ops-code

Run openseespy models directly in VS Code with instant 3D visualization and interactive analysis results.

Quick Start

1. Install the extension from the VS Code Marketplace
2. Select openseespy model file
3. Right-click → "Run in ops-code"
4. View your 3D model in the viewer panel
5. Click Run Analysis in the viewer to execute the model.

Features

• 3D Visualization — Real-time rendering of OpenSees models: nodes, elements, supports, and nodal loads
• Run Analysis — Execute OpenSeesPy analyses and view results instantly (displacements, reactions, section forces)
• Force Visualization — Color-mapped elements by internal forces (N, V, M, T, My, Mz) with interactive rainbow colorbar
• Code-Driven UI — Control viewer appearance via Python: color sections, set precision, no UI panels needed
• Auto-Reload — Model updates automatically when you save your script

Example

import openseespy.opensees as ops

# Create model
ops.model('basic', '-ndm', 2, '-ndf', 3)

# Nodes
ops.node(1, 0, 0)
ops.node(2, 10, 0)

# Section and element
ops.section('Elastic', 1, 1000, 1, 1)
ops.element('elasticBeamColumn', 1, 1, 2, 1, 1)

# Support and load
ops.fix(1, 1, 1, 1)
ops.load(2, 10, -100, 0)

# Configure viewer appearance
__viewer__ = {
    'sections': [
        {'tag': 1, 'color': '#e06c75', 'label': 'Main Beam'}
    ],
    'precision': 4
}

Requirements

• Python 3.7+ on your system
• openseespy (for analysis; model viewing works without it via code interception)

To install openseespy:

pip install openseespy

Optional: Configure the Python path in VS Code settings if auto-detection fails.

Viewer Configuration (__viewer__)

Control visualization directly from Python:

__viewer__ = {
    'sections': [
        {
            'tag': 1,
            'color': '#e06c75',      # CSS color
            'label': 'CHS 114x8'     # Optional label shown in Elements tab
        },
        {
            'tag': 2,
            'color': '#4ec9b0',
            'label': 'LS 50x5'
        }
    ],
    'precision': 4,                  # Significant figures in results panel
    'nodalLoads': {
        'scale': 1.5,                # Arrow length multiplier
        'color': '#ff8800'           # CSS color
    },
    'supports': {
        'scale': 1.2,                # Symbol size multiplier
        'color': '#44aaff'           # CSS color
    },
    'label': {
        'size': 1.0                  # Node/element label size multiplier (e.g. 2.0 = double size)
    }
}

All fields are optional. An empty __viewer__ = {} or missing definition uses defaults.

Controls

• Mouse: Rotate (drag), Pan (middle-click + drag), Zoom (scroll)
• Analysis panel: Toggle results visibility, switch between force components
• Elements tab: Click to select and view member diagrams
• Ctrl+S (viewer focused): Save a screenshot of the current view

Tools

Tools are Python scripts that run automatically after analysis, consuming the results and producing tabular output displayed in the panel. See examples/pylone.py and examples/tools/buckling_en1993.py for a working example.

Creating a Tool

Place a .py file in a tools/ folder next to your model script:

my_project/
  pylone.py
  tools/
    buckling_en1993.py

Each tool must expose a run(outputs) function that returns {"elements": [...]}. Each entry in the list must follow this exact shape:

def run(outputs: dict) -> dict:
    results = []
    for el in outputs["elements"]:
        N = el["responses"]["localForce"][0]
        results.append({
            "tag": el["eleTag"],          # int — element tag
            "name": "N",                  # str — result label
            "value": round(N, 2),         # int | float | str | bool
            "description": "axial force (kN)",  # str — optional
        })
    return {"elements": results}

ops-code exposes analysis results to tools via the outputs dict. Section data is only available for Truss, TrussSection, CorotTruss, and elasticBeamColumn elements.

Declaring Tools in Your Model

Tools are opt-in. Declare which tools apply to a model with a standard Python import:

import openseespy.opensees as ops
from tools import buckling_en1993

Only tools imported in your model file are run.

Current Limitations

• Tools run only after Run Analysis — they require analysis results
• forceBeamColumn and dispBeamColumn section data is not resolved; those elements have no entry in outputs["sections"]

Known Limitations

• 2D and 3D frame elements only (truss, beam, elasticBeamColumn)
• Distributed element loads not yet included in section force diagrams
• Requires openseespy for analysis; model geometry loads without it

Configuration

Set optional preferences in VS Code settings:

• ops-code.pythonPath — Path to Python interpreter (auto-detected if blank)
• ops-code.autoRenderOnSave — Re-render model on file save (default: true)

Development

Setup

1. Clone the repository:

   git clone https://github.com/igor-barcelos/ops-code.git
   cd ops-code


2. Install dependencies:

   npm install


3. Build the extension:

   npm run build


Running in Debug Mode

1. Open the project in VS Code
2. Press F5 or go to Run → Start Debugging
3. A new VS Code window opens with the extension active
4. Open a .py file and test: right-click → "Run in ops-code"

Development Workflow

• Watch mode — Auto-rebuild on file changes:

  npm run watch


• Build and package VSIX — Create a distributable package:

  npm run bundle


• Package only — Create VSIX file (after build):

  npm run package


License

MIT — see LICENSE file for details.
