Fanuc Macro Executor extension for Visual Studio Code

Visual Studio Code extension with support for the Fanuc Macro Executor programming language including syntax highlighting, validating and project building.

News

Document formatting
Function call hierarchy for incoming and outgoing calls

Features

Compiling and linking
Compiler problem matcher
Syntax/Semantic highlighting
Syntax validation
Symbol provider
Completion provider
CodeLens
Lint features
Sequence number refactoring
Function call hierarchy
Formatting provider

Supported display languages

English en
Deutsch de
中文 zh-cn

Required file extensions

Macro files .src
Include files .def
Link files .lnk

To associate other file extensions with the macro executor language, see the following setting sample:

   "files.associations": {
        "*.PRG": "macro"
    }

Coding conventions

$Include paths must be absolute or relative to the workspace folder
Uppercase for constants: @MY_CONSTANT 100
Space between statements: O SUB_PROGRAM; N9000 G01 X1; DO 1; END 1; GOTO 1 etc.
A comment of a declaration @var /* my comment is displayed on hover and completion

Validation

References

The reference service supports the search for the following types:

Symbols
Labels
Sequence numbers
GOTO Label/sequence numbers
M-Codes and G-Codes
Macro variables (#..)
Addresses

The search for symbol and label references is global (workspace) if the definitions are included by a definition file .def, otherwise the search is limited to the current file scope. Sequence numbers only can be found within a file scope (there is currently no function scope available).

Sequence number definition

References

Symbol references

References

Implementations

Implementations of one of the following types are found by the implementations search service:

Subprograms
Label statements
GOTO Label/Sequence number

The global / local search behavior is equal to the reference search.

Implementations

Sequence number refactoring for functions

Consecutive numbering on completion (snippet N-Number)
Command for renumbering sequences (incl. GOTOs)
Command for adding missing sequences (for NC statements)

Semantic highlighting

Semantic highlighting is used to highlight the represented type of a symbol. Following types are supported:

M-Code and G-Code
Address
Parameter
Macro variable
Constant
Label

For some color themes, the semantic highlighting must be enabled in the settings:

"editor.semanticTokenColorCustomizations": {
       "enabled": true,
}

disabled	enabled

The color theme used in screenshot → Noctis

Custom Keywords

Highlighting
Description for hover and completion

Out of the box the extension supports semantic highlighting for >Labels, @Symbols, M/G-Codes and, Variables. Sometimes it could be useful to change the default highlighting for a particular symbol or for a type like a macro variable. Such a customization can be achieved by adding custom keyword items to the configuration property macro.keywords in the user/workspace settings:

Keyword item
symbol	Symbol text
scope	Scopes
nodeType	Label, Symbol, Code (M/G), Variable
description	Markdown `string` \| `string[]`

The field nodeType defines the related type in the macro program. If the field is empty, a keyword item affects all symbol occurrences regardless of the symbols type. E.g. if you want to add a hover text to a particular P-Code variable, an item could be structed as follows:

{
       "symbol": "10000",
       "nodeType" :"Variable",
       "description": "some variable text"
}

Scopes

	Style for compile-time Variable nodeType
number	Numeric (@var 10000)
macrovar	Macro variable (@var #10000)
constant	Constant numeric (@UPPER 10000)
language	Language constant (e.g. true/false)
label	Label
code	M-Code/G-Code
parameter	NC-Parameter
address	Address

These scopes are used internally and are responsible for the symbol style which depends on the chosen color theme like Noctis. To override the style just add rules to the editor.semanticTokenColorCustomizations configuration property.

In case the default scopes should be unchanged, the additional custom scopes custom_1 - custom_5 could be used:

Example

The following example changes the symbol M08, which has a default scope code, to custom_1 and the scope custom_1 is associated with the color red:

"macro.keywords" : [
       {
              "symbol": "M08",
              "scope": "custom_1",
              "description": ["*Coolant*", "ON"]
       }
],

"editor.semanticTokenColorCustomizations": {
       "enabled": true,
       "rules": {
              "custom_1": "#ff0000"
       }
},

Example

Multi-Root Workspaces

The extension supports multi-root workspaces. Each workspace is handled as a separate macro project. This could be useful if a fanuc project consists of several controls e.g machine and handling:

multi root workspace

Lint

The Lint is configurable by changing the following rules in the settings (user or workspace). Three levels are supported: error, warning and ignore.

