, topics and the send form accept {{variables}} from the collection picked under Variables from collection. Profiles are stored in global state; the SASL password only in VS Code Secret Storage.
• Start position: latest, from beginning, specific offsets (offset, partition:offset or topic:partition:offset), from a timestamp (ISO date or epoch ms) or the last N messages per partition. Offsets are clamped to what the log still holds. Messages show the broker record timestamp; the arrival time is in the tooltip.
• Authentication presets: Confluent Cloud (API key/secret over SASL PLAIN + TLS), AWS MSK IAM (SigV4 token signed in-process from the profile's access key or AWS_* environment variables; region taken from the broker host, the profile or AWS_REGION), OAuth bearer (static token or client-credentials token endpoint) and mutual TLS (CA, client certificate and key as paths or pasted PEM, optional passphrase, optional server verification off). Tokens, client secrets, AWS secrets, pasted keys and passphrases live only in VS Code Secret Storage, never in the saved profile.
• Reconnect: if the broker drops or the consumer crashes, the listener reconnects with jittered exponential backoff (1 s up to 30 s), shows reconnecting (attempt n) with a Stop reconnecting button, and resumes after the last received offset instead of replaying. Authentication, TLS and unsupported-codec errors stop immediately with a friendly message; Disconnect never reconnects.
• Compression: gzip, snappy, lz4 and zstd records are decoded (pure JavaScript, no native modules); producing zstd is not supported. Other codecs produce a clear error naming the codec.
• Busy topics: message lists are windowed, incoming messages are batched per frame, and values above routiq.kafka.maxMessageBytesDisplayed are truncated with a Show full button.
• Messages: newest first, grouped by flow. The flowId is read from the flowId / flowid / flow-id header, then the JSON content (resource.flowId first, then flowId, flowid, flow-id, flow_id, or a recursive search), then the message key. Search (value, topic, flowId, key, headers), topic filter, Pause, Follow newest, Clear, Export all, per-message/per-flow copy, download and delete, multi-select copy/delete, command/success/error badges and fail, flowId, commandId highlighting.
• Send: produce a message with topic, key, headers (JSON object) and value; Use for Send and Resend reuse a received message.
• Log file: import a Splunk JSON export (single JSON, array or NDJSON) and browse it as flows with search, container/level filters and sorting.
• Topics: list topics with partitions, replication factor, low/high watermarks, approximate message count and leader/replicas/ISR; filter, show internal topics, view topic configs (read-only), add a topic to the listener or consume it, create topics (name, partitions, replication factor, optional configs) and delete them, both with confirmation.
• Consumer groups: state, protocol and members; per-partition committed offset, log end offset and lag with total lag; manual or auto refresh; delete an empty group or reset its offsets (earliest, latest, timestamp).
• Cluster: brokers (id, host, port, controller marker) and the cluster id. Missing ACL permissions are shown as friendly errors.
• The latest messages per connection are remembered between sessions.

Message experience

• Filters: free text with regex and case toggles, scope (all/key/value/headers), a JSON-path condition ($.status == 'FAILED', or just a path to test existence), header key/value, partition, time range and errors-only. Named filters can be saved, applied, renamed and deleted; they are stored in global state. Regex patterns are length-limited and invalid ones are ignored.
• Views: save the current filter and topic as a tab to watch several slices of the same live connection.
• Value viewer: each message value can be shown as Tree (collapsible, searchable, click a key to copy its JSON path, click a value to copy it), Text or Raw, and decoded as Auto / JSON / Text / Hex / Base64 / Avro.
• Schema Registry / Avro: Confluent wire format (magic byte 0 + 4-byte schema id) is decoded using the connection's Schema Registry URL (falling back to the routiq.kafka.schemaRegistryUrl setting), with optional basic auth (password in Secret Storage). Schemas are cached by id; JSON Schema payloads are shown as JSON, Protobuf messages are decoded with the registry schema (including references) and shown as JSON, and binary payloads or an unreachable registry fall back to a hex preview.
• Protobuf from a local .proto file: in the connection form set a .proto path, a default message type and optional topic=Type pairs; plain protobuf payloads are decoded with it, or choose Protobuf in the Value as selector. Failures fall back to hex.
• Tombstones: a null value is shown as null (tombstone), stays distinct from an empty string, and is kept in exports (null / a tombstone CSV column), replay and kcat commands.
• CSV import: Import log / CSV in the log panel also opens a Routiq CSV export.
• Topic administration: in the Topics tab edit configs (validate first, then confirm; read-only and sensitive configs are locked) and increase partitions. The Cluster tab shows inter.broker.protocol.version when the broker reports it.
• Highlight rules: text, regex or JSON-path rules colour the message border, optionally show a badge and raise a rate-limited VS Code notification; hit counts are shown in the rules dialog.
• Compare: select two messages and click Compare selected for a side-by-side JSON diff.
• Save as Routiq request: creates an HTTP POST request in a chosen collection, named topic/flowId, with the message value as body and its headers as request headers (URL left empty).

