🌟 Features

🧠 Agentic RAG with Query Planning

• Intelligent Query Decomposition: Automatically breaks complex queries into sub-queries
• LLM-Powered Planning: Uses GPT-4o via VS Code LM API for advanced reasoning
• Heuristic Fallback: Works without LLM using rule-based planning
• Iterative Refinement: Confidence-based iteration for high-quality results
• Parallel/Sequential Execution: Smart execution strategy based on query complexity

🔍 Multiple Retrieval Strategies

• Hybrid Search (recommended): Combines vector + keyword (70%/30% weights, configurable)
• Vector Search: Pure semantic similarity using embeddings
• Ensemble Search: Advanced RRF (Reciprocal Rank Fusion) with BM25 for highest accuracy
• BM25 Search: Pure keyword search using Okapi BM25 algorithm (no embeddings needed)
• Position Boosting: Keywords near document start weighted higher
• Result Explanations: Human-readable scoring breakdown for all strategies

📚 Document Processing

• Multi-Format Support: PDF, Markdown, HTML, plain text, GitHub repositories
• Semantic Chunking: Automatic strategy selection (markdown/code/recursive)
• Structure Preservation: Maintains heading hierarchy and context
• Batch Processing: Multi-file upload with progress tracking
• GitHub Integration: Load entire repositories from GitHub.com or GitHub Enterprise Server
• LangChain Loaders: Industry-standard document loading

💾 Vector Storage

• LanceDB: Embedded vector database with file-based persistence (no server needed)
• Cross-Platform: Works on Windows, macOS, Linux, and ARM
• Per-Topic Stores: Efficient isolation and management
• Serverless: Truly embedded, like SQLite for vectors
• Caching: Optimized loading and reuse

🎨 Enhanced UI

• Configuration View: See agentic settings at a glance
• Statistics Display: Documents, chunks, store type, model info
• Progress Tracking: Real-time updates during processing
• Rich Icons: Visual hierarchy with emojis and theme icons

🛠️ Developer Experience

• Comprehensive Logging: Debug output at every step
• Type-Safe: Full TypeScript with strict mode
• Error Handling: Robust error recovery throughout
• Async-Safe: Mutex locks prevent race conditions
• Configurable: 15+ settings for customization

---

🚀 Quick Start

Installation

From Source

git clone https://github.com/hyorman/ragnarok.git
cd ragnarok
npm install
npm run compile
# Press F5 to run in development mode

From VSIX

code --install-extension ragnarok-0.1.0.vsix

Basic Usage

1. Create a Topic

Cmd/Ctrl+Shift+P → RAG: Create New Topic

Enter name (e.g., "React Docs") and optional description.

2. Add Documents

Cmd/Ctrl+Shift+P → RAG: Add Document to Topic

Select topic, then choose one or more files. The extension will:

• Load documents using LangChain loaders
• Apply semantic chunking
• Generate embeddings
• Store in vector database

Supported formats: .pdf, .md, .html, .txt

2b. Add GitHub Repository

Cmd/Ctrl+Shift+P → RAG: Add GitHub Repository to Topic

Or right-click a topic in the tree view and select the GitHub icon. You can:

• GitHub.com or GitHub Enterprise Server: Choose between public GitHub or your organization's GitHub Enterprise Server
• Enter repository URL:
  • GitHub.com: https://github.com/facebook/react
  • GitHub Enterprise: https://github.company.com/team/project
• Specify branch (defaults to main)
• Configure ignore patterns (e.g., *.test.js, docs/*)
• Add access token for private repositories (see Token Management below)

The extension will recursively load all files from the repository and process them just like local documents.

Note: Supports GitHub.com and GitHub Enterprise Server only. The repository must be accessible from your network. For other Git hosting services (GitLab, Bitbucket, etc.), clone the repository locally and add it as local files.

2c. GitHub Token Management

For accessing private repositories, RAGnarōk securely stores GitHub access tokens per host using VS Code's Secret Storage API.

