Dungeon Coder

A VS Code extension in which you steer a hero through a pixel-art dungeon with a Python program. The game runs in a VS Code tab; your script sends it commands such as hero.move() over a local REST API and gets answers such as True or False. It was built for a first-semester course on computational thinking at Munich University of Applied Sciences, where the exercises train both programming and critical thinking: predict before you run, test on levels you haven't seen, measure instead of believing.

Using it

Install: Python 3.10+ (developed on 3.15), VS Code 1.102+, the VS Code Python extension, and this extension: Dungeon Coder (hm-benidiet.vscode-dungeon-coder) from the Marketplace, version 1.0 or later. Pre-releases (odd minor versions, e.g. 1.1) come with Switch to Pre-Release Version on the extension's page. Version 0.1 was the first course version and drew the course's art itself; it is still available ("Install Specific Version…").

First program, in a folder opened in VS Code:

1. In a virtual environment: pip install dungeoncoder (the Python package, on PyPI, same version as the extension). Without internet access, command palette (Ctrl/Cmd+Shift+P) → Dungeon Coder: Copy Python API to workspace puts a copy into the folder instead.
2. Command palette → Dungeon Coder: Enter the dungeon. The game opens in a tab and listens on http://127.0.0.1:3000.
3. Write a level as text (karte.txt; # wall, . floor, H hero, Z exit) and a script, and run it:

style: station
start: east
---
######
#H...#
#...Z#
######

from dungeoncoder import Game

game = Game("karte.txt")          # a text map, or a Tiled level (.json)
hero = game.get_hero()
while not hero.is_collision_in_front():
    hero.move()
print(game.get_statistics()["moves"])

The extension brings only free pictures: a demo pack and four worlds (station, a hospital ward; studio, a light studio; werkstatt, a factory floor; gelaende, a survey area). Text maps (style:) and Game.generate(..., style=...) name one of them; without a style they use demo, the demo pack's plain dungeon, which has a picture for every symbol. The pixel-art dungeon of the course at Munich University of Applied Sciences comes as its own asset pack (setting dungeonCoder.assetPacks, below).

The hero only senses the field in front of it (is_collision_in_front(), is_abyss_in_front(), is_switch_in_front(), is_torch_in_front(), is_enemy_in_front(), is_at_goal(), get_items_at_position(), …) and acts with move(), turn_left(), interact(), pickup(name), drop(name). There is deliberately no turn_right() and no get_position(): building those yourself is part of the learning. Every method has a docstring; help(hero) lists them. Business outcomes never raise: a blocked step returns False.

More in the game: while a program runs, the cell a sensor looked at lights up for a moment (green: yes, white: no), and in levels with show_calls: true a list of the last calls (move() ✓, is_switch_in_front() → False) sits in the tab's corner (key L shows or hides it in any level). The Explorer has a Dungeon Coder Levels view: one click loads a level; the ▶▶ button over a Python file runs it on several levels in the simulator; the status bar shows moves and turns.

Without VS Code: dungeoncoder.use_simulator() (or DUNGEONCODER_SIM=1) runs the same script in a pure-Python simulator of the game's rules: no window, no waiting, the same answers. That is what automatic grading and pytest use (dungeoncoder.testing.spiel(map_text) gives (game, hero) for a test).

Traces and the command line: game.save_trace("spur.json") (or DUNGEONCODER_TRACE=spur.json) writes every call with its answer and the level itself.

python -m dungeoncoder                          setup check
python -m dungeoncoder load LEVEL [--seed N]    load a level into the game
python -m dungeoncoder variants PROG LEVEL...   run a program on several levels in the simulator (--traces DIR)
python -m dungeoncoder replay TRACE             watch a trace in the game
python -m dungeoncoder trace TRACE              list a trace with the hero's field after each call

Settings:

