Render Flow [Beta]

A VS Code extension that gives you real-time visual telemetry for your frontend app: as you interact with the UI, the corresponding code in VS Code lights up and appears in an Activity Feed.

What It Does

• Live mapping: When your app runs, the lines that fired show a short gutter highlight in VS Code.
• Activity Feed: A sidebar lists the sequence of recent events (file:line and function name). Click an entry to jump to that location.
• React support: Use the renderflow-sdk in your React app to send events; the extension shows them instantly.
• PHP support: Use the renderflow-php client in your PHP app to send events; same Activity Feed and gutter.
• JavaScript support: Vanilla JS or Node can send events with framework: 'javascript' (or use .mjs/.cjs); React apps use renderflow-sdk and are handled as React.

Quick Start

1. Install & run the extension

   • Open this repo in VS Code, press F5 to launch the Extension Development Host.
   • In the new window, run "Render Flow: Start" from the Command Palette (Ctrl/Cmd+Shift+P).
   • Open the Render Flow view (pulse icon in the Activity Bar) and expand Activity Feed.

2. Use the SDK in your React app

   npm install renderflow-sdk


   import { connect, sendEvent } from 'renderflow-sdk';

   connect(8765);  // same port as extension (default 8765)

   // In a click handler or effect:
   sendEvent({ filePath: 'src/App.jsx', line: 42, functionName: 'handleClick' });


3. Optional: Use the useRenderFlow() hook to report on each component render, or reportRender() for manual events.

PHP: Copy or require packages/renderflow-php/src/RenderFlowClient.php, then call $client->sendEvent(['filePath' => '...', 'line' => 42, 'functionName' => '...', 'framework' => 'php']). See packages/renderflow-php/README.md.

See doc/RUN_AND_TEST.md for step-by-step run and test instructions, and doc/DEVELOPMENT.md for the full SDK API and integration details.

Repo Layout

Requirements

• VS Code 1.85+
• Node.js 18+ (for building the extension and sample app)
• React app using the SDK (browser; connects to ws://127.0.0.1:8765)

Configuration

In VS Code settings (search for Render Flow):

• renderflow.port – WebSocket port (default 8765). Must match the port passed to connect() in your app.
• renderflow.activityFeedMaxItems – Max entries in the Activity Feed (default 100).
• renderflow.gutterFlashDurationMs – How long the line highlight stays (default 1500 ms).

Vision & Roadmap

Render Flow addresses the "black box" in frontend development: you click, the UI changes, but tracing which code caused it is hard. The extension bridges the running app and the editor so you can see what fired.

• Done: VS Code extension, WebSocket bridge, React SDK, gutter flash, Activity Feed.
• Planned: Filtering and throttling, heatmaps, Vue/Angular SDKs, optional manual instrumentation (e.g. // renderflow:watch).

See doc/PLAN.md for the full implementation plan.

Support the Project

If Render Flow has made your workflow easier, consider supporting (No Pressure):

License

MIT. See LICENSE.