Add a Token:

Cmd/Ctrl+Shift+P → RAG: Add GitHub Token

1. Enter the GitHub host (e.g., github.com, github.company.com)
2. Paste your GitHub Personal Access Token (PAT)
3. The token is securely stored and automatically used for that host

List Saved Tokens:

Cmd/Ctrl+Shift+P → RAG: List GitHub Tokens

Shows all hosts with saved tokens (tokens themselves are never displayed).

Remove a Token:

Cmd/Ctrl+Shift+P → RAG: Remove GitHub Token

Select a host to remove its stored token.

How to Create a GitHub PAT:

1. Go to GitHub Settings → Developer settings → Personal access tokens → Tokens (classic)
2. Click "Generate new token (classic)"
3. Select the repo scope
4. Generate and copy the token
5. Use the "RAG: Add GitHub Token" command to save it

Benefits:

• ✅ Tokens stored securely in VS Code's Secret Storage (not in settings.json)
• ✅ Support for multiple GitHub hosts (GitHub.com + multiple Enterprise servers)
• ✅ Automatic token selection based on repository URL
• ✅ No need to enter token every time you add a repository

3. Query with Copilot

Open Copilot Chat (@workspace)
Type: @workspace #ragQuery What is [your question]?

The RAG tool will:

1. Match your topic semantically
2. Decompose complex queries (if agentic mode enabled)
3. Perform hybrid retrieval
4. Return ranked results with context

---

⚙️ Configuration

Basic Settings

{
  // Number of results to return
  "ragnarok.topK": 5,

  // Chunk size for splitting documents
  "ragnarok.chunkSize": 512,

  // Chunk overlap for context preservation
  "ragnarok.chunkOverlap": 50,

  // Embedding model to use (local Transformers.js models)
  "ragnarok.embeddingModel": "Xenova/all-MiniLM-L6-v2",

  // Retrieval strategy
  "ragnarok.retrievalStrategy": "hybrid"
}

Note: GitHub access tokens are now managed via secure Secret Storage, not settings.json. See GitHub Token Management section.

Agentic Mode Settings

{
  // Enable agentic RAG with query planning
  "ragnarok.useAgenticMode": true,

  // Use LLM for query planning (requires Copilot)
  "ragnarok.agenticUseLLM": false,

  // Maximum refinement iterations
  "ragnarok.agenticMaxIterations": 3,

  // Confidence threshold (0-1) for stopping iteration
  "ragnarok.agenticConfidenceThreshold": 0.7,

  // Enable iterative refinement
  "ragnarok.agenticIterativeRefinement": true,

  // LLM model for planning (when agenticUseLLM is true)
  "ragnarok.agenticLLMModel": "gpt-4o",

  // Include workspace context in queries
  "ragnarok.agenticIncludeWorkspaceContext": true
}

Available Embedding Models (local, no API needed):

• Xenova/all-MiniLM-L6-v2 (default) - Fast, 384 dimensions
• Xenova/all-MiniLM-L12-v2 - More accurate, 384 dimensions
• Xenova/paraphrase-MiniLM-L6-v2 - Optimized for paraphrasing
• Xenova/multi-qa-MiniLM-L6-cos-v1 - Optimized for Q&A

LLM Models (for agentic planning when enabled):

• gpt-4o (default) - Most intelligent
• gpt-4o-mini - Faster, still capable
• gpt-3.5-turbo - Fastest, most economical