"macro.lint": {
       "rules" : {
              "duplicateInclude":         "error",
              "duplicateDeclaration":     "error",
              "duplicateFunction":        "warning",
              "duplicateAddress":         "ignore",
              "duplicateSequence":        "warning",
              "duplicateLabel":           "warning",
              "duplicateLabelSequence":   "warning",
              "unknownSymbol":            "error",
              "whileLogicOperator":       "error",
              "doEndNumberTooBig":        "error",
              "doEndNumberNotEqual":      "error",
              "nestingTooDeep":           "error",
              "duplicateDoEndNumber":     "warning",
              "mixedConditionals":        "error",
              "tooManyConditionals":      "error",
              "seqNotFound":              "error",
              "incompleteParameter":      "error",
              "includeNotFound":          "error",
              "assignmentConstant":       "Ignore",
              "blockDelNumber":           "error",
              "unsuitableNNAddress":      "warning",
			  "dataInputNotClosed" :      "error"
       }

Default Commands

Command	Key
Build	Ctrl+Shift+B
Link / build all	Ctrl+Shift+L
Clean	Ctrl+Shift+C

Extension Settings

This extension contributes the following settings:

macro.callFunctions : Custom call functions (default: M98, G65)
macro.keywords : Custom Keywords
macro.lint: Lint settings and rule configuration
macro.sequence.base: Sequences start number for refactoring
macro.sequence.increment: Sequences increment for refactoring
macro.validate.enable: Enables or disables the validation
macro.validate.workspace: Enables or disables the workspace validation
macro.validate.onBuild: Enables or disables the workspace validation when building the project

Build settings:

macro.build.compiler: Selection of the macro compiler
macro.build.controlType: Selection of the control type
macro.build.compilerParams: Additional compiler parameters: -NR, -L1, -L2, -L3, -PR
macro.build.linkerParams: Additional linker parameters: -NR, -NL, -Fm, -Fr
macro.build.makeFile: The path to the makefile
macro.project.exportPath: The path to the directory for the memory card file (.mem)
macro.project.sourcePath: The path to the directory for the source files (.src)
macro.project.buildPath: The path to the directory for the build files
macro.project.linkPath: The path to the directory for the link files (.lnk) and the library (.mex)

External build system

The building process can be performed by using an external script or the internal system. If an external script is used, just set the path in macro.build.makeFile. If a clean script in the same directory exists, it is used for the cleaning process. The following parameters are passed to the external script:

Export directory
Option [make, clean].
Compiler
Control type parameter

Internal build system

If macro.build.makeFile is empty the internal system is used.

Currently only working with powershell (select default shell -> powershell)

The compiler must be available over the system path

All .src files under the folder macro.project.sourcePath and its subfolders will be compiled

There are two ways to define a libray path in a link file:

absolute: CNC=C:\lib.mex

relative: CNC=..\lnk\lib.mex (relative to macro.project.buildPath)

Example

Directory tree

project
│
└───src
│   │   file1.src
│   │   file2.src
│   │
│   └───sub
│           file3.src
│           file4.src
└───def
│      file1.def
│      file2.def
│
└───lnk
│      file1.lnk
│      file2.lnk
│      F30iA_01.MEX
│
└───bin
       .rom
       .ref
       .prg

Settings

Implementations

The path settings could also be empty if no further directory tree is needed

macro.project.exportPath
macro.project.sourcePath
macro.project.buildPath

Link file

CNC=..\lnk\F30iA_01.MEX

Source file

/* file1.src
$INCLUDE def\file1.def

/* file3.src
$INCLUDE def\file2.def

16 bit Compiler

A convenient way to compile 16 bit macro programs if the host system doesn't support it, is to use Dosbox. Below an example task definition which executes dosbox and passes the build script as command line argument.

{
       "label": "Fanuc Macro 16bit build",
       "type": "shell",
       "command": "C:/Program Files (x86)/DOSBox-0.74-3/DOSBox.exe",
       "args": [
              "Make.bat",
              "-noconsole"
       ],
       "group": {
              "kind": "build",
              "isDefault": true
       },
       "presentation": {
              "echo": true,
              "reveal": "always",
              "focus": false,
              "panel": "shared",
              "showReuseMessage": true,
              "clear": false
       },
       "problemMatcher": []
}

Credits

Special thanks to Pan and Yu for translating the chinese texts

特别感谢潘先生和于先生翻译了中文文本
