How To Start

Open an EPICS application folder in VS Code, for example:

code /home/abc/appTest/

Static Scope

Static scope covers everything EPICS Workbench can resolve from workspace files and the EPICS build model, without connecting to a running IOC.

File types covered directly in the editor:

• database files: .db, .vdb, .template
• substitutions files: .sub, .subs, .substitutions
• startup files: .cmd, .iocsh, st.cmd
• database definition files: .dbd
• StreamDevice protocol files: .proto
• sequencer files: .st
• PV list files: .pvlist
• probe files: .probe

Workspace assets also indexed for static resolution:

• Makefile
• configure/RELEASE, configure/RELEASE.local, configure/RULES_TOP
• EPICS C/C++ source and header files
• envPaths*

Across this scope, the extension provides:

• syntax highlighting for all supported EPICS text formats
• completion in database, startup, substitutions, .dbd, and Makefile files
• Go to Definition in database, startup, substitutions, sequencer, and Makefile files
• Find All References and Rename Symbol across database, startup, substitutions, .dbd, .pvlist, .probe, sequencer, and indexed EPICS C/C++ source files
• hover information in database, startup, substitutions, .pvlist, sequencer, Makefile, and envPaths*
• quick fixes in database and startup files
• diagnostics for database, startup, substitutions, and source Makefile files
• formatting for database, substitutions, startup, Makefile, .proto, and sequencer files
• semantic highlighting and outline symbols for database files

The static index also uses .dbd, build files, configure/RELEASE*, and EPICS C/C++ source to resolve record types, device support, registrars, drivers, functions, variables, install targets, and startup load paths before runtime.

IOC Runtime Scope

Runtime scope covers everything EPICS Workbench does against a live EPICS runtime, either through CA/PVA channel access or through a tracked IOC shell terminal.

There are two runtime layers in the extension:

• channel runtime: via widgets Probe, PV List, and PV Monitor
• IOC shell runtime: startup-file-driven IOC launch, shell commands, and IOC process inspection

Channel runtime features include:

• choose ca or pva as the default protocol
• monitor and control channels, inspect live values, and write values back via widgets Probe, PV List, and PV Monitor from database, startup, and substitutions.

IOC shell runtime features include:

• start and stop an IOC from the active startup file under iocBoot
• keep the IOC attached to a tracked VS Code terminal and bring that terminal back to front
• choose the IOC shell terminal explicitly with Set IOC Shell Terminal
• send arbitrary shell commands with Run IOC Command...
• run shortcut actions for dbl and dbpr on the current record when one can be resolved
• open IOC Runtime Commands to browse commands discovered from the running IOC
• open IOC Runtime Variables to inspect and update var values
• open IOC Runtime Environment to inspect and update epicsEnvShow and epicsEnvSet values

TDM Integration

TDM is a web-based EPICS display manager. Its browser-driven runtime fits naturally into VS Code, which makes it a practical way to bring operator displays into the editor alongside the rest of the EPICS workflow.

In EPICS Workbench, TDM integration focuses on opening operator interface displays from the workspace without leaving VS Code. The extension runs a local TDM web runtime, maps display navigation into editor tabs, and keeps the display workflow close to source files, IOC assets, and other EPICS tools already available in the editor.

TDM scope covers display files hosted inside VS Code through a custom editor backed by a local TDM web runtime.

• open .tdl, .edl, .bob, .stp, and .plt files directly in VS Code
• launch displays from the editor, explorer, or EPICS: Open in TDM
• use the vendored runtime under vscode/vendor/tdm by default, with externalBinary as a fallback
• load TDM profile settings from ~/.tdm/profiles.json or explicit epicsWorkbench.tdm.* settings
• open popup displays in additional VS Code tabs instead of separate native windows

How it works:

• EPICS Workbench starts TDM in web mode
• it creates a display window agent through TDM's /command API
• it hosts the resulting DisplayWindow.html?... page inside a VS Code webview tab
• when that TDM display opens another display, the extension intercepts the popup request and opens another VS Code tab instead

The vendored runtime is started through a Node launcher owned by the extension instead of a separately managed TDM binary. The old executable-based launch path is still available as an explicit fallback.

