NQBP Integration Extension

This extension adds NQBP build system integration to VS Code.

Features

NQBP Build Selection - Right-click files/folders in Explorer to select NQBP build configuration
Automatic environment setup - Every new terminal automatically runs env.sh (Linux/Mac) or env.bat (Windows)

Requirements

NQBP2 1.1.1 or higher
- Note: The extension make use of the sancho.py script that is contained in the NQBP repository.
Your local repo uses the NQBP2 build system and has env.sh or env.bat scripts in the repo root. These scripts are responsible for configuring the compiler toolchain environment. Example repos that use NQBP
- kit.core
- epc
VS Code 1.85.0 or higher

Usage

NQBP Build Selection

Right-click on any file or directory in the Explorer
Select "Select NQBP Build..." from the context menu
A QuickPick dropdown appears list of NQBP build directories. The most relevant build directories are listed first.
When a build directory is selected, VSCode is configured for the selected NQBP build project. This includes tasks such as:
- Updating the compiler_flags.txt for the Clangd language server
  - And then restarts the Clangd language server
- Creating GDB debugger configurations for the build project

Customization

You can customize the behavior extension via the file .nqbp-configuration.json stored in the root of your repository. It recommended that this file be checked into your repository, i.e. is shared by all developers using the repository. The extension provides a default configuration file is configure for use by the kit.core repository. Below is example file:

{
    "active-projects": [
        "projects/MyProject"
    ],
    "exclude-list": [
        "xpkgs"
    ],
    "build-naming": [
        {
            "windows": {
                "msvc": 1,
                "clang-host": 3,
                "gcc-arm-mcu": 5
            }
        },
        {
            "linux": {
                "gcc-host": 1,
                "gcc-arm-mcu": 2
            }
        }
    ]
}