Local Kafka with Docker

Save as docker-compose.yml and run docker compose up -d, then connect to localhost:9092:

services:
  zookeeper:
    image: confluentinc/cp-zookeeper:7.5.0
    container_name: kafka-zookeeper
    ports:
      - '2181:2181'
    environment:
      ZOOKEEPER_CLIENT_PORT: 2181
      ZOOKEEPER_TICK_TIME: 2000

  kafka:
    image: confluentinc/cp-kafka:7.5.0
    container_name: kafka-broker
    depends_on:
      - zookeeper
    ports:
      - '9092:9092'
      - '9093:9093'
    environment:
      KAFKA_BROKER_ID: 1
      KAFKA_ZOOKEEPER_CONNECT: 'zookeeper:2181'
      KAFKA_LISTENER_SECURITY_PROTOCOL_MAP: PLAINTEXT:PLAINTEXT,PLAINTEXT_INTERNAL:PLAINTEXT
      KAFKA_ADVERTISED_LISTENERS: PLAINTEXT://localhost:9092,PLAINTEXT_INTERNAL://kafka:9093
      KAFKA_OFFSETS_TOPIC_REPLICATION_FACTOR: 1
      KAFKA_TRANSACTION_STATE_LOG_MIN_ISR: 1
      KAFKA_TRANSACTION_STATE_LOG_REPLICATION_FACTOR: 1
      KAFKA_AUTO_CREATE_TOPICS_ENABLE: 'true'

UI

The request editor uses Hugeicons (@hugeicons/react, free core set) for icons and the Jost font, bundled locally via @fontsource-variable/jost (copied into dist/ by esbuild; no CDN). Code and response bodies stay monospace.

Components follow the shadcn/ui structure (src/webview/components/ui/) built on Radix primitives, class-variance-authority and clsx, styled with plain CSS (ui.css) instead of Tailwind. Shadcn design tokens (--background, --border, --ring, --primary, …) are mapped to --vscode-* variables in one place (theme.css), so light, dark and high-contrast themes work. The webview CSP allows a nonce on style-src for Radix's injected style tags.

Storage

Each collection is one pretty-printed JSON file (2-space indent, stable key order, written atomically) named after the collection (my-api.json; a short id suffix is added on name clashes). The file name is kept when a collection is renamed. Files are the same shape as one entry of an export's collections array plus a leading "version": 2. Files written by older versions (flat requests, no version) load transparently and are upgraded the next time the collection is saved.

Set routiq.storagePath to .routiq in workspace settings to keep collections in your project and commit them to git. Files edited externally (git pull, manual edits) are picked up automatically via a file watcher; invalid JSON files are ignored. Changing the setting switches directory immediately.

History

Every sent HTTP request is recorded (method, final URL, status, duration, size, request/response headers, request body, truncated response body). SSE, WebSocket and gRPC sessions are recorded when they end (connection summary, outcome/gRPC status, duration, and a message log capped at 200 messages of up to 8 KB each); selecting one shows its transcript in the History tab. History lives in the extension's global storage (…/globalStorage/<id>/history/<requestId>.json, atomic writes), never in the collection file. Open the History tab in a request panel to view a stored response without re-sending, restore the request snapshot into the editor, delete an entry or clear all. The Routiq: Clear Request History command wipes all history. Deleting a request (or a folder/collection containing it) removes its history file, and deleting a collection also removes its cookie jar file.

Help and About

• Routiq: Help (routiq.openHelp) opens a searchable help page: getting started, requests, variables, importing/exporting, scripts, runner, GraphQL, WebSocket/SSE, gRPC, Kafka, storage and Git, network settings, keyboard shortcuts and a FAQ. Its search box filters sections and items by text, and it has an Open settings button and an Open README button.
• Routiq: About (routiq.openAbout) shows the version, publisher, license, VS Code / Electron / Node versions, the storage directory in use (with Reveal and Copy path), collection and request counts, credits for the main open-source libraries, and Copy diagnostics (versions and settings, with proxy credentials redacted, no secrets) for bug reports.
• Both are in the command palette and the overflow (...) menu of the Routiq view title; the empty view also offers a Get Started link.

Credits and contact

Developed by Israel Saraiva (israelspm@gmail.com); use Contact / Send feedback on the About page to write an email.

Built with React, Radix UI, Hugeicons, the Jost font (SIL OFL 1.1), undici, ws, @grpc/grpc-js, kafkajs, graphql, https-proxy-agent and yaml.

Development

npm install
npm run typecheck
npm test
npm run build      # esbuild: dist/extension.js + dist/webview.js/css
npm run watch
npm run package    # .vsix via vsce
npm run harness    # visual QA: headless Chromium screenshots in scripts/webview-harness/out

Press F5 (Run Extension) to launch an Extension Development Host.

Publishing

Create the israelsaraiva publisher at https://marketplace.visualstudio.com/manage and a Personal Access Token (scope: Marketplace → Manage). Add it as the VSCE_PAT repository secret (and optionally OVSX_PAT for Open VSX). Pushing a v* tag runs .github/workflows/publish.yml; locally use npm run package and npm run publish:vsce.

npm run harness builds the webview, renders it with a mocked acquireVsCodeApi and the same CSP as the extension under Dark Modern, Light Modern and High Contrast theme variables, and reports console/CSP errors, missing fonts and horizontal overflow. Pass a name filter to run a subset (node scripts/webview-harness/run.js grpc). The first run needs npx playwright install chromium.

Layout: src/core (pure logic + tests, file store), src/extension (VS Code host), src/webview (React UI), src/shared/types.ts (models and host/webview messages).