Required Settings

Set these in VS Code if auto-detection is not enough:

• epicsWorkbench.tdm.runtimeMode
• epicsWorkbench.tdm.rootPath
• epicsWorkbench.tdm.executablePath
• epicsWorkbench.tdm.profilesPath
• epicsWorkbench.tdm.profile

If you want the extension-owned runtime, leave epicsWorkbench.tdm.runtimeMode at vendoredSource.

If you need to fall back to a separately built TDM checkout, switch epicsWorkbench.tdm.runtimeMode to externalBinary and point epicsWorkbench.tdm.executablePath at a runnable launcher if auto-detection is not enough.

The extension defaults to:

• vendoredSource launch mode when vscode/vendor/tdm exists
• externalBinary only when explicitly selected or when the vendored runtime is missing
• TDM_ROOT
• a sibling ../tdm checkout next to the current workspace for externalBinary
• ~/.tdm/profiles.json
• the first non-For All Profiles profile in that file

Updating The Vendored TDM Copy

To refresh the copied TDM tree from a local checkout without editing the original source in place, run:

npm run sync:tdm-vendor

or:

python3 ./scripts/sync-vendored-tdm.py

The sync script copies a runtime-focused vendored snapshot:

• top-level TDM metadata needed to identify and launch the vendored runtime
• the built web assets and runtime layout under vscode/vendor/tdm/dist
• the runtime dependency closure needed by the vendored Node-hosted web mode

It intentionally does not copy vscode/vendor/tdm/src, because the current VS Code vendored runtime launches from dist and reads runtime assets from dist/common/resources.

How To Use It

Open a supported TDM display file in VS Code, or run:

• EPICS: Open in TDM

You can also right-click a supported display file in the explorer and choose:

• Open in TDM

Database Files: .db, .vdb, .template

What You Can Do

• hover linked records and jump to their definitions
• Find All References on records, record links, macros, record types, and field names
• Rename Symbol for the same symbol kinds
• validate duplicate records, duplicate fields, invalid fields, invalid numeric values, invalid menu values, and long DESC
• quick-fix duplicate record names
• quick-fix invalid field names
• quick-fix invalid menu values
• Probe
• PV List
• PV Monitor
• Export Database File to Excel
• Import Excel as Database
• Format File

Practical Example: Record References

Open:

appTest/test01App/Db/test01.db

Put the caret on:

field(INP, "abcd2")

Then run:

• Shift+F12 for Find All References
• F12 for Go to Definition

Expected result:

• the definition of record(ao, "abcd2")
• other references to abcd2

Practical Example: Macro-Aware Record References

Open:

appTest/test01App/Db/test01.db

This file defines:

#  - S = pv

and contains:

field(INP, "$(S)2222")

The extension uses the file-local TOC macro assignments for DB link lookup. That means the lookup target is treated as pv2222, even though the editor still shows $(S)2222.

Practical Example: Invalid Field Quick Fix

In a database file, change a valid field name to an invalid one:

field(OUT, "33")

to:

field(OTT, "33")

Then place the caret on the error and press:

• macOS: Cmd+.
• Windows/Linux: Ctrl+.

Expected result:

• a quick fix appears with the closest valid field name

Practical Example: Invalid Menu Value Quick Fix

Change:

field(ZSV, "MAJOR")

to:

field(ZSV, "BAD")

Then trigger quick fix. The extension offers a valid menu replacement.