Levels and asset packs

• Levels are Tiled maps (JSON), or text maps that Game("x.txt") turns into one. Map properties switch on the game's mechanics: fog (explored/dark), keyboard: false, win (all_sweets, all_switches, sorted, stable), inventory_size, hero_inventory, fernrohr, orakel, amulett (hero.sense_goal(): the exit's distance as the crow flies), max_moves (a move budget: one call too many and the hero collapses), show_sensing: false (no frames around the cells a sensor looked at), show_calls: true (the list of the program's last calls in the tab's corner; off otherwise, key L shows or hides it), and more; a program can set the last two itself: Game(LEVEL, show_calls=True, show_sensing=False) for one level, or Game.SHOW_CALLS = True / Game.SHOW_SENSING = False for every level loaded afterwards; text maps write them as header lines. Game.generate(kind="maze") builds a maze, a new one each time (the seed is printed; seed= repeats it); a text map with the header generate: maze and seed: random does the same from a file. Variants: objects with the property region lie anywhere in their Region rectangle: Game("x.json", seed=17) (text maps: region: s 2,2 17,13); the end screen shows the seed. Co-op: further heroes are Character objects named Hero2, Hero3, … (text maps: 2 to 9); game.get_heroes() gives them all, heroes block each other (hero.is_hero_in_front() tells one from a wall), win: all_heroes wants each on an exit. A live game in the room (arena: true with the teams' codes): the referee loads the level into one game (its page on the beamer), each team joins from its own computer with Game.join("ROT-4711") and waits for the start (Space on the page; E ends the round), every hero has its own counters, budget and end; generate: arena builds a fair one (ARCHITECTURE.md, 4.7). Without a dev server: "Dungeon Coder: Open the game to the room" in VS Code. A file .dungeoncoder-url next to the teams' scripts spares them the address; Game.join(code, name="…") names the team; lang: de puts the scoreboard in German.
• Asset packs hold the pictures: a folder with tilesets/, images/, optionally styles/ (text-map styles) and a pack.json. A tile's class (Torch, Switch, Door, Goal, Abyss, …) and its properties (collision, state, item) give it its rules, so a pack can redraw the whole game without touching levels or code. A pack's manifest pack.json gives its name and version, engine (the oldest Dungeon Coder that draws it correctly: the extension warns at game start if a configured pack needs a newer one), the styles and worlds it brings, and the tiles of the items the engine creates itself, the start inventory (hero_inventory) and the crystals and pebbles of text maps: "items": {"Pebble": {"tileset": "x.json", "tile": 20}, "Crystal": {...}, "Crystal:orange": {...}}; the first pack that names an item wins. The free demo pack in packs/demo/ (CC0, drawn by tools/make_demo_pack.py, 16 px and 32 px tiles) shows the format. A level whose tilesets no pack has is refused with a message naming the missing tileset, and the pack if the level names it (map property pack). How the engine works inside: ARCHITECTURE.md.

Developing

Prerequisites: Node.js 18+ and npm, VS Code 1.102+, Python 3.

npm install
npm run compile         # development build -> dist/extension.js (also: watch, package)
npm run lint            # eslint on src, game/src, game/test, tools
npm run test:engine     # unit tests of the game's rules in Node (no browser, demo pack)
npm run compile-tests   # type check
npm run check:version   # package.json, dungeoncoder.__version__ and openapi.yaml agree
npm run build:wheel     # the Python package dungeoncoder as a wheel -> out/wheel/
npm run test:download   # once: VS Code for the integration tests -> ~/.cache/vscode-test
npm test                # integration tests in a real VS Code (src/test/)

compile, watch and package first run npm run generate, which derives from api/openapi.yaml, the single source of truth for the REST API: game/src/commands.js (command registry and route table for both servers), src/generated/api-types.d.ts, game/src/api-config.js and api/python/dungeoncoder/_api_config.py. Only the last one is committed (a pip install from git can't run the generator). The low-level Python client api/python/dungeoncoder/_generated/ is committed (students need no code generator); regenerate it after changing the spec with npm run generate:python-client (creates its own venv in .codegen-venv/). npm test runs the VS Code test runner on test-fixtures/side-by-side/exercise, an exercise folder whose .vscode/settings.json names an asset pack by a relative path: it starts the game and loads a level of that pack over the REST API.

The Python package lives in api/python/ (pyproject.toml) and has the extension's version. Install it with pip install dungeoncoder (PyPI), or from a wheel built by npm run build:dist (RELEASING.md). The command "Copy Python API to workspace" still copies it into a workspace (offline use); a copied folder sits next to the scripts and wins over an installed package.

Run in VS Code: press F5 (needs the recommended extension amodio.tsl-problem-matcher; without it the window may report "Extension host did not start in 10 seconds"), or code --extensionDevelopmentPath="$PWD" <folder> after npm run compile. Close the game tab of an installed Dungeon Coder first, since both use port 3000. For the game canvas, use "Developer: Open Webview Developer Tools".

Run in a browser (faster loop, no VS Code):

DC_PORT=3100 DC_ASSET_PACKS=packs/demo npm run dev:browser
# open http://127.0.0.1:3100/index.html, then run scripts with
DUNGEONCODER_PORT=3100 python my_script.py

The dev server serves the same REST API and game page as the extension and relays to the browser tab over a WebSocket on port 8000 (fixed, so one dev server at a time).

Layout

Adding an API command

1. Add the path to api/openapi.yaml, then npm run generate.
2. Add a handler in game/src/script.js (HANDLERS) and the logic in CharacterInterface or the engine. Both servers create routes from the spec; only a command that needs special handling after success gets an entry in their afterSuccess tables.
3. npm run generate:python-client, then a wrapper method with a docstring in api/python/dungeoncoder/dungeoncoder.py.
4. Port the rule to the simulator (sim.py, a cmd_<operationId> method) and check that game and simulator answer every call the same way.
5. Add a unit test in game/test/, and a CHANGELOG entry.

Licence

Code: MIT (LICENSE.txt). Demo pack and the four worlds' pictures: CC0, drawn by tools/make_demo_pack.py and tools/make_world_art.py (packs/demo/LICENSE.md). Based on Dungeon Coder 0.1 by Benedikt Dietrich, Munich University of Applied Sciences.