---

🏗️ Architecture

Component Overview

┌─────────────────────────────────────────────────────┐
│                   VS Code Extension                 │
├─────────────────────────────────────────────────────┤
│                                                     │
│  ┌─────────────┐  ┌──────────────┐   ┌────────────┐ │
│  │ Commands    │  │ Tree View    │   │ RAG Tool   │ │
│  │ (UI)        │  │ (UI)         │   │ (Copilot)  │ │
│  └─────┬───────┘  └──────┬───────┘   └─────┬──────┘ │
│        │                 │                 │        │
│  ┌─────┴─────────────────┴─────────────────┴──────┐ │
│  │              Topic Manager                     │ │
│  │  (Topic lifecycle, caching, coordination)      │ │
│  └─────┬──────────────────────────────────┬───────┘ │
│        │                                  │         │
│  ┌─────┴─────────┐                 ┌──────┴───────┐ │
│  │ Document      │                 │ RAG Agent    │ │
│  │ Pipeline      │                 │ (Orchestr.)  │ │
│  └┬─────────┬────┘                 └┬─────────┬───┘ │
│   │         │                       │         │     │
│ ┌─┴────┐ ┌──┴────┐           ┌──────┴──┐ ┌────┴───┐ │
│ │Loader│ │Chunker│           │ Planner │ │Retriev.│ │
│ │      │ │       │           │         │ │        │ │
│ └──┬───┘ └───┬───┘           └────┬────┘ └───┬────┘ │
│    │         │                    │          │      │
│  ┌─┴─────────┴────┐          ┌────┴──────────┴────┐ │
│  │ Embedding      │          │ Vector Store       │ │
│  │ Service        │          │ (LanceDB)          │ │
│  │ (Local Models) │          │ (Embedded DB)      │ │
│  └────────────────┘          └────────────────────┘ │
│                                                     │
└─────────────────────────────────────────────────────┘
                          │
                   ┌──────┴───────┐
                   │ LangChain.js │
                   │ (Foundation) │
                   └──────────────┘

Core Components

TopicManager (managers/topicManager.ts)

• Topic lifecycle management (CRUD operations)
• Vector store per topic with caching
• Coordinates document processing
• Statistics and metadata tracking

DocumentPipeline (managers/documentPipeline.ts)

• End-to-end document processing
• Load → Chunk → Embed → Store
• Progress callbacks for UI
• Error recovery and retry logic

RAGAgent (agents/ragAgent.ts)

• Main orchestrator for queries
• Coordinates planner and retriever
• Iterative refinement loop
• Result deduplication and ranking

QueryPlannerAgent (agents/queryPlannerAgent.ts)

• Query complexity analysis
• LLM-powered decomposition
• Heuristic fallback planning
• Structured output with Zod schemas

HybridRetriever (retrievers/hybridRetriever.ts)

• Vector + keyword search fusion
• BM25-like scoring algorithm
• Configurable weights
• Result explanation generation

VectorStoreFactory (stores/vectorStoreFactory.ts)

• LanceDB embedded vector database
• File-based persistence (no external server)
• Per-topic vector stores
• Store lifecycle management and caching

DocumentLoaderFactory (loaders/documentLoaderFactory.ts)

• Multi-format document loading
• LangChain loader integration
• Metadata enrichment
• Batch processing support

SemanticChunker (splitters/semanticChunker.ts)

• Automatic strategy selection
• Markdown-aware splitting
• Code-aware splitting
• Heading hierarchy preservation

---

🔧 API Reference

TopicManager

// Get singleton instance
const topicManager = TopicManager.getInstance();

// Create topic
const topic = await topicManager.createTopic({
  name: "My Topic",
  description: "Optional description",
  embeddingModel: "Xenova/all-MiniLM-L6-v2", // optional, uses local model
});

// Add documents
const results = await topicManager.addDocuments(
  topic.id,
  ["/path/to/doc1.pdf", "/path/to/doc2.md"],
  {
    onProgress: (progress) => {
      console.log(`${progress.stage}: ${progress.progress}%`);
    },
  }
);

// Get topic stats
const stats = await topicManager.getTopicStats(topic.id);
// { documentCount, chunkCount, embeddingModel, lastUpdated }

// Delete topic
await topicManager.deleteTopic(topic.id);

RAGAgent

// Create agent
const agent = new RAGAgent();
const vectorStore = await topicManager.getVectorStore(topicId);
await agent.initialize(vectorStore);

// Agentic query
const result = await agent.query("How do I use React hooks?", {
  topK: 5,
  enableIterativeRefinement: true,
  maxIterations: 3,
  confidenceThreshold: 0.7,
  useLLM: true,
  retrievalStrategy: "hybrid",
});

// Simple query (bypasses planning)
const results = await agent.simpleQuery("React hooks", 5);

HybridRetriever

// Create retriever
const retriever = new HybridRetriever();
retriever.setVectorStore(vectorStore);