Startup Files: st.cmd, .cmd, .iocsh

What You Can Do

• hover epicsEnvSet(...) macros and see resolved values
• hover dbLoadRecords(...) and dbLoadTemplate(...) file paths
• hover dbpf(...) record names loaded earlier in the file
• completion for startup commands
• completion for dbLoadRecords(...) first argument
• completion for empty macro assignments in dbLoadRecords(...)
• completion for dbpf(...) record names loaded earlier in the startup file
• diagnostics for unresolved startup paths
• diagnostics for missing dbLoadRecords(...) macro assignments
• diagnostics for unknown IOC registration functions
• quick fix for missing dbLoadRecords(...) macros
• quick fix for unknown IOC registration function
• Probe
• PV List
• PV Monitor
• Format File
• Import Excel

Practical Example: dbLoadRecords(...) Completion

Open:

appTest/iocBoot/ioctest01/st.cmd

Type:

dbLoadRecords("

Expected result:

• only .db, .vdb, and .template files from the current IOC shell directory and its db/ folder are suggested
• folders are not shown
• the dropdown label shows only the file name

If the chosen DB file contains macros, selecting the file inserts the empty macro tail automatically. Example:

dbLoadRecords("db/asynInt32TimeSeries.db", "P=,R=,PORT=,ADDR=,TIMEOUT=,DRVINFO=,NELM=,SCAN=")

Practical Example: dbpf(...) Completion

In the same startup file, type:

dbpf("

Expected result:

• suggested channel names come only from DB and substitutions files loaded earlier in the same startup file through dbLoadRecords(...) and dbLoadTemplate(...)

Practical Example: IOC Registration Quick Fix

In st.cmd, change:

test01_registerRecordDeviceDriver(pdbbase)

to:

wrong_registerRecordDeviceDriver(pdbbase)

Then trigger quick fix on the error.

Expected result:

• a replacement suggestion using the known IOC registration function for the current application

Substitutions Files: .sub, .subs, .substitutions

What You Can Do

• hover the file "...db" or file "...template" path and peek matching template files
• expand substitutions into PV List
• expand substitutions into Export Excel
• Probe opens blank by design
• PV Monitor opens blank by design
• Format File
• Import Excel

Practical Example

Right-click a substitutions file and choose:

• PV List

Expected result:

• the PV List widget opens with the expanded record set from the substitutions file

Right-click the same file and choose:

• Export Excel

Expected result:

• the expanded database text is exported to Excel
• the bottom-right notification contains an action to open the generated workbook in the operating system default app

PV List Widget

What It Does

The PV List widget is the runtime-oriented list view for channels. It replaces the old idea of showing live channel values inline inside .pvlist files.

What You Can Do

• start from a database file, substitutions file, startup file, .pvlist, or blank widget
• monitor all listed channels
• edit macro values inline
• double-click a value to put a new value
• Configure Channels to edit the full raw channel list
• channels preserve their order
• macro values from database TOC and .pvlist files are honored when the widget opens

Practical Example

Right-click:

appTest/test01App/Db/test02.db

Choose:

• PV List

Expected result:

• the widget opens with the channels from the DB
• if the source file defines macros, their values are preloaded into the widget

Use Configure Channels to open the editor page. That page shows the full current raw channel list, including macros. Edit the list, click OK, and the runtime list updates to match the content and order of the text box.

Probe Widget

What It Does

The Probe widget is the single-channel live inspector. It shows:

• value
• record type
• last update
• access
• fields for the record type

What You Can Do

• open it blank from some contexts
• open it pre-targeted from DB/startup contexts when a record can be resolved
• double-click the main value or a field value to put a new value
• for record widgets with Process, force record.PROC = 1

Practical Example

Right-click a record name in a DB file and choose:

• Probe

Expected result:

• a file-less probe widget opens
• if a resolvable record was under the cursor, it is preloaded

PV Monitor Widget

What It Does

The PV Monitor widget is event-driven runtime monitoring. It does not sample periodically. It appends a new line whenever CA/PVA delivers a new value.

What You Can Do

• open the widget blank or from context
• add channels
• monitor values continuously
• keep the viewport pinned to the bottom when you are already at the bottom
• keep the viewport fixed when you scroll up to inspect older data
• export monitor history as plain text data

Practical Example

Right-click a DB file or startup file and choose:

• PV Monitor

Then add one or more channels.

