PlusPim — MIPS Assembly Debugger for VS Code

A VS Code extension that integrates the PlusPim time-travel debugger for MIPS assembly code.

Features

• Step execution — Step through MIPS assembly one instruction at a time.
• Step back — Rewind execution to the previous state (time-travel debugging).
• Register view — Inspect all 32 MIPS registers, HI, LO, and PC during a debug session.
• Label resolution — Jump targets and branch labels are resolved automatically.
• Pseudo-instruction hints — During a debug session, lines with a pseudo-instruction (la, li, move, ...) show the machine instructions they expand to as inlay hints, e.g. => lui $a0, 0x1000; ori $a0, $a0, 0x0000. Stepping is per machine instruction, so such a line takes several steps. The hints are hidden while the file has unsaved or post-launch edits, and can be turned off with pluspim.inlayHints.pseudoInstructions (VS Code's editor.inlayHints.enabled also applies).
• DAP trace — Optional DAP communication logging to the PlusPim DAP Trace output channel.

Requirements

• .NET 10 Runtime (bundled in the published extension)
• VS Code ^1.108.0

Getting Started

1. Open a MIPS assembly file (.asm).
2. Open the Run and Debug view (Ctrl+Shift+D).
3. If no launch.json exists, VS Code will prompt you to create one — select PlusPim Debugger. The generated configuration looks like this:

{
    "version": "0.2.0",
    "configurations": [
        {
            "type": "pluspim",
            "request": "launch",
            "name": "Minimal Launch",
            "program": "${file}"
        }
    ]
}

4. Press F5 to start debugging the currently open file.

Launch Configuration

How It Works

When a debug session starts, the extension:

1. Starts listening on a free loopback port chosen by the OS.
2. Spawns the bundled PlusPim binary in a VS Code terminal with --connect 127.0.0.1:<port>, passing the target file and options.
3. Takes the first connection from PlusPim as the debug session. If PlusPim does not connect within 5 seconds, or exits before connecting, the session fails; see the terminal for details.

The program's standard input and output are the terminal itself, so you type input there and the output is written there as raw bytes. Non-ASCII output is shown correctly only if the terminal decodes it as UTF-8. By default the extension asks PlusPim to switch the terminal to UTF-8 while it runs (forceTerminalUtf8); if you turn that off, the terminal itself must decode UTF-8.

Known Limitations

• The terminal is closed by VS Code when PlusPim exits, so the program's output disappears when the session ends.
• On Windows, UTF-8 output is garbled when forceTerminalUtf8 is false and the console code page is not UTF-8 (for example Shift_JIS). The code page is restored when PlusPim exits, but not if PlusPim is killed forcibly.
• Pseudo-instruction hints are only shown during a debug session, because the expansion needs the assembled program.

Development

Prerequisites:

• Bun 1.3 or later
• .NET 10 SDK

Run the following in clients/vscode:

bun install
bun run compile

Release publishes are compiled with ReadyToRun. Cross-publishing from another OS works, but the binaries are unsigned, so macOS may require xattr -d com.apple.quarantine on first run.

License

MIT