// Hybrid search
const results = await retriever.search("React hooks", {
  k: 5,
  vectorWeight: 0.7,
  keywordWeight: 0.3,
  minSimilarity: 0.3,
});

// Vector-only search
const vectorResults = await retriever.vectorSearch("React hooks", 5);

// Keyword-only search
const keywordResults = await retriever.keywordSearch("React hooks", 5);

---

🎯 How It Works

Agentic Query Flow

User Query: "Compare React hooks vs class components"
    ↓
┌───┴────────────────────────────────────────┐
│ 1. Topic Matching (Semantic Similarity)    │
│    → Finds best matching topic             │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 2. Query Planning (LLM or Heuristic)       │
│    Complexity: complex                     │
│    Sub-queries:                            │
│    - "React hooks features and usage"      │
│    - "React class components features"     │
│    Strategy: parallel                      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 3. Hybrid Retrieval (for each sub-query)   │
│    Vector search: 70% weight               │
│    Keyword search: 30% weight              │
│    → Returns ranked results                │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 4. Iterative Refinement (if enabled)       │
│    Check confidence: 0.65 < 0.7            │
│    → Refine query and retrieve again       │
│    Check confidence: 0.78 ≥ 0.7 ✓          │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 5. Result Processing                       │
│    - Deduplicate by content hash           │
│    - Rank by score                         │
│    - Limit to topK                         │
└───┬────────────────────────────────────────┘
    ↓
Return: Ranked results with metadata

Document Processing Flow

User uploads: document1.pdf, document2.md
    ↓
┌───┴────────────────────────────────────────┐
│ 1. Document Loading (LangChain Loaders)    │
│    PDF: PDFLoader                          │
│    MD: TextLoader                          │
│    HTML: CheerioWebBaseLoader              │
│    → Returns Document[] with metadata      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 2. Semantic Chunking                       │
│    Strategy selection:                     │
│    - Markdown: MarkdownTextSplitter        │
│    - Code: RecursiveCharacterTextSplitter  │
│    - Other: RecursiveCharacterTextSplitter │
│    → Preserves headings and structure      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 3. Embedding Generation (Batched)          │
│    Model: Xenova/all-MiniLM-L6-v2 (local)  │
│    Batch size: 32 chunks                   │
│    → Generates 384-dim vectors             │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 4. Vector Storage                          │
│    LanceDB embedded database               │
│    → Stores embeddings + metadata          │
└───┬────────────────────────────────────────┘
    ↓
Complete: Documents ready for retrieval

---

📊 Performance

Benchmarks (M1 Mac, 16GB RAM)

Operation	Time	Notes
Load PDF (10 pages)	~2s	Using PDFLoader
Chunk document (50 chunks)	~100ms	Semantic chunking
Generate embeddings (50 chunks)	~3-5s	Local Transformers.js model
Store in LanceDB	~100ms	File-based persistence
Hybrid search (k=5)	~50ms	Vector + BM25
Query planning (LLM)	~2s	GPT-4o via Copilot
Query planning (heuristic)	<10ms	Rule-based

Optimization Tips

1. Use local embeddings for privacy and no API costs
2. Enable agent caching (automatic per topic)
3. Adjust chunk size based on document type
4. Use simple mode for fast queries
5. Batch document uploads for efficiency
6. LanceDB scales well - no size limits like in-memory stores

---

🔬 Testing

Run Tests

npm test

Test Coverage

• Unit tests: 80%+ coverage target
• Integration tests: Key workflows
• Manual testing: UI and commands

---

🤝 Contributing

We welcome contributions! Please see CONTRIBUTING.md for guidelines.

Development Setup

git clone https://github.com/hyorman/ragnarok.git
cd ragnarok
npm install
npm run watch  # Watch mode for development

📄 License

MIT License - see LICENSE for details

---

🙏 Acknowledgments

Built with:

• LangChain.js - Document processing framework
• Transformers.js - Local embeddings
• LanceDB - Embedded vector database
• VS Code Extension API - Extension platform
• VS Code LM API - Copilot integration

---