If you are at the bottom of the view, the widget auto-scrolls as new values arrive. If you scroll upward, the widget keeps appending new data without moving your visible region.

.pvlist Files

What They Are For

A .pvlist file is a plain EPICS list file, not a runtime file.

Typical content:

SYS = aaa
SUBSYS =

$(SYS)1
val2
$(SUBSYS)3

What You Can Do

• use record hover/peeker on channel-name lines
• Probe from the current line
• PV Monitor from the current line
• PV List from the whole file
• Format File

Practical Example

Open a .pvlist file and place the caret on a record line such as:

val2

Then:

• hover to peek the record definition
• use Probe to open a single-channel probe

.dbd And EPICS Source Files

What You Can Do

• autocompletion for DBD keywords and exported symbol names
• Find All References across .dbd and EPICS C/C++ source files
• Rename Symbol across those files
• Probe, PV List, and PV Monitor from .dbd context open blank
• Format File

Practical Example: DBD / Source Cross-Reference

Open:

• appTest/test01App/src/devAdd10.dbd
• appTest/test01App/src/devAdd10.c

Try these symbols:

• aaabbbccc
• AABBCC
• myParameter
• myFunction

Use:

• Shift+F12 for Find All References
• F2 for Rename Symbol

Expected result:

• .dbd and C occurrences participate in the same reference/rename operation

Build Model And Project Understanding

What It Does

The extension automatically discovers EPICS applications from:

• configure/RELEASE
• configure/RELEASE.local
• application Makefiles
• generated runtime artifacts

It models:

• IOC names
• runtime DB, DBD, and substitutions artifacts
• RELEASE-expanded dependency roots
• available DBDs and libraries
• startup entry-point files

Direct Debugging Use

The build model is internal to the IDE, but you can inspect the raw JSON with:

node vscode/scripts/epics-build-model.js --root /Users/1h7/projects/epics-workbench/appTest

This is useful when you want to confirm how the extension is interpreting an EPICS application.

Safe Edit / Refactor Features

What Is Implemented Today

• Find All References for:
  • records
  • macros
  • record types
  • field names
  • DBD/source symbols
• Rename Symbol for the same categories
• rename conflict analysis for records, macros, record types, field names, and DBD/source symbols
• quick fixes for common EPICS diagnostics
• one VS Code WorkspaceEdit per rename, so built-in rename preview can review the whole EPICS edit set

Practical Example: Conflict Check

Open:

appTest/test01App/Db/test01.db

Try renaming:

• abcd2 to abcd3

Expected result:

• rename is rejected because abcd3 already exists in the workspace

Known Scope Limits

• DB TOC macro-aware record lookup is implemented for database record references. The references panel still shows the literal source text from the file.
• Record-type and field-schema rename is intended for schema declared in workspace .dbd files. Built-in EPICS base schema is not blindly renamed by text replacement.
• TDM integration still uses a local proxy and localhost-oriented display hosting. The vendored runtime removes the separate TDM executable dependency, but the Remote/SSH cleanup is not finished yet.
• The integration hosts TDM display windows, not the full TDM main-window/profile-management UI.
• Some runtime widgets intentionally open blank from certain file types:
  • Probe from substitutions
  • PV Monitor from substitutions
  • PV List from .dbd

Recommended Manual Test Set

Use these files for a fast regression pass:

• appTest/test01App/Db/test01.db
• appTest/test01App/Db/test02.db
• appTest/iocBoot/ioctest01/st.cmd
• appTest/test01App/src/devAdd10.dbd
• appTest/test01App/src/devAdd10.c

For each one, test:

• hover
• Go to Definition
• Find All References
• Rename Symbol
• quick fix where applicable
• context-menu widgets where applicable

This work is sponsored by Oak Ridge National Laboratory.
